Enterprise Java Overview

1
Enterprise Java Overview

• Panos Konstantinidis
• Java Developer
• JUG Leader Java Champion
• http//thejavablog.wordpress.com

2
Java Enterprise Edition

• Introduction to JEE
• JEE architecture/technologies
• JEE Application Servers
• SOA The next step
• Spring Framework.

3
Enterprise Systems

• Enterprise Systems
• Large scale and complex systems
• n number or tiers
• Distributed
• Thousands of users
• Multithreading
• Thousands or millions of requests per hour
• Support for fail-over
• Support for transactions
• Support for security

4
Before JEE

• Developer had to do everything
• Care about multithreading
• Care about transactions
• Care about fail-over
• Care about security
• ... on top of that care about the business logic

5
After JEE

• Application Server/Container takes care of
  application details
• Multithreading
• Security
• Fail-over
• etc.
• Developer takes care of business logic

6
JEE Architecture

• JEE architecture layers (image taken from
  http//www.itindepth.com/)?

7
Servlets

• Servlets
• Java objects that extend the functionality of a
  web server
• Run on the server
• Require a servlet container to run in
• Platform and server independent
• They access all the Java APIs
• Having HTML/XML/WML code within a Java class is
  ugly, error-prone and hard to maintain

8
JSP

• JSP
• A simple and easy way to create dynamic web
  content
• HTML/XML/WML/etc with Java code (scriplets)
  embedded into it
• Runs on the server
• Platform and server independent
• Needs to be pre-compiled into a servlet

9
Servlets JSP

• They work together
• JSP used for presentation
• Servlets are used as controllers/implement logic
• By separating logic from presentation (design) it
  is easier to maintain, scale and build web
  applications

10
EJB

• The cornerstone of a JEE application
• Server side components
• They enable fast and simplified development of
  distributed, transactional, secure and portable
  enterprise applications
• They are deployed into a container

11
EJB (continued)?

• Three types of EJB (Session, Entity, Message
  driven)?
• The container is responsible for
• Loading and initialising
• Transactions
• Persistence (activation/passivation and db
  persistence)?
• communication with clients via remote interfaces
• JNDI for finding EJB instances

12
Session Beans

• Perform actions on behalf of a particular client
• Stateful
• Maintains conversational state with the client
• Stateless
• Does not maintain state between client calls. The
  container can substitute beans as necessary
  between method calls.

13
Entity Beans

• Map data to a database row
• Provide abstraction layer so when working with an
  entity the storage mechanism is not specific.
• Container Managed
• The container persists the data to the db
  automatically.
• Beans Managed
• Developer writes code that persists data to the
  db and container calls these methods

14
Message Driven Beans

• Receive asynchronous notifications from a JMS
  server
• for example send a purchase order to a JMS queue
• Client does not interact with them directly but
  only through message queues

15
Java Messaging Service

• Software that provides service for messaging
• Can be stand-alone or consolidated within an
  application server
• JMS Queue
• Messages are sent into a queue and read from the
  queue. One consumer only
• JMS Topic
• Publish/subscribe mode. Messages are broadcast to
  all the consumers

16
JNDI

• Java Naming and Directory Interface
• It is used to store and retrieve objects by name
• Object have to register with a naming service
  first
• Can interact with existing naming services like
  LDAP

17
JTA

• The Java Transaction API allows application
  servers to handle transactions
• Developer declares the transaction properties
• The application server takes care of the rest

18
Java Mail

• The Java Mail API provides classes that model a
  mail system
• Supports many common protocols
• IMAP
• POP
• SMTP
• MIME

19
JAAS

• Java Authentication and Autorisation Service
• Authenticates users, makes sure users can log
  into the system and execute Java code
• Authorises users, makes sure users have the right
  permissions to perform the actions required
• Authentication modules include
• Kerberos
• Keystore
• Windows NT

20
JDBC

• Java Database Connectivity
• Lets developers access database from Java
• Also provides access to other form of data such
  as excel files
• There are drivers for all the known databases

21
J2EE Connectors

• Connectors provide a way to connect J2EE
  applications to heterogenous systems not written
  in Java (Siebel, SAP, etc)?
• System vendor provides the right connector

22
Application Servers

• Take care of application-related functionality
• Provide sophisticated means to handle
  multithreading/transactions/security/etc
• Handle the life-cycle of the installed components
• Usually cost thousands of pounds per CPU

23
Application Servers (continued)?

• All of application servers provide their own
  services (JMS, JNDI, servlet containers, etc)?
• Some application servers
• WebLogic
• WebSphere
• Oracle
• JBoss (free and open source, but you pay for
  support)?
• Glassfish (same)?

24
Deployment

• You deploy the application onto the application
  server in a form of EAR (Enterprise ARchive) file
• EAR is nothing more than a zipped file that
  contains all relevant files needed.
• It is expanded on deployment

25
Console

• Application servers usually provide a console
  where the administrator or developer can manage
  the application
• Deploy/undeploy applications
• Define JDBC resource
• Define users and roles
• etc

26
Web Services

• Services residing somewhere on the web
• Web services enable application to application
  interaction via the web
• Built on existing standards (SOAP over HTTP)?
• Web services are focused on messages not APIs (we
  don't care what created the message)?

27
Web Services (continued)?

• Interoperability between disparate systems
• You can access a .NET web service from a Java
  client (the opposite is also true), etc
• Enable Service Oriented Architecture (SOA)?
• Traditional approach is based on objects, we
  discover and use objects
• With SOA we discover and use services

28
Web Services protocol

• Simple Object Access Protocol (SOAP)?
• Transmission over existing HTTP protocol
• In essence we send HTTP requests with the whole
  SOAP message in the body of the POST
• XML based

29
WSDL

• Web Services Description Language
• Describes a web service
• Describes methods and parameter types
• Describes return types
• How to access it (what port it's running on,
  where it's running on)?
• XML based
• Complicated, use tools to generate the WSDL

30
UDDI

• Universal Description, Discovery and Integration
• It's a registry of services
• Publishes information about a web service
  (similar to yellow pages)?
• Publishes the access point of a web service

31
Spring

• Aims behind Spring
• Enterprise Java should be easier.
• Interfaces are better than classes.
• JavaBeans better than EJBs.
• Testability is important and should be easier.

32
Spring (continued)?

• Small size (around 6MB).
• One core jar file (and a few more dependencies).
• Spring manages life-cycle and configuration of
  application objects.
• Dependency Injection
• Objects are given their dependencies instead of
  creating/looking for them.
• Spring gives dependencies upon instatiation.

33
Spring (continued)?

• Application data are configured through an XML
  configuration file.
• Can be complicated and hard to maintain if there
  are too many beans configured.
• Like JEE, developer is only concerned about
  business logic, Spring takes care of application
  related functionality.

34
Spring Modules

• Spring contains several modules, each one can be
  used on its own.
• Core and Context modules, the heart of the Spring
  framework. Provide fundamental functionality.
• AOP module.
• JDBC module.
• ORM Module (hooks for other ORM implementations).
• Web Module.

35
Spring Core Modules

• Initialise all the application objects
  (JavaBeans) by reading the XML configuration
  file.
• Supply enterprise services such as JNDI,
  multithreading, remote calls etc.
• Provide support with integration with other
  frameworks (FreeMarker, iBatis etc).

36
Spring AOP

• Aspect a general feature we want to apply
  globally to our application (e.g. logging or
  exception handling).
• Aspects are declared through the XML
  configuration file.
• Container executes the aspect after, before or
  around a method call.
• Around can change the method behaviour.

37
Spring JDBC

• Provides functionality for JDBC.
• Database information (url, port etc) is
  configured via the XML configuration file.
• Handles the creation of connections, result sets,
  statements, pools etc.
• Closes the connection and returns it to the pool
  of available connections.

38
Spring Transactions

• Declare transactions in the configuration
  file/class meta data by using annotations.
• Can declare roll back behaviour per method or
  exception type.
• You can't do that with EJBs, only
  programmatically.
• No native support for distributed transactions.
  Only through JTA.
• EJBs support distributed transactions by default.

39
Spring Persistence

• Doesn't support out of the box ORM solutions.
• We need to integrate with existing technologies
  (Hibernate, TopLink etc). Spring provides the
  right plumbing to do so.
• Alternatively use plain JDBC.

40
Spring Web applications

• Provides its own web framework (Spring MVC).
• Typical MVC pattern with a central servlet acting
  as controller.
• Spring supports several web-oriented tasks
  (multipart file uploading, session handling etc).
• Can be integrated with other web frameworks like
  Struts, Tapestry, JSF.

41
Spring Distributed computing

• Remote calls to Spring ca be done via
• RMI (same as EJBs)?
• JAX/RPC (for Web Services)?

42
Spring Security

• Spring Security (formerly Acegi security)?
• Supports declarative security via XML
  configuration or class meta data annotations for
  security (EJBs also support declarative security
  via roles and users).

43
Spring Deployment

• Platform independent.
• A Spring application should run the same on any
  other machine that supports Spring.
• Migration should be easy (just copy paste the
  application data the XML configuration file).
• Same with EJBs, although a bit tricky.

44
Learning more

• Enterprise Java - http//java.sun.com/javaee/
• JEE compatible servers - http//java.sun.com/produ
  cts/servlet/industry.html
• JEE tutorial - http//java.sun.com/javaee/5/docs/t
  utorial/doc/
• JDBC tutorial - http//java.sun.com/docs/books/tut
  orial/jdbc/basics/
• JNDI - http//java.sun.com/products/jndi/tutorial/

• Servlets tutorial - http//java.sun.com/j2ee/tutor
  ial/1_3-fcs/doc/Servlets.html
• JMS - http//java.sun.com/products/jms/
• Spring Framework - http//www.springframework.org/

• Spring projects - http//www.springsource.org/proj
  ects
• WebLogic Server - http//www.bea.com
• WebSphere server - http//www.ibm.com/software/inf
  o/websphere/r
• JBoss Server - http//www.jboss.org/
• Glassfish Server - https//glassfish.dev.java.net/

45
Questions?
