Leica Image Extensions for ArcMap

1
Leica Image Extensions for ArcMap

• This exercise will cover
• Image Creation
• Image Enhancement
• Image Sub-setting

NSF Grant DUE-0703185
2
Here We Go

• Our first step will be to open ArcMap
• Second we will locate our Image Analysis
  extension
• Locate the Menominee L7 Folder

3
Open ArcMap
4
We then navigate to Image Analysis
5
Navigate to Utilities under Image Analysis and
choose Layer Stack
6
The box below will open
7
We Open the Input Images Folder and Navigate to
the Menominee Folder
8
We will choose 40, 30 and 20 as our Selected
Layers and choose OK
9
The chosen bands will be added as input images
and click OK
10
The following Widget will Open
11
After the Widget Finishes the following Image
will appear
12
Image Pan-merging

• In this exercise we will pan-sharpen the image
• This means to merge the 15 meter panchromatic
  band with the existing 30 meter false color image
• Pan-merging will provide us with an image
  resolution of 15 meters

13
Navigate to Image Analysis and the Spatial
Enhancement
14
Choose Resolution Merge
15
A new target will open
16
Choose Band 80 as the high resolution Image
17
Choose the previously added image as the
multi-spectral image
18
Once again the following widget will open
19
The Finished Product
20
Add the Boundary Shape File
21
Subset Image by navigating to Data Preparation
and Subset Image
22
Choose our last image, the boundary shape file as
the Analysis Mask and click OK
23
The process begins again with our Widget
24
Our new Subset Image
