Title: Let wood move you


1
(No Transcript)
2
Let wood move you
  • Interwood from Grass
  • for perfect drawer movement

3
Grass Interwood
  • For your customers, quality is the sum of
  • Visual appearance
  • Function
  • Functionality
  • Workmanship
  • Durability
  • Grass Interwood supports your quality in all
    these points.
  • Nothing disturbs the wood design required by your
    customers and all the features of Grass Interwood
    contribute to the functionality of your furniture.

4
Grass Interwood
Grass Interwood Product Family
InterwoodAccessories
Interwood Full Extension Airmatic
InterwoodFull Extension Touch/Latch
Interwood Regular Extension Airmatic
InterwoodFull Extension Senso
5
Selling Points for Interwood Full Extension
Airmatic
  • 40kg load capacity
  • Integrated Airmatic gently cushioned closure
  • Excellent smooth running in proven Grass quality
  • Simple drawer insertion and removal
  • Tool-free height adjustment of front
  • Integrated tolerance compensation
  • Wide range of lengths
  • Outstanding side stability
  • Drilling pattern compatible with Nova Pro and
    other competitor products
  • Full extension without over-extension

6
40kg Load Capacity
  • 40kg load capacity ? 1/3 more than competitor
    products in standard range
  • The 40kg ensure reliability and long service life

7
Integrated Airmatic
  • Airmatic, the clean integrated cushioning system
  • The operating medium air is environmentally
    friendly and offers the advantage that it is
    hygienic
  • Oil-free there is no oil which can leak out

8
Simple Drawer Insertion and Removal
Release lever with ribbing
  • Compact design of snap-in device
  • Readily accessible release lever
  • Good surface feel thanks to ergonomic shape and
    the ribbing of the release lever

Snap-in device
9
Tool-free Height Adjustment of Front
Release lever with ribbing
Slider for height adjustment
  • Snap-in device
  • Tool-free gap alignment
  • Memory function. The height adjustment remains in
    the same position, even after drawer insertion
    and removal
  • Adjustment range 2.5mm

10
Change to Snap-in Device
Release lever with ribbing
  • New snap-in device
  • Green latch
  • Benefits
  • Simpler, more secure locking
  • Possible to achieve 0mm gap between cabinet and
    front by fixing the cabinet member at 38.5mm
    instead of 37mm. Today, only 1-1.5mm possible.
  • No new order number. Mixed installation of
    old/new possible.
  • Old snap-in device
  • Black latch

11
Wide Range of Lengths and Drilling Pattern
Compatibility
  • Lengths ranging from 270-650mm.
  • Standard lengths in 50mm increments
  • Intermediate lengths such as 320mm, 380mm, etc.
    make it possible to make optimal use of cabinet
    depth.
  • Drilling pattern compatible with Nova Pro cabinet
    member

12
Full Extension without Over-extension
Over-extension
Release lever with ribbing
  • Grass Interwood full extension without
    over-extension protects against nip injuries
  • Memory function. The height adjustment remains in
    the same position, even after drawer insertion
    and removal
  • Adjustment range 2.5mm

13
Grass Interwood
Grass Interwood Product Family
InterwoodAccessories
Interwood Full Extension Airmatic
InterwoodFull Extension Touch/Latch
Interwood Regular Extension Airmatic
InterwoodFull Extension Senso
14
Selling Points for Interwood Regular Extension
Airmatic
  • Integrated Airmatic gently cushioned closure
  • Installation compatible with Interwood full
    extension
  • Simple drawer insertion and removal
  • Tool-free height adjustment of front
  • Outstanding side stability
  • Proven Grass quality
  • 30kg load capacity
  • Integrated tolerance compensation
  • Low pull-out forces

15
Interwood Regular Extension Range
  • Lengths ranging from NL 270-550mm, all standard
    lengths
  • Same fixing positions for cabinet member as with
    Interwood full extension
  • Product launch After Interzum, available from
    the summer.

16
Compatible with Interwood Full Extension
  • Dimensions of Interwood regular extension
  • Drawer width and length identical
  • Installation dimension identical

Difference Notch at rear of drawer on the
? regular extension min. 15mm ? full
extension min. 27mm
17
Grass Interwood
Grass Interwood Product Family
InterwoodAccessories
Interwood Full Extension Airmatic
InterwoodFull Extension Touch/Latch
Interwood Regular Extension Airmatic
InterwoodFull Extension Senso
18
Selling Points for Interwood Full Extension
Touch/Latch
  • Handle-free drawers are opened by tapping
  • Integrated opening mechanism
  • Load-dependent opening distance, similar to Senso
    technology
  • Activation zone approx. 2/3 of front surface
  • Tool-free front gap adjustment Factory setting
    4mm front gap.Adjustment range 4-7mm
  • Auto-correct facility in the event of operating
    error
  • Emergency opening function
  • Absolute stability and side stability
  • Proven Grass quality, as with full extension
    Interwood Airmatic
  • Load capacity of full extension up to 40 kg
  • Integrated tolerance compensation
  • Simple drawer insertion and removal
  • Tool-free height adjustment of front

19
Interwood Full Extension Touch/Latch
  • Interwood Touch/Latch range
  • Product launch After Interzum, available from
    summer 2007.

20
Grass Interwood
Grass Interwood Product Family
InterwoodAccessories
Interwood Full Extension Airmatic
InterwoodFull Extension Touch/Latch
Interwood Regular Extension Airmatic
InterwoodFull Extension Senso
21
Interwood Full Extension Senso
  • View of rear side of drawer

22
Interwood Full Extension Senso
View of the left-hand rear side of the drawer
View of the right-hand rear side of the drawer
23
Interwood Full Extension Senso
  • Handle-free drawers are opened by tapping
  • Activation zone over entire front of drawer
  • Integrated opening mechanism
  • Load-dependent opening distance, similar to Senso
    technology
  • Tool-free front gap adjustment
  • Auto-correct facility in the event of operating
    error
  • Emergency opening function
  • Absolute stability and side stability
  • Proven Grass quality, as with full extension
    Interwood Airmatic
  • Load capacity of full extension up to 40 kg
  • Integrated tolerance compensation
  • Simple drawer insertion and removal
  • Tool-free height adjustment of front

24
Interwood Full Extension Senso
Locking units
Adapters
  • System description/requirements
  • The technology of Nova Pro Senso is to be adapted
    to Interwood.
  • Adapted locking unit and synchronisation bars
  • To actuate the locking unit, adapters are fitted
    to the back panel of the drawer. The front gap is
    adjusted by means of these adapters.
  • The opening unit is integrated into the cabinet
    member.
  • Product launch autumn 2007

25
Grass Interwood
Grass Interwood Product Family
InterwoodAccessories
Interwood Full Extension Airmatic
InterwoodFull Extension Touch/Latch
Interwood Regular Extension Airmatic
InterwoodFull Extension Senso
26
The New Grass Front Buffer
  • Specially developed for TL Senso
  • Minimum possible head thickness means
  • absorption of contact sound plus
  • minimum front gap

Available NOW
27
Grass Ino(x)sys
  • The flexible, modular organiser system for wooden
    drawers
  • High-grade stainless steel trays
  • Dishwasher-safe
  • Compact range 1 length (500) 2
    widths (400 and 500)

28
Grass Ino(x)sys
29
Chrome Railing
Chrome railing, length and width divisions
Bottle holders
30
Chrome Railing Range
31
Railing Accessories
32
Interwood Application
  • Application samples of Interwood full
    extension with wire basket from Vauth-Sagel
  • Like Nova Pro, Interwood is suitable for
    applications for a wide range of uses
  • The three basket pull-out versions Saphir, Opal
    and Scalea can be adapted for Interwood with
    minor changes.
  • Interwood remains unchanged, the new feature is
    that Vauth Sagel has to adapt the snap-in device
    to the basket pull-out.

33
Interwood Application
Skalea
Saphir
Opal
  • Procedure in the case of interest in this
    product
  • Contact Vauth-Sagel, wwww.vauth-sagel.de
  • Person to speak to in Export Heinz Otto Sagel,
    Tel. 0049-5272-601-114
  • Person to speak to for domestic sales Klaus
    Wittekind, Tel. 0049-5272-601-112

34
Thank you for your attention
