Unified Parallel C

1
Unified Parallel C

• Kathy Yelick
• EECS, U.C. Berkeley and NERSC/LBNL
• NERSC Team Dan Bonachea, Jason Duell, Paul
  Hargrove, Parry Husbands, Costin Iancu, Mike
  Welcome, Christian Bell

2
Outline

• Global Address Space Languages in General
• Programming models
• Overview of Unified Parallel C (UPC)
• Programmability advantage
• Performance opportunity
• Status
• Next step
• Related projects

3
Programming Model 1 Shared Memory

• Program is a collection of threads of control.
• Many languages allow threads to be created
  dynamically,
• Each thread has a set of private variables, e.g.
  local variables on the stack.
• Collectively with a set of shared variables,
  e.g., static variables, shared common blocks,
  global heap.
• Threads communicate implicitly by writing/reading
  shared variables.
• Threads coordinate using synchronization
  operations on shared variables

x ...
Shared
y ..x ...
Private
. . .
Pn
P0
4
Programming Model 2 Message Passing

• Program consists of a collection of named
  processes.
• Usually fixed at program startup time
• Thread of control plus local address space -- NO
  shared data.
• Logically shared data is partitioned over local
  processes.
• Processes communicate by explicit send/receive
  pairs
• Coordination is implicit in every communication
  event.
• MPI is the most common example

send P0,X
recv Pn,Y
Y
X
. . .
Pn
P0
5
Tradeoffs Between the Models

• Shared memory
• Programming is easier
• Can build large shared data structures
• Machines dont scale
• SMPs typically lt 16 processors (Sun, DEC, Intel,
  IBM)
• Distributed shared memory lt 128 (SGI)
• Performance is hard to predict and control
• Message passing
• Machines easier to build from commodity parts
• Can scale (given sufficient network)
• Programming is harder
• Distributed data structures only in the
  programmers mind
• Tedious packing/unpacking of irregular data
  structures

6
Global Address Space Programming

• Intermediate point between message passing and
  shared memory
• Program consists of a collection of processes.
• Fixed at program startup time, like MPI
• Local and shared data, as in shared memory model
• But, shared data is partitioned over local
  processes
• Remote data stays remote on distributed memory
  machines
• Processes communicate by reads/writes to shared
  variables
• Examples are UPC, Titanium, CAF, Split-C
• Note These are not data-parallel languages
• heroic compilers not required

7
GAS Languages on Clusters of SMPs

• Cluster of SMPs (CLUMPs)hb
• IBM SP 16-way SMP nodes
• Berkeley Millennium 2-way and 4-way nodes
• What is an appropriate programming model?
• Use message passing throughout
• Most common model
• Unnecessary packing/unpacking overhead
• Hybrid models
• Write 2 parallel programs (MPI OpenMP or
  Threads)
• Global address space
• Only adds test (on/off node) before local
  read/write

8
Support for GAS Languages

• Unified Parallel C (UPC)
• Funded by the NSA
• Compaq compiler for Alpha/Quadrics
• HP, Sun and Cray compilers under development
• Gcc-based compiler for SGI (Intrepid)
• Gcc-based compiler (SRC) for Cray T3E
• MTU and Compaq effort for MPI-based compiler
• LBNL compiler based on Open64
• Co-Array Fortran (CAF)
• Cray compiler
• Rice and UMN effort based on Open64
• SPMD Java (Titanium)
• UCB compiler available for most machines

9
Parallelism Model in UPC

• UPC uses an SPMD model of parallelism
• A set if THREADS threads working independently
• Two compilation models
• THREADS may be fixed at compile time or
• Dynamically set at program startup time
• MYTHREAD specifies thread index (0..THREADS-1)
• Basic synchronization mechanisms
• Barriers (normal and split-phase), locks
• What UPC does not do automatically
• Determine data layout
• Load balance move computations
• Caching move data
• These are intentionally left to the programmer

10
UPC Pointers

• Pointers may point to shared or private variables
• Same syntax for use, just add qualifier
• shared int sp
• int lp
• sp is a pointer to an integer residing in the
  shared memory space.
• sp is called a shared pointer (somewhat sloppy).

x 3
Shared
sp
sp
sp
Global address space
Private
11
Shared Arrays in UPC

• Shared array elements are spread across the
  threads
• shared int xTHREADS /One element per
  thread /
• shared int y3THREADS / 3 elements per
  thread /
• shared int z3THREADS / 3 elements per
  thread, cyclic /
• In the pictures below
• Assume THREADS 4
• Elements with affinity to processor 0 are red

Of course, this is really a 2D array
x
y
blocked
z
cyclic
12
Overlapping Communication in UPC

• Programs with fine-grained communication require
  overlap for performance
• UPC compiler does this automatically for
  relaxed accesses.
• Accesses may be designated as strict, relaxed, or
  unqualified (the default).
• There are several ways of designating the
  ordering type.
• A type qualifier, strict or relaxed can be used
  to affect all variables of that type.
• Labels strict or relaxed can be used to control
  the accesses within a statement.
• strict x y z y1
• A strict or relaxed cast can be used to override
  the current label or type qualifier.

13
Performance of UPC

• Reason why UPC may be slower than MPI
• Shared array indexing is expensive
• Small messages encouraged by model
• Reasons why UPC may be faster than MPI
• MPI encourages synchrony
• Buffering required for many MPI calls
• Remote read/write of a single word may require
  very little overhead
• Cray t3e, Quadrics interconnect (next version)
• Assuming overlapped communication, the real
  issues is overhead how much time does it take to
  issue a remote read/write?

14
UPC vs. MPI Sparse MatVec Multiply

• Short term goal
• Evaluate language and compilers using small
  applications
• Longer term, identify large application

• Show advantage of t3e network model and UPC
• Performance on Compaq machine worse
• Serial code
• Communication performance
• New compiler just released

15
UPC versus MPI for Edge detection
b. Scalability
a. Execution time

• Performance from Cray T3E
• Benchmark developed by El Ghazawis group at GWU

16
UPC versus MPI for Matrix Multiplication
a. Execution time
b. Scalability

• Performance from Cray T3E
• Benchmark developed by El Ghazawis group at GWU

17
Implementing UPC

• UPC extensions to C are small
• lt 1 person-year to implement in existing compiler
• Simplest approach
• Reads and writes of shared pointers become small
  message puts/gets
• UPC has relaxed keyword for nonblocking
  communication
• Small message performance is key
• Advanced optimizations include conversions to
  bulk communication by either
• Application programmer
• Compiler

18
Overview of NERSC Compiler

• Compiler
• Portable compiler infrastructure (UPC-gtC)
• Explore optimizations communication, shared
  pointers
• Based on Open64 plan to release sources
• Runtime systems for multiple compilers
• Allow use by other languages (Titanium and CAF)
• And in other UPC compilers, e.g., Intrepid
• Performance of small message put/get are key
• Designed to be easily ported, then tuned
• Also designed for low overhead (macros, inline
  functions)

19
Compiler and Runtime Status

• Basic parsing and type-checking complete
• Generates code for small serial kernels
• Still testing and debugging
• Needs runtime for complete testing
• UPC runtime layer
• Initial implementation should be done this month
• Based on processes (not threads) on GASNet
• GASNet
• Initial specification complete
• Reference implementation done on MPI
• Working on Quadrics and IBM (LAPI)

20
Benchmarks for GAS Languages

• EEL End to end latency or time spent sending a
  short message between two processes.
• BW Large message network bandwidth
• Parameters of the LogP Model
• L Latencyor time spent on the network
• During this time, processor can be doing other
  work
• O Overhead or processor busy time on the
  sending or receiving side.
• During this time, processor cannot be doing other
  work
• We distinguish between send and recv overhead
• G gap the rate at which messages can be
  pushed onto the network.
• P the number of processors

21
LogP Parameters Overhead Latency

• Non-overlapping overhead

• Send and recv overhead can overlap

P0
osend
orecv
P1
EEL osend L orecv
EEL f(osend, L, orecv)
22
Benchmarks

• Designed to measure the network parameters
• Also provide gap as function of queue depth
• Measured for best case in general
• Implemented once in MPI
• For portability and comparison to target specific
  layer
• Implemented again in target specific
  communication layer
• LAPI
• ELAN
• GM
• SHMEM
• VIPL

23
Results EEL and Overhead
24
Results Gap and Overhead
25
Send Overhead Over Time

• Overhead has not improved significantly T3D was
  best
• Lack of integration lack of attention in software

26
Summary

• Global address space languages offer alternative
  to MPI for large machines
• Easier to use shared data structures
• Recover users left behind on shared memory?
• Performance tuning still possible
• Implementation
• Small compiler effort given lightweight
  communication
• Portable communication layer GASNet
• Difficulty with small message performance on IBM
  SP platform
