Mobile Motion Tracking using Onboard Camera

1
Mobile Motion Tracking using Onboard Camera

• Supervisor Prof. LYU, Rung Tsong Michael
• Prepared by Lam Man Kit
• Wong Yuk Man

2
Outline

• Motivations
• Objective
• Methods
• Results
• Future Work
• QA

3
Motivations

• Rapid increase in the use of camera-phone.
• Commonly used for taking photos or capturing
  video only.
• Is it possible to add more values to the camera
  and make full use of it ?

4
Motivations

• Unlike traditional camera, camera-phone has more
  functions than just taking photos.
• Camera-phone can perform image processing tasks
  on the device itself.
• Symbian OS makes programming on mobile phones
  possible.

5
Objective

• To add more values to camera-phone, so that it
  enhances the human-computer interaction.
• Implement real-time motion tracking on Symbian
  phone, without requiring additional hardware.
• Movement detected acts as an innovative input
  method for different applications
• Camera mouse to control the cursor
• New input method for interactive games
• Gesture input

6
Objective

• Novel ubiquitous computing applications can be
  developed !

7
Real-World Interaction
A
8
Motion Estimation

• Motion estimation is a process to find the motion
  vector of the current frame from reference
  frame(s).
• Optical flow
• Block matching
• Block matching algorithm is an integral part for
  most of the motion-compensated video coding
  standards. Eg MPEG 1, MPEG 2, H.263.

9
Block Matching

• Divide the previous frame to small rectangular
  blocks.
• Find the best match for the reference block in
  current frame.
• Calculate motion vector between the previous
  block and its counterpart in the current frame.
• Typical size for a block 16x16 pixels.
• Search Range W typically 16 or 32 pixels.
• Similarity Measures
• Mean Absolute Error (MAE)
• Mean Square Error (MSE)
• Sum of the Absolute Difference (SAD)
• SAD is used in our project.

Current frame
MV
Previous frame
10
Block Matching
center pixel
2W 1
BW 1 BH 1 W 4 H 4









Search Window

• Search Window
• (in current frame)
• A region which has the same center as the
  selected block in the previous frame, extended by
  w pixels in both directions

2BW 1
2BH 1
2H 1
W
Block in previous frame
11
Block-match Motion Estimation

• Two kinds of methods commonly used
• Fast Search Algorithms
• 2-D Logarithmic Search
• 3-Step Search (3SS)
• Diamond Search
• Exhaustive Search Algorithm (ESA)

12
Fast Algorithms

• Fast Search Algorithms
• 2-D Logarithmic Search
• 3-Step Search (TSS)
• Diamond Search
• Assumption
• The matching error monotonically increases as the
  search position moves away from the optimal
  motion vector

13
Fast Algorithms - TSS
Center of Block
1
2
3

• Three-Step Search (TSS)
• 1st Step
• Search 8 surroundings and the central point
• Distance w/2 pixels
• Find the best match
• 2nd Step
• Use previous best match as center
• Repeat 1st step with distance w/4 pixels
• 3th Step
• Repeat 1st step with distance w/8 pixels
• Searched only 25 points

Search Window
1
1
1
1
1
1
2
2
2
3
3
3
1
1
1
2
2
3
3
3
3
3
2
2
2
14
Fast Algorithms

• Advantages
• Extremely fast
• Disadvantages
• All fast algorithms greatly rely on a
  monotonically increasing match criteria around
  the location of the optimal motion vector
• Easily fall into local minimum
• limited number of positions examined (only 25
  points) inside the search window, only find
  suboptimal solution

15
Exhaustive Search

• All candidates within search window are examined
• (2w1)2 positions should be examined
• Advantage Good accuracy Finds best match
• Disadvantage High computational load.
  Impractical for real-time applications
• Solution
• Fast Exhaustive Search

16
Fast Exhaustive Block Matching Algorithms

• Much Faster
• No performance Loss
• Idea exclude many search positions while still
  finding best match
• SEA(Successive Elimination Algorithm)
• PNSA(Progressive Norm Successive Algorithm)
• SEA and PNSA can be calculated quickly

17
SEA algorithm
Slow

• SAD of two blocks X and Y is defined as
• By Minkowski inequality
• Thus,
• By calculating the block-sum difference first, we
  can eliminate
• many candidate blocks (if D gt SAD) before doing
  slow SAD
• There exist fast method to calculate the
  block-sum for SEA
• About 2 times faster than exhaustive search !!

Fast
Denoted as D
18
Fast Exhaustive Block-Matching Algorithm
Search range2W1
SEA
Total No of candidate block (2w1)2
.
PNSA
.
SAD
SAD
SAD
SAD
.
Probability of eliminating invalid candidate
block SEA lt PNSA lt SAD Computation LoadSEA lt
PNSA lt SAD
The smallest SAD
19
Feature Selection
Is that block good?
No

• Which block should be chosen for tracking?
• Flat-colored block is not good.
• A block in a region of repeated pattern is not
  good.
• Why is the eye a good candidate?
• It is a good tracking location because of the
  brightness difference between the black and skin
  colors.
• How do we find a good feature block?

It is a good block !!
Is that block good?
No
20
Feature Selection

• Goal
• Find a good reference block for tracking
• Criteria
• The candidate block should have great SAD with
  its neighbors
• It contains complex information
• Great SAD with neighbors block
• Prevent ambiguous detection
• Speed up the searching algorithm
• Many candidate blocks are eliminated by the tree
  in upper level
• Complex block
• Prevent choosing flat region as reference block
• Enhance the performance of PDE (Partial
  Distortion Elimination)

21
PDE (Partial Distortion Elimination)
X candidate block Y feature block

• Simple, small overhead
• Comparison can be done Halfway
• Stop if the sub-blocks SAD between block X and Y
  is already larger than the previous minimum SAD
• Removes unnecessary computations efficiently
• if the feature block Y has high complexity
• It will have great SAD with block X
• Increase chance of halfway stop
• We implement a simple feature selection algorithm
  based on the above criteria

22
Feature Selection

• Divide the current frame to small rectangular
  blocks
• For each block, sum all the pixels value, denoted
  as Ixy (Intensity of the block)
• Calculate the variance of each block which
  represent the complexity of the block
• Use Laplacian Mask for each block
• The Laplacian operator indicates how the
  reference block differs from the neighbors
• Flat background gt small output
• Dissimilar with neighbors gt large output
• Select the block which has the largest Ixy and
  large variance as the feature block

Laplacian Mask
23
Adaptive Search Window

• Conventional method
• Search window is defined as a rectangle with the
  same center as block in previous frame, extended
  by W pixels in both directions.

Search Window
Block
Center of Search Window
24
Adaptive Search Window

• Proposed method
• Center of the search window is predicted based on
  the previous displacement and previous predicted
  displacement
• Example
• Previous motion vector is (1,0), i.e. one pixel
  to the right
• The predicted center of search window can be the
  position next to the center of the previous block

Search Window
Block
Center of Search Window
25
Adaptive Search Window

• Motivation
• To Increase the speed of fast full search
  algorithm by searching the most probably optimal
  position first
• Need to corporate with Spiral Scan
• To increase the chance of finding the true
  optimum point
• Explained in the following slides

26
Conventional Search Window

• We used web camera to track the motion of an
  object and graph showing its x-axis velocity
  against time is plotted
• Due to the limited size of search window, if an
  object is moving too fast, the optimal position
  would fall out of the search window, detection
  error results

Velocity lt W pixels/s Assume the algorithm is
run every second
27
Adaptive Search Window

• Based on the previous optimal position and motion
  vector, we estimate the next optimal position,
  and this will be the center of the search window

P Predicted Displacement P Previous Predicted
Displacement L Learning Factor, range is 0.5,
1.0 D Previous Displacement
28
Adaptive Search Window

• Applying adaptive search window method, the
  relative velocity fall within the range -20,20,
  all true optimum points fall into the search
  window and thus no serious detection error
  results

Relative velocity actual disp. expected disp.
Acceleration (relative velocity) lt W
pixels/s W Search Range Assume the algorithm is
run every second
29
Raster Scan Method

• Conventional Block Scanning Method
• when we use the previous block to find a best
  match in the current frame, we calculate the Sum
  of Absolute Difference (SAD) of the previous
  block with the current block at the left top
  position of the search window first. Then scan
  from top to bottom, from left to right.
• Simply to implement
• Small code overhead

Search Window
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
represents the priority of each current block
in block matching
30
Spiral Scan Method

• Proposed Block Scanning Method
• Observation
• The order of scanning can affect the time to
  reach the optimum candidate block
• When SEA, PPNM or PDE method are used, this can
  affect the amount of computation
• When adaptive search window method is used, the
  motion vectors are center biased
• Objective
• Search the motion vector around the center of a
  search window first
• Higher chance to meet the optimal position
  earlier ? algorithm run faster

31
Spiral Scan Method

• First find the SAD at the center of the search
  window
• Then find the SAD at position that are n pixels
  away from the center where n 1,BW

Search Window







32
Spiral Scan Method

• Proposed Block Scanning Method
• Result
• Require larger memory space
• If fast calculation of block sum is used
  together, the whole block sum 2D array is needed
  to be stored.
• A bit larger code overhead
• Degradation in speed not significant
• Spiral Scan Complexity O(DX2)
• SAD Complexity O(DX2 BW2)
• Speed of Algorithm significantly improved, when
  use with adaptive search method, about 2-3 times
  speed-up in real-time motion tracking

33
Result
Static Frame Motion Tracking
Table showing the time required to find the
motion vector at different regions using
different algorithms (Each algorithm is run 5
times using 2.0GHz CPU)
Time Typical Point ESA SAD Algorithm ESA PDE SAD Algorithm SEA PPNM SAD Algorithm SEA PPNM PDE SAD Algorithm Spiral SEA PPNM PDE SAD Algorithm Adaptive Spiral SEA PPNM PDE SAD Algorithm
High Gradient High Variance 2078ms 484ms 156ms 109ms 16ms 16ms
Low Gradient High Variance 2203ms 515ms 578ms 375ms 94ms 47ms
Low Gradient Low Variance 2078ms 360ms 359ms 203ms 79ms 47ms
This is just to illustrate speed is possible to
be improved with our final algorithm, a more
general measurement will be presented at the next
slide
Optimal Motion Vector (-5, 12), Previous Motion
Vector (-2, 4) ? Affecting Spiral Scan and
Adaptive Search Window algorithm
34
Result
Real-Time Motion Tracking
Average Velocity/Distance 15 pixels
Average Velocity/Distance 6 pixels

• Algorithm using adaptive spiral method can reduce
  the average distance between search windows
  center and optimum blocks position, thus improve
  the speed of algorithm ( as illustrated in the
  previous slide )

35
Summary
Video Source captured by camera
Already selected feature block?
Source Frames
Extractor
No
Frame t
Yes
Feature Selection
MV of reference block
Block-matching Algorithm using two image frames
Transmitter
delay
Frame t-1
e.g. Bluetooth
A feature block is selected as reference block
Server
Application
36
Contribution

• Proposed a method to improve the block matching
  algorithm for our application
• Adaptive Spiral Method
• Improve performance
• Require larger memory space
• New combination
• Adaptive Spiral SEA PPNM PDE SAD algorithm

37
Testing Platform on Window

• In order to test the performance of our
  algorithms, we have written a GUI program using
  Window MFC and OpenCV library.

38
Testing Platform on Symbian

• We finally built an application on Symbian as an
  testing platform to further test and fine tune
  our algorithm.
• Ready for other applications to build on top and
  use the motion tracking result directly.

39
Simple Applications finished

• A pong game written in C
• Play in Window using Web camera as input device
• A pong game written in Symbian Language
• Play in Symbian phone using onboard camera

40
Future Work

• Further improve the block matching algorithm by
  hierarchical method
• Study and implement algorithms to detect rotation
  angle
• Develop virtual mouse application
• Develop multiplayer game
• Build motion tracking API on Symbian

41
Q A
