Quaternary Environments Pollen Analysis

1
Quaternary EnvironmentsPollen Analysis
2
Pollen Analysis

• Millions of tons of organic material is dispersed
  into the atmosphere by flowering plants and
  cryptogams every year
• Sedimentation rate is important for fine
  resolution

3
Basis of Pollen Analysis

• Distinct morphology of pollen grains
• Produced in vast quantities by wind-pollinated
  plants
• Extremely resistant to decay
• Reflect natural vegetation

4
Pollen

• 10 150 microns
• Exine Chemically resistant outer layer
• Morphology
• Shape
• Size
• Sculpturing
• Number of apertures

5
(No Transcript)
6
Treatment

• Hydrochloric Acid
• Sulfuric Acid
• Hydrofluoric Acid
• Acetic Anhydride
• Pollen Solution
• Lycopodium Control

7
Pollen Prep and Microscope Work
8
Pollen Morphology
9
(No Transcript)
10
(No Transcript)
11
Catchment

• Preservation sites
• Lakes
• Bogs
• Estuaries
• Alluvial deposits
• Marine sediments
• Glacial ice
• Archaeological sites
• Packrat middens
• Coprolites

12
Scale

• Basin size determines catchment area
• Based on dispersal distance
• Based on pollen productivity
• Different spatial and temporal scales of pollen
  change are driven by different processes

13
(No Transcript)
14
Lake Coring
15
(No Transcript)
16
(No Transcript)
17
Sediment Core
18
Other Factors that Affect Pollen Dispersal

• Fire
• Insect infestation
• Plant successional changes
• Season of pollination
• Interference by humans

19
Under and Over Represented Pollen Types
20
Dispersal Model
21
(No Transcript)
22
Problems

• Differential production
• Wind versus insect or animal pollinated
• Differential preservation
• Populus pollen disintegrates easily
• Number of pollen grains to count
• Greater than 200
• Bioturbation

23
Biostratigraphic Zones

• Biostratigraphic Zone "A biostratigraphic zone
  is defined solely by the fossils it contains,
  without reference to lithology, inferred
  environment, or concepts of time." Code of
  Stratigraphic Nomenclature. Bull.Amer.Assoc.Petrol
  .Geol. 45(5)645-665.

24
(No Transcript)
25
Vegetation versus Modern Pollen
Hickory
Oak
Ash
Elm
26
Callibration

• Compare pollen assemblages to known temperature
  and precipitation
• Develop transfer functions to reconstruct past
  climate

27
(No Transcript)
28
(No Transcript)
29
Pollen Diagram
30
Pollen Diagram from Carp Lake, Oregon
31
Temporal Reconstruction of Temperature and
Precipitation
32
Spatial Reconstruction of Vegetation
33
Isochrones of Vegetation Migration
34
Altitudinal Changes in vegetation zones in the
Eastern Cordillera of Columbia
35
(No Transcript)
