Title: Possible Bi-directional Switch Configurations


1
High Voltage, High Power, High Frequency
Converters for Industrial Applications
Dr David Cook Power Electronics, Machines and
Control Group
2
Applications of HV PSU
  • High voltage power supplies are used in range of
    medical, scientific, industrial and defence
    applications
  • Treatment of tumours
  • Particles physics research, e.g. CERN, LANL,
    ORNL,
  • Emerging power station technology, e.g. ITER
  • Industrial processing of rock and mineral
  • Radar and EW

3
Conventional Power Supply
High Voltage Rectifier
Filter
Grid Voltage, Line Frequency Transformer
Crowbar
Load
AC LF input
x3
Shunt Thyristor Rectifier
High Voltage, Line Frequency Transformer
4
Why HV, HF?
  • Techniques used at the University of Nottingham
    utilise high frequency (20kHz) resonant circuits.
  • High frequency operation significantly reduces
    the size of the high voltage transformer and
    input/output filters
  • Estimated that 20kHz transformers may are
    approximately 1 the size of line frequency
    counterparts
  • Resonant circuits allow for soft-switching
    (ZVS/ZCS), therefore allowing high power at high
    frequency
  • Allows for highly compact power converter in many
    applications where space and weight are critical

5
Current and RecentResearch Projects
6
Long PulseExisting Technology
  • Disadvantages
  • Very large capacitor bank (energy storage 80kJ)
  • Crowbars Required
  • Large filter components required to limit
    flicker

7
Long PulseExisting Technology
  • Large Utility frequency transformer and
    rectifier
  • Poor input quality
  • Huge DC capacitor bank (need low droop during
    pulse)
  • 2 Crowbars
  • High voltage series switch

8
Long Pulse New Technology direct modulation
(Mike Bland)
9
Long Pulse Converter
Voltage gain / frequency characteristics of
resonant tank
Simulation result
10
Long Pulse Converter Some key features
  • Long Pulse or CW operation
  • High power factor input (low harmonic content)
  • Intelligent recharging of Cdc between shots
    eliminates flicker
  • Soft switching high power, high frequency
    operation
  • HF transformer for reduced size
  • HF multiphase operation gives high ripple
    frequency
  • Small output filter
  • low energy storage small energy dump during
    fault
  • Direct modulation of HF inverter for long pulse
    operation

11
Long Pulse Modulator Assembly
Wave guide
Solenoid
Cathode Voltage Monitor
Magnetron
Input from Pulsed PSU
Control Unit
Auxiliary PSUs
Pulsed PSU (UoN)
Heater Supply
Industrial experimental prototype
12
Long Pulse Modulator Results
Experimental result obtained from operation with
Magnetron load
13
CW Converter
Direct Conversion Approach
CONTROL
3-phase to 1-phase matrix
Resonant tank and transformer
Rectifier filter
Filter
LOAD
AC Supply
14
CW Converter
Resonant tank
Input matrix
Predictive control of resonant tank every ½ cycle
of resonance
Line Filter
S1
S3
S5
AC LF input
Output Filter/Rectifier
S2
S4
S6
HF transformer
Switches S1-S6 commutated when tank current
passes through zero soft switching
Bi-directional switch
15
CW Converter Some Key Features
  • No energy storage
  • Potential for small size
  • CW only
  • Soft switching of matrix
  • High efficiency
  • High power factor input (low harmonic content)
  • High operating frequency
  • Small input filter
  • HF transformer for reduced size
  • Small output filter
  • low energy storage small energy dump during
    fault

16
CW ConverterResults
DC Output Waveform
  • Experimental result
  • Converter producing 25kV DC
  • 25kW Output
  • Simulation result
  • Converter producing 25kV DC
  • 25kW Output

17
CW ConverterResults
Phase Current
  • Experimental result
  • Converter producing 25kV DC
  • 25kW Output
  • Simulation result
  • Converter producing 25kV DC
  • 25kW Output

18
High Efficiency Pulsed Power Supplies (Fabio
Carastro)
  • Scalability and reliability of pulsed power
    supplies utilising IGBTs
  • Thermal cycling of IGBT during pulsed operation
  • Asses reliability implications
  • 250kW (500J) test rig to asses thermal cycling
  • Consider different topologies for high power
    (500kW) units
  • 500kW prototype in construction at partner company

19
Electrostatic Precipitator(Vivek Tailor)
  • Knowledge Partnership with Castlet Ltd.
  • World leader in manufacture of Electro-Static
    Precipitators
  • Used to remove particulate emissions from power
    station exhaust.
  • Existing supplies are based on line-frequency
    approaches
  • Competitors are starting to introduce supplies
    utilising high frequency techniques to the market
  • More responsive
  • Pulsed Operation
  • Can be mounted on the chimney (space saving)

20
Electrostatic Precipitator(Vivek Tailor)
  • 100kV, 2Amp Unit
  • LCC Resonant circuit
  • Phase Control
  • Highly demanding load (short and open circuits)
  • Less stringent power quality and output ripple
    specifications

H-Bridge
High Voltage, High Frequency Transformer
Cockcroft-Walton Multiplier
Resonant Tank (LCC)
21
Ultra Compact Capacitor Charging System
  • Design of a 40kJ/s capacitor charging system for
    high voltage (20kV) applications
  • Ultimate requirement is for minimised converter
    volume / height (100mm)
  • Weight and efficiency are a secondary
    consideration
  • Twin Shot Application Only required to charge
    the output capacitor twice.
  • Then de-activated until converter has cooled
    sufficiently

22
High Power, High Voltage, High Frequency
Transformers for Switching Converters (Todor
Filchev)
  • Follows on from previous PPARC project, Power
    Supplies for High Power RF Systems .
  • Optimal design of the transformer/rectifier was
    identified as a critical component in order to
    fulfil the potential of new converter concepts.
  • In particular a reduction in size, weight and
    cost whilst maintaining reliability.
  • Required to generate the knowledge and confidence
    such that industrial exploitation of compact (HF)
    power converters can become a reality

23
Background to Project
  • Key requirement of emerging high frequency high
    voltage converters is the requirement for step up
    transformers
  • Present knowledge is based on (at best)
    experience at line frequency
  • Many factors influencing transformer design are
    frequency dependant

24
HVHF Transformer
  • Main concern is the HVHF Transformer
  • High voltage insulation requirements (Choice of
    materials is essential)
  • Leakage inductance/stray winding capacitance (LC
    tank interaction)
  • Core loss and heat dissipation (reduced
    efficiency)
  • Rectification and output terminal connections

Equivalent transformer model.
25
  • Thank you
  • Any questions?
