Title: EEL 5930 sec. 5, Spring


1
EEL 5930 sec. 5, Spring 05Physical Limits of
Computing
http//www.eng.fsu.edu/mpf
  • Slides for a course taught byMichael P. Frankin
    the Department of Electrical Computer
    Engineering

2
Module 6 Fundamental Physical Limits of
Computing
  • A Brief Survey

3
Fundamental Physical Limits of Computing
ImpliedUniversal Facts
Affected Quantities in Information Processing
Thoroughly ConfirmedPhysical Theories
Speed-of-LightLimit
Communications Latency
Theory ofRelativity
Information Capacity
UncertaintyPrinciple
Information Bandwidth
Definitionof Energy
Memory Access Times
QuantumTheory
Reversibility
2nd Law ofThermodynamics
Processing Rate
Adiabatic Theorem
Energy Loss per Operation
Gravity
4
A Slightly More Detailed View
5
The Speed-of-Light Limit on Information
Propagation Velocity
  • What are its implications for future computer
    architectures?

6
Implications for Computing
  • Minimum communications latency!
  • Minimum memory-access latency!
  • Need for Processing-in-Memory architectures!
  • Mesh-type topologies are optimally scalable!
  • Hillis, Vitanyi, Bilardi Preparata
  • Together w. 3-dimensionality of space implies
  • No network topology with ?(n3) connectivity (
    nodes reachable in n hops) is scalable!
  • Meshes w. 2-3 dimensions are optimally scalable.
  • Precise number depends on reversible computing
    theory!

7
How Bad it Is, Already
  • Consider a 3.2 GHz processor (off todays shelf)
  • In 1 cycle a signal can propagate at most
  • c/(3.2 GHz) 9.4 cm
  • For a 1-cycle round-trip to cache memory back
  • Cache location can be at most 4.7 cm away!
  • Electrical signals travel at 0.5 c in typical
    materials
  • In practice, a 1-cycle memory can be at most 2.34
    cm away!
  • Already ? logics in labs at 100 GHz speeds!
  • E.g., superconducting logic technology RSFQ
  • 1-cycle round trips only within 1.5 mm!
  • Much smaller than a typical chip diameter!
  • As f?, architectures must be increasingly local.

8
Latency Scaling w. Memory Size
  • Avg. time to randomly access anyone of n bits of
    storage (accessibleinformation) scales as
    ?(n1/3).
  • This will remain true in all future technologies!
  • Quantum mechanics gives a minimum size for bits
  • Esp. assuming temperature pressure are limited.
  • Thus n bits require a ?(n)-volume region of
    space.
  • Minimum diameter of this region is ?(n1/3).
  • At lightspeed, random access takes ?(n1/3) time!
  • Assuming a non-negative curvature region of
    spacetime.
  • Of course, specific memory technologies (or a
    suite of available technologies) may scale even
    worse than this!

?(n1/3)
n bits
9
Scalability Maximal Scalability
  • A multiprocessor architecture accompanying
    performance model is scalable if
  • it can be scaled up to arbitrarily large
    problem sizes, and/or arbitrarily large numbers
    of processors, without the predictions of the
    performance model breaking down.
  • An architecture ( model) is maximally scalable
    for a given problem if
  • it is scalable, and if no other scalable
    architecture can claim asymptotically superior
    performance on that problem
  • It is universally maximally scalable (UMS) if it
    is maximally scalable on all problems!
  • I will briefly mention some characteristics of
    architectures that are universally maximally
    scalable

10
Shared Memory isnt Scalable
  • Any implementation of shared memory requires
    communication between nodes.
  • As the of nodes increases, we get
  • Extra contention for any shared BW
  • Increased latency (inevitably).
  • Can hide communication delays to a limited
    extent, by latency hiding
  • Find other work to do during the latency delay
    slot.
  • But, the amount of other work available is
    limited by node storage capacity, parallizability
    of the set of running applications, etc.

11
Unit-Time Message Passing Isnt Scalable
  • Model Any node can pass a message to any other
    in a single constant-time interval (independent
    of the total number of nodes)
  • Same scaling problems as shared memory!
  • Even if we assume BW contention (traffic) isnt a
    problem, unit-time assumption is still a problem.
  • Not possible for all N, given speed-of-light
    limit!
  • Need cube root of N asymptotic time, at minimum.

12
Many Interconnect Topologies arent Scalable
  • Suppose we dont require a node can talk to any
    other in 1 time unit, but only to selected
    others.
  • Some such schemes still have scalability
    problems, e.g.
  • Hypercubes
  • Binary trees, fat trees
  • Butterfly networks
  • Any topology in which the number of unit-time
    hops to reach any one of N nodes is of order less
    than N1/3 is necessarily doomed to failure!
  • Caveat Except in negative-curvature spacetimes!

13
Only Meshes (or subgraphs thereof) Are Scalable
  • See papers by Hillis, Vitanyi, Bilardi
    Preparata
  • 1-D meshes
  • linear chain, ring, star (w. fixed of arms)
  • 2-D meshes
  • square grid, hex grid, cylinder, 2-sphere,
    2-torus,
  • 3-D meshes
  • crystal-like lattices w. various symmetries
  • Caveat
  • Scalability in 3rd dimension is limited by
    energy/information I/O considerations!

Amorphousarrangementsin ?3d, w. localcomms.,
are also ok
14
Ideally Scalable Architectures
Claim A 2- or 3-D mesh multiprocessor with a
fixed-size memory hierarchy per node is an
optimal scalable computer systems design (for any
application).
Processing Node
Processing Node
Processing Node
Local memory hierarchy(optimal fixed size)
Local memory hierarchy(optimal fixed size)
Local memory hierarchy(optimal fixed size)
Processing Node
Processing Node
Processing Node
Local memory hierarchy(optimal fixed size)
Local memory hierarchy(optimal fixed size)
Local memory hierarchy(optimal fixed size)
Mesh interconnection network
15
Landauers Principle
  • Low-level physics is reversible
  • Means, the time-evolution of a state is bijective
  • Deterministic looking backwards in time
  • as well as forwards
  • Physical information (like energy) is conserved
  • Cannot be created or destroyed, only reversibly
    rearranged and modified
  • Implies the 2nd Law of Thermodynamics
  • Entropy (unknown info.) in a closed, unmeasured
    system can only increase (as we lose track of the
    state)
  • Irreversible bit erasure really just moves the
    bit into surroundings, increasing entropy heat

16
Scaling in 3rd Dimension?
  • Computing based on ordinary irreversible bit
    operations only scales in 3d up to a point.
  • Discarded information associated energy must be
    removed thru surface. Energy flux limited.
  • Even a single layer of circuitry in a
    high-performance CPU can barely be kept cool
    today!
  • Computing with reversible, adiabatic operations
    does better
  • Scales in 3d, up to a point
  • Then with square root of further increases in
    thickness, up to a point. (Scales in 2.5
    dimensions!)
  • Scales to much larger thickness than irreversible!

17
Universal Maximum Scalability
  • Existence proof for universally maximally
    scalable (UMS) architectures
  • Physics itself is a universal maximally scalable
    architecture because any real computer is
    merely a special case of a physical system.
  • Obviously, no restricted class of real computers
    can beat the performance scalability of physical
    systems in general.
  • Unfortunately, physics doesnt give us a very
    simple or convenient programming model.
  • Comprehensive expertise at programming physics
    means mastery of all physical engineering
    disciplines chemical, electrical, mechanical,
    optical, etc.
  • Wed like an easier programming model than this!

18
Simpler UMS Architectures
  • (I propose) any practical UMS architecture will
    have the following features
  • Processing elements characterized by constant
    parameters (independent of of processors)
  • Makes it easy to scale multiprocessors to large
    capacities.
  • Mesh-type message-passing interconnection
    network, arbitrarily scalable in 2 dimensions
  • w. limited scalability in 3rd dimension.
  • Processing elements that can be operated in an
    arbitrarily reversible way, at least, up to a
    point.
  • Enables improved 3-d scalability in a limited
    regime
  • (In long term) Have capability for
    quantum-coherent operation, for extra perf. on
    some probs.

19
Limits on Amount of Information Content
20
Some Quantities of Interest
  • We would like to know if there are limits on
  • Information density
  • Bits per unit volume
  • Affects physical size and thus propagation
    delayacross memories and processors. Also
    affects cost.
  • Information flux
  • Bits per unit area per unit time
  • Affects cross-sectional bandwidth, data I/O
    rates, rates of standard-information input
    effective-entropy removal
  • Rate of computation
  • Number of distinguishable-state changes per
    unit time
  • Affects rate of information processing achievable
    in individual devices

21
Bit Density No classical limit
  • In classical (continuum) physics, even a single
    particle has a real-valued positionmomentum
  • All such states are considered physically
    distinct
  • Each position momentum coordinate in general
    requires an infinite string of digits to specify
  • x 4.592181291845019587661625618991009 meters
  • p 2.393492301938881726153514427394001 kg m/s
  • Even the smallest system contains an infinite
    amount of information! ? No limit to bit
    density.
  • This picture is the basis for various analog
    computing models studied by some theoreticians.
  • Wee problem Classical physics is dead wrong!

22
The Quantum Continuum
  • In QM, still ? uncountably many describable
    states (mathematically possible wavefunctions)
  • Can theoretically take infinite info. to describe
  • But, not all this info has physical relevance!
  • States are only physically distinguishable when
    their state vectors are orthogonal.
  • States that are only indistinguishably different
    can only lead to indistinguishably different
    consequences (resulting states)
  • due to linearity of quantum physics
  • There is no physical consequence from presuming
    an infinite of bits in ones wavefunction!

23
Quantum Particle-in-a-Box
  • Uncountably manycontinuouswavefunctions?
  • No, can expresswave as a vectorover
    countablymany orthogonalnormal modes.
  • Fourier transform
  • High-frequencymodes have higherenergy (Ehf)
    alimit on average energy impliesthey have low
    probability.

24
Ways of Counting States
  • The entire field of quantum statistical mechanics
    is all about this, but here are some simple ways
  • For a system w. a constant of particles
  • of states numerical volume of the
    position-momentum configuration space (phase
    space)
  • When measured in units where h1.
  • Exactly approached in the macroscopic limit.
  • Unfortunately, of particles is not usually
    constant!
  • Quantum field theory bounds
  • Smith-Lloyd bound. Still ignores gravity.
  • General relativistic bounds
  • Bekenstein bound, holographic bound.

25
Smith-Lloyd Bound
Smith 95Lloyd 00
  • Based on counting modes of quantum fields.
  • S entropy, M mass, V volume
  • q number of distinct particle types
  • Lloyds bound is tighter by a factor of
  • Note
  • Maximum entropy density scales with only the 3/4
    power of mass-energy density!
  • E.g., Increasing entropy density by a factor of
    1,000 requires increasing energy density by
    10,000.

26
Whence this scaling relation?
  • Note that in the field theory limit, S ? E3/4.
  • Where does the ¾ power come from?
  • Consider a typical mode in field spectrum
  • Note that the minimum size of agiven wavelet is
    its wavelength ?.
  • of distinguishable wave-packet location states
    in a given volume ? 1/?3
  • Each such state carries just a little entropy
  • occupation number of that state ( of photons in
    it)
  • ?1/?3 particles each energy ?1/?, ?1/?4 energy
  • S?1/?3 ? E?1/?4 ? S?E3/4

27
Whence the distribution?
  • Could the use of more particles (with less energy
    per particle) yield greater entropy?
  • What frequency spectrum (power level or particle
    number density as a function of frequency) gives
    the largest states?
  • Note ? a minimum particle energy in finite-sized
    box
  • No. The Smith-Lloyd bound is based on the
    blackbody radiation spectrum.
  • We know this spectrum has the maximum info.
    content among abstract states, b/c its the
    equilibrium state!
  • Empirically verified in hot ovens, etc.

28
Examples w. Smith-Lloyd Bound
  • For systems at the density of water (1 g/cm3),
    composed only of photons
  • Smiths example 1 m3 box holds 61034 bits
  • 60 kb/Å3
  • Lloyds example 1 liter ultimate laptop,
    21031 b
  • 21 kb/Å3
  • Pretty high, but whats wrong with this picture?
  • Example requires very high temperaturepressure!
  • Temperature around 1/2 billion Kelvins!!
  • Photonic pressure on the order of 1016 psi!!
  • Like a miniature piece of the big bang. -Lloyd
  • Probably not feasible to implement any time soon!

29
More Normal Temperatures
  • Lets pick a more reasonable temperature 1356 K
    (melting point of copper)
  • The entropy density of light is only 0.74
    bits/?m3!
  • Less than the bit density in a DRAM today!
  • Bit size is comparable to avg. wavelength of
    optical-frequency light emitted by melting copper
  • Lesson Photons are not a viable nanoscale info.
    storage medium at ordinary temperatures.
  • They simply arent dense enough!
  • CPUs that do logic with optical photons cant
    have their logic devices packed very densely.

30
Entropy Density of Solids
  • Can easily calculate from standard empirical
    thermochemical data.
  • E.g. see CRC Handbook of Chemistry Physics.
  • Obtain entropy by integrating heat capacity
    temperature, as temperature increases
  • Example result, for copper
  • Has one of the highest entropy densities among
    pure elements, at atmospheric pressure.
  • _at_ room temperature 6 bits/atom, 0.5 b/Å3
  • At boiling point 1.5 b/Å3
  • Cesium has one of the highest bits/atom at room
    temperature, about 15.
  • But, only 0.13 b/Å3
  • Lithium has a high bits/mass, 0.7 bits/amu.

1012denser thanits light!
Related toconductivity?
31
General-Relativistic Bounds
  • Note the Smith-Lloyd bound does not take into
    account the effects of general relativity.
  • Earlier bound from Bekenstein Derives a limit on
    entropy from black-hole physics
  • S lt (2?ER / ?c) nats
  • E total energy of system
  • R radius of the system (min sphere)
  • Limit only attained by black holes!
  • Black holes have 1/4 nat entropy per square
    Planck length of surface (event horizon) area.
  • Absolute minimum size of a nat 2 Planck lengths,
    square

41039 b/Å3average ent. dens.of a 1-m
radiusblack hole!(Mass?Saturn)
32
The Holographic Bound
  • Based on Bekenstein black-hole bound.
  • The information content I within any surface of
    area A (independent of its energy content!)
    is I A/(2?P)2 nats
  • ?P is the Planck length (see lecture on units)
  • Implies that any 3D object (of any size) is
    completely definable via a flat (2D) hologram
    on its surface having Planck-scale resolution.
  • This information is all entropy only in the case
    of a black hole with event horizonthat surface.

33
Holographic Bound Example
  • The age of the universe is 13.7 Gyr 1 WMAP.
  • Radius of currently-observed part would thus be
    13.7 Glyr
  • But, due to expansion, its edge is actually 46.6
    Glyr away today.
  • Cosmic horizon due to acceleration is 62 Glyr
    away
  • The universe is flat, so Euclidean formulas
    apply
  • The surface area of the eventually-observable
    universe is
  • A 4pr2 4p(62 Glyr)2 4.331054 m2
  • The volume of the eventually-observable universe
    is
  • V (4/3)pr3 (4/3)p(62 Glyr)3 8.481080 m3
  • Now, we can calculate the universes total info.
    content, and its average information density!
  • I An/4?P2 (pr2/?P2) n 4.1510123 n
    5.9810123 b
  • I/V 7.061042 b/m3 7.0610-3 b/fm3 1b/(.19
    fm)3
  • A proton is 1 fm in radius.
  • Very close to 1 bit per quark-sized volume!

34
Do Black Holes Destroy Information?
  • Currently, it seems that no one completely
    understands exactly how information is preserved
    during black hole accretion, for later
    re-emission in the Hawking radiation.
  • Perhaps via infinite time dilation at event
    horizon?
  • Some researchers have claimed that black holes
    must be doing something irreversible in their
    interior (destroying information).
  • However, the arguments for this may not be valid.
  • Recent string theory calculations contradict this
    claim.
  • The issue seems not yet fully resolved, but I
    have many references on it if youre interested.
  • Interesting note Stephen Hawking recently
    conceded a bet he had made, and decided black
    holes do not destroy information.

35
Implications of InformationDensity Limits
  • There is a minimum size for a bit-device.
  • thus there is a minimum communication latency to
    randomly access a memory containing n bits
  • as we discussed earlier.
  • There is also a minimum cost per bit, if there is
    a minimum cost per unit of matter/energy.
  • Implications for communications bandwidth limits
  • coming up

36
Some Quantities of Interest
  • We would like to know if there are limits on
  • Information density
  • Bits per unit volume
  • Affects physical size and thus propagation
    delayacross memories and processors. Also
    affects cost.
  • Information flux
  • Bits per unit area per unit time
  • Affects cross-sectional bandwidth, data I/O
    rates, rates of standard-information input
    effective entropy removal
  • Rate of computation
  • Number of distinguishable-state changes per
    unit time
  • Affects rate of information processing achievable
    in individual devices

37
Communication Limits
  • Latency (propagation-time delay) limit from
    earlier, due to speed of light.
  • Teaches us scalable interconnection technologies
  • Bandwidth (information rate) limits
  • Classical information-theory limit (Shannon)
  • Limit, per-channel, given signal bandwidth SNR.
  • Limits based on field theory (Smith/Lloyd)
  • Limit given only area and power.
  • Applies to I/O, cross-sectional bandwidths in
    parallel machines, and entropy removal rates.

38
Hartley-Shannon Law
  • The maximum information rate (capacity) of a
    single wave-based communication channel is C
    B log (1S/N)
  • Where
  • B bandwidth of channel, in frequency (1/Tper)
    units
  • S signal power level
  • N noise power level
  • The log base gives the information unit, as usual
  • Law not sufficiently powerful for our purposes!
  • Does not tell us how many effective channels are
    possible,
  • given available power and/or area.
  • Does not give us any limit if..
  • we are allowed to indefinitely increase bandwidth
    used,
  • or indefinitely decrease the noise floor (better
    isolation).

39
Density Flux
  • Note that any time you have
  • a limit ? on density (per volume) of something,
  • a limit v on its propagation velocity,
  • this automatically implies
  • a limit F ?v on the flux
  • by which I mean amount per time per area
  • Note also we always have a limit (c) on velocity!
  • At speeds near c, must account for relativistic
    effects
  • Often, slower velocities vltc may also be
    relevant
  • Electron saturation velocity, in various
    materials
  • Max velocity of air or liquid coolant in a
    cooling system
  • Thus, a density limit ? implies flux limit F?c

Cross-section
v
40
Relativistic Effects
  • For normal matter (bound massive-particle states)
    moving at a velocity v approaching c
  • Entropy density increases by a factor 1/?
  • Due to relativistic length contraction
  • But, energy density increases by factor 1/?2
  • Both length contraction mass amplification!
  • ? entropy density scales up only w. square root
    (1/2 power) of energy density from high velocity
  • Note that light travels at c already,
  • its entropy density scales with energy density
    to the 3/4 power. ? Light wins in limit as v?c.
  • If you want to maximize entropy flux/energy flux

41
Max. Entropy Flux Using Light
Smith 95
  • Where
  • FS entropy flux
  • FE energy flux
  • ?SB Stefan-Boltzmann constant, ?2kB4/60c2?3
  • This is derived from the same field-theory
    arguments as the information density bound.
  • Again, the blackbody spectrum maximizes the
    entropy flux, given the energy flux
  • Because it is the equilibrium spectrum!

42
Entropy Flux Examples
  • Consider a 10 cm wide, flat, square wireless
    tablet with a 10 W power supply.
  • Whats its maximum possible rate of bit
    transmission?
  • Independent of spectrum used, noise floor, etc.
  • Answer
  • Energy flux 10 W/2(10 cm)2 (use both sides)
  • Smiths formula gives 2.21021 bps
  • Whats the rate per square nanometer surface?
  • Only 109 kbps! (ISDN speed, in a 100 GHz CPU?)
  • 100 Gbps/nm2 ? nearly 1 GW power!

Light is not informationally dense enough for
high-bandwidth communication between densely
packed nanometer-scale devices at reasonable
power levels!!!
43
Entropy Flux w. Atomic Matter
  • Consider liquid copper (?S 1.5 b/Å3) moving
    along at a leisurely v 10 cm/s
  • BW 1.5x1027 bps through the 10-cm wide square!
  • A million times higher BW than with 10W light!
  • 150 Gbps/nm2 entropy flux!
  • Plenty for nano-scale devices to talk to their
    neighbors
  • Most of this entropy is in the conduction
    electrons...
  • Less conductive materials have much less entropy
  • Can probably do similarly well (or better) just
    moving the electrons in solid copper. (Higher
    velocities attainable.)
  • Nano-wires can probably carry gt100 Gbps
    electrically.
  • Lesson
  • For maximum bandwidth density at realistic power
    levels, encode information using states of matter
    (electrons) rather than states of radiation
    (light).

Exercise Kinetic energy flux?
44
Some Quantities of Interest
  • We would like to know if there are limits on
  • Infropy density
  • Bits per unit volume
  • Affects physical size and thus propagation
    delayacross memories and processors. Also
    affects cost.
  • Infropy flux
  • Bits per unit area per unit time
  • Affects cross-sectional bandwidth, data I/O
    rates, rates of standard-information input
    effective entropy removal
  • Rate of computation
  • Number of distinguishable-state changes per
    unit time
  • Affects rate of information processing achievable
    in individual devices

45
Computation Speed Limits
46
The Margolus-Levitin Bound
  • The maximum rate ?? at which a system can
    transition between distinguishable (orthogonal)
    states is ?? ? 4(E ? E0)/h
  • where
  • E average energy (expectation value of energy
    over all states, weighted by their probability)
  • E0 energy of lowest-energy or ground state of
    system
  • h Plancks constant (converts energy to
    frequency)
  • Implication for computing
  • A circuit node cant switch between 2 logic
    states faster than this frequency determined by
    its energy.

This is for pops,rate of nops ishalf as great.
47
Example of Frequency Bound
  • Consider Lloyds 1 liter, 1 kg ultimate laptop
  • Total gravitating mass-energy E of 9?1016 J
  • Gives a limit of 5?1050 bit-operations per
    second!
  • If laptop contains 2?1031 bits (photonic
    maximum),
  • each bit can change state at a frequency of
    2.5?1019 Hz (25 EHz)
  • 12 billion times higher-frequency than todays 2
    GHz Intel processors
  • 250 million times higher-frequency than todays
    100 GHz superconducting logic
  • But, the Margolus-Levitin limit may be far from
    achievable in practice!

48
More Realistic Estimates
  • Most of the energy in complex stable structures
    is not accessible for computational purposes...
  • Tied up in the rest masses of atomic nuclei,
  • Which form anchor points for electron orbitals
  • mass energy of core atomic electrons,
  • Which fill up low-energy states not involved in
    bonding,
  • of electrons involved in atomic bonds
  • Which are needed to hold the structure together
  • Conjecture Can obtain tighter valid quantum
    bounds on info. densities state-transition
    rates by considering only the accessible energy.
  • Energy whose state-information is manipulable.

49
More Realistic Examples
  • Suppose the following system is accessible1
    electron confined to a (10 nm)3 volume, at an
    average potential of 10 V above ground state.
  • Accessible energy 10 eV
  • Accessible-energy density 10 eV/(10 nm)3
  • Maximum entropy in Smith bound 1.4 bits?
  • Not clear yet whether bound is applicable to this
    case.
  • Maximum rate of change 9.7 PHz
  • 5 million typical frequencies in todays CPUs
  • 100,000 frequencies in todays superconducting
    logics

50
Summary of Fundamental Limits
About PowerShow.com
