Partial Method Compilation using Dynamic Profile Information

1
Partial Method Compilationusing Dynamic Profile
Information
John Whaley Stanford University October 17, 2001
2
Outline

• Background and Overview
• Dynamic Compilation System
• Partial Method Compilation Technique
• Optimizations
• Experimental Results
• Related Work
• Conclusion

3
Dynamic Compilation

• We want code performance comparable to static
  compilation techniques
• However, we want to avoid long startup delays and
  slow responsiveness
• Dynamic compiler should be fast AND good

4
Traditional approach

• Interpreter plus optimizing compiler
• Switch from interpreter to optimizing compiler
  via some heuristic
• Problems
• Interpreter is too slow! (10x to 100x)

5
Another approach

• Simple compiler plus optimizing compiler
  (Jalapeno, JUDO, Microsoft)
• Switch from simple to optimizing compiler via
  some heuristic
• Problems
• Code from simple compiler is still too slow!
  (30 to 100 slower than optimizing)
• Memory footprint problems (Suganuma et al.,
  OOPSLA01)

6
Yet another approach

• Multi-level compilation (Jalapeno, HotSpot)
• Use multiple compiled versions to slowly
  accelerate into optimized execution
• Problems
• This simply increases the delay before the
  program runs at full speed!

7
Problem with compilation

• Compilation takes time proportional to the amount
  of code being compiled
• Many optimizations are superlinear in the size of
  the code
• Compilation of large amounts of code is the cause
  of undesirably long compilation times

8
Methods can be large

• All of these techniques operate at method
  boundaries
• Methods can be large, especially after inlining
• Cutting inlining too much hurts performance
  considerably (Arnold et al., Dynamo00)
• Even when being frugal about inlining, methods
  can still become very large

9
Methods are poor boundaries

• Method boundaries do not correspond very well to
  the code that would most benefit from
  optimization
• Even hot methods typically contain some code
  that is rarely or never executed

10
Example SpecJVM db

• void read_db(String fn)
• int n 0, act 0 byte buffer null
• try
• FileInputStream sif new FileInputStream(fn)

• buffer new byten
• while ((b sif.read(buffer, act, n-act))gt0)

• act act b
• sif.close()
• if (act ! n)
• / lots of error handling code, rare /
• catch (IOException ioe)
• / lots of error handling code, rare /

Hot loop
11
Example SpecJVM db

• void read_db(String fn)
• int n 0, act 0 byte buffer null
• try
• FileInputStream sif new FileInputStream(fn)

• buffer new byten
• while ((b sif.read(buffer, act, n-act))gt0)

• act act b
• sif.close()
• if (act ! n)
• / lots of error handling code, rare /
• catch (IOException ioe)
• / lots of error handling code, rare /

Lots of rare code!
12
Hot regions, not methods

• The regions that are important to compile have
  nothing to do with the method boundaries
• Using a method granularity causes the compiler to
  waste time optimizing large pieces of code that
  do not matter

13
Overview of our technique

• Increase the precision of selective
• compilation to operate at a sub-method
• granularity
• Collect basic block level profile data for hot
  methods
• Recompile using the profile data, replacing rare
  code entry points with branches into the
  interpreter

14
Overview of our technique

• Takes advantage of the well-known fact that a
  large amount of code is rarely or never executed
• Simple to understand and implement, yet highly
  effective
• Beneficial secondary effect of improving
  optimization opportunities on the common paths

15
Overview of Dynamic Compilation System
16
interpreted code
Stage 1
when execution count t1
compiled code
Stage 2
when execution count t2
fully optimized code
Stage 3
17
Identifying rare code

• Simple technique any basic block executed during
  Stage 2 is said to be hot
• Effectively ignores initialization
• Add instrumentation to the targets of conditional
  forward branches
• Better techniques exist, but using this we saw no
  performance degradation
• Enable/disable profiling is implicitly handled by
  stage transitions

18
Method-at-a-time strategy
of basic blocks
execution threshold
19
Actual basic blocks executed
of basic blocks
execution threshold
20
Partial method compilation technique
21
Technique

• Based on profile data, determine the set of rare
  blocks.
• Use code coverage information from the first
  compiled version

22
Technique

• Perform live variable analysis.
• Determine the set of live variables at rare block
  entry points

live x,y,z
23
Technique

• Redirect the control flow edges that targeted
  rare blocks, and remove the rare blocks.

to interpreter
24
Technique

• Perform compilation normally.
• Analyses treat the interpreter transfer point as
  an unanalyzable method call.

25
Technique

• Record a map for each interpreter transfer point.
• In code generation, generate a map that specifies
  the location, in registers or memory, of each of
  the live variables.
• Maps are typically lt 100 bytes

live x,y,z
x sp - 4
y R1
z sp - 8
26
Optimizations
27
Partial dead code elimination

• Modified dead code elimination to treat rare
  blocks specially
• Move computation that is only live on a rare path
  into the rare block, saving computation in the
  common case

28
Partial dead code elimination

• Optimistic approach on SSA form
• Mark all instructions that compute essential
  values, recursively
• Eliminate all non-essential instructions

29
Partial dead code elimination

• Calculate necessary code, ignoring all rare
  blocks
• For each rare block, calculate the instructions
  that are necessary for that rare block, but not
  necessary in non-rare blocks
• If these instructions are recomputable at the
  point of the rare block, they can be safely
  copied there

30
Partial dead code example

• x 0
• if (rare branch 1)
• ...
• z x y
• ...
• if (rare branch 2)
• ...
• a x z
• ...

31
Partial dead code example

• if (rare branch 1)
• x 0
• ...
• z x y
• ...
• if (rare branch 2)
• x 0
• ...
• a x z
• ...

32
Pointer and escape analysis

• Treating an entrance to the rare path as a method
  call is a conservative assumption
• Typically does not matter because there are no
  merges back into the common path
• However, this conservativeness hurts pointer and
  escape analysis because a single unanalyzed call
  kills all information

33
Pointer and escape analysis

• Stack allocate objects that dont escape in the
  common blocks
• Eliminate synchronization on objects that dont
  escape the common blocks
• If a branch to a rare block is taken
• Copy stack-allocated objects to the heap and
  update pointers
• Reapply eliminated synchronizations

34
Copying from stack to heap
Heap
copy
stack object
stack object
rewrite
35
Reconstructing interpreter state

• We use a runtime glue routine
• Construct a set of interpreter stack frames,
  initialized with their corresponding method and
  bytecode pointers
• Iterate through each location pair in the map,
  and copy the value at the location to its
  corresponding position in the interpreter stack
  frame
• Branch into the interpreter, and continue
  execution

36
Experimental Results
37
Experimental Methodology

• Fully implemented in a proprietary system
• Unfortunately, cannot publish those numbers!
• Proof-of-concept implementation in thejoeq
  virtual machine http//joeq.sourceforge.net
• Unfortunately, joeq does not perform significant
  optimizations!

38
Experimental Methodology

• Also implemented as an offline step, using
  refactored class files
• Use offline profile information to split methods
  into hot and cold parts
• We then rely on the virtual machines default
  method-at-a-time strategy
• Provides a reasonable approximation of the
  effectiveness of this technique
• Can also be used as a standalone optimizer
• Available under LGPL as part of joeq release

39
Experimental Methodology

• IBM JDK 1.3 cx130-20010626 on RedHat Linux 7.1
• Pentium 3 600 mhz, 512 MB RAM
• Thresholds t1 2000, t2 25000
• Benchmarks SpecJVM, SwingSet, Linpack, JavaLex,
  JavaCup

40
Run time improvement
First bar original Second bar PMC Third bar
PMC my opts
Blue optimized execution
41
Related Work

• Dynamic techniques
• Dynamo (Bala et al., PLDI00)
• Self (Chambers et al., OOPSLA91)
• HotSpot (JVM01)
• IBM JDK (Ishizaki et al., OOPSLA00)

42
Related Work

• Static techniques
• Trace scheduling (Fisher, 1981)
• Superblock scheduling (IMPACT compiler)
• Partial redundancy elimination with cost-benefit
  analysis (Horspool, 1997)
• Optimal compilation unit shapes (Bruening,
  FDDO00)
• Profile-guided code placement strategies

43
Conclusion

• Partial method compilation technique is simple to
  implement, yet very effective
• Compile times reduced drastically
• Overall run times improved by an average of 10,
  and up to 32
• System is available under LGPL at
  http//joeq.sourceforge.net
