ASP.NET

• Dynamic Styles
• Response and Request Objects

2
Dynamic Styles

• DHTML is a browser phenomenon, using JavaScript
  to manipulate the properties and methods of HTML
  tags in response to user or browser events.
• Under ASP.NET these same style settings can take
  place, in this case through server scripts rather
  than browser scripts

3
Dynamic Styles

• ltSCRIPT language"javascript"gt
• function Format()
• document.all.BROWSERButton.style.backgroundColor
  "FF0000
• document.all.BROWSERButton.style.fontFamily
  "comic sans ms
• document.all.BROWSERButton.style.fontSize
  "12pt
• document.all.BROWSERButton.style.width "150px
• document.all.BROWSERButton.value "Thank
  You"lt/SCRIPTgtltinput id"BROWSERButton"
  type"button" value"Click Me" onClick"Format()
  style"background-colorsteelblue
  colorFFFFFF font-familyarial font-size10pt
  width100 cursorhand"gt

4
Built-in ASP Objects

• Response Object
• Send text, data and cookies to the browser and
  control each stage of transmitting the page
• Server Object
• Overall scripting control, set the timeout
  variable for the script
• Request Object
• Read submitted form data, cookies and server
  variables

5
Built-in ASP Objects

• Session Object
• Allows to attach data to a specific user browsing
  the site that is isolated and invisible to other
  users (user session is identifiable by the cookie
  that is sent every time a user makes a request)
  (stay active by default until 20 minutes after
  the users last request or until the session is
  explicitly abandoned through the code)
• Application Object
• Allows to manipulate global data in the script
  that will be visible to all users browsing the
  site (ASP application itself)

6
RESPONSE OBJECT

• Gives control over what data and data types sent
  to the client in the headers of HTTP response
• Gives control over what data and data types sent
  to the client in the body of HTTP response
• Gives control over when and how data is sent

7
RESPONSE OBJECT- Properties/Methods

8
RESPONSE OBJECT Write (ASP)

• Writes information directly to the HTTP response
  body.
• lt
• Response.Write lttable border1gt
• Response.Write lttrgt
• Response.Write lttdgt
• Response.Write Hello
• Response.Write lt/tdgt
• Response.Write lt/trgt
• Response.Write lt/tablegt
• gt

9
RESPONSE OBJECT Write (.NET)

• Response.Write() statements are placed throughout
  a script to trace the processing sequence and to
  write the contents of a variable.
• ltSCRIPT runat"server"gtSub ProcessThis (Src As
  Object, Args As EventArgs)  Response.Write("Start
  of ProcessThis" "ltbrgt")  ...  ...  Response.
  Write("End of ProcessThis" "ltbrgt")  ProcessThat
  End Sub

10
RESPONSE OBJECT Write (.NET)
Sub ProcessThat  Response.Write("Start of
ProcessThat" "ltbrgt")  Dim VarA
"Howdy"  ...  ...  Response.Write("Value of
VarA " VarA "ltbrgt")  Response.Write("End
of ProcessThat" "ltbrgt")End Sub lt/SCRIPTgt

11
RESPONSE OBJECT Write (.NET)
ltaspButton Text"Trace" OnClick"ProcessThis"
runat"server" /gt Result Start of
ProcessThisEnd of ProcessThisStart of
ProcessThatValue of VarA HowdyEnd of
ProcessThat

12
RESPONSE OBJECT - Redirect

• Redirects the clients request to another URL.
• Response.Redirect http//www.mis.boun.edu.tr
• Response.Redirect x.asp
• x.asp resides in the same folder as the
  requested page
• If the script has written any content to the HTTP
  response body, that content is ignored by the
  script once the call to the Redirect method is
  executed.

13
Response.Redirect (ASP)

• lt Response.Redirect "http//www.mis.boun.edu.tr"
  gt
• ltHTMLgt
• ltBODYgt
• xx
• lt/BODYgt
• lt/HTMLgt

14
Response.Redirect (.NET)

• ltSCRIPT runat"server"gtSub GoBack (Src As
  Object, Args As EventArgs)  Response.Redirect("as
  pnet02-06.aspx")End Sublt/SCRIPTgtltaspButton
  Text"Go Back" OnClick"GoBack" runat"server" /gt

15
RESPONSE OBJECT - IsClientConnected

• The Response.IsClientConnected property is useful
  when you need to make sure that the visitor is
  still connected to your Web site.
• This issue arises when, say, you are conducting
  e-commerce with a customer. If you have just
  completed processing a set of transactions for a
  purchase being made, you might wish to check that
  the customer has not abandoned your site before
  finalizing those transactions.

16
RESPONSE OBJECT - Buffer

• Determines whether the content created by the
  script is delivered to the client browser as a
  whole or send immediately to the client browser
  as each line is created and entered into the HTML
  stream
• If set to TRUE, then all script on the page is
  run before the results of that script are sent to
  the client browser
• lt Response.Buffer True gt

17
RESPONSE OBJECT - Clear

• Empties the current contents of the Response
  buffer.
• It does so without sending any of the buffered
  response to the client.

18
RESPONSE OBJECT - End

• Ends all storage of information in the response
  buffer and sends the current contents of the
  buffer immediately to the client.
• Any code present after the call to the End method
  is not processed.

19
Response.Buffer/Clear/End

• lt Response.Buffer True gt
• ltHTMLgt ltBODYgt
• lt
• Dim err
• err 1
• If Err ltgt 0 Then
• Response.Clear
• Response.Write "Error Created"
• Response.End
• End If
• gt

20
Example Get System Time (ASP)

• lt LANGUAGEVBSCRIPT gt
• lthtmlgt ltbodygt
• lt If Minute(Now) lt 30 Then gt
• Before Half
• lt Else gt
• After Half
• lt End If gt
• of
• lt response.write (Hour(Now)) gt
• lt/bodygt lt/htmlgt

• Screen
• After half of 9
• Source
• lthtmlgt ltbodygt
• After Half
• of
• 9
• lt/bodygt lt/htmlgt

21
Example System Time

• lt whennow()
• twoweekslaterdateadd("w",2,when)
• monthlaterdateadd("m",1,when)
• sixminuteslaterdateadd("n",6,when)
• sixhourslaterdateadd("h",6,when)
• response.write "Now ltbgt" when "lt/bgtltbrgt"
• response.write "1 month from Now ltbgt"
  monthlater "lt/bgtltbrgt"
• response.write "2 weeks from Now ltbgt"
  twoweekslater "lt/bgtltbrgt" gt six minutes from
  now ltbgt
• ltsixminuteslatergt lt/bgtltbrgt six hours from now
  ltbgt
• ltsixhourslatergt lt/bgtltbrgt

22
ASP - REQUEST OBJECT

• Collections
• Form (POST)
• Server Variables
• QueryString (GET)
• Cookies
• ClientCertificate
• Method
• BinaryRead
• Properties
• TotalBytes

23
REQUEST OBJECT- HttpRequest Class
HttpRequest class provides a Request object that
contains information about a URL request issued
for a Web page. In general, the Request object
pertains to Web page input, with a set of
properties that provide information about the URL
request received by the page

24
REQUEST OBJECT- ServerVariables
Contain several predefined environment variables
in the context of the clients specific HTTP
request of the web server.

25
REQUEST OBJECT- ServerVariables
ltSCRIPT runat"server"gtSub Page_Load  Browser.
Text Request.Browser.Browser  BrowserVersion.Te
xt Request.Browser.Version  BrowserPlatform.Tex
t Request.Browser.PlatformEnd Sub lt/SCRIPTgt

26
REQUEST OBJECT- ServerVariables
lthtmlgtltbodygtlth3gtProperties of your request for
this pagelt/h3gtltbgtBrowser Type lt/bgtltaspLabel
id"Browser" runat"server"/gtltbrgtltbgtBrowser
Version lt/bgtltaspLabel id"BrowserVersion"
runat"server"/gtltbrgtltbgtBrowser Platform
lt/bgtltaspLabel id"BrowserPlatform"
runat"server"/gtltbrgt lt/bodygtlt/htmlgt

27
REQUEST OBJECT- ServerVariables
Output of the script is shown below Properties
of your request for this page Browser Type
IEBrowser Version 6.0Browser Platform WinXP

28
REQUEST OBJECT- Browser Properties

29
REQUEST OBJECT- Browser Properties

30
REQUEST OBJECT- Browser Properties

31
REQUEST OBJECT- Browser Properties

32
REQUEST OBJECT- Browser Properties

33
REQUEST OBJECT- Browser Properties

34
REQUEST OBJECT- Browser Properties

35
REQUEST OBJECT- Browser Properties

36
REQUEST OBJECT- Browser Properties

37
REQUEST OBJECT- ServerVariables

• Possible Keys
• REMOTE_ADDR TCP/IP of the client
• REMOTE_HOST The IP address from which the web
  server receives the request
• REQUEST_METHOD Get, Post, etc.
• SERVER_NAME Web servers TCP/IP
• HTTPS ON if the clients request is using SSL.
• ALL_HTTP One long string containing al the HTTP
  headers send by the clients browser.

38
REQUEST OBJECT- ServerVariables

• Possible Keys
• LOGON_USER Windows NT account with which the
  user has logged onto the system
• URL The base URL requested by the client in its
  HTTP request.
• SERVER_PORT The server port to which the
  clients HTTP request is sent.
• lt
• Dim strUserName
• strUserNameRequest.ServerVariables(LOGON_USER)
• gt

39
Get IP

• ltHTMLgt ltBODYgt
• lt Dim strUserName strUserNameRequest.ServerVaria
  bles
• ("REMOTE_ADDR")
• Response.Write strUserName
• gt
• merhaba
• lt/BODYgt lt/HTMLgt

40
GET vs. POST

• GET can be used to retrieve any document, POST
  cannot
• GET and POST can be used to pass data to the
  object indicated by the URL
• When POST is used, the data is passed to the
  server in the body of the request message
• When GET is used, the data is included in the URL
  as argument string and needs to be parsed

41
REQUEST OBJECT- Form (POST)

• User enters input into the fields of a form
• When form is submitted, data in each field is
  transferred to the server, and then to ASP
• Data is sent in the format
• name value
• name (attribute of ltINPUTgt)

42
HTTP Request Header

• Create the form
• lthtmlgt ltbodygt lth2gt Sample Order lt/h2gt
• ltform methodpost actionresponse.aspgt
• ltpgt First Name ltinput name fname size48gt
• ltpgt Last Name ltinput name lname size48gt

43
HTTP Request Header

• ltpgt Title ltinput nametitle typeradio
• valuemrgt Mr.
• ltinput nametitle typeradio valuemsgt Ms.
• ltpgt ltinput typesubmitgt ltinput typeresetgt
• lt/formgt lt/bodygt lt/htmlgt

44
Response.asp

• You should use the Form collection of the
  Request object to manipulate information
• lt title request.form(title)
• lastname request.form(lname)
• If title mr Then gt
• Mr. lt lastname gt
• lt ElseIf title ms Then gt
• Ms. lt lastname gt
• lt Else gt
• lt request.form (fname) lastname gt
• lt End If gt

45
REQUEST OBJECT-TotalBytes

• TotalBytes property is a read-only value that
  specifies the total number of bytes posted to the
  web server by the client in the HTTP request
  body.
• Var Request.TotalBytes

46
REQUEST OBJECT-Client Certificate

• Provides access to the certification fields of
  the clients digital certificate.
• Client certificates are sent to the web server
  when a clients browser supports the Secure
  Sockets Layer and that browser is connected to a
  web server running the SSL (https//).
• Request.ClientCertificate

47
REQUEST OBJECT-Client Certificate

• Subject A list of comma-delimited strings that
  provide information about the owner of the
  digital certificate.
• Issuer Information about the issuer.
• ValidFrom and ValidUntil Validation dates
• SerialNumber An ASCII representation
• Ex 0A-B7-34-23
• Certificate A string value that contains the
  entire binary stream from the certificate
  content.
• Flags Provide additional information such as
  presence of certificate.

48
REQUEST OBJECT-Client Certificate

• Request.ClientCertificate (IssuerC)
• Retrieve the country of origin for the Issuer.
• Request.ClientCertificate (SubjectO)
• Retrieve the organization of the Subject.

49
Session Tracking

• HTTP is a stateless protocol that does not
  support persistent connections that would enable
  Web servers to maintain state information
  regarding clients.
• A session ID represents a unique client on the
  Internet. If the client leaves a site and returns
  later, the client will still be recognized as the
  same user.
• To help the server distinguish among clients,
  each client must identify itself to the server.
• The tracking of each individual clients, known as
  session tracking, can be achieved in a number of
  ways.

50
Session Tracking

• Session tracking ways
• Use of input form elements of type hidden and
  sending them to the form handler on the Web
  server.
• Use of HttpSessionState object
• Cookies

51
Cookies

• Cookie Small pieces of information stored by the
  web server on the web clients machine.
• This information is sent to the server each time
  the client requested a page from the same area
  from which the information was received.
• A cookie is a text file.

52
Cookies

• Domain Returns a String containing the cookies
  domain. This determines which web server can
  receive the cookie.
• Expires Returns a DateTime object indicating
  when the browser can delete the cookie.
• Name Returns a String containing the cookies
  name.

53
Cookies

• Path Returns a String containing the URL prefix
  for the cookie.
• Secure Returns a Boolean value indicating
  whether the cookie should be transmitted through
  a secure protocol. The value True causes a secure
  protocol to be used.
• Value Returns a String containing the cookies
  value.

54
Cookies

• Send Cookie
• Response.Cookies("Cust").Name"BE"
• Response.Cookies("Cust").Expirestime.AddDays(10)

• Get Cookie
• Request.Cookies("Cust")
• Delete Cookie
• Response.Cookies("Cust").Expires Date 365
• ' Deleted by setting expiration date to a past
  date

55
Session

• A user Session is created by ASP.NET whenever a
  visitor arrives at any Web page located in your
  root application directory.
• A Session Object maintains identification
  information about the visitor and allows ASP.NET
  to differentiate between visitors and their
  browsing status as they navigate the Web site.

56
SessionID

• Your visit to this site, for instance, can be
  identified by the SessionID value,
• Session.SessionID "filyqavdzfnqrj45ofykaeel"
• SessionID value is a random number that was
  generated when you first arrived at the site.
• Session remains alive until 20 minutes after your
  last interaction with a page or until you close
  your browser.
• A revisit generates a new SessionID number.

57
Session Variable

• The Session Object also serves as a global
  storage area that scripts can use to maintain
  data values between pages.
• A Session variable is created by assigning a
  value to a name
• Session("name") "value"

58
HttpSessionState Properties

• Count Specifies the numebr of key-vaue pairs in
  the Session object.
• IsNewSession Indicates whether this is a new
  session.
• IsReadOnly Indicates whether the Session object
  is read only.
• Keys Returns an object containing the Session
  objects keys.

59
HttpSessionState Properties

• SessionID Returns the sessions unique ID.
• Session.SessionID
• Timeout Specifies the maximum number of minutes
  during which a session can be inactive before the
  session expires.
• Session.Timeout
• Session.Add(TR,2005)
• Store in session as name-value pair

60
HttpSessionState Properties

• SessionID Returns the sessions unique ID.
• Session.
• Timeout Specifies the maximum number of minutes
  during which a session can be inactive before the
  session expires.
• Session.Timeout
