Clustering of Streaming Time Series is
Meaningless

• presentation by Rafal Ladysz
• after the original paper by
• Eamonn Keogh
• Jessica Lin
• Wagner Truppel
• Computer Science Engineering,
• University of California-Riverside

2
interesting and important topic

• foreward of the original paper reads
• Clustering is perhaps the most frequently used
  data mining algorithm, being useful in it's own
  right as an exploratory technique, and also as a
  subroutine in more complex data mining algorithms
  such as rule discovery, indexing, summarization,
  anomaly detection, and classification
• Time series data is perhaps the most frequently
  encountered type of data examined by the data
  mining community
• thus, a lot of interest, works, papers,
  conferences on these two, nevertheless
• it has never appeared in the literature what
  the title claims

3
QUIZ questions (asked upfront)

• what are two main ways of clustering time series
  data? (name and describe each in one sentence)
• one can convert hierarchical clustering into
  k-means clustering which of these two is
  deterministic (if any)?
• what method can help subclustering time series
  work?

4
time series (TS) mini-primer

• intuitive definition sequence of real numbers
  (usually acquired in equal time intervals)
• examples of experimental time series
• meteorological observations
• EEG, EKG, patients temperature (medical)
• laser light intensity measured
• stock market indices
• predator-prey population recorded
• possible division
• periodic/non-periodic
• stochastic (random)/chaotic (deterministic)

5
possible TS hierarchy tree
the leaf nodes refer to the actual
representation, and the internal nodes refer to
the classification of the approach credit
Keogh et al.
6
TS illustration
SP laser Lorenz earthquake chaotic
7
mining TS

• general examples
• anomaly detection (deviation from some mean
  value, e.g. monitoring functioning of space
  shuttle)
• classification/ forecasting
• rule discovery (surprising/interesting patterns)
• particular example (of my current interest)
• detecting chaos in dynamic TS data streams
• getting insight of the underlying systems
  dynamics
• computing some crucial parameter(s)
• possible applications of the above
• EEG
• stock market
• weather-related catastrophes (extremally complex)

8
TS similarity issue

• in many (though not all) cases similarity is
  necessary to investigate TS data
• we need some measure of similarity to mine TS
• classification, e.g. ECG patterns of new patients
  as indicator of heart deseases with known ECG
  pattern
• clustering, e.g. groupping websites with similar
  traffic patterns
• association, e.g. a plateau followed by a sudden
  decrease in EEG an epileptic seizure can happen
• we need it for searching particular pattern
• (once we can use techniques/tools to mine TS)

9
TS similarity possible measures

• in general there are many and what to use
  depends on the application
• an obvious similarity measure is one based on
  Euclidean distance (with its pros and cons)
• each sequence as a point in n-dimensional
  Euclidean space, where n length of TS points
• then similarity Lp between TS sequences X, Y
  is
• Lp (?i1n xi yip)1/p
• old problem of dimensionality curse exists
• thus scalability is desired and enforces
• trade off between accuracy and efficiency

10
Euclidean distance for TS in action

• credit A. K. Singh

11
similarity of TS when we use it

• Indexing problem
• find all lakes whose water level fluctuations are
  similar to X
• Subsequence Similarity problem
• find out other days in which stock X had similar
  movements as today
• Clustering problem
• group regions that have similar sales patterns
• Rule Discovery problem
• find rules such as if stock X goes up and Y
  remains the same, then Z will go down soon

12
clustering algorithms quick look at three of
them

• well known k-means
• choosing k the number of clusters to generate
• initializing k centers of clusters to be
  generated
• keep re-estimating k clusters centers
• ... greedy
• ... converges but not (necessarily) to global
  minimum
• ... depends on initialization is step 2
• stops when no changes (in cluster membership)
• hierarchical clustering
• density-based clustering

13
hierarchical clustering step by step

• 1. distances between objects compute and put
• into distance matrix
• 2. search through distance matrix to find two
  closest (i.e. most similar) objects (clusters in
  next iterations)
• 3. join the two to get cluster of at least two
  objects
• 4. update distance matrix (new clusters
  generated)
• 5. repeat step 2 until there is one cluster of
  all objects (from step 1)
• Q is it bottom up (aglomerative) or top down?

14
hierarchical clustering illustration
averages

• TS being clustered hierarchically - starting
  with 10 sequences
• sliding either way along green line the cut
  off line determines
• k (clusters) - thus determines bottom-up or
  top-down way
• so we can convert hierarchical clustering to
  k-means cluster.

15
hierarchical clustering summary

• it produces the same results every time with a
  given set of data (unlike k-means clustering)
• cons
• splitting or merging irreversible in next
  iterations (i.e. no element redistribution among
  clusters)
• poor scaling (quadratic in input size)
• pros
• no input parameters (like number of clasters k)
• simplicity
• can be integrated with other clustering methods

16
density-based clustering (DBC)

• based on density - local cluster criterion
• recognizes clusters as dense regions
• major features
• discover clusters of arbitrary shape
• handle noise
• one scan
• need density parameters as termination condition
• sources and algorithms
• DBSCAN Ester, et al. (KDD96)
• OPTICS Ankerst, et al (SIGMOD99).
• DENCLUE Hinneburg D. Keim (KDD98)
• CLIQUE Agrawal, et al. (SIGMOD98)

17
TS and its subsequences

• formally, TS can be expressed as an ordered set
  of m variables or a point in m-dim space
• TS t1, t2, ..., tm
• this formality enables applying clustering to a
  set of TS sequences as if they were such points
• Cp denotes a subsequence of length w of a TS,
  where w lt m
• Cp tp, tp1, ..., tpw-1, 1 ? p ? m-w1
• a technique of sliding window (of size w) is a
  useful concept here

18
subsequences via sliding window

• sliding window extracts all subsequences Cp
  described earlier from a given TS
• a matrix S of all such subsequences can be built
  by moving the sliding window across a given TS
• and placing subsequence Cp in the pth row of S
  whose size is (m-w1) times w

far left first eight subsequences Cp, each of
length 16 middle C67 of the same length
19
sliding window and its matrix

• denoting all possible subclusters Cp
• C1 t1, t2, , t10
• C2 t2, t3, , t11
• Cm-w tm-9, tm-8, tm
• and their corresponding matrix S

20
meaninglessness of STS clustering

• to demonstrate meaninglessness of STS clustering
  two algorithms have been used
• k-means
• hierarchical clustering
• important remark
• to minimize any methodological bias, the whole
• clustering (besides STS sliding window
  clustering)
• has been performed to provide control results for
• comparison

21
variability of k-means one data set

• let A, B denote cluster centers derived from two
  different runs of k-means algorithm over the same
  data set (expect different results)
• the cluster_distance(A, B) defines the distance
  between two sets of clusters A and B
• remark the above definition enforces closest
  pairs from A, B

22
variability of k-means two data sets

• applying this approach for different data sets
• experiment performing 3 random restarts of
  k-means (applying sliding window) on a stock
  market dataset
• set X the 3 resulting sets of cluster centers
• similarly with 3 random runs of k-means on a
  random walk dataset
• set Y the resulting cluster centers

23
more definitions

• denote the avarage cluster_distance between each
  set of cluster centers in X to each other set of
  cluster centers in X (as it was for one data set)
  by
• within_set_X_distance
• denote the average cluster distance between each
  set of cluster centers in X to cluster centers in
  Y by
• between_set_X_and_Y_distance

24
a brief analysis of the claster
meaningfullness(X, Y)

• numerator (within set distance X) measuring
  clustering algorithms sensitivity to initial
  conditions (seeds)
• briefly it asumes zero for same results
• on the other hand there is no reason for
  similarity of clustering results for two
  different (and unrelated) data sets
• briefly denominator (between set X and Y
  distance) should be (relatively) large
• overall tendency
• claster meaningfullness(X, Y) ? 0 if X, Y
  differ

25
experiment STS vs whole clustering

• to obtain control set of results (for
  comparison)
• the same experiment has been repeated by k-means
• for the same data
• using whole clustering method (i.e. randomly
  extracted subsequences)
• entire process has ben repeated 100 times for
  every combination of parameters k and w
• k3, 5, 7, 11
• w8, 16, 32
• results first surprise!!!

comparison whole (yellow) vs. STS Z-axis
meaningfulness value
26
same experiment hierarchical clust.

• having proven meaningless of k-means clustering
  of STS,
• the experiment has been performed using
  hierarchical clustering
• new challenge defining distance between two
  clusters
• linkage method - applicable for bottom-up
  clustering

cluster objects can be based on different
methods Single Linkage the minimum distance
between them (nearest neighbour rule) Complete
Linkage the maximum distance between them
(furthest neighbour rule) Average Linkage the
average distance between all pairs of objects
(one member of the pair must be from a
different cluster)
cluster meaningfullness comparison whole
clustering vs. STS clustering using hierarchical
approach data used SP 500 again, no
significant difference!
27
why it is really surprising dissimilarity of
data sets

• the below two TS are very dissimilar
• neverteless, the experimental results obtained
  for buoy sensor and ocean TS (using k-means)
  continue showing meaningless of STS clust.

28
preliminary conclusions

• the authors reported similar results
• using other clustering algorithms, e.g. EM, SOMs
  (self-organizing featire maps)
• applied to more than 40 data sets
• using Euclidean, L, Mahalanobis and time warping
  distances
• and normalization techniques
• and for all of those combinations observed
• whole clustering of TS usually is to be
  meaningful
• sliding window clustering of STS never is
  meaningful

29
looking for explanation

• another comparison of both methods
• using cylinder, bell and funnel data sets
• 30 instances generated for each pattern (90
  total)
• k-means applied (k 3)
• all (three) clusters have been recognized
• close resemblance found

30
more results, more surprises

• the 90 TS data sets (generated) have been
  concatenated to one long TS
• sliding window w 128, k-mean with k 3 (as
  expected!)
• the above graph illustrates obtained result, i.e.
  cluster centers found by subsequence clustering
  (using sliding the window described above)
• a big surprise the lines are sinusoids no
  resemblence to any patterns in data sets used as
  it was for whole clustering
• summarizing regardless clustering algorithm,
  number of clusters, datasets used if w ltlt m and
  STS then sinusoid

31
summarizing once again

• the authors conclude
• obtained approximate sinusoids with STS
  clustering regardless of the clustering
  algorithm, the number of clusters, or the dataset
  used
• if sinusoids appear as cluster centers for every
  dataset, then clearly it will be impossible to
  distinguish one datasets clusters from another
• this is all the more true as the joint phase of
  the sinusoids is arbitrary does not depend on
  any input-related parameters
• recall that independence on such parameters was
  defined as mininglessness

32
another concept Hidden Constraint

• lets agree with the following theorem
• for any TS dataset,
• if TS is clustered using sliding windows with
  wltltm,
• then the mean of all the data (i.e. case for
  k1)
• will be approximately constant
• (Im not sure why they use the tem vector
  here)

space shuttle flutter speech power data koski
ecg rarthquake chaotic cylinder random
walk balloon
visual proof of the theorem w 32, k 1, 10
dissimilar datasets right resulting cluster
centers (no rescaling has been done)
33
(more) intuitive proof of the theorem

• consider a time series TS and a single datapoint
  ti, where w ? i ? m-w1
• as the sliding window pass by, ti goes on to
  appear exactly once in every possible location
  within it
• ti contribution to the overall shape is the same
  every where and must be a horizontal line
• the average of many horizontal lines is just
  another horizontal line

ti
34
trivial match the main idea

• consider TS subsequence Cp being a member of a
  cluster
• searchng for similar subsequences, where one can
  expect them to be?
• in closest proximity! thus
• ..., Cp-2, Cp-1, Cp1, Cp2, ...

35
trivial match definition

• trivial match C and M are subsequences beginning
  at p and q, respectively, while R is a distance
• M is a trivial match to C of order R
• if either p q
• or there does not exist a subsequence M
• beginning at q
• and such that D(C, M) gt R,
• and
• either q lt q lt p
• or p lt q lt q

C M M
pq
pltqltq
36
trivial match observation

• smooth, slowly changing subsequences tend to have
  many trivial matches
• rapidly changing subsequences (i.e. their
  features) tend to have very few trivial matches
• the smooth pattern is surrounded by many trivial
  matches sort of compelling as a cluster
  center
• highly featured, noisy pattern has few trivial
  matches, often ignored as a cluster center
  candidate

illustration of the observation A TS sequence
with a cluster of 3 square waves w 64 B
number of trivial matches
37
tentative conclusions

• smooth patterns are surrounded by many trivial
  matches
• extremely promising cluster center in clustering
  algorithms
• D(C,M) lt R
• in 1920s, Evgeny Slutsky demonstrated that any
  noisy time series will converge to a sine wave
  after repeated applications of moving window
  smoothing
• STS, though not exactly such, is closely related

38
sine qua non for STS cluster

• the weighted mean of the k patterns must sum to a
  horizontal line (constant line)
• rach of the k patterns must have approximately
  equal number of trivial matches
• the chances of both conditions being met is
  essentially zero

39
a tentative solution

• proposed a method as an existence proof only that
  such an algorithm exists at all (conceptually)
• presented below is a motif-based clustering
• definition of K-motifs
• given TS, a subsequence of length n, distance
  range R
• the most significant motif in TS called 1-Motif
  is the subsequence C1 with the highest count of
  non-trivial matches
• each subsequent K-motif in TS is the CK which
  differs from C1 in that additionaly D(CK, Ci) gt
  2R for all 1 ? i lt K

the motif (red) occurs 4 times winding(4)
dataset used
40
motif vs. cluster

• when mining motifs, we must specify an additional
  parameter R
• assuming the distance R is defined as Euclidean,
  motifs always define circular regions in space,
  whereas clusters may have arbitrary shapes
• motifs generally define a small subset of the
  data, and not the entire dataset
• the definition of motifs explicitly eliminates
  trivial matches

41
algorithm for motif-based clustering

1. decide on a value for k
2. discover the K-motifs in the data, for Kk?c (c
   is some constant about 2 to 30)
3. run k-means, or k partitional hierarchical
   clustering, or any other clustering algorithm on
   the subsequences covered by K-motifs

42
experimental results

• repeated experiment for searching cluster centers
  for cyllinder-bell-funnel trio
• the results obtained are okey, i.e. they
  resemble the original patterns (see right) of the
  three TS data sets (as well as results obtained
  using whole clustering approach)

43
side remark another point of view

• by Anne Denton
• needlessly to say her Ph.D. thesis was entitled
  Fast kernel-density-based classification and
  clustering using P-trees, a good motivation to
  defend meaningfullness of STS
• experimental setup
• data sets halved before clustering
• comparing derived cluster centers from both
  halves using meaningfullness measure
  (within/between) and similar cluster distance
  measure
• claim such a test is stricter than that
  reported so far (based on separate runs of
  k-means on same data)
• conclusion kernel-based clustering shows
  meaningful results for subsequence clustering

44
references

• Keogh, Lin, Truppel Clustering of Time Series
  Subsequences is Meaningless Implications for
  Previous and Future Research
• Han, Kamber Data mining. Concepts and
  Techniques
• Lin, Keogh, Lonardim Chiu A symbolic
  representation of Time Series...
• Denton Density-based Clustering of Time Series
  Subsequences
• Sprott Chaos and Time-Series Analysis
• references of the above ones and many
  pertaining web pages
• THANK YOU!
