Particle Acceleration in Compact Objects

- Demosthenes Kazanas
- NASA
- Goddard Space Flight Center

- There is plenty of evidence for the presence of

particle acceleration in compact objects - High (and low) energy emission from pulsars.
- High (and low) energy emission from plerionic SN

remnants. - Emission from 109 1027 Hz in Active Galactic

Nuclei.

- Outline
- Direct particle acceleration by electric fields

(in EM gaps). - Bulk acceleration of particles in MHD flows.
- Stochastic Acceleration (shocks, turbulence).
- Dynamic Effects of accelerated particles (effects

on accretion disks, outflows).

The Seven Highest-Confidence Gamma-ray Pulsars

Broad-band spectra

- Power peaked in g-rays
- No pulsed emission above 20 GeV
- Increase in hardness with age
- High-energy turnover
- Increase in hardness with age
- Thermal component appears in older pulsars

(No Transcript)

(No Transcript)

- Must distinguish between acceleration of

individual particles and acceleration in bulk. - These two are generally distinct processes,

however, there are cases in which they are

intimately related. - The most obvious evidence of the presence of

acceleration of particles is that of pulsars.

Rotating Magnetic Field

(No Transcript)

Formation of an outflow

- The rotation of the highly conducting neutron

star crust generates enormous potential

differences over the surface - above the surface gt very large

outward-acting unbalanced electric stresses - A charged magnetosphere is spontaneously built up

in order to short-out the parallel component of

the electric field (Goldreich-Julian 1969)

The density of charge carriers can be easily

estimated

- This density co-rotates with the pulsar out to
- the light cylinder. Beyond that the magnetic
- stresses cannot confine the plasma and must
- open-up, i.e. the dipole is not a valid
- magnetospheric solution

The flux of the open field lines at thelight

cylinder defines the polar cap of thepulsar, as

the region of the last open field line

The pulsar slow down can then be worked out in a

simple way. It does not require the pulsar to be

misaligned the same slow down works out for a

purely aligned magnetosphere.

Surface Fields and Currents

- The presence of a sufficiently dense plasma
- cancels all parallel E. Discrepancy between
- the actual charge density from that of GJ
- leads to gaps (Polar Cap Outer Gap models).
- Particles can be accelerated at gaps and lead to
- the creation of photons. The resulting spectra
- depend on the ensuing interactions (A. Harding)
- The EM potentials available are of order of
- 1018 (P/ms) B15 eV. As such they
- could produce galactic cosmic rays up to the
- energy of ankle (Arons 02).

- The problem of pulsar magnetospheric
- emission, as is the case with all problems
- that involve magnetic fields (which cannot
- be shorted out) is a global one. One has to
- solve for the currents and the resulting
- magnetic fields over all space before we can
- decide the dynamics and radiation emission
- from a pulsar.

- The magnetosphere is determined by the
- balance between the current and electro-
- static forces in the magnetosphere. These
- are given by the Pulsar Equation

The parameters involved are

- Poloidal electric current
- Magnetic flux
- Force-free
- Space charge density

Contopoulos, Kazanas Fendt 1999 Gruzinov 2005

- The solution is smooth, contains a return
- Current, it contains a zero charge line and
- it provides the wind asymptotic structure.
- Emission is expected at places where MHD is

violated (polar cap, zero charge line, return

current boundary, but not the Light Cylinder).

Pulsar Winds/The s-Problem

- For the geometry of the magnetic lines beyond
- the Light Cylinder (split monopole) for which
- Bp 1/R2, Bf 1/ R , r 1/R2.
- Therefore their ratio, s 106 near the LC should
- be independent of the radius R .
- However, the spectra of the Crab nebula need a
- value s 3 10-3 to fit the observed spectrum and
- for Vela one needs s 1.

- The asymptotic (split) monopole geometry
- of CKF allows a crack at this problem
- The energy conservation equation along a field
- line has the form
- While the flux freezing condition reads

- Under force-free conditions
- the energy equation reads
- Leading eventually to
- (Contopoulos DK 2002)

- Under conditions of a monopole geometry the

Lorentz - factor of the flow increases linearly with

distance. This - happens as long as the effects of inertia are

negligible. - Beyond this point the field geometry should

deviate - From monopolar and possibly part of it collimate

and - part form an equatorial wind. The wind terminates

at a - shock which is responsible for the nebular

emission. - (The extent of monopole geometry is debatable.

It may - extend only up to the fast magnetosonic point

then the - maximum g will be only s1/3 ).

Plerion Components

Vlahakis Konigl 2001

- Linearly increase in Lorentz factor is a property

of general MHD flows of geometries different

from monopolar (VlahakisKonigl 2001)

The MHD outflow acceleration and the s-Problem

are related issues. They demand the simultaneous

solution of the conservation equations along with

the transverse force balanc.e

- First axisymmetric wind
- solutions by Blandford
- Payne extended to
- Relativistic case by Li,
- Chieuh, Begelman (92)
- and Contopoulos (94).
- Solutions known only for
- self-similar geometry.

- Flow acceleration
- depends on assumptions
- used. LCB find logarithmic
- acceleration with height.
- Contopoulos (94) finds final
- velocity similar to that at
- the accretion disk at the
- base of the flow (Vlahakis
- Konigl 04 for a more
- recent study).

The relativistic outflows produce shocks, which

accelerate particles and lead to radiation

emission. Blazaremission is thought to be

derived this way.

- The apparently thin
- photon spectra indicate
- emission from large
- distances and suggests
- association with jet
- flows (Mastichiadis
- Kirk 1997).

Particle acceleration (in shocks, converging

flows, turbulence) is the result of an interplay

between particle energy gains in scattering and

particle transport. The exponentially small

probability of undergoing N interactions with

the plasma before escape, coupled with

exponentially increasing energy with the number

of scatterings lead to power law distributions.

The geometry of particle transport across a plane

shock. The upstream velocity is u1 and the

downstream u2u. The particle velocity is v. The

shaded region shows the fraction of particles

that make it upstream and have a chance to

accelerate.

Generic description of the acceleration process.

Application to plane parallel shocks (r is the

compres- sion ratio, P(p) is the integral

spectrum).

Effects of acceleration on dynamics

- The presence of relativistic particles
- can affect the dynamics of the flow
- Relativistic particles reduce the fluid
- adiabatic index and increase the shock
- compression ratio r. This hardens the
- spectra most kinetic energy is
- converted to relativistic particles that
- dominate the pressure.
- Particle (relativistic) escape from the
- system also increases the compression
- ratio of the shock with similar effect.

- (Ellison et al 2000)

- In the vicinity of a compact object, the strong

gravitational - field could separate the relativistic and the

non-relativistic - populations, provided that cooling does not

this can cause - outflows similar to those inferred in compact

objects (DK - Ellison 86) Subramanian et al (99), provided

that the - accelerated particles do not lose energy on time

scales shorter - than free-fall.
- Separation can also take place through the

production of - neutral particles (neutrons) that can increase

the power of - relativistic outflows (Contopoulos DK 94).

Plasma production outside an Acc. Disk from n -gt

p e. For a large black hole, most neutron

produced protons are relativistic while for a

small one most are non-relativistic. The critical

value is M108 M_o

The Radio Jets of GRS 1915105

The Radio Jets of GRS 1915105

The Radio Jets of GRS 1915105

- Acceleration in Accretion Disks can
- result from particle-wave interactions
- (e.g. Dermer, Miller, Li 96). Acceler.
- Time scales are quite short and should
- Produce accelerated populations.

- Accretion Disks could accelerate
- particles by their shearing motion
- (Subramanian et al. 99). This leads
- to 2nd order acceleration.

Slope and Maximum Energies

- The slope of accelerated population depends on

the interplay between energy gain per interaction

and escape probability (e.g. the Comptonization

parameter t kT/mc2). For shocks this is 3/(r-1)

(integral slope). - The acceleration rate is hap-pening on the

gyro-period at the given field E(eV)/B(G)

- Maximum energy is given by the balance between

accele-ration and losses or escape from the

system. For electrons this energy is TeV

(blazars), while for protons it gets close to

1020 eV. - Eventually, the max.energy is roughly R (v/c)

B, where R is the size of the system, v the

velocity and B the magnetic field.

Conclusions - Questions

- Particle Acceleration is a ubiquitous process in

compact objects (spectra, superluminal motions). - Particles can get accelerated in EM gaps

(deviations from MHD conditions). Energy/particle

Potential drop across gap. - MHD acceleration in rotating magnetospheres.

Conversion of magnetic to kinetic energy of high

efficiency (depends on current distribution).

Lorentz factors of 10 106 possible. - Particle acceleration possible in turbulent,

shocked plasmas. Conversion of KE to relativistic

particles with high efficiency. Max. energy

depends on particulars of system. - Why dont we see prominent non-thermal emission

in the spectra of accreting binary sources? Why

are most AGN radio quiet? - Does acceleration take place in the Acc. Disks of

AGN, GBHC? If yes, do the accelerated particles

play any role in the dynamics of these disks? Are

observational tests to distinguish between these

possibilities?

(No Transcript)

(No Transcript)

(No Transcript)

The geometry of particle transport across a

shock. The upstream velocity is u1 and the

downstream u2u. The particle velocity is v. The

shaded region shows the fraction of particles

that make it upstream and have a chance to

accelerate.

(No Transcript)

(No Transcript)

About PowerShow.com

PowerShow.com is a leading presentation/slideshow sharing website. Whether your application is business, how-to, education, medicine, school, church, sales, marketing, online training or just for fun, PowerShow.com is a great resource. And, best of all, most of its cool features are free and easy to use.

You can use PowerShow.com to find and download example online PowerPoint ppt presentations on just about any topic you can imagine so you can learn how to improve your own slides and presentations for free. Or use it to find and download high-quality how-to PowerPoint ppt presentations with illustrated or animated slides that will teach you how to do something new, also for free. Or use it to upload your own PowerPoint slides so you can share them with your teachers, class, students, bosses, employees, customers, potential investors or the world. Or use it to create really cool photo slideshows - with 2D and 3D transitions, animation, and your choice of music - that you can share with your Facebook friends or Google+ circles. That's all free as well!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

You can use PowerShow.com to find and download example online PowerPoint ppt presentations on just about any topic you can imagine so you can learn how to improve your own slides and presentations for free. Or use it to find and download high-quality how-to PowerPoint ppt presentations with illustrated or animated slides that will teach you how to do something new, also for free. Or use it to upload your own PowerPoint slides so you can share them with your teachers, class, students, bosses, employees, customers, potential investors or the world. Or use it to create really cool photo slideshows - with 2D and 3D transitions, animation, and your choice of music - that you can share with your Facebook friends or Google+ circles. That's all free as well!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

presentations for free. Or use it to find and download high-quality how-to PowerPoint ppt presentations with illustrated or animated slides that will teach you how to do something new, also for free. Or use it to upload your own PowerPoint slides so you can share them with your teachers, class, students, bosses, employees, customers, potential investors or the world. Or use it to create really cool photo slideshows - with 2D and 3D transitions, animation, and your choice of music - that you can share with your Facebook friends or Google+ circles. That's all free as well!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

Recommended

«

/ »

Page of

«

/ »

Promoted Presentations

Related Presentations

Page of

Home About Us Terms and Conditions Privacy Policy Presentation Removal Request Contact Us Send Us Feedback

Copyright 2018 CrystalGraphics, Inc. — All rights Reserved. PowerShow.com is a trademark of CrystalGraphics, Inc.

Copyright 2018 CrystalGraphics, Inc. — All rights Reserved. PowerShow.com is a trademark of CrystalGraphics, Inc.

The PowerPoint PPT presentation: "Particle Acceleration in Compact Objects" is the property of its rightful owner.

Do you have PowerPoint slides to share? If so, share your PPT presentation slides online with PowerShow.com. It's FREE!
