Distributed Systems 600'437

1
Distributed Systems600.437 Replication II
Department of Computer Science The Johns Hopkins
University
2
Resilient Replication
Lecture 8

• Further readings
• Paxos Made Simple, Leslie Lamport
• Practical Byzantine Fault Tolerance, Miguel
  Castro and Barbara Liskov, OSDI 99.
• Paper from DSN 2006 on our www.cnds.jhu.edu/publi
  cations web page (Scaling Byzantine
  Fault-Tolerant Replication to Wide Area Networks)

3
Introduction

• Resilient State Machine Replication
• What does resilient mean?
• We want our replicated system to work even when
  faults occur.
• What kinds of faults can occur?
• Servers may crash!
• Servers might recover
• Network partitions can separate servers from each
  other.
• Byzantine faults. Servers may lie!
• We are going to use a class of protocols that is
  able to handle network connectivity changes
  better than those based on membership.

4
State Machine Replication

• Servers start in the same state.
• Servers change their state only when they execute
  an update.
• State changes are deterministic. Two servers in
  the same state will move to identical states, if
  they execute the same update.
• If servers execute updates in the same order,
  they will progress through exactly the same
  states. State Machine Replication!

5
State Machine Replication Example

• Our State one variable
• Operations (cause state changes)
• Op 1) n Add n to our variable
• Op 2) ?vn If variable v, then set it to n
• Start All servers have variable 0
• If we apply the above operations in the same
  order, then the servers will remain consistent

v9
v9
v3
v9
?39
?39
1
?39
v3
v3
v2
v3
1
1
1
?39
v2
v2
v2
v2
2
2
2
2
v0
v0
v0
v0
6
State Machine Replication
Clients Generate Updates
B,3
D,1
A,2
C,2
ESTABLISH ORDER
C,1
C,1
C,1
C,1
B,2
B,2
B,2
B,2
A,1
A,1
A,1
A,1
B,1
B,1
B,1
B,1
Apply Updates
7
Simple Replication
Can we use a Leader to establish an order?
u,s
Leader
u,s
u,s
u
Is this resilient?
If leader fails, then the system is not live!
u
u,s
u,s

• Server sends update, u, to Leader
• Leader assigns a sequence number, s, to u, and
  sends the update to the non-leader servers.
• Servers order update u with sequence number s.

8
How can we improve resiliency?
Elect another leader.
Use more messages.
Assign a sequence number to each leader. (Views)
Use the fact that two sets, each having at least
a majority of servers, must intersect!
First We need to describe our system model and
service properties.
9
Our System Model

• N servers
• Uniquely identified in 1N
• Asynchronous communication
• Message loss, duplication, and delay
• Network partitions
• No message corruption
• Benign faults
• Crash/recovery with stable storage
• No Byzantine behavior - Not yet anyway )

10
What is Safety?

• Safety If two servers execute the ith update,
  then these updates are the same.
• Another way to look at safety
• If there exists an ordered update (u,s) at some
  server, then there cannot exist an ordered update
  (u,s) at any other server, where u not u.
• We will now focus on achieving safety -- making
  sure that we dont execute updates in different
  orders on different servers.

11
Achieving Safety
Leader 2
u,s
Leader 1
u,s
u,s
Is this safe?
u,s
u,s
A new leader can violate safety! Can we fix this?

• A new leader must not violate previously
  established ordering!
• The new leader must know about all updates that
  may have been ordered.

12
Achieving Safety
u,s
u,s
What does this give us?
If a new leader gets information from any
majority of servers, it can determine what may
have been ordered!
Leader
u,s
u,s
u,s
u,s
u
u
u,s
u,s
u,s
u,s

• Leader sends Proposal(u,s) to all servers
• All servers send Accept(u,s) to all servers.
• Servers order (u,s) when they receive a majority
  of Proposal/Accept(u,s) messages

13
Changing Leaders

• Changing Leaders is commonly called a View
  Change.
• Servers use timeouts to detect failures.
• If the current leaders fails, the servers elect a
  new leader.
• The new leader cannot propose updates until it
  collects information from a majority of servers!
• Each server reports any Proposals that it knows
  about.
• If any server ordered a Proposal(u,s), then at
  least one server in any majority will report a
  Proposal for that sequence number!
• The new server will never violate prior
  ordering!!
• Now we have a safe protocol!!

14
Changing Leaders Example
Leader 2 can send a Proposal(u,s). We say it
replays (u,s)
Leader 2
Leader 1
u,s
u,s
5
u,s
4
3

• If any server orders (u,s), then at least
  majority of servers must have received
  Proposal(u,s).
• If a new server is elected leader, it will gather
  Proposals from a majority of servers.
• The new leader will learn about the ordered
  update!!

15
Is Our Protocol Live?

• Liveness If there is a set, C, consisting of
  majority of connected servers, then if any server
  in set C has a new update, then this update will
  eventually be executed.
• Is there a problem with our protocol? It is safe,
  but is it live?

16
Liveness Example
Leader 2
u,s
Leader 3
Leader 1
u,s
5
u,s
u,s
4
3

• Leader 3 gets conflicting Proposal messages!
• Which one should it choose?
• What should we add??

17
Adding View Numbers
Leader 2
2,u,s
Leader 3
Leader 1
1,u,s
2,u,s
1,u,s
4
3

• We add view numbers to the Proposal(v,u,s)!
• Leader 3 gets conflicting Proposal messages!
• Which one should it choose?
• It chooses the one with the greatest view number!!

18
Normal Case

• Assign-Sequence()
• A1. u NextUpdate()
• A2. next_seq
• A3. SEND Proposal(view, u,next_seq)
• Upon receiving Proposal(v, u,s)
• B1. if not leader and v my_view
• B2. SEND Accept(v,u,s)
• Upon receiving Proposal(v,u,s) and
• majority - 1 Accept(v,u,s)
• C1. ORDER (u,s)

We use view numbers to determine which Proposal
may have been ordered previously.
A server sends an Accept(v,u,s) message only for
a view that it is currently in, and never for a
lower view!
19
Leader Election

• Elect Leader()
• Upon Timer T Expire
• A1. my_view
• A2. SEND New-Leader(my_view)
• Upon receiving New-Leader(v)
• B1. if Timer T Stopped
• B2. if v gt my_view, then my_view v
• B3. SEND New-Leader(my_view)
• Upon receiving majority New-Leader(v)
• where v my_view
• C1. timeout 2 Timer T timeout
• C2. Start Timer T

Let V_max be the highest view that any server
has. Then, at least a majority of servers are in
view V_max or V_max - 1.
Servers will stay in the maximum view for at
least one full timeout period.
A server that becomes disconnected/connected repea
tedly cannot disrupt the other servers.
20
We Have Paxos
request
proposal
accept
reply
C
0
1
2

• The Part-Time Parliament Lamport, 98
• A very resilient protocol. Only a majority of
  participants are required to make progress.
• Works well on unstable networks.
• Only handles benign failures (not Byzantine).

21
What Happens If Servers Lie?

• Servers must be able to verify who sent each
  message.
• Crypto! Digital Signatures or MACS
• The leader might be bad!
• What might happen?
• The leader can send Proposal(u,s) to 2 out of 5
  servers and Proposal(u,s) to 2 out of 5 servers
  -- can we have a safety violation?
• Correct servers must make sure the malicious
  servers dont cause safety errors.
• The bad servers might send messages or they might
  not.

22
Byzantine Leader Example
2
u,s
Bad Leader
u,s
u,s
,s
3
u,s
u,s
u,s
4
5

• Bad Leader Sends Proposal(u,s) to servers 4 and
  5.
• Bad Leader Sends Proposal(u,s) to servers 2 and
  3.
• Server 4 could order (u,s) and server 3 could
  order (u,s).

23
How Do We Solve this Problem?

• Assume that there are at most f malicious
  servers, which can fail or become malicious. All
  of the other servers are correct.
• Let N denote the number of servers in our system.
• Any correct server can wait for at most N - f
  messages from servers, because f may fail or be
  malicious (and not send their messages).
• Can we add more servers?

24
How many servers do we need?

• Malicious servers can lie.
• Good servers tell the truth.
• We need to guarantee that a malicious server
  cannot generate two groups of Accept/Proposal
  messages that conflict. (i.e., (u,s) and (u,s))
  within the same view.
• We need at least N3f1 servers to do this!!
• We wait for 2f1 messages that say the same
  thing!
• The f bad servers can say Accept(u,s) and
  Accept(u,s).
• The good servers say only one thing, but a bad
  leader can lie to them.
• Lets try to generate the two sets of messages --
  Can we do it?
• Liar tells f1 of the good servers (u,s), and f
  of the good servers (u,s).

(u,s) f(bad) f1(good)
(u,s) f(bad) f(good)
total 2f1
total 2f
25
Lets use N3f1!
2
u,s
Bad Leader
u,s
,s
3
u,s
u,s
4

• f 1, N 4
• Bad Leader sends Proposal(u,s) to Server 3 and 4.
• Bad Leader sends Proposal(u,s) to Server 2.
• Can the Bad Leader violate safety?

26
Is the Protocol Live?

• f 2, N 321 7
• Bad Leader is Server 7, and Server 4 is bad, too!
• Bad Leader sends Proposal(v,u,s) to Servers 1, 2,
  and 3
• Bad Leader sends Proposal(v,u,s) to Servers 4,
  5, and 6
• There is a partition, Servers 2,3,4,5,6 are
  together.
• They cant determine which update server 1
  ordered.

1, (u,s)
2, (u,s)
3, (u,s)
7, (,s)
4, (,s)
5, (u,s)
6, (u,s)
27
How Can We Guarantee Liveness?

• We can add another round to the our fault
  tolerant protocol. The Normal Case Protocol
  becomes
• The Leader broadcasts a Pre-Prepare(v,u,s)
• If not Leader, Upon receiving a
  Pre-Prepare(v,u,s) that doesnt conflict with
  what I know about, broadcast a Prepare(v,u,s)
• Upon receiving 2f Prepare(v,u,s) and 1
  Pre-Prepare(v,u,s), broadcast Commit(v,u,s)
• Upon receiving 2f1 Commit Messages, Order the
  message
• Rounds 1 and 2 allow the correct servers to
  preserve safety within the same view.
• Round 3 preserves safety across view changes.

28
What About Changing Leaders?

• If any server orders (v,u,s), then 2f1 servers
  must have collected a set of 2f Prepare(v,u,s)
  messages and 1 Pre-Prepare(v,u,s)
• We call such a set a Prepare-Certificate(v,u,s).
• If Prepare-Certificate(v,u,s) exists, then
  Prepare-Certificate(v,u,s) cannot exist.
• How do we change Leaders (View Changes)
• The new leader collects information from 2f1
  servers. The servers supply Prepare-Certificates.
  If something was ordered, the new leader will
  find out.
• The new leader needs to send this information to
  all of the correct servers, otherwise the correct
  servers will not participate in the protocol.
• A Prepare-Certificate can be viewed as a trusted
  message (agreed upon by all of the servers). We
  use it like we use a Proposal message in Paxos.

29
We have BFT
request
pre-prepare
prepare
reply
commit
C
0
1
2
3

• Byzantine Fault Tolerance Castro and Liskov, 99
• Excellent LAN performance. Over 1000 updates/sec.
• 2/3 total servers 1 required to make progress
• Three rounds of message exchanges
• Expensive for large networks.

30
Steward A Hierarchical Approach

• Each site acts as a trusted logical unit that can
  crash or partition.
• Within each site Byzantine-tolerant agreement
  (similar to BFT).
• Masks f malicious faults in each site.
• Threshold signatures prove agreement to other
  sites.
• Between sites light-weight, fault-tolerant
  protocol (similar to Paxos).

31
Main Idea 1 Common Case Operation

• A client sends an update to a server at its local
  site.
• The update is forwarded to the leader site.
• The representative of the leader site assigns
  order in agreement and issues
  a threshold signed proposal.
• Each site issues a threshold signed
  accept.
• Upon receiving a majority of accepts, servers in
  each site order the update.
• The original server sends a response to the
  client.

32
Hierarchy Benefits

• Reduces the number of messages sent on the wide
  area network.
• O(N2) ? O(S2) helps both in throughput and
  latency.
• Reduces the number of wide area crossings.
• BFT-based protocols require 3 wide area
  crossings.
• Paxos-based protocols require 2 wide area
  crossings.
• Availability of the system is increased
• (2/3 of total servers 1) ? (A majority of
  sites).
• Read-only queries can be answered locally.

33
Hierarchy Challenges

• Each site has a representative that
• Coordinates the Byzantine protocol inside the
  site.
• Forwards packets in and out of the site.
• One of the sites acts as the leader in the wide
  area protocol
• The representative of the leader site assigns
  sequence numbers to updates.
• View Changes
• How do we select and change representatives and
  the leader site in agreement ?
• How do we transition safely when we need to
  change them ?

34
Main Idea 2 View Changes

• Sites change their local representatives based on
  timeouts.
• Leader site representative has a larger timeout.
• allows contact with at least one correct rep. at
  other sites.
• After changing enough leader site
  representatives, servers at all sites stop
  participating in the protocol, and elect a
  different leader site.

35
What About Pending Updates ?

• The new representative or leader site should not
  violate the order assigned by previous ones.
• After changing the site representative The new
  representative gathers information from 2f1
  local servers.
• After changing the leader site The
  representative of the new leader site gathers
  information from a majority of sites.

36
Non-Byzantine Comparison
Boston
MITPC
Delaware
4.9 ms
San Jose
UDELPC
9.81Mbits/sec
TISWPC
3.6 ms 1.42Mbits/sec
ISEPC
1.4 ms 1.47Mbits/sec
ISEPC3
100 Mb/s lt1ms
38.8 ms 1.86Mbits/sec
ISIPC4
Virginia
ISIPC
100 Mb/s lt 1ms
Los Angeles

• Based on a real experimental network (CAIRN).
• Several years ago we benchmarked benign
  replication on this network.
• Modeled on our cluster, emulating bandwidth and
  latency constraints, both for Steward and BFT.

37
CAIRN Emulation Performance

• Steward is limited by bandwidth at 51 updates per
  second.
• 1.8Mbps can barely accommodate 2 updates per
  second for BFT.
• Earlier experimentation with benign fault
  2-phase commit protocols achieved up to 76
  updates per sec. Amir et. all 02.

38
The Basic Idea

• Reduce database replication to Global Consistent
  Persistent Order
• Use group communication ordering to establish the
  Global Consistent Persistent Order on the
  updates.
• deterministic serialized consistent
• Group Communication membership quorum primary
  partition.
• Only replicas in the primary component can commit
  updates.
• Updates ordered in a primary component are marked
  green and applied. Updates ordered in a
  non-primary component are marked red and will be
  delayed.

39
Throughput Comparison (WAN)
40
Resilient Replication Summary

• We can build resilient replication protocols that
  do not use membership!
• Failures can be benign (crashes, network
  partitions) or Byzantine (servers can lie)
• We can add message exchanges (rounds) to
  guarantee Safety and Liveness with different
  fault models.
• Performance can be improved by adding hierarchy!
