Conceptual Design of a Lunar Regolith ClusteredReactor System

1
Conceptual Design of a Lunar Regolith
Clustered-Reactor System
2
Conceptual Design of a LRCS

• John Darrell BessJohn.Bess_at_inl.gov
• University of UtahCenter for Space Nuclear
  ResearchFebruary 14, 2008

Space Technology and ApplicationsInternational
Forum (STAIF 2008)
3
Project Luna Succendo

• Preliminary development of a fast-fission,
  heatpipe-cooled, nuclear reactor that is modular,
  safe, reliable, and can be optimized for
  lunar-base power demand as well as implemented,
  and later evolved, using in situ lunar-regolith
  resources.

Preliminary development of a fast-fission,
heatpipe-cooled, nuclear reactor that is modular,
safe, reliable, and can be optimized for
lunar-base power demand as well as implemented,
and later evolved, using in situ lunar-regolith
resources.
lunar-regolith blanket rock, the layer of
loose,heterogeneous material scattered across
the lunar surface
4
Supporting Objectives

• Neutronics analysis with Monte Carlo criticality
  code comparison
• MCNP5 and KENO-VI
• Launch accident characterization analyses
• Sensitivity studies regarding physical lunar
  emplacement
• Uncertainties analysis of variations in lunar
  regolith composition

5
Lunar Surface Power

• Sustained human and robotic presence
• Life-support systems
• Communications
• Transportation
• Scientific missions
• Development of innovative spacetechnologies
  andknowledge
• Lunar colonization and in situ resourcemining
  and manufacturing

Eventual development of tourism,
commercialization, and a lunar society ( M )
6
Fast-Fission, Heatpipe-Cooled Reactor

• Fast-Fission
• Dense, compact cores
• High fissile loading
• Liquid salt/metal coolant
• Actinide transmutation
• Deeper fuel burnup
• Low corrosion
• Intrinsic safety
• Transient stability

• Heatpipe-Cooling
• High heat transfer rate
• Latent heat
• Faster than conduction
• Wick structure
• Heat source/sink
• Inherent stability

7
Power Conversion

• Potassium Boiler
• Stirling Engines
• Optimal for 40 kWe
• Developing 5 kWe free-piston, space convertor for
  NASA

• Heatpipe Radiator
• Redundancy in design
• Fin failure
• Loop failure
• Carbon armor

Heater Head Assembly
Displacer Drive Assembly
Alternator Assembly
8
Defining the Reactor

• Additional Components
• Instrumentation and control
• Power management and distribution
• Connection to grid
• Axial shielding and/or reflector
• Lunar regolith shielding
• Lunar regolith reflectors

• lt100 kWt per subunit
• At least 10-yr power lifetime per subunit
• UO2 fuel pellets
• 93 U-235
• 95 TD
• SS-316 cladding
• Sodium (Na) heatpipes
• Distributed core design

9
LEGO Reactor Subunit Core

• SS-316 monolithic, hexagonal core
• 2.94-cm (1.16) Pitch
• 23.8-cm (9.37) D
• 43 heatpipes
• 84 fuel pins
• 1.64-cm (0.64) OD

10
The Concern for Launch Safety

• Subunit must remain subcritical (keff lt 0.985)
• Prior to launch
• During launch
• Upon accidental impact
• When submerged in moderator and/or reflector
  material
• When immersed in fire
• i.e. Always

• Current methods for maintaining a subcritical
  reactor
• Poison control rods or drums
• Removable beryllium reflectors
• Incorporated spectral shift absorbers (Re, B4C,
  Gd2O3)
• Fuel reactor in-orbit (or on the lunar surface)

11
Launch Accident Analyses
12
Computational and Data Biases
13
gt7 r
14
Lunar Regolith Composition
Engineering, Construction and Operations in Space
IV,American Society of Chemical Engineering, pp.
857-866, 1994.
15
Rock-Melt Drilling

• Also known as Subterrene or Subselene drilling
• High temperature application with heat pipes to
  melt rock
• Melted material is forced into porous rock
• Results in a glassy finish with no debris
• 4-9 kWth power requirement

16
Tri-Cluster, Base-Case Scenario

• JSC-1 composition
• Bulk density 1.8 g/cc
• Melt density 3.1 g/cc
• 2-m drilled depth
• Trace elements and volatiles were not included

• Tri-unit cluster
• Placed with centerline distances of 64 cm
• keff 1
• 24-cm inner diameter of hole
• 37-cm outer diameter of melt

17
Tri-Cluster, Base-Case Scenario
Subunits placed 64 cm apart in JSC-1 (keff1)
18
Emplacement Code Comparison
Regolith Fill1.6 0.22.50
sk lt 0.2Dkcodes 0.5 0.2
19
Iron Variation Comparison
20
Lunar Regolith Variation
Global Elemental Maps of the Moon The Lunar
Prospector Gamma-Ray Spectrometer, D.J.
Lawrence, et al., Science, 4, September 1998.
21
Conclusions

• A modular, fast-fission, heatpipe-cooled, lunar
  regolith clustered-reactor system has been
  developed
• Some analyses of launch accident scenarios
  demonstrate favorably
• Need additional code comparison analyses for
  accident validation
• Awaiting upcoming code and data library releases

• Tri-cluster emplacement has been characterized
  with both codes
• Iron composition confirmed as dominant
  constituent in regolith
• Further thermodynamic and heat transfer analyses
  necessary to develop final coupled-reactor design

22
(No Transcript)
23
(No Transcript)
24
Lunar Power Supply
25
Space Reactor Heritage

• U.S. has launched one SNAP-10A reactor
• Russia has launched over 30 space reactor systems
• Various concepts have been developed over the
  past 50 yrs
• SP-100
• Mars Surface Reactor (MSR)
• Sectored Compact Reactor (SCoRe)
• Safe and Affordable Fission Engine (SAFE)
• Space Nuclear Steam Electric Energy (SUSEE)
• Space Power Annular Reactor System (SPARS)
• Submersion Subcritical Safe Space (S4) Reactor
• Affordable Fission Surface Power System (AFSPS)
• Heatpipe Operated Mars/Moon Exploration Reactor
  (HOMER)

26
The Stagnant Cycleof Space Technology
27
The One-Size-Fits-All Reactor

• Inexpensive
• Extremely low mass
• Available now
• Continuous power in range of kW MW
• Directly scalable to higher power levels
• Functions under various gravitational and
  environmental conditions

• Functions on any lunar or planetary surface
• Highly reliable with graceful performance
  degradation
• Can support human and robotic missions
• 3-20 yr lifetime without maintenance
• Completely testable on Earth

• Inexpensive
• Extremely low mass
• Available now
• Continuous power in range of kW MW
• Directly scalable to higher power levels
• Functions under various gravitational and
  environmental conditions

• Functions on any lunar or planetary surface
• Highly reliable with graceful performance
  degradation
• Can support human and robotic missions
• 3-20 yr lifetime without maintenance
• Completely testable on Earth

• Inexpensive
• Extremely low mass
• Available now
• Continuous power in range of kW MW
• Directly scalable to higher power levels
• Functions under various gravitational and
  environmental conditions

• Functions on any lunar or planetary surface
• Highly reliable with graceful performance
  degradation
• Can support human and robotic missions
• 3-20 yr lifetime without maintenance
• Completely testable on Earth
• Proliferation resistant

28
Lunar Regions of Interest

• Lunar Poles
• H2O?
• Solar extremes
• Imbrium Region
• K, Fe, Ti, Th
• Equatorial Regions
• He-3
• Lunar geology
• Far Side of Moon
• Solar wind and volatiles
• Space telescopes

29
Average Atomic Compositions of Lunar Regolith
Samples
G. HEIKEN, D. VANIMAN, and B.M. FRENCH, Lunar
Sourcebook A Users Guide to the Moon,
Cambridge University Press, (1991).
30
Average Atomic Compositions of Lunar Regolith
Basalts
G. HEIKEN, D. VANIMAN, and B.M. FRENCH, Lunar
Sourcebook A Users Guide to the Moon,
Cambridge University Press, (1991).
31
Average Atomic Compositions of Lunar Regolith
Breccias
G. HEIKEN, D. VANIMAN, and B.M. FRENCH, Lunar
Sourcebook A Users Guide to the Moon,
Cambridge University Press, (1991).
32
Average Trace Elements
G. HEIKEN, D. VANIMAN, and B.M. FRENCH, Lunar
Sourcebook A Users Guide to the Moon,
Cambridge University Press, (1991).
33
Maximum Trace Elements
G. HEIKEN, D. VANIMAN, and B.M. FRENCH, Lunar
Sourcebook A Users Guide to the Moon,
Cambridge University Press, (1991).
34
Regolith Sample Sites
35
Lunar ExplorationPast, Present, Future

• Ranger Program
• Lunar Impact
• Lunar Orbiter Program
• Sightseeing
• Surveyor Program
• Soft Landing
• Apollo Program
• Human Spaceflight
• Luna (Lunik) Programme
• Russian Missions
• Lunar Prospector
• And Many More

36
Technological Assumptions

• Deployable using existing or proposed launch
  vehicles
• Robotic or human assembly capabilities
• Rock-melt drilling
• Microwave sintering
• Use control, power, radiator, and transmission
  systems already developed

37
Launch Vehicles
Faring Limits10.5-m H, 7.5-m D
Faring Limitslt13.8-m H, lt5-m D

• Current (7-9 mT)
• Delta IV Heavy
• Atlas V Heavy Launch Vehicle (HLV)

• Proposed (20-21 mT)
• NASAs Exploration System Architecture Study
  (ESAS)

38
Stirling Engines

• External combustion piston engine
• 25 efficiency
• 12.5 kWe units
• Developing 50 kWe units
• Operate by repeated heating and cooling of a
  sealed gas

39
Microwave Sintering

• Effective and efficient heating and sintering of
  ceramic objects
• Fine Fe-metal dust particles
• Reduces local lunar dust
• Lunar Lawn mower

Microwave Sintering of Lunar Soil Properties,
Theory, and PracticeL.A. Taylor and T.T. Meek,
J Aero Eng, 18( 3) 188-196 July 2005.
40
Primary Subunit Dimensions

• 49-cm (19) fueled height
• 106-cm (42) heatpipe extension from core
• 170-cm (67) primary subunit length

41
Basic Analyses

• Coolant void effects nonexistent
• Na, K, NaK coolant neutronically interchangeable
• Subunit rotation insignificant
• Trace Elements
• Ave 0.4-0.8 Dr
• Max 2.7-3.0 Dr

• Doppler effect slightly negative due to small
  quantities of U-238 in fuel
• Moderator effect slightly positive
• Geometrically delayed neutrons
• Lunar surface acts as large thermal sink

42
Subunit Emplacement

• Basic centerline placement
• 37 to 100 cm distances between all three units
• Void, water, or loose regolith fill (r1.3 g/cc)
  around reactor and heatpipes
• X-, Y-, and Z-deviations of single subunit

• Drilled hole radius
• 12 to 21 cm
• Melt radius predicted by the following
  equation
• Avoided melt interaction between holes

43
Effects of Tri-Cluster Emplacement
1.7 0.22.70
44
Rock-Melt Reflector Worth

4 - 57.15
45
X-Deviation of a Single Subunit
No significant change in reactivity in the Y or Z
directions
46
Effect of Drilled Hole Radius
47
Variability of the Lunar Regolith

• Bulk density 1.2 1.92 g/cc
• Melt density 2.6 3.6 g/cc
• Compositional analysis of major constituents of
  samples from various Apollo and Luna missions

48
Variations in the Bulk and Melt Densities of the
Lunar Regolith
49
Variation in Regolith Iron
50
Variation in Regolith Titanium
51
Variation in Regolith Aluminum
52
Variation in Regolith Oxygen
53
30 kWe Hexagonal Cluster

• Similar hole and regolith characteristics as
  tri-cluster arrangement
• Average trace element composition included
• Subunits placed 60-cm apart
• 10-cm diameter, interstitial B4C control rods to
  determine controllability of complete reactor
  system

54
Effects of Hexagonal Emplacement
sk lt 0.2Dkfill 0.5 0.2
55
Estimated Mass of Single Subunit
Each subunit contains 88 kg HEU. Maximum
shielding mass would not increase total mass
above 1 metric ton.
56
Specific Mass Comparison
57
Physical Dimensions
58
Coupling Analysis

• Averys coupling coefficients
• Coefficients determined between all units in the
  hexagonal cluster
• Adjacent kij 0.11210.0025
• 2-Away kij 0.13740.0026
• Cross-Cluster kij 0.14110.0025
• Infinite coupling kij 0.14960.0025
• Reactor system is very loosely coupled

Tightly coupled systems typically have kij values
in the thousandths decimal place.
59
Drafting Board ? Launch Pad

• Thorough thermodynamic and heat transfer analysis
• Ground testing
• Confirmation of final design for flight testing
• Safety and security measures

60
Linearly Coupled Subunits
60-cm apart
61
Extended Tri-Cluster Coupling
62
Averys Coupling Coefficients

• DEFINITIONS
• For a system of N coupled reactors
• kij is the expectation that a neutron from
  reactor i causes a fission in reactor j
• Si is the total system neutron source
• kex is the excess reactivity of the system
• Di is the measure of subcriticality of a reactor

63
Averys Coupling Coefficients
i
j
k
64
Coupling the LEGO Reactor
65
Uniqueness of the Reactor Design

• Lunar regolith functions as both shielding and
  reflector material
• Reactor subunits are subcritical in design
• Potential for unlimited reactor lifetime and
  power level
• Modularity

• Decreased neutron fluence reduced material
  damage
• Reduced thermal loads
• Failure of single subunit does not cause complete
  reactor failure
• Versatility in placement of new reactor systems
• Potential for Lunar evolution of design (in situ)

66
LEGO Reactor Evolution

• Fuels Development
• Nitride Fuels
• U-233, Cm-245/-244
• Reactor Control
• B4C Tri-Shades
• Axial Reflectors/Shielding
• Be or BeO
• Hydride Material

• Cladding Development
• Refractory Metals
• Tungsten-Cermet
• Waste-Heat Rejection
• Liquid Droplet Radiators
• Regolith Heat Sink
• Thermophotovoltaics

67
Potential Applications

• Non-Lunar, Extraterrestrial Surfaces
• Mars, Mercury, Moons, Asteroids
• Symbiosis with Lunar Manufacturing
• Thorium Breeding

• Irradiation Research and Development
• Neutron Flux-Trap
• Radioisotope Breeding
• Component Testing
• Regolith Analyses
• Terrestrial Develop of Modular Reactors for Rural
  and Developing Areas

68
Lunar Power Expansion
69
Conclusions

• A modular, fast-fission, heatpipe-cooled, lunar
  regolith clustered-reactor system was developed
• Uncertainties in regolith composition and
  emplacement has been characterized
• Narrow, deep holes
• Iron composition
• Subterrene lining
• Non-nuclear reactor component studies needed to
  develop axial reflector and/or shielding

• Launch accident scenarios demonstrate favorably
  yet need additional code comparison analyses
• Awaiting next code and data library releases
• Preliminary mass and volume estimates are
  favorable for a lunar reactor design
• Technological advancements will produce more
  competitive design
• Further thermodynamic and heat transfer analyses
  necessary to develop final LEGO reactor design

70
(No Transcript)
