Russ Alger

1
Russ Alger Director - Institute of Snow
Research Keweenaw Research Center Michigan
Technological University In Partnership with
(next slide)
2
(No Transcript)
3
Epoxy Overlay Systems
Epoxy / aggregate overlays are being installed
across the country as a means to seal bridge
decks and apply wear coats. Many bridges in
Michigan have already been sealed.
4
Pavement Sealing
Decreased Corrosion Less Chemical
Infiltration Armored Pavement Surface
5
What is Anti-Icing?

• Anti-Icing practice is an attempt to armor the
  pavement surface prior to a freezing or frozen
  precipitation event by use of freezing point
  depressants.

6
Anti-Icing Can
Eliminate Frost Development Limit Black Ice
Development Minimize Snow Bonding
7
Anti-Icing is Optimized by
Pavement Condition Forecasting Chemical
Types Pavement Interaction
8
Anti-Icing Smart Pavements

• Anti-Icing Smart Pavements are an epoxy overlay
  system that greatly enhances the residual effect
  properties of the pavement. These overlays are
  also excellent seal coats for the pavement
  surface and structure.

9
Click Above to Play Animation
Patent Pending Keweenaw Research Center
10
Advantages
Advantages

• Enhanced Friction
• Pavement Seal
• Less Chemical Used
• Chemical Cost Easier to Overcome
• Less Environmental Effect
• Dry Pavement
• Fewer Call Outs
• Less Reliance on Forecasting

11
Laboratory Frost Testing
12
Normal Washing
13
Field Test at ACY

• 8 by 200 test bed
• Installed by KRC
• Friction tests by FAA
• Natural Snow
• Water misting

14
Chemical Held on Surface ACY
15
Durability
Epoxies have been and are presently being tested
in many states and in many different pavement
scenarios. Aggregates used to date are MI DOT
certified using MTM 111 (Determination of
aggregate wear index.)
Epoxies have been and are presently being tested
in many states and in many different pavement
scenarios. Aggregates used to date are DOT
certified using
16
Enhanced Friction
Mu values along the test bed are consistently
high. FAA Tech Center.
17
Good Results at ACY
18
Easy to Apply
Minimum Pavement Closure
Minimum Pavement Closure
Were working on better equipment to optimize
application.
Were working on better equipment to optimize
application.
19
Set Up Time 2 Hours
20
Blends in Nicelyon Existing Pavement
21
Tough Surface
22
Great Results!!
23
Other Applications
Other Applications
Permanent Pavement Marking Minimize Wet Pavement
Effects Sidewalks
Permanent Pavement Marking Minimize Wet Pavement
Effects Sidewalks
24
The Next Step

• New application equipment
• Field tests in the mix
• Further Surface RD
• More Chemicals

25
Russ Alger Director Institute of Snow
Research Michigan Technological University 1400
Townsend Drive Houghton, MI 49931 phone -
906-487-2498 fax - 906-487-2202 email -
rgalger_at_mtu.edu Web www.mtukrc.org Or
26
Larry Micek Technology Commercialization
Manager Process Solutions Technology Development
Center Cargill, Inc. 2301 Crosby Road Wayzata,
MN  55391-3297 Phone  [phone]
