Chemoembolization, Cryotherapy and Microwave Thermotherapy

1
Chemoembolization, Cryotherapy and Microwave
Thermotherapy

• Fred T. Lee Jr., MD
• University of Wisconsin Dept. of Radiology

2

• Chemoembolization
• ChemoembolizationRF
• Cryotherapy
• Microwave thermotherapy
• Comparison of techniques

3
Chemoembolization

• Delivery of concentrated chemotherapy to liver
  via hepatic artery
• Used for hepatocellular carcinoma and metastases
  (lobar or segmental)
• Less systemic side effects than IV chemotherapy

4

• Chemoembolization
• Indications
• Unresectable HCC or liver mets
• Nonsurgical candidates
• Single or multiple lesions
• Palliation/selective prolongation of life

5
ChemoembolizationContraindications

• Total bilirubingt3.5
• Portal Vein Thrombosis
• Active Infection

6
Chemoembolization

• Prep bowel, skin, Abx, steroids, hydration
• Selective, superselective catherization of tumor
  vessels bypass GDA, cystic artery
• Slowly inject cocktail

7
(No Transcript)
8
Wisconsin cocktail

• Cisplatin 100 mg
• Mitomycin C 10 mg
• Adriamycin 50 mg
• Ethiodol 10 cc
• Contrast 8 cc
• Ivalon particles 300-500 µ

McDermott J, Wojtowycz M, Sproat I, Omary
R, Salem R, Wagner HJ
9
Results (many different cocktails, protocols)

• Mets ? response rates, but probably no survival
  advantage. Palliation.
• HCC High local tumor response rates. Probably
  no survival advantage vs. symptomatic rx. Less
  effective than surgery in resectable patients.
• Pelletier. J Hep 1998
• Kanematsu. Cancer 1993

10
Chemoembolization as adjuvant therapy

• Chembo ETOH for HCC
• Chembo ETOH prior to Ltxp
• Chembo RF?
• Tanaka. Radiology 1992
• Lencioni. Radiology 1994
• Troisi. Clin Transpl 1998

11
RF Ablation Why We Fail

• Mets local failures30-50
• Miss lesion
• Cover, but dont kill entire tumor
• Most failures occur in the rim vessels!

12
Cooled-tip electrode Porcine Liver Slice
13
(No Transcript)
14
3-days post
2 months post
Pre-ablation
15
Pre-ablation
5 months post
16
Conventional RF Current Density
tumor
4
Current density1/r
17
Conventional RF Current Density
vessel
tumor
4
Current density1/r
18
(No Transcript)
19
Vessels as cause of RF failures

• Lu DS, RSNA 2000
• Gillams AR, Lees W. RSNA 1999, 2000

20
Better RF Lesion Size/Shape with Vascular
Occlusion

• Bodie AW, Cancer Res 1986
• Goldberg SN, Radiology, JVIR 1998
• Patterson EJ, Ann Surg 1998
• Chinn SB, Lee FT, AJR 2001

21
Decreased local recurrence (19) of HCC with
bland vascular occlusion

• Rossi S, Garbagnati F, Lencioni R, et al.
  Radiology 2000217

22
RF lesion volume with vascular occlusion

• Vessel Volume shape
• None 4.3 cc irreg
• HA 7.6 sltly irreg
• PV 8.6 round
• Pringle 12.6 round

Chinn AJR, 2001
23
Effect of vascular occlusion on lesion size/shape
Hepatic Artery
No Occlusion
24
Effect of vascular occlusion on lesion size/shape
Portal vein
Pringle
25
RF ablationchemoembolizationRationale

• Embo increases size, rounder
• Deposits chemo in tumor, EDGES!
• RF increases dwell time of chemo
• Need long term results

26
RF Chembo RSNA 2001

• Yamakado K
• Pereira P
• Good local control of large HCC

27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
1 month post
4 months post
31
Courtesy Riad Salem, MD
32
Chemoembolization RF ablation
33
(No Transcript)
34
Post Chemoembolization
Post ChemboRF
35
Pre-treatment
Post chemboRF
36
Microwave Coagulation Therapy
37
UW coach's son gets 10 days for parrot's
microwave death Chad Alvarez will begin jail
term on Dec. 20 By Dennis Chaptman of the
Journal Sentinel staff Last Updated Dec. 10,
1999 Madison - The microwave-oven killing of
Iago, a Quaker parrot owned by a fraternity
brother, landed Chad Alvarez two felony
convictions and a sentence of probation and
38
Microwave Coagulation Therapy

• Used in Japan for gt10 years
• No system currently available in the USA
• Microwave field causes tissue heating
• Net effect is much like RF

39
RF ablation
generator
4
Current drop 1/r
2
Heating drop 1/r
40
MCT ablation
generator
No grounding pads necessary
41
RF ablation
Active zone
Several mms
Microwave
2 cm
42
Microwave Coagulation Therapy
43
Microwave vs RF

• Microwave Hotter, possibly faster, multiple
  probes, no ground pads. No USA experience
• RF Available, robust technology, increasing
  lesion size

44
Microwave vs RF
RF
MW
Immediate
45
MW vs. RF
RF
MW
48 Hours
4 Weeks
46
Hepatic Cryoablation

• Very powerful local ablation technique
• Multiple probes can be used together to ablate a
  tumor of virtually any size
• Freezes tissue to app. -150 degrees C.
• Tissue death due to cellular rupture, vascular
  occlusion

47
Cryoablation of liver tumors

• First focal tumor ablation technology
• Performed clinically since the early 1960s
• Combined with IOUS in 1980s (Onik)

48
Courtesy of G. Onik, MD
49
(No Transcript)
50
(No Transcript)
51
In era of RF, is cryo still needed?

• Very powerful. Multiple probes make a large
  iceball in a short period of time, can ablate up
  to large vessels.

52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
4 months post
Precryo
POD 5
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
In era of RF, is cryo still needed?

• Very powerful. Multiple probes make a large
  iceball in a short period of time, can ablate
  adjacent to large vessels.
• Low local recurrence rates

60
Cryoablation Local Recurrence

• Deaconess (Kane) 5-year followup 12
• Wisconsin (Lee) 28 mo f/u 9 Surgical margin
  recurrences 11
• RSNA 97
• J GI Surg, 2001
• RF local recurrence 54 (Livraghi, Radiology 2001)

61
Hepatic Cryoablation
Cryoablation
RF ablation
62
In era of RF, is cryo still needed?

• Very powerful. Multiple probes make a large
  iceball in a short period of time, can ablate
  adjacent to large vessels.
• Low local recurrence rates
• Visualize area being ablated

63
(No Transcript)
64
(No Transcript)
65
In era of RF, is cryo still needed?

• Very powerful. Multiple probes make a large
  iceball in a short period of time, can ablate up
  to large vessels.
• Low local recurrence rates (10 vs 40-50
• Intraoperative Dont miss lesionsgt3mm

66
Precryo
67
Precryo
POD 5
68
Liver cryosurgery

• Laparotomy
• Mini-laparotomy
• Percutaneous

69
Liver cryosurgery

• Laparotomy
• Monitored by IOUS
• Can detect tumorslt3.0 mm
• Often combined with hepatic resection
• Place probes to cover lesion
• margin with iceball

70
(No Transcript)
71
(No Transcript)
72
Cryosurgery at open laparotomy

• Need to mobilize liver for many tumor locations
• Can access virtually any lesion

73
(No Transcript)
74
IVC
IVC
75
Hepatic Cryosurgery Minilaparotomy

• Use transvaginal US transducer
• Small incision, direct puncture of lesion

76
(No Transcript)
77
Laparoscopic vs. Minilaparotomy
78
(No Transcript)
79
Cryosurgery via minilaparotomy
80
Percutaneous CT-guided cryosurgery
81
Percutaneous Cryotherapy
Courtesy Peter J. Littrup, MD
82
Balloon Protection
Courtesy Peter J. Littrup, MD
83
MRI guided Cryotherapy
Courtesy Stuart Silverman, MD
84
Cryoablation - complications (n869 pooled
worlds literature)

• Mortality 1.6
• Hemorrhage 3.9
• Coagulopathy 3.8

• ARF 1.4
• Biloma 2.9

Seifert. J Roy Coll Surg Edin 1998
85
Survival statistics for hepatic cryosurgery
Ref N Med. F/u (mo) Disease-free survival () Alive with disease () Overall survival ()
Ravikumar 32 24 34 28 62
Ravikumar 24 24 29 33.5 62.5
Onik 18 28.8 (mean) 22 67 89
Onik 50 18 (mean) 27 25 52
Zhou 75 60, 120 7.3, 0
Zhou 32 60, 120 48.8, 17.1
HCC gt5.0 cm HCC lt5.0 cm
86
RF vs. Cryo (no trials)
87
2
Cryoablation vs. Resection Survival
1
(20)
88
Followup of cryolesions

• Hole in liver where tumor was
• Enhancing rim for several months
• Eventual shrinkage and scarring

89
1 month post
4 months post
1 year post
90
Cryoablation Complications (n869)

• Mortality1.6
• Hemorrhage 3.9
• Coagulopathy 3.8
• Renal Failure 1.4
• Biloma 2.9

Seifert, J Royal Coll Surg 1998
91
SummaryChemoembolization

• Used alone for palliation of unresectable/unablata
  ble tumor
• Powerful when used in combination with RF

92
Summary Microwave

• Theoretical advantages over RF
• (hotter, faster, multiple probes)
• Extensive experience in Asia, little in USA
• Awaiting optimization of technology

93
Summary Cryoablation

• Very powerful, easy to see (CT,US,MRI)
• Generally used at surgery, emerging percutaneous
  applications
• Probably few more complications than thermal
  ablation

94
Cryoablation vs. RF
Cryo
RF

• Surgery, rare perc
• Very powerful, multiple probes
• Few more comps
• Easy to monitor
• More mature technology

• Perc, rare surgery
• Less powerful
• Less complications
• Tough to monitor
• Rapid technological advances
