Ever Upwards: The rise and rise of fluids in optical capillaries

1
Ever UpwardsThe rise and rise of fluids in
optical capillaries
Andrew Danos
2
Photonic Crystal Fibres

• Anti-Resonating Reflecting Optical Waveguide
  (ARROW)
• All holes filled with optical fluid
• Bandgap Omitted Waveguide (BOW)
• Inner ring filled only

NL-3.0-870-02 (3mm hole diameter)
SC-5.0-1040 (1.6mm hole diameter)
ESM-12-01 (3.7mm hole diameter)
3
Making BOW Fibre

• Apply a UV curing glue to fibre ends to seal
  target channels
• Delicate and prone to catastrophic failure, but
  not impossible
• Previously filled by pumping from reservoir
• Unable to fill reliably by this method
• Fluid escaping free end makes unable to couple

Sealed ESM
Sealed SC-1040
4
The Problem

• Require a method to keep fluid away from free end

5
The Problem

• Filled channels act as waveguides themselves
• No BOW effect, since light is not being carried
  in the fibre
• n2 lt n1 allows total internal reflection q2 gt
  90
• Fibre effectively becomes an array of
  independent, high loss waveguides

q2
q1
n2
n1
www.timbercon.com/Total-Internal-Reflection.html
n1sinq1 n2 sinq2
6
The Fluids

• Oils with precisely engineered refractive index
• Referred to by their index
• Wide range available
• Requested fluid properties datasheets from
  manufacturer

7
The Idea

• Fluid is drawn up fibre by its surface tension

• Fluid properties
• Surface tension (g) Nm-1
• Density (r) kgm-3
• Viscosity (h) kgm-1s-1

r
Upward force on fluid column 2prg
L
Downward force on fluid column mg
(Volume)rg (pr2L)rg
2g
http//www.physics.usyd.edu.au/helenj/PHYS1902/Fl
uids3.pdf
Equilibrium at L But this is FAR too long for
us 70cm
rgr
8
The Solution

• Time capillary infiltration so that fluid doesnt
  reach the end

?
finite time
9
It Should WorkIn Theory

• Washburn (1921) gives
• PA atmospheric pressure difference 0 since
  fibre open at both ends
• Ph hydrostatic pressure 0 at examined L
• Pc capillary pressure
• e coefficient of slip 0 (material
  property)
• q contact angle between glass and fluid 0
  on large scale test
• Equation has recent experimental support on cm,
  nm scale and regarding contact angle, but not on
  mm scale

2gcosq
r
10
Contact Angle

• Should expect contact angles to be different in
  different glass/fluid combinations

gsv solid surface free energy (tabulated) glv
liquid surface free energy (surface tension)
gsl solid/liquid interfacial free energy (not
tabulated) q contact angle
q
11
A Bit of Maths

• Cancelling
• Integrating with L(0)0 (ie, the fluid starts
  at the bottom)

D diameter of fibre channel 2r
12
Verification

• Measure time taken for fluid to reach given L
• Time measurement is easy
• use a stopwatch
• Length is more difficult
• exploit change in scattering pattern between
  filled and unfilled fibre to know when fluid has
  passed

13
Verification
filled pattern
scatters off fibre
laser
unfilled pattern
14
Pattern Change

15
Setup
diode laser
16
Setup
focusing lens
17
Setup
positionable fibre and fluid mount
18
Setup
sample fibre (white) testing half cm increments
over 4 cm fluid reservoir (yellow)
19
Results

• Record time for first sign of pattern change and
  end of change at each L
• Gives data of form (L,t1,t2)
• Plot against L and get a linear
  relationship
• Washburn predicts the gradient
• Then compare experimental gradient with
  Washburns under assumption that cosq 1

20
Results Index Matching in SC-1040

• For L against ( in S.I units)
• Experimental gradient 1190
• (solid line, fitted to data points)
• Theoretical gradient 1163
• (dashed line)
• Indicates that cosq 0.955
• q 17.25

Squaring both sides gives relationship between L
and t
21
Results

• Took results from a range of fibre and fluid
  types
• Confirms Washburn for both fluid and capillary
  property dependences

Increasing capillary radius
Fluids SC-1040 NL-870 ESM
Index matching (1.4587) ? ? ?
1.46 ?
1.48 ?
1.62 ?
1.63 ?
Changing fluid properties
actual fibre/fluid combination used for filled
fibres
22
Problem Solved

• It is the empirical constant relating t and L
  that is useful for accurately filling fibres
• even if it cant be determined exactly from fluid
  and fibre properties
• And now it works, so Im told

23
Acknowledgements

• Made possible by
• Dr. Jeremy Bolger lab manager and direct
  supervisor
• Dr. Boris Kuhlmey leading theoretician
• Prof. Ben Eggleton CUDOS director
• Dr. Eduard Tsoy
• Dr. Helen Johnston
• Prof. Dick Hunstead TSP coordinator

24
References

1. Washburn, E (1921) The Dynamics of Capillary
   Flow, The Physical Review, 17(3)
2. Chebbi, R (2007) Dynamics of Liquid Penetration
   into Capillary Tubes, The Journal of Colloid and
   Interface Science, 135(1), p255-260
3. Tas, N et al. (2004) Capillary Filling of Water
   in Nanotubes, Applied Physical Letters, 85(15),
   p3274-3276
4. Xue, H et al. (2006) Contact Angle Determined by
   Spontaneous Capillary Rises with Hydrostatic
   Effects Explanation and Theory, Chemical
   Physics Letters, 432(1-3), p326-330
