Title: CASTING


1
CASTING
  • General Manufacturing Processes Engr.-20.2710
  • Instructor - Sam Chiappone

2
The Industry
  • 14 million pounds of castings are produced every
    year
  • The most common materials cast are gray iron,
    ductile iron, aluminum alloys, and copper alloys
  • 35 of the market is in automotive and light
    truck manufacturing
  • Castings are used in applications ranging from
    agriculture to railroad equipment and heating and
    refrigeration

3
. . . Of the marvelous mechanism by which this
great picture was disclosed to men it is enough
to say that its cost was 400,000, that the axle
on which the beam turns weighs 140,000 pounds and
is the largest piece of steel ever cast in one
piece. The entire weight of the wheel and its
mechanism is 4,800 tons as is moved by two
engines of 1,000-horse power each. Over 2,100
persons may make the trip at one time. The
History of the Ferris Wheel Pittsburgh Commercial
Gazette, 17 June 1893
4
Process Steps
  • Six basic steps of casting
  • 1. Mold cavity is produced having the desired
    shape and size of the part
  • Takes shrinkage into account
  • Single-use or permanent mold
  • 2. Melting process
  • Provides molten material at the proper
    temperature
  • 3. Pouring technique
  • Molten metal is poured into the mold at a proper
    rate to ensure that erosion and or defects are
    minimized

5
Process Steps
  • 4. Solidification process
  • Controlled solidification allows the product to
    have desired properties
  • Mold should be designed so that shrinkage is
    controlled
  • 5. Mold removal
  • The casting is removed from the mold
  • Single-use molds are broken away from the casting
  • Permanent molds must be designed so that removal
    does not damage the part
  • 6. Cleaning, finishing, and inspection operations
  • Excess material along parting lines may have to
    be machined

6
Casting Terms
  • Pattern- approximate duplicate of the part to be
    cast
  • Molding material- material that is packed around
    the pattern to provide the mold cavity
  • Flask- rigid frame that holds the molding
    aggregate
  • Cope- top half of the pattern
  • Drag- bottom half of the pattern
  • Core- sand or metal shape that is inserted into
    the mold to create internal features

7
Casting Terms
  • Mold cavity- combination of the mold material and
    cores
  • Riser-additional void in the mold that provides
    additional metal to compensate for shrinkage
  • Gating system- network of channels that delivers
    the molten metal to the mold
  • Pouring cup- portion of the gating system that
    controls the delivery of the metal
  • Sprue- vertical portion of the gating system
  • Runners- horizontal channels
  • Gates- controlled entrances

8
Casting Terms
  • Parting line- separates the cope and drag
  • Draft- angle or taper on a pattern that allows
    for easy removal of the casting from the mold
  • Casting- describes both the process and the
    product when molten metal is poured and solidified

9
Casting Terms
10
The Solidification Process
  • Molten material is allowed to solidify into the
    final shape
  • Casting defects occur during solidification
  • Gas porosity
  • Shrinkage
  • Two stages of solidification
  • Nucleation
  • Growth

11
Nucleation
  • Stable particles form from the liquid metal
  • Occurs when there is a net release of energy from
    the liquid
  • Undercooling is the difference between the
    melting point and the temperature at which
    nucleation occurs
  • Each nucleation event produces a grain
  • Nucleation is promoted (more grains) for enhanced
    material properties
  • Inoculation or grain refinement is the process of
    introducing solid particles to promote nucleation

12
Grain Growth
  • Occurs as the heat of fusion is extracted from
    the liquid
  • Direction, rate, and type of growth can be
    controlled
  • Controlled by the way in which heat is removed
  • Rates of nucleation and growth control the size
    and shape of the crystals
  • Faster cooling rates generally produce finer
    grain sizes

13
Cast Structure Cooling Zones
  • Three distinct regions or zones
  • Chill zone
  • Rapid nucleation that occurs when the molten
    metal comes into contact with the cold walls of
    the mold
  • Forms a narrow band of randomly oriented crystals
    on the surface of a casting
  • Columnar zone
  • Rapid growth perpendicular to the casting surface
  • Long and thin
  • Highly directional
  • Equiaxed zone
  • Crystals in the interior of the casting
  • Spherical, randomly oriented crystals

14
Cast Structure
Figure 11-5 Internal structure of a cast metal
bar showing the chill zone at the periphery,
columnar grains growing toward the center, and a
central shrinkage cavity.
15
Process Factors
  • Molten metal problems
  • Reaction of the metal and its environment can
    lead to poor quality castings. Oxygen and molten
    metal react to form slag or dross. These
    impurities can become trapped in castings to
    impair surface finish, machinability, or reduce
    the mechanical properties of the castings.

16
Process Factors
  • Fluidity
  • Molten metal must flow then freeze into the
    desired shape. Incorrect flow characteristics
    can result in short shots, incorrect part
    tolerances, cracks in castings, voids, etc.
  • Gating System
  • Correct design of the gating system is a must.
    Gating system controls the speed, rate, and
    delivery of molten material into the mold cavity.
  • Example PIM general rule is gate depth is equal
    to 1/3 its width

17
Process Factors
  • Patterns
  • Shrinkage allowance
  • Typical allowances
  • Cast iron 0.8-1.0
  • Steel 1.5-2.0
  • Aluminum 1.0-1.3
  • Magnesium 1.0-1.3
  • Brass 1.5
  • Amount of draft
  • Size and shape of pattern
  • Depth of mold cavity
  • Method used to withdraw pattern
  • Pattern material
  • Mold material
  • Molding procedure

18
Process Factors
  • Finish material allowance
  • Final dimensional accuracy of the casting

19
Design ConsiderationsParting Lines
  • Location and orientation of the parting line is
    important to castings
  • Parting line can affect
  • Number of cores
  • Method of supporting cores
  • Use of effective and economical gating
  • Weight of the final casting
  • Final dimensional accuracy
  • Ease of molding

20
Design ConsiderationsParting Lines
Figure 11-17 (Right) Elimination of a dry-sand
core by a change in part design.
Figure 11-16 (Left) Elimination of a core by
changing the location or orientation of the
parting plane.
21
Design ConsiderationsDraft and Allowances
Figure 11-14 Two-part mold showing the parting
line and the incorporation of a draft allowance
on vertical surfaces.
Figure 11-15 Various allowances incorporated into
a casting pattern.
22
Design ConsiderationsSections
Figure 11-19 (Above) Typical guidelines for
section change transitions in castings.
Figure 11-20 a) The hot spot at section r2 is
cause by intersecting sections. B) An interior
fillet and exterior radius lead to more uniform
thickness and more uniform cooling.
23
Expendable Molding Process
  • Process for class discussion
  • Sand
  • Investment
  • Lost-Foam

24
Sand Casting Steps
  • Drag portion of pattern is placed in flask
  • Types of patterns
  • One piece, split, match plate, and loose piece
  • Materials
  • Wood
  • Metal
  • Plastics
  • 3D printing
  • Stereolithography (SLA)

25
Sand Casting Steps
Figure 12-2 (Above) Single-piece pattern for a
pinion gear.
Figure 12-4 Split pattern, showing the two
sections together and separated. The
light-colored portions are core prints.
26
Sand Casting Steps
Figure 12-5 Match-plate pattern used to produce
two identical parts in a single flask. (Left)
Cope side (right) drag side. (Note The views
are opposite sides of a single-pattern board.
Figure 12-6 Cope-and-drag pattern for producing
two heavy parts. (Left) Cope section (right)
drag section. (Note These are two separate
pattern boards.)
27
Sand Casting Steps
  • Drag is packed with sand
  • Sand characteristics
  • Refractoriness- Ability to withstand high
    temperatures
  • Cohesiveness- Ability to retain given shape
  • Permeability- Ability to allow gasses to escape
  • Collapsibility-Ability to allow metal to shrink
    and free the casting

28
Sand Casting Steps
  • Mold turned over
  • Insert sprue and riser
  • Pack with sand
  • Flask is separated - pattern removed
  • Gates and runners cut into mold
  • Similar process steps performed on cope
  • Cope drag reassembled
  • Possibly a core is added

29
Sand Casting Steps
  • Molten metal poured into mold
  • Casting solidifies
  • Mold opened..distorted
  • Part removed
  • Post Processing

30
Sand Casting Steps
1
2
3
5
6
4
http//www.foundryonline.com/
31
Sand Casting Steps
Figure 12-1 Sequential steps in making a sand
casting. a) A pattern board is placed between the
bottom (drag) and top (cope) halves of a flask,
with the bottom side up. b) Sand is then packed
into the bottom or drag half of the mold. c) A
bottom board is positioned on top of the packed
sand, and the mold is turned over, showing the
top (cope) half of pattern with sprue and riser
pins in place. d) The upper or cope half of the
mold is then packed with sand.
32
Mold Processing Methods
  • Hand ramming - low production
  • Jolt and squeeze machines - medium to high
    production
  • Vertical parted flaskless molding machines - high
    production
  • Pit molding - large parts example 36 water
    valves Ross Mfg. Valve Co.

33
Sand Casting Advantages Disadvantages
  • Disadvantages
  • Part tolerances /- .01 - .032
  • Poor surface finish
  • Limited design freedom
  • In hand ramming, process can be labor intensive
  • Single use of mold

34
Sand Casting Advantages Disadvantages
  • Advantages
  • General tooling costs are low
  • Sand in most cases can be reused in some form
  • Can handle a wide variety of metals
  • Relatively easy process to obtain net shape or
    near-net shape

35
Investment Casting
  • Process steps
  • Produce master pattern of desired casting
  • Produce master die
  • Produce wax patterns
  • Assemble wax patterns on a common sprue sometimes
    called a tree
  • Coat tree with an initial investment material
  • Vibrate to remove air and settle material around
    patterns

36
Investment Casting
  • Process steps continued
  • Finish coat
  • Allow investment to harden
  • Fire investment to finish hardening process and
    melt our wax patterns
  • Preheat mold
  • Pour molten metal into mold cavity
  • Allow metal to solidify
  • Remove castings
  • Post processing

37
http//www.flinthills.com/ramsdale/EngZone/castin
g.htm
38
Advantages Disadvantages
  • Advantages
  • Wide variety of metals can be cast including high
    temperature alloys
  • Excellent surface finish
  • Good dimensional accuracy (/- .003 up to ΒΌ)
  • Tooling cost average
  • Complex shapes are possible

39
Advantages Disadvantages
  • Disadvantages
  • Price per unit costs can be high
  • One mold per batch
Write a Comment
User Comments (0)
About PowerShow.com
