Title: Methods


1
The Sorcerer II Global Ocean Sampling Expedition
Metagenomic Characterization of Viruses within
Aquatic Microbial Samples Shannon J. Williamson,
Douglas B. Rusch, Shibu Yooseph, Aaron L.
Halpern, Karla B. Heidelberg, John I. Glass,
Cynthia Andrews-Pfannkoch, Douglas Fadrosh,
Christopher S. Miller, Granger Sutton, Marvin
Frazier, J. Craig Venter
2
Why so hard for Classical Marine Biologists and
Microbiologists?
  • Enormous and diversity of microorganisms,
  • Difficult to culture and study in the lab, etc.
  • Venters answers,
  • Whole Genome Shotgun Sequencing,
  • computationally derived metabolisms
  • http//biocyc.org/

3
http//camera.calit2.net/metagenomics/what-is-meta
genomics.php
4
(No Transcript)
5
Discoverynth1,500 liters of water
  • 1.045 x 109 new bp of non-redundant sequence,
  • gt1,800 new species,
  • 148 new bacterial phylotypes,
  • 1.2 x 106 new protein sequences,
  • 70,000 novel (no match in the database),
  • etc.

"We chose the Sargasso seas because it was
supposed to be a marine desert," says Venter
wryly. "The assumption was low diversity there
because of the extremely low nutrients. -
Venter (Bio-IT World, 4/16/04)
6
Figure 1
S1
7
(No Transcript)
8
Points to Ponder
  • What about Unitigs, and the assembly of an
    environmental sample?
  • All data went to Genbank.

9
Figure 2
10
Figure 3
11
Figure 5
12
Close-up
13
Figure 6
14
(No Transcript)
15
The Sorcerer II Global Ocean Sampling Expedition
Metagenomic Characterization of Viruses within
Aquatic Microbial Samples Shannon J. Williamson,
Douglas B. Rusch, Shibu Yooseph, Aaron L.
Halpern, Karla B. Heidelberg, John I. Glass,
Cynthia Andrews-Pfannkoch, Douglas Fadrosh,
Christopher S. Miller, Granger Sutton, Marvin
Frazier, J. Craig Venter
16
Detection of Viruses in the OceanProblems
  • Large viruses (0.1 µm0.22 µm) get caught in the
    filters because of their size and geometric
    shape,
  • Small free living phages flow through the filter,
  • When filtrating large volumes, biomass
    accumulates on the filter and viruses get caught,
  • Most viruses found within the aquatic microbial
    communities studies seemed to be in the lytic
    infection cycle.

17
(No Transcript)
18
Methods
First
  • Cruise the world
  • Collect 90-200 L of seawater
  • from each of 37 different stations
  • Record pH, salinity, temperature,
  • etc. of water

19
Methods
  • Pass water through 2.0, 0.8, 0.1
  • µm filters,
  • Store at -20C until shipment from
  • next port.

20
Sequencing Preparation
  • Extract DNA
  • Nebulize DNA
  • Average of 1.0-2.2 kb fragments
  • Gel electrophoresis extraction
  • purify and determine lengths
  • Subclone into E. coli
  • Colonies selected for inserts
  • Shotgun sequence inserts

21
Sequencing
  • End sequence each insert
  • Average of 822 bp sequenced per end

www.pasteur.fr/recherche/genopole/PF8/equipement_e
n.htmlnopole/PF8/equipement_en.html
22
Metagenomic Assembly
  • Same procedure as in humans, Drosophila, dogs,
    etc.

Unitigs using 98 or 94 homology for overlap
Scaffolding
Consensus sequence
23
Metagenomic Assembly
  • New uses for shotgun sequencing and assembly
  • Multiple organisms at once,
  • Likely novel organisms.

Problems?
  • Mate-pair data relied on more heavily, since
    overlap coverage is
  • low or unknown,
  • Need verification of assembly somehow?

24
Metagenomic Assembly
  • Created multiple distinct assemblies
  • 98 and 94 homology unitigs
  • non-preassembled end-pairs at various
    stringencies for multiple sequence alignments
  • Multiple assemblies allowed cross-referencing,
  • quality assurance.

25
Taxonomic Assignment
  • Protein-ORF based strategy
  • 5.6 million sequences from GOS
  • All ORFs in same sequence scaffold compared to
  • NCBI protein database using BLAST
  • Votes tallied from each ORF into pools for
    scaffold
  • Archea, Bacteria, Eukaryota, Viral
  • 5.0 million sequence assigned using this
    method

26
Quantitative PCR
  • Quantifying genes in environmental samples
  • from station to station?
  • versus one another?

http//www.invitrogen.com/content.cfm?pageid10037
27
(No Transcript)
28
Clustering and Phylogeny
  • Genes clustered and compared to NCBI
  • Sequence alignments, not just domains
  • Phylogeny trees generated
  • Multiple sequence alignments CLUSTALW
  • Used only long, fairly homologous samples
  • PHYLIP used to build trees
  • Based on difference matrix

29
Phylogenetic Analyses
Figure 2. Phylogenetic trees of all GOS and
publicly available psbA(A) and psbD(B) sequences.
BS indicates bootstrap values. GOS and
public viral sequences are colored aqua and pink
respectively. GOS and public prokaryotic
sequences are navy blue and lime green
respectively. doi10.1371/journal.pone.0001456.g00
2
30
Figure 3. Phylogenetic trees of all GOS and
publicly available pstS(A) and talC(B) sequences.
BS indicates bootstrap values. GOS and public
viral sequences are colored aqua and pink
respectively. GOS and public prokaryotic
sequences are navy blue and lime green
respectively. GOS eukaryotic sequences are
colored yellow. doi10.1371/journal.pone.0001456.g
003
31
Identification of Viral Sequences
  • Data from microbial fraction of water samples was
    examined
  • Looked for viral sequences by comparison to the
    NCBI non-redundant protein database
  • 154,662 viral peptide sequences were identified
  • Approximately 3 of predicted proteins were
    identified as viral sequences
  • Number of viral sequences thought to be largely
    underestimated

32
Classification through Protein Clustering
  • Of 154,662 viral peptide sequences, 117,123 or
    76 fell within 380 protein clusters containing
    at least 20 proteins
  • Remaining sequences fell within clusters
    containing less than 20 proteins
  • Average cluster size contained 258 peptide
    sequences

33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
All viral gene families were positively
correlated with water temperature Some viral
gene families were correlated with salinity,
water depth, and calculated trophic status
indices Different environmental pressures may
influence acquisition of these genes by
viruses Table S7 shows the correlations between
viral gene families and environmental parameters
37
Neighbor Functional Linkage Analysis
  • Used to verify that they were on viral instead of
    pro-viral regions of bacterial genomes
  • Proportion of viral same-scaffold ORFs range from
    32 to 92 for the metabolic gene families
    studied
  • Occurrence of viral neighbors on same scaffolds
    as host-derived viral genes supports hypothesis
    that sources of the sequences are viruses rather
    than bacterial

38
Viruses with Metabolic Genes
  • Through lateral gene transfer, metabolic genes
    can be acquired from the host
  • Acquisition, retention, and expression of
    metabolic genes may increase fitness
  • Key metabolic processes and pathways running
    during infection allows maximum replication
  • Previous studies on host-derived metabolic viral
    genes has been on the photosynthesis genes psbA
    and psbD of a cyanophage
  • Previous studies did not focus on abundance or
    distribution of these genes in the oceans

39
Host-Derived Metabolic Gene Families
  • In aquatic viral communities sampled,
    host-derived genes were found widely distributed
    in significant proportions
  • Quantitative PCR of the these genes confirmed
    high abundance
  • Not known if these genes were expressed at the
    time of sampling
  • Unlikely to see these genes in high abundance if
    they
  • Were not expressed
  • Did not have a fitness advantage

40
Suggests that viruses may play a more
substantial role in environmentally relevant
metabolic processes than previously recognized
such as the conversion of light to energy,
photoadaptation, phosphate acquisition, and
carbon metabolism
41
Discussion
  • Most studies have focused on the filtered viral
    fraction of the data
  • This is the first study to focus on the viral
    components in the microbial fraction of the data
  • Strong evidence for abundance and distribution of
    environmentally important host-derived viral gene
    families
  • Distribution patterns of host-derived viral
    families over environmental gradients
  • Evidence of interactions between bacteriophage
    and host organisms

42
Potential Evolutionary Viral-Host Relationships
  • The study of the cyanophage found that the
    host-derived genes undergo higher mutation rates
    than their cyanobacterial nucleotide counterpart
  • After phage acquisition, the genes could
    diversify
  • Mutated viral genes could form gene reservoirs
    for the host
  • Through horizontal gene transfer, viruses could
    promote diversity and distribution

43
Prochlorococcus P-SSM4-like Phage
  • Prochlorococcus is one of the most widespread
    picophytoplankton in the ocean
  • P-SSM4-like phage may influence the abundance,
    diversity, and distribution of Prochlorococcus
  • Statistically significant relationship between
    the Prochlorococcus and the P-SSM4-like phage

44
Metagenomic Viral-Microbial Interactions
  • This study of viral-microbial association between
    communities was coincidental
  • Horizontal transfer of metabolic genes
  • More studies necessary on the viral-microbial
    diversity and genetic complement
  • Community relationships
  • Evolutionary relationships

45
Any Questions?
