Module Networks

1
Module Networks

• Discovering Regulatory Modules and their
  Condition Specific Regulators from Gene
  Expression Data

Cohen Jony
2
Outline

• The Problem
• Regulators
• Module Networks
• Learning Module Networks
• Results
• Conclusion

3
The Problem

• Inferring regulatory networks from gene
  expression data.

From
4
Regulators
5
Regulation types
6
Regulators example
This is an example for a regulating module.
7
Known solution Bayesian Networks
The problem Too many variables and too little
data cause statistical noise to lead to spurious
dependencies, resulting in models that
significantly over fit the data.
8
From Bayesian To Module
9
Module Networks

• We assume that we are given a domain of random
  variables X X1 Xn.
• We use Val(Xi) to denote the domain of values of
  the variable Xi.
• A module set C is a set of such formal
• variables M1 MK. As all the variables in
  a module share the same CPD.
• Note that all the variables must have the same
  domain of values!

10
Module Networks

• A module network template T (S ?) for C
  defines, for each module Mj in C
• 1) a set of parents PaMj from X
• 2) a conditional probability template (CPT) P( Mj
  PaMj ) which specifies a distribution over Val
  (Mj ) for each assignment in Val (PaMj ).
• We use S to denote the dependency structure
  encoded by PaMj Mj in C and ? to denote the
  parameters required for the CPTs P( Mj PaMj )
  Mj in C.

11
Module Networks

• A module assignment function for C is a function
  A X ? 1 K such
  that A(Xi) j only if Val (Xi) Val (Mj ).
• A module network is defined by both the module
  network template and the assignment function.

12
Example

• In our example, we have three modules M1, M2, and
  M3.
• PaM1 Ø , PaM2 MSFT, and PaM3 AMAT
  INTL.
• In our example, we have that A(MSFT) 1, A(MOT)
  2, A(INTL) 2, and so on.

13
Learning Module Networks

• The iterative learning procedure attempts to
  search for the model with the highest score by
  using the expectation Maximization (EM)
  algorithm.
• An important property of the EM algorithm is that
  each iteration is guaranteed to improve the
  likelihood of the model, until convergence to a
  local maximum of the score.
• Each iteration of the algorithm consists of two
  steps

M-step
E-step
14
Learning Module Networks cont.
M-step

• In the , the procedure is given
  a partition of the genes into modules and learns
  the best regulation program (regression tree) for
  each module.
• The regulation program is learned via a
  combinatorial search over the space of trees.
• The tree is grown from the root to its leaves. At
  any given node, the query which best partitions
  the gene expression into two distinct
  distributions is chosen, until no such split
  exists.

15
Learning Module Networks cont.
E-step

• In the , given the inferred
  regulation programs, we determine the module
  whose associated regulation program best predicts
  each genes behavior.
• We test the probability of a genes measured
  expression values in the dataset under each
  regulatory program, obtaining an overall
  probability that this genes expression profile
  was generated by this regulation program.
• We then select the module whose program gives the
  genes expression profile the highest
  probability, and re-assign the gene to this
  module.
• We take care not to assign a regulator gene to a
  module in which it is also a regulatory input.

16
Bayesian score

• When the priors satisfy the assumptions above,
  the Bayesian score decomposes into local module
  scores

• Where

17
Bayesian score cont.

• Where Lj(U,X, ?MjD) is the Likelihood function .
• Where P(?Mj Sj u) is the Priors.

• Where Sj U denotes that we chose a structure
  where U are the parents of module Mj.
• Where Aj X denotes that A is such that Xj X.

18
Assumptions

• Let P(A), P(S A), P(? S,A) be assignment,
  structure, and parameter priors.
• P(? S,A) satisfies parameter independence if
• P(? S,A) satisfies parameter modularity if
• for all structures S1 and S2 such that

19
Assumptions

• P(?, S A) satisfies assignment independence if
• P(? S, A) P(? S) and P(S A) P(S).
• P(S) satisfies structure modularity if
• where Sj denotes the choice of parents for
  module Mj , and ?j is a distribution over the
  possible parent sets for module Mj.
• P(A) satisfies assignment modularity if
• where Aj is the choice of variables assigned to
  module Mj, and aj j 1 K is a family
  of functions from 2X to the positive reals.

20
Assumptions - Explainations

• Parameter independence, parameter modularity, and
  structure modularity are the natural analogues of
  standard assumptions in Bayesian network
  learning.
• Parameter independence implies that P(? S, A)
  is a product of terms that parallels the
  decomposition of the likelihood, with one prior
  term per local likelihood term Lj.
• Parameter modularity states that the prior for
  the parameters of a module Mj depends only on the
  choice of parents for Mj and not on other aspects
  of the structure.
• Structure modularity implies that the prior over
  the structure S is a product of terms, one per
  each module.

21
Assumptions - Explainations

• These two assumptions are new to module networks.

• Assignment independence makes the priors on the
  parents and parameters of a module independent of
  the exact set of variables assigned to the
  module.
• Assignment modularity implies that the prior on
  A is proportional to a product of local terms,
  one corresponding to each module.
• Thus, the reassignment of one variable from one
  module Mi to another Mj does not change our
  preferences on the assignment of variables in
  modules other than i j.

22
Experiments

• The network learning procedure was evaluated on
  synthetic data, gene expression data, and stock
  market data.
• The data consisted solely of continuous values.
  As all of the variables have the same domain, the
  definition of the module set reduces simply to a
  specification of the total number of modules.
• Beam search was used as the search algorithm,
  using a look ahead of three splits to evaluate
  each operator.
• As a comparison, Bayesian networks were used with
  precisely the same structure learning algorithm,
  simply treating each variable as its own module.

23
Synthetic data

• The synthetic data was generated by a known
  module network.
• The generating model had 10 modules and a total
  of 35 variables that were a parent of some
  module. From the learned module network, 500
  variables where selected, including the 35
  parents.
• This procedure was run for training sets of
  various sizes ranging from 25 instances to 500
  instances, each repeated 10 times for different
  training sets.

24
Synthetic data - results

• Generalization to unseen test data, measuring the
  likelihood ascribed by the learned model to4500
  unseen instances.
• As expected, models learned with larger training
  sets do better but, when run using the correct
  number of 10 modules, the gain of increasing the
  number of data instances beyond 100 samples is
  small.
• Models learned with a larger number of modules
  had a wider spread for the assignments of
  variables to modules and consequently achieved
  poor performance.

25
Synthetic data results cont.

• Log-likelihood per instance assigned to held-out
  data.

• For all training set sizes, except 25, the model
  with 10 modules performs the best.

26
Synthetic data results cont.

• Fraction of variables assigned to the largest 10
  modules.

• Models learned using 100, 200, or 500 instances
  and up to 50 modules assigned 80 of the
  variables to 10 modules.

27
Synthetic data results cont.

• Average percentage of correct parent-child
  relationships recovered.

• The total number of parent-child relationships in
  the generating model was 2250.
• The procedure recovers 74 of the true
  relationships when learning from a dataset of
  size 500 instances.

28
Synthetic data results cont.

• As the variables begin fragmenting over a large
  number of modules, the learned structure contains
  many spurious relationships.
• Thus in domains with a modular structure,
  statistical noise is likely to prevent overly
  detailed learned models such as Bayesian networks
  from extracting the commonality between different
  variables with a shared behavior.

29
Gene Expression Data

• Expression data which measured the response of
  yeast to different stress conditions was used.
• The data consists of 6157 genes and 173
  experiments.
• 2355 genes that varied significantly in the data
  were selected and learned a module network over
  these genes.
• A Bayesian network was also learned over this
  data set.

30
Candidate regulators

• A set of 466 candidate regulators was compiled
  from SGD and YPD.
• Both transcriptional factors and signaling
  proteins that may have transcriptional impact.
• Also included genes described to be similar to
  such regulators.
• Excluded global regulators, whose regulation is
  not specific to a small set of genes or process.

31
Gene Expression reasults

• The figure demonstrates that module networks
  generalize much better then Bayesian network to
  unseen data for almost all choices of number of
  modules.

32
Biological validity

• Biological validity of the learned module network
  with 50 modules was tested.
• The enriched annotations reflect the key
  biological processes expected in our dataset.
• For example, the protein folding module
  contains 10 genes, 7 of which are annotated as
  protein folding genes. In the whole data set,
  there are only 26 genes with this annotation.
  Thus, the p-value of this annotation, that is,
  the probability of choosing 7 or more genes in
  this category by choosing 10 random genes, is
  less than 10-12.
• 42 modules, out of 50, had at least one
  significantly enriched annotation with a p-value
  less than 0.005.

33
Biological validity Cont.

• The enrichment of both HAP4 motif and STRE,
  recognized by Hap4 and Msn4, respectively,
  supporting their inclusion in the modules
  regulation program.
• Lines represent 500 bp of genomic sequence
  located upstream to the start codon of each of
  the genes colored boxes represent the presence
  of cis-regulatory motifs locates in these
  regions.

34
Stock Market Data

• NASDAQ stock prices for 2143 companies, covering
  273 trading days.
• stock ? variable, instance ? trading day.
• The value of the variable is the log of the ratio
  between that days and the previous days closing
  stock price.
• As potential controllers, 250 of the 2143 stocks,
  whose average trading volume was the largest
  across the dataset were selected.

35
Stock Market Data

• Cross validation is used to evaluate the
  generalization ability of different models.
• Module networks perform significantly better than
  Bayesian networks in this domain.

36
Stock Market Data

• Module networks compared with Autoclass

• Significant enrichment for 21 annotations,
  covering a wide variety of sectors where found.
• In 20 of the 21 cases, the enrichment was far
  more significant in the modules learned using
  module networks compared to the one learned by
  AutoClass.

37
Conclusions

• The results show that learned module networks
  have much higher generalization performance than
  a Bayesian network learned from the same data.
• Parameter sharing between variables in the same
  module allows each parameter to be estimated
  based on a much larger sample, this allows us to
  learn dependencies that are considered too weak
  based on statistics of single variables. (these
  are well-known advantages of parameter sharing)
• An interesting aspect of the method is that it
  determine automatically which variables have
  shared parameters.

38
Conclusions

• The assumption of shared structure significantly
  restricts the space of possible dependency
  structures, allowing us to learn more robust
  models than those learned in a classical Bayesian
  network setting.
• In module network, a spurious correlation would
  have to arise between a possible parent and a
  large number of other variables before the
  algorithm would introduce the dependency.

39
Overview on Module Networks
40
Literature

• Reference Discovering Regulatory Modules and
  their Condition Specific Regulators from Gene
  Expression Data.
• By Eran Segal, Michal Shapira, Aviv Regev, Dana
  Peer, David Botstein, Daphne Koller Nir
  Friedman.
• Bibliography
• P. Cheeseman, J. Kelly, M. Self, J. Stutz, W.
  Taylor, and D. Freeman. Autoclass a Bayesian
  classification system. In ML 88. 1988.

41
THE END
