1Overview of BOCC Approach
International Comparison of Cost for
Construction Sector, Walsh and Sawhney (2004)
2BOCC Approach
3Concrete Footing Component
4Concrete Slab Component
5Roadway Component
6BOCC Hierarchy
7Components of Systems for Residential
System Name System Explanation
Site-work Construction components related to site preparation of a residential construction project
Substructure Structural components and related work items below the ground surface that are part of a residential construction project. These components are load-bearing and transfer all the loads from the superstructure to the ground below
Superstructure Structural components and related work items above the ground surface that are part of a residential construction project. These components are load-bearing and provide resistance to live and dead load on the building
Exterior Shell/ Building Envelope Construction components that form the exterior shell of a residential construction project. They are non-load-bearing members that rest upon the superstructure of the building
Interior Partitions All interior walls and opening in the building
Interior and Exterior Finishes All construction components in place for the purpose of satisfying a cosmetic function, including for example paint or plaster.
Mechanical and Plumbing All construction components related to providing climate control or water services such as heating and cooling systems, hot and cold water systems, fire fighting systems etc.
Electrical All construction components related to distribution of alternating current and direct current including electrical fixtures for a residential construction project
8Components of Systems for Non-residential
System Name System Explanation
Site-work Construction components related to site preparation of a non-residential construction project
Substructure Structural components and related work items below the ground surface that are part of a non-residential construction project. These components are lo-bearing and transfer all the loads from the superstructure to the ground below
Superstructure Structural components and related work items above the ground surface that are part of a non-residential construction project. These components are load-bearing and provide resistance of all types of live and dead load on the building
Exterior Shell/ Building Envelope Construction components that form the exterior shell of a residential construction project. They are non-load-bearing members that rest upon the superstructure of the building
Interior Partitions All interior walls and opening in the building
Interior and Exterior Finishes All construction components in place for the purpose of satisfying a cosmetic function, including for example paint or plaster
Mechanical and Plumbing All construction components related to providing climate control or water services such as heating and cooling systems, hot and cold water systems, fire fighting systems etc.
Electrical All construction components related to distribution of alternating current and direct current including electrical fixtures for a non-residential construction project
9Components of Systems for Civil Works
System Name System Explanation
Site-work Construction components related to site preparation of a civil engineering project including earthwork, earthmoving, and surface treatments such sidewalks and pavements
Substructure Structural components and related work items below the ground surface that are part of a civil engineering project. These components are load-bearing and transfer all the loads from the superstructure to the ground below
Superstructure Structural components and related work items above the ground surface that are part of a civil engineering project. These components are load-bearing and provide resistance to live and dead loads
Mechanical Equipment Equipment installed on civil engineering projects such as pumps, turbines, boilers, air handling equipment, cooling towers, vessels etc including all connecting pipes and valves. Mechanical includes utility systems (steam, compressed air, and refrigeration), process systems (rotating pumps, compressors, agitators, filters, etc.) special vessel design (tanks, pressure vessels), etc.
Electrical Equipment Equipment installed on civil engineering projects for power distribution systems, substations, power distribution panels, motor control centers, lighting, communications, etc.
Underground Utility Any underground line, system or facility used for producing, storing, conveying, transmitting, or distributing communication or telecommunication, electricity, gas, petroleum and petroleum products, coal slurry, hazardous liquids, water under pressure, steam, or sanitary sewage. These include wires, ducts, fiber optic cable, conduits, pipes, sewers, and cables and their connected appurtenances installed beneath the surface of the ground
10Construction Components
Construction Component Residential Basket Non-Residential Basket Civil Engineering Works Basket
Aggregate ? ? ?
Aggregate Base ? ? ?
Column Footing ? ?
Culvert ?
Drilled Shaft ? ?
Earthwork ? ? ?
Electrical Service Point ? ?
Exterior Paint ? ?
Exterior Wall Cement Plaster ? ?
Interior Ceiling Plaster ? ?
11Construction Components
Construction Component Residential Basket Non-Residential Basket Civil Engineering Works Basket
Interior Painting ? ?
Interior Wall Plaster ? ?
Portland Cement ? ? ?
Reinforcing Steel ? ? ?
Roadway Lane ?
Round Bridge Pier ?
Sand ? ? ?
Sand Filter ?
Structural Column Round ? ?
Structural Column Square ? ?
12Construction Components
Construction Component Residential Basket Non-Residential Basket Civil Engineering Works Basket
Round Bridge Pier ?
Aluminum Frame Window ? ?
Bridge T Beam ?
Bridge Spread Footing ?
Concrete Airfield Pavement ?
Exterior Sidewalk ? ?
Masonry Interior Wall ? ?
Concrete ? ? ?
Structural Steel ? ? ?
Unskilled Labor ? ? ?
13Construction Components
Construction Component Residential Basket Non-Residential Basket Civil Engineering Works Basket
Skilled Labor ? ? ?
Backhoe ? ? ?
Vibratory Plate Compactor ? ?
Centrifugal Pump ?
Plywood ? ? ?
14Advantages of BOCC Approach
- The BOCC provides a much simpler and better
defined price comparison tool. - It drastically reduces the resource and expertise
requirements in the price collection process. - It underlines the importance of the various
components comprising different sets of labor and
materials as well as equipment use. It thus
captures productivity differentials by accounting
for labor and equipment trade-off. - Allows reasonable flexibility to compare
different construction projects by identifying
core components that are common across countries. - Many countries have shown interest and asked for
technical support to adapted the BOCC approach
for use as a national inter-temporal price
comparison tool to build their capacity.
15Labor Equipment Trade-off
16Price Collection Process
17Overview of Price Collection
- BOCC uses the SPD/PS methodology for price
collection - Identified components are representative and
comparable - Components are converted into SPDs for price
collection purposes - Country resources such as public works department
and published schedule of rates can be used for
pricing
18Price Comparison Under BOCC
- In the BOCC method 34 Components are identified.
They include - Two types of labor skilled and unskilled.
- Four types of equipment for hire a back-hoe, a
centrifugal pump, a vibratory plate compactor and
a sand filter. - Five kinds of building material Portland
cement, sand, plywood, reinforcing steel, and
aggregate. Aggregate is gravel which,
together with cement, water and sand, is used too
make concrete. - Complete components including a mix of labor,
equipment and material. - Prices for the 34 components are used to obtain
PPPs for Systems. - PPPs for systems together with expenditure
weights are then used to obtain PPPs for
residential buildings, non-residential buildings,
and civil engineering works.
19Who collects the data?
- Building engineers, architects, quantity
surveyors or other experts have to be involved - Most statistical agencies do not have the
necessary expertise - Some countries may be able get the help of
specialists from public works departments - Other government agencies responsible for
building regulations may also be useful - In other countries the work has to be contracted
out to construction firms or freelance engineers
20When and where data are collected
- In principle the prices should be national annual
average. - This means data collection should be across
regions and should cover all year (quarterly),
but this would be excessively costly. - In practice some simplifications are necessary
for construction sector. - Prices should only be collected in 2 or 3 three
cities that would give a close approximation to
national average. - In smaller countries this may not be a major
issue. In large countries the scope of coverage
should be extended to cover major cities and
regions. - Price collection in mid-year is recommended.
21How many observations?
- For building materials and for equipment multiple
pricing is recommended - Ideally, prices should be collected from at least
four or five outlets again with the objective of
providing an approximation of national average - Again this may not be a major issue I relatively
small countries with low price variations. In
large countries the scope of coverage should be
extended to cover major cities and regions - For skilled and unskilled labor the number of
observations required depends on the data sources
used
22What is in the cost estimate?
- For the completed components the price is the
total of the cost, at purchaser prices of the
materials, labor and equipment. - The price reported for completed components does
not include any profit margin or any fees for
architects, quantity surveyors and other
construction specialists - The purchaser prices of the materials and hire of
equipment includes only non-deductible product
taxes. - Value added taxes are often fully deductible for
goods and services that are considered to be
investments and so will usually be excluded from
the purchaser price.
23Expenditure Weights
24 Expenditure Weights in BOCC
25 Sample System Weight W2
Cost Breakdown for Construction in Canada for
Year 2000
Systems Multi Level parking Garage Light Industrial Warehouse Commercial Office Building Elementary School High rise office complex
Substructure 9.1 8.7 6.4 2.1 1.8 3.7
Structure 58.3 21.2 18.9 16.2 11.5 20.1
Exterior Closure 7.0 19.3 36.4 14.2 16.4 16.0
Partitions and Doors 0.7 0.9 7.0 5.0 7.4 4.7
Finishes 4.0 7.8 0.6 8.4 10.3 9.3
Fitting and Equipment 2.8 5.6 0.0 5.3 8.8 9.6
Mechanical 6.2 17.7 20.9 26.5 25.6 19.9
Electrical 4.9 12.3 2.4 14.9 10.7 9.3
General Requirements and Fees 7.0 6.5 7.4 7.4 7.4 7.4
Total 100 100 100 100 100 100
