A Mechanical Turing Machine: Blueprint for a Biomolecular Computer

1
A Mechanical Turing MachineBlueprint for a
Biomolecular Computer

• Udi Shapiro
• Ehud Shapiro

2
Medicine in 2050
3
Medicine in 2050 Doctor in a Cell

• A genetically modified cell that can operate in
  the human body
• with an intra-cellular computer
• that receives input from signal transduction
  pathways
• and, based on its program, produces output to
  protein synthesis and secretion pathways
• effecting any desired molecular medical treatment

4
Medicine in 2050 Doctor in a Cell
Programmable Computer
5
Possible types of molecular output

• Drugs (proteins and small molecules) synthesized
  on-command by the cell
• Stress signals detectable by external devices
• Encoded status report messages decipherable by
  external devices

6
Possible types of molecular treatment

• Simple stimulus-response
• Output multiple drugs based on multiple signals
  and a decision procedure
• Feedback-controlled drug output (titration,
  negative control)
• Any repetitive, programmable combination of the
  above

7
Possible types of cellular doctors

• Generalists that circulate in the blood and
  lymphatic vessels
• Specialists that reside in specific organs
  (heart, liver, kidney, bone marrow)
• All use the same intra-cellular computer, each
  with different software

8
A design for an intra-cellular computer should be

• Implementable from biomolecules (biopolymers)
• that utilize standard operations of biomolecular
  machines (polymer cleavage, ligation, elongation,
  movement along a polymer, control via allosteric
  conformational changes), and can
• sense biomolecular input, and
• synthesize biomolecular output

9
Logical Design for an Intra-Cellular Computer
10
1900 Hilbert Posed a Problem

• 23rd Find a method for deciding the truth or
  falsity of any statement of predicate calculus
  (decision procedure)
• Part of larger program to establish all of
  mathematics on solid formal foundation, by
  proving every mathematical theorem mechanically
  from first principles (first order logic and
  elementary set theory)

11
1936 Turing had an answer...

• Hilberts 23rd problem has no solution, i.e.,
  there is no such procedure
• The proof required to formalize the notion of a
  procedure
• So Turing defined a pencil-and-paper
  computation device, now called the Turing Machine
• and established its universality (Church-Turing
  thesis)

12
The Turing Machine
INFINTE TAPE
D
A
T
A
Read/Write Head may read and/or write a symbol,
and move one cell to the left or to the right
Tape Cell may contain one symbol of a given tape
alphabet
S7
Finite Control may be in one of finitely many
states S0,S1,,Sn
13
Transitions

• If the control is in state S and the read/write
  head sees symbol A to the left right, then
  change state to S, write symbol A, and move one
  cell to the left right.
• S,A ? A,S or
• A,S ? S,A where A can be blank

14
Configuration
State symbol and location of read/write head
Alphabet tape symbols
Initial configuration
15
Example Control ProgramWell-formed Expressions

• Accept well-formed expressions over ( and )
• (), (()), ()(), (())() are well-formed, ((), )(,
  ()), ()()(, are not.
• States
• S0 Scanning right, seeking right parenthesis
• S1 Right paren found, scan left seeking left
  paren.
• S2 Right end of string found, scan left, accept
  if no excess parens found.
• S3 Accept

16
Example computation

Scan right to first )

Scan left to first (

Scan right to first )
Scan left to left paren
Stop, not accepting
17
Example Control ProgramWell-formed Expressions

• S0,( ? (,S0
• S0, , ? ,S0
• S0,) ? ,S1 (erase right paren and enter S1)
• S0,blank ? ,S2 (end of string, enter S2)
• (,S1 ? S0, (erase left paren and enter S0)
• ,S1 ? S1,
• ,S2 ? S2,
• blank,S2 ? S3, (end of string, enter S3)

18
Movie
19
A Mechanical Turing Machine
20
Device Components
Alphabet monomers
Control
Transition monomers
21
Alphabet Monomers
Side group representing symbol
A
D
C
B
A
Left Link
Right Link
Alphabet Polymer
Alphabet Monomer
22
Transition Molecules
S
Transition Molecule for A,S ? S,X
A
S

• One side group representing target state S
• Three recognition sites source state S, source
  symbol A, target symbol A

23
Transition Molecules
S
S
A
S
A
S
Transition Molecule for A,S ? S,X
Transition Molecule for S,A ? X,S
S
A
A
S
A Loaded Transition Molecule for A,S ? S,A
24
Example Configuration
25
Example Configuration
Current state
Tape polymer
A
B
C
E
S2
S0
D
S0
D
S1
S1
Trace polymer
26
Example Transition Before
The device in operation Before
A
B
C
C
S3
D
S0
S0
D
S2
S2
F
E
S1
S1
27
Example Transition After
The device in operation After
A
B
C
C
S3
S0
S0
D
D
S2
S2
F
E
S1
S1
28
Example Control ProgramWell-formed Expressions
(

S0
S0

S2

S1
b
)
S0
S0
S0
S0

(

S0

S1
S2


S3
2
S1
S1
(
S2

S2
b

29
Example Computation
We show only good random moves
Movie
30
Example Trace Polymer
S
A
A
S
S
A
A
S
S
A
A
S
S
A
A
A
S
31
Implementation
32
Implementation
Transition Molecules
Alphabet Molecules
33
A Transition
4
3
1
1
4
5
6
3
5
6
2
2
Before
After
34
The Device
35
Device Ribosome

• Both operate on two polymers symultaneously
• Tape polymer messenger RNA
• Transition molecule transfer RNA
• Trace polymer Polypeptide chain
• Move one cell per transition Move one codon per
  transition

36
Device is unlike the Ribosome

• Read/write tape vs. Read-only tape
• Transition molecule with side group vs. transfer
  RNA without side group
• Move in both directions vs. Move in one direction
• Trace polymer made of transition monomers vs.
  Polypeptide chain made of amino acids

37
Cellular Input
38
Computer Input

• Device suspends if needed molecules are not
  available
• Non-deterministic choices can be affected by
  availability of molecules
• Hence device can be sensitive to chemical
  environment

39
Cellular output
40
Computer Output

• Device extended with transition that cleaves the
  tape polymer and releases one part to the
  environment
• Hence device can synthesize any computable
  polymer of alphabet molecules
• If alphabet monomers are ribonucleic acids,
  cleaved segment can be used as messenger RNA

41
Ultimately...
42
Ultimately...

• Universal programmable computing device that can
  operate in vivo
• Can interact with biochemical environment
• Can be sent on a mission
• Can diagnose, prescribe, synthesize, and
  deliver...

43
Related work

• C. H. Bennett 1970-
• Assignment considered (thermodynamically)
  harmful
• Reversible computation is the answer
• Hypothetical Enzymatic Turing machine
• L.M. Adelman et al. 1994-
• DNA Computing
• Biological steps (outside intervention)
• Self-assembly (tiling)
• S. A. Kurtz et al. 1997
• Hypothetical modified ribosome implements string
  rewriting on RNA

44
Wanted Single recognition site, constant
distance splicer
D N bp
