CfN High Field Workshop 4/9/08

1
CfN High Field Workshop4/9/08
2
Motivation for Workshop

• Highlight the upcoming delivery of a 7T
  whole-body MRI system at Penn
• Describe the potential benefits of 7T for basic
  and clinical neuroscience research
• Begin to plan for 7T pilot projects
• Science
• Instrumentation
• Regulatory

3
Workshop Schedule

• 900 Welcome and Introduction to 7T Imaging (me)
• 915 BOLD fMRI Opportunities and Pitfalls (Mark
  Elliott)
• 945 1H Spectroscopy (Harish Poptani)
• 1015 Coffee Break
• 1030 Multinuclear Imaging (Ravinder Reddy)
• 1100 ASL (Jiongjiong Wang)
• 1130 Discussion of Potential Projects and
  Instrumentation

4
7T Project

• Supported by NCRR HEI Grant (2M)
• Ravi Reddy PI
• CfN LSNI projects contributed significantly
• Other 7T MRI HEI to JHU, Vanderbilt, Pitt, NYU
• Total project cost 10M
• First 7T whole-body system in region
• JHU held up due to siting issues
• 20 7T sites worldwide

5
Why 7T?

• Continue tradition of biomedical MRI development
• Resource for Magnetic Resonance and Optical
  Research (NCRR RR)
• Highest commercially-available field strength
• Few experimental whole-body systems at 8T, 9.4T
• Cost (shielding) rises exponentially above 7T
• Years of experience with Siemens 7T platform
• System is now fully integrated
• Some product coils are also available
• Software platform same as 1.5T and 3T

6
Siemens 7 Tesla MRI

• 7T Whole body magnet
• Weight 35000 kg
• Unshielded
• Shield 400 tons
• 90cm bore
• 2.4mx3.4 m longx3.8m
• 5 ppm peak to peak over a 45 cm
• Gradient system
• Based on Tim Trio gradients
• Resistive shims are tuned for 7T
• 45mT/m for longitudinal
• 40mT/m for horizontal and vertical direction
• Max slew rate 200 mT/m/ms
• Minimal rise time 200 ms, from 0 to 40 mT/m
  amplitude
• Minimum slice thickness 0.1 mm (2D)

7
RF System

• 18 fully independent, fast receiver channels
• each with 1MHz bandwidth.
• RF Power amplifier
• 7kW RFPA, 280-300 MHz
• Parallel transmission in the future
• The following transmit receive RF coils will be
  provided
• CP head (quadrature Tx/Rx)
• 24-channel head array coil
• TX/RX surface loop coil
• Additional 3rd party coils include Na/head, Tx/Rx
  head array

7T_head_PD_TSE_133x133
8
7T Fee Schedule

• During initial 6 months of operation, scanning
  charges will not be implemented
• Much of this time will be used to implement and
  validate sequences and protocols
• Also intended to stimulate early applications
• At some point, hourly fees similar to the other
  resources will be implemented
• 7T ProDev will also be available

9
7T Regulatory Process

• IRB CAMRIS, similar to 3T
• CAMRIS review will be outsourced to a 7T-specific
  committee
• 7T is not FDA approved, but remains minimal risk
• A 7T Techdev protocol will cover initial studies
• The CfN will develop approved verbiage for 7T
  protocols and consents
• Initial studies on healthy volunteers

10
Known Advantages of 7T

• Increased sensitivity
• Although sensitivity of MRI scales with field, a
  doubling of sensitivity (from 3T to 7T) only
  translates to a 1.3X improvement in resolution
• Major sensitivity advantage is for non-1H nuclei
  at standard resolution
• Increased spectral resolution
• Improvement in spectral quality for both 1H and
  multinuclear
• May obviate the need for spectral editing for
  some resonances
• Better ASL
• T1 increases with field so improvement is
  gtgtlinear
• Different BOLD contrast
• Susceptibility effects increase with field (but
  so does physiological noise)
• Spatial sensitivity changes

11
1H Imaging at 7T

• Susceptibility effects are dramatically increased
• Alters appearance of vasculature, iron calcium
  deposits
• These may provide basis for altered parenchymal
  appearance

8T MRI, Robitaille et al., JCAT 2000
7T MRI, Li et al., NeuroImage 2006
12
Phase Based ContrastDuyn et al, PNAS 2007
13
MRA at 7Tvon Morze et al, JMRI 2008
3T
7T

• N5
• GE Signa
• 8-channel array
• Identical resolution

14
Tolerability of 7TTheysohn et al, MAGMA 2008
15
Conclusions

• 7T MRI will be ready for use this summer
• Coils available for brain and cortical regions
• BOLD fMRI, MRS, some ASL, Sodium imaging should
  be feasible soon after deployment
• Initial experience on healthy volunteers, but
  ambulatory patients will eventually be eligible
• Despite existence of human 7T for gt5yrs, limited
  literature on applications
• Opportunity to have fast impact with simple, good
  ideas
• Successful applications could provide competitive
  advantage for new grant applications
