Title: Normalization of Database Tables


1
Lesson 5
  • Normalization of Database Tables

2
In this lesson, you will learn
  • What normalization is and what role it plays in
    the database design process
  • About the normal forms 1NF, 2NF, 3NF
  • Transforming from lower normal forms to higher
    normal forms
  • What and when to perform Denormlization

3
Database Tables and Normalization
  • Normalization
  • Process for evaluating and correcting table
    structures to minimize data redundancies
  • helps eliminate data anomalies
  • Works through a series of stages called normal
    forms
  • Normal form (1NF)
  • Second normal form (2NF)
  • Third normal form (3NF)

4
Database Tables and Normalization (continued)
  • 2NF is better than 1NF 3NF is better than 2NF
  • For most business database design purposes, 3NF
    is highest we need to go in the normalization
    process
  • Highest level of normalization is not always most
    desirable (sometime lower level needed, more
    redundancy, less join faster performance)

5
The Need for Normalization
  • Example company that manages building projects
  • Charges its clients by billing hours spent on
    each contract
  • Hourly billing rate is dependent on employees
    position
  • Periodically, a report is generated that contains
    information displayed in Table 5.1

6
A Sample Report Layout
7
A Table in the Report Format
8
The Need for Normalization (continued)
  • Structure of data set in Figure 5.1 does not
    handle data very well
  • The table structure appears to work report is
    generated with ease
  • Unfortunately, the report may yield different
    results, depending on what data anomaly has
    occurred

9
Data Anomalies
  • Update
  • modifying an attribute/value of an entity,
    require many alterations (where that entity
    exist)
  • eg)) changing EMP_NAME of an employee, changing
    JOB_CLASS of employee EMP_NUM 15
  • Insertion
  • adding a new record, all attributes must be added
    or dummy value assigned
  • eg)) new employee added, not yet assigned to any
    project, need to assigned to dummy project record
  • Deletion
  • losing of vital data due to deletion of an entity
  • eg)) if emp_num 103 quits, deleting from employee
    record, need to assign new employee to project
    that emp 103 work on (otherwise lost of data,
    causes effects to the charge)

10
Conversion to First Normal Form
  • Relational table must not contain repeating
    groups
  • Repeating group
  • when a group of multiple (related) entries can
    exist for any single key attribute occurrence(a
    field of a record referring to more than one
    occurrence in a record)
  • 3 steps procedure
  • Step 1 Eliminate the Repeating Groups
  • Step 2 Identify Primary key
  • Step 3 Identify all Dependencies

11
Step 1 Eliminate the Repeating Groups
  • Present data in a tabular format, where each cell
    has a single value and there are no repeating
    groups
  • Eliminate repeating groups by eliminating nulls,
    making sure that each repeating group attribute
    contains an appropriate data value

12
Data Organization First Normal Form
To normalized diagram
To 1NF summary
To Dependency
To 3NF
13
Step 2 Identify Primary key
  • Primary key/Prime attribute? attribute that
    uniquely identify a record
  • Old key of PROJ_NUM not unique
  • New key must be composed
  • What should be the key?

PROJ_NUM EMP_NUM
14
Step 3 Identify all Dependencies
  • Dependency diagram
  • Depicts all dependencies found within a given
    table structure
  • Providing birds-eye view of all relationships
    among a tables attributes
  • Partial Dependency
  • when an attribute depend on only part of the
    primary key
  • exist only for table with composite key
  • eg)) PROJ_NAME depend only on PROJ_NUM
  • Transitive Dependency
  • dependency of nonprime attribute on another
    nonprime attribute
  • eg)) CHG_HOUR depend on JOB_CLASS

Back to PROJECT table
15
A Dependency Diagram First Normal Form (1NF)
16
A Dependency Diagram First Normal Form (1NF)
17
1NF
  • Tabular format in which
  • All key attributes are defined
  • There are no repeating groups in the table
  • All attributes are dependent on primary key
  • All relational tables satisfy 1NF requirements

Back to PROJECT table
18
Conversion to Second Normal Form
  • Table is in second normal form (2NF) if
  • It is in 1NF and
  • It includes no partial dependencies
  • No attribute is dependent on only a portion of
    the primary key
  • NOTE a table with only one attribute as primary
    key is already in 2NF

19
Conversion to Second Normal Form
  • 2 steps
  • Step 1 Identify All Key Components and Separate
    into different tables
  • Step 2 Identify the Dependent Attributes and
    remove partial dependency

20
Step 1 Identify All Key Components
  • Write each key component on separate line, and
    then write the original (composite) key on the
    last line
  • Each component will become the key in a new table
  • PROJ_NUM
  • EMP_NUM
  • PROJ_NUM, EMP_NUM

Back to Dependency Diagram
21
Step 2 Identify the Dependent Attributes
  • Remove partial dependency
  • PROJECT (PROJ_NUM, PROJ_NAME)
  • EMPLOYEE (EMP_NUM, EMP_NAME, JOB_CLASS, CHG_HOUR)
  • ASSIGNMENT (PROJ_NUM, EMP_NUM, ASSIGN_HOUR)

To 3 NF
22
Second Normal Form (2NF) Conversion Results
23
Conversion to Third Normal Form
  • A table is in third normal form (3NF) if
  • It is in 2NF and
  • It contains no transitive dependencies
  • Transitive Dependency
  • dependency of nonprime attribute on another
    nonprime attribute

24
Conversion to Third Normal Form
  • 3 Steps
  • Step 1 Identify Each New Determinant (transitive
    dependency)
  • Step 2 Identify the Dependent Attributes
  • Step 3 Remove the Dependent Attributes from
    Transitive Dependencies

25
Step 1 Identify Each New Determinant
  • For every transitive dependency, write its
    determinant as a PK for a new table
  • Determinant
  • Any attribute whose value determines other values
    within a row
  • Eg)) CHG_HOUR depends on JOB_CLASS
  • JOB_CLASS ? CHG_HOUR
  • JOB_CLASS

26
Step 2 Identify the Dependent Attributes
  • List the attributes dependent on each determinant
    identified in Step 1 and identify the dependency
  • Name the table to reflect its contents and
    function
  • JOB(JOB_CLASS,CHG_HOUR)

Back to PROJECT table
27
Step 3 Remove the Dependent Attributes from
Transitive Dependencies
  • Eliminate all dependent attributes in transitive
    relationship(s) from each table
  • Draw a new dependency diagram to show all tables
    defined in Steps 13
  • JOB (JOB_CLASS, CHG_HOUR)
  • PROJECT (PROJ_NUM, PROJ_NAME)
  • EMPLOYEE (EMP_NUM, EMP_NAME, JOB_CLASS)
  • ASSIGNMENT (PROJ_NUM, EMP_NUM, ASSIGN_HOUR)

Back to 2 NF
28
Third Normal Form (3NF) Conversion Results
EMPLOYEE table
Back to PROJECT table (Compare attribute name)
ASSIGN table
29
Improving the Design (continued)
  • the following changes were made
  • PK assignment (Add a new attribute, JOB_CODE as
    PK)
  • Naming conventions (change attribute name to
    match with table)
  • Adding attributes PROJECT (PROJ_NUM,PROJ_NAME,EMP_
    NUM) as project leader
  • Adding relationships (new relationship affected
    by adding EMP_NUM to PROJECT table)
  • Attribute atomicity (split necessary composite
    attribute, EMP_NAME ? EMP_FNAME, EMP_LNAME)

PROJECT JOB EMPLOYEE ASSIGNMENT
30
Improving the Design (continued)
  • the following changes were made
  • Refining PKs (Add a new attribute, ASSIGN_NUM as
    PK)
  • Maintaining historical accuracy (add a new
    attribute, ASSIGN_CHG_HOUR, if change of CHG_HOUR
    historical record not affected)
  • Using derived attributes (add a new attribute,
    TOTAL_ASSIGN) in ASSIGN table, even though a
    derived attribute should not be stored but this
    will help in faster report generation time)

PROJECT JOB EMPLOYEE ASSIGNMENT
31
The Completed Database
Improvements
32
Back normalized diagram
Improvements
33
Improvements
Back normalized diagram
New PK
34
Limitations on System-Assigned Keys
  • System-assigned primary key may not prevent
    confusing entries
  • Data entries in Table 5.2 are inappropriate
    because they duplicate existing records
  • Yet there has been no violation of either entity
    integrity or referential integrity
  • Solved by making Index Key

35
Duplicate Entries in the JOB Table
36
Normalization and Database Design
  • Normalization should be part of design process
  • Make sure that proposed entities meet required
    normal form before table structures are created
  • Database design process (like a loop) redesign
    and modification occur

37
Normalization and Database Design (continued)
  • ER diagram
  • Provides the big picture, or macro view, of an
    organizations data requirements and operations
  • Created through an iterative process
  • Identifying relevant entities, their attributes
    and their relationship
  • Use results to identify additional entities and
    attributes

38
Normalization and Database Design
  • Normalization procedures
  • Focus on the characteristics of specific entities
  • A micro view of the entities within the ER
    diagram
  • Difficult to separate normalization process from
    ER modeling process
  • Two techniques should be used concurrently

39
Overall Review for Contract Company
  • company manage many projects
  • each project requires many employees
  • each employee may be assigned to many projects
  • some employees are not assigned to a project
  • each employee has only one major job
    classification, which determine the hourly
    billing rate
  • many employee can have the same job
    classification

What are entities?
PROJECT, EMPLOYEE, JOB
40
Overall Review for Contract Company
PROJECT requires MN EMPLOYEE PROJECT
requires 1M ASSIGNMENT EMPLOYEE enters 1M AS
SIGNMENT JOB assigns 1M EMPLOYEE
PROJECT(PROJ_NUM, PROJ_NAME) EMPLOYEE(EMP_NUM,
EMP_LNAME, EMP_FNAME, EMP_INITIAL,
JOB_DESCRIPTION, JOB_CHG_HOUR)
41
The Initial ERD for a Contracting Company
1NF? 2NF? (any partial) 3NF? (any transitive)
42
The Modified ERD for a Contracting Company
43
The Incorrect Representation of a MN
Relationship
44
The Correct Representation of a MN Relationship
45
The Final (Implementable) ERD for a Contracting
Company
Is ASSIGNMENT a weak entity?
NO. ASSIGNMENT is not weak entity because it does
not inherit PK from EMPLOYEE and PROJECT to be
used as its PK but only used as FK
46
Denormalization
  • normalization ? decomposed to many tables
  • many join between tables
  • many disk I/O operations and processing, reduce
    speed
  • therefore some may need denormalization to
    increase processing speed
  • speed must be balanced against data anomalies
    EG)) customer address (ZIP_CODE,CITY)
