Toward image-based localization for AIBO using wavelet transform

1
Toward image-based localization for AIBO using
wavelet transform
A. Pretto, E. Menegatti, E. Pagello, Y.
Jitsukawa, R. Ueda, T. Arai
Centre for Engineering University of Tokyo, Japan
Department of Information Engineering University of Padua, Italy
Abstract This paper describes a similarity
measure for images to be used in image-based
localization for autonomous robots with low
computational resources. We propose a novel
signature which allows memory saving and fast
similarity calculation. The signature is based on
the calculation of the 2D Haar Wavelet Transform
of the gray-level image. We present experiments
showing the effectiveness of the proposed image
similarity measure. The used images were
collected using the AIBOs ERS-7 of the RoboCup
Team Araibo of the University of Tokyo on a
RoboCup field, however, the proposed image
similarity measure does not use any information
on the structure of the environment and do not
exploit the peculiar features of the RoboCup
environment.

• Wavelet signature
• We use as image signature a 2-D Haar Wavelet
  Transform of the grey-level values of the image.
  We decide to stop at 4-th level decomposition,
  and to characterize images only by the detailed
  coefficient (horizontal, vertical and diagonal)
  of this level.
• Haar Wavelet because
• very effective in detecting discontinuity (one of
  the most important features in image-based
  localization)
• easily implemented and very fast to compute
• If one is interested in image reconstruction
  phase, the Haar Wavelets are not the good choice,
  because they tend to produce a lot of squared
  artifacts
• Memory saving
• a gray-scale omnidirectional image 720x160
  115.2 Kbyte gt only 1.3 Kbyte.

• Introduction
• Three are the main problems to be solved by any
  techniques of image-based localization
• how to reduce the number of images necessary to
  fully describe the environment
• how to efficiently store a large data set of
  reference images (it is common to have several
  hundred reference images for typical
  environments)
• how to calculate in a fast and efficient way the
  similarity
• Each of the referred works addressed one or all
  of these problems.

• The problem
• How to implement an image-based localization
  approach on a robot with limited storage memory
  and limited computational resources, as the Sony
  AIBO ERS-7?
• How to store in a memory-saving way the reference
  images?
• How to efficiently compare them with the input
  images?
• Which feature should we relay on, for a general
  approach not targeted to a particular
  environment?

Experiments We tested the system in a RoboCup
Four-legged League 540x360 cm soccer field,
using a grid of 13 by 9 reference images. The
proposed systems do not relay on RoboCup features

• Our approach
• To minimize the reference images to be stored,
  keep as reference images two 180 degree panoramic
  views of the environment at every reference
  location
• We developed an algorithm that allows the ERS-7
  robot to autonomously build two 180 degrees
  panorama images using its standard camera and to
  stitch them together.
• We use as image signature a 2-D Haar Wavelet
  Transform of the grey-level values of the image.
  We decide to stop at 4-th level decomposition,
  and to characterize images only by the detailed
  coefficients (horizontal, vertical and diagonal)
  of this level.

• References
• 1. R. Cassinis, D. Duina, S. Inelli, and A.
  Rizzi. Unsupervised matching of visual landmarks
  for robotic homing using Fourier-Mellin
  transform. Robotics and Autonomous Systems,
  40(2-3), August 2002.
• 4. M. N. Do and M. Vetterli. Wavelet-based
  texture retrieval using generalized Gaussian
  density and Kullback-Leibler distance. IEEE Tr.
  Im. Proc., 11(2)146158, February 2002.
• 6. Emanuele Frontoni and Primo Zingaretti. An
  efficient similarity metric for om-
• nidirectional vision sensors. Robotics and
  Autonomous Systems, 54(9)750757, 2006.
• 7. J. Gaspar, N. Winters, and J. Santos-Victor.
  Vision-based navigation and environmental
  representations with an omnidirectional camera.
  IEEE Transaction on Robotics and Automation, Vol
  16(number 6), Dec. 2000.
• 8. H.-M. Gross, A. Koenig, Ch. Schroeter, and
  H.-J. Boehme. Omnivision-based prob-abilistic
  self-localization for a mobile shopping assistant
  continued. In IEEE/RSJ Int. Conference on
  Intelligent Robots and Systems (IROS 2003), pages
  pp. 15051511, October 2003, Las Vegas USA.
• 11. B.J.A. Koerse, N. Vlassis, R. Bunschoten, and
  Y. Motomura. A probabilistic
• model for appareance-based robot localization.
  Image and Vision Computing, vol.19(6)pp.
  381391, April 2001.
• 12. Emanuele Menegatti, Takeshi Maeda, and
  Hiroshi Ishiguro. Image-based memory for robot
  navigation using properties of the
  omnidirectional images. Robotics and Autonomous
  Systems, Elsevier, 47(4)pp. 251267, July 2004.
• 16. M. Vetterli and J Kovacevic. Wavelets and
  Subband Coding. Signal Processing Series. 1995.
• 17. J. Wolf, W. Burgard, and H. Burkhardt. Robust
  vision-based localization by combining an image
  retrieval system with monte carlo localization.
  IEEE Transactions on Robotics, 21(2)208216,
  2005.
