Integrating Advanced Algorithms into
Undergraduate Computer Science Curriculum

• Yana Kortsarts
• Widener University
• Computer Science Department

2
Plan

• Randomized Algorithms
• Teaching a Power of Randomization Using a Simple
  Game
• Additional Examples of Advanced Algorithms in
  Undergraduate Computer Science Curriculum

3
Algorithm

• An algorithm is a sequence of instructions for
  solving a problem
• Deterministic Algorithm runs in the same way on
  the same input every time. Deterministic
  algorithm has predicted behavior
• Randomized Algorithm is an algorithm that makes
  random choices during execution

4
Deterministic Algorithm
THE SAME INPUT
THE SAME BEHAIVOR
OUTPUT
5
Randomized Algorithm
THE SAME INPUT
DIFFERENT BEHAIVOR
OUTPUT
6
Why Should We Teach Randomized Algorithms?

• Randomization is a general tool that applies in
  various computer science areas and not just a
  subject by itself.
• Significance many of the breakthroughs in
  various algorithmic areas have used
  randomization.
• Example Prime Number Test
• Simple polynomial one-sided error Monte Carlo
  algorithm Rabin Algorithm (1980)
• A deterministic polynomial time algorithm was
  given by Agarwal, Kayal, and Saxena (2002).

7
Advantages of Randomized Algorithms

• Performance for many problems, randomized
  algorithms run faster than the best known
  deterministic algorithm
• Simplicity many randomized algorithms are
  simpler to describe and implement than
  deterministic algorithms of comparable
  performance.

8
Challenges and Solutions

• The concept of a randomized algorithm can be
  difficult to understand.
• Usually, there is no separate course on
  Randomized Algorithms in undergraduate CS
  curriculum
• The idea of a randomized algorithm is clearer for
  students when presented as a game.
• Topic could be integrated into introductory
  courses

9
Algorithm as Part of the Game
Design of an Algorithm for a Combinatorial Problem
GAME
Algorithm Player
Input Player
Designs the Algorithms
Goal Minimize Running Time of the Algorithm
Goal Maximize Running Time of the Algorithm
Selects Test Input for Selected Algorithm
10
Deterministic Algorithms
Input Player
Algorithm Player
Deterministic Strategy (Deterministic Algorithm)
Best Strategy Finding the Worst Input for the
Algorithm Produced by the Algorithm Player

• Reveals an entire strategy
• (algorithm) first
• Input Player can pick
• the worst example for
• the suggested algorithm

11
Deterministic Algorithms

• The problem facing the algorithm player is that
  if it uses a deterministic strategy, then since
  in a sense it moves first", the second (input)
  player can indeed pick the worst example for the
  suggested algorithm

12
Randomized Algorithms
Input Player
Algorithm Player
Randomized Strategy (Randomized Algorithm)
A bad input for a randomized algorithm
has to be an input which is bad for several
algorithms simultaneously

• Randomized algorithm can be seen
• as a distribution over all possible
• deterministic algorithms
• Doesnt reveal his cards fully in advance
• Tells the second player the probability by
• which it selects any one of the possible
• deterministic algorithms
• The coins have not fallen yet, and the game
• only begins after the input player chooses
• its adversarial input.

13
Game Description

• Player 1 Decides on integer x gt 0
• Player 2 Has to find a number yn so that yn ?
  x
• Rules
• Player 2 y1lt y2lt lt yn
• y1lt y2lt lt yn-1 lt x and yn ? x
• On a guess yj, player 1 either says
• smaller than x, please provide a next guess
• larger or equal x, and reveals x stopping the
  game

14
Optimization Criteria

• Let the guesses be y1, y2, .yn, so that
• yn ? x
• yj lt x for all j n 1
• The optimization criteria is the
• performance ratio

15
EXAMPLE
Player 1
Player 2
x is chosen, please provide a guess
1
Smaller than x, next guess
3
Smaller than x, next guess
10
Smaller than x, next guess
28
Smaller than x, next guess
76
STOP! x 37
Performance Ratio 118 / 37 3.189189
16
EXAMPLE
Player 1
Player 2
x is chosen, please provide a guess
1
Smaller than x, next guess
2
Smaller than x, next guess
3
Smaller than x, next guess
4
Smaller than x, next guess
23
STOP! x 5
Performance Ratio (123423) / 5 6.6
17
Teaching the Game

• Discussion of the Optimization Criteria
  selection
• Why not to choose yi/x, where yi ? x?
• Answer simple strategy 1, 2, 3, is optimal
• Discussion of possible strategies
• Why not to start with some large number?
• Why do we not benefit from increasing the next
  guess only a little compared to the previous
  guess?
• What is the disadvantage of making the next
  guess, say, 100 times larger than previous guess?

18
The Powers of 2 Strategy for the Second Player

• It turns out that the simple strategy that
  selects powers of 2 y0 1, y1 2, y2 4, yi
  2i
• is an optimal deterministic strategy for
  this game
• The worst case for the strategy is when the
  number selected by the first player is x 2j 1

• In this case the game is played until the second
  player suggests 2j1

19
EXAMPLE

• x 13
• guesses 1, 2, 4, 8, 16
• sum 124816 31
• performance ratio is 2.384615
• x 65
• guesses 1, 2, 4, 8, 16, 32, 64, 128
• sum 1248163264128 255
• performance ratio is 3.923

20
The Powers of 2 Strategy Analysis

• The strategy y0 1, y1 2, y2 4, yi 2i
  gives a following performance ratio
• Worst Case x 2j 1, the performance ratio is

21
Teaching the Game

• Encourage students to find by themselves the
  worst case for the powers of 2 strategy.
• This example serves well in illustrating the
  strict notion of the worst case input.
• The bad instance for the powers of 2 strategy is
  a very specific and rare number. (1, 2, 4, 8, 16,
  17, 32)

22
Teaching the Game

• If x is some random number, the powers of 2
  strategy performs much better.
• A good place to discuss the difference between
  random strategy and random inputs.
• The input is sometimes not within our control,
  while the randomized algorithm is within our
  control as the designers of the algorithms.

23
A Deterministic Worst CaseLower Bound

• Let ? gt 0 be a small as desired constant.
• We show that any deterministic strategy has
  examples with performance ratio at least 4 - ?
• The powers of 2 is the optimal deterministic
  strategy.

24
A Randomized Strategy

• The following simple randomized strategy gives an
  improved expected value
• Let ? ?R 0, 1) randomly and uniformly chosen
  from interval 0, 1)
• Define yj ?exp( j ? )?
• Let i be so that ?exp( i - 1 ? )? lt x ?exp( i
  ? )?
• The expected performance ratio is

25
EXAMPLE
Player 1
Player 2
x is chosen, please provide a guess
? 0.419
?exp(?)? 1
Smaller than x, next guess
?exp(?1)? 4
Smaller than x, next guess
?exp(?2)? 11
Smaller than x, next guess
?exp(?3)? 30
Smaller than x, next guess
?exp(?4)? 83
STOP! x 48
Performance Ratio 129 / 48 2.6875
26
EXAMPLE
Player 1
Player 2
x is chosen, please provide a guess
? 0.866
?exp(?)? 2
Smaller than x, next guess
?exp(?1)? 6
Smaller than x, next guess
?exp(?2)? 17
Smaller than x, next guess
?exp(?3)? 47
Smaller than x, next guess
?exp(?4)? 129
STOP! x 63
Performance Ratio 201 / 63 3.190476
27
EXAMPLE
Player 1
Player 2
x is chosen, please provide a guess
? 0.195
?exp(?)? 1
Smaller than x, next guess
?exp(?1)? 3
Smaller than x, next guess
STOP! x 6
?exp(?2)? 8
Performance Ratio 12 / 6 2.0000
28
A Deterministic Worst CaseLower Bound Intuitive
Explanation

• The second player cannot
• choose yi1 to be
• too large compared to yi

If after may times the second player makes such
choices
x yi 1 ltlt yi1 (yi1 yi)/x is already a
large number
For some yj y1y2yj-1 gtgt yj
The second player always selects yi1 to be not
much larger than yi
The choice x yj is bad for second player,
since (y1y2.yj)/yj is large
29
Summary

• Simple game illustrating the power of
  randomization.
• The full analysis of the game is presented in
  Teaching the Power of Randomization Using Simple
  Game, SIGCSE 2006 (Y. Kortsarts, J. Rufinus)
• Teaching the game
• Introduction to Computer Science I and II
• Design and Analysis of Algorithms
• Undergraduate Research Projects

30
Summary

• The game is well-motivated from the point of view
  of modern scheduling research
• Even though this specific game seems not to have
  been studied before, the techniques illustrated
  here have been used in a series of papers on
  approximating scheduling problems 11, 7, 8, 4.
  These papers study the fast scheduling of
  conflicting jobs with the goal of minimizing the
  sum of finish times of these jobs. Hence, the
  suggested game is at the heart of modern research.

31
Advanced Algorithms in Introductory CS Curriculum

• Las Vegas - always gives the correct solution.
• Monte Carlo - may sometimes produce an incorrect
  solution
• How (and why) to Introduce Monte Carlo
  Randomized Algorithms Into a Basic Algorithms
  Course?, Y. Kortsarts, J. Rufinus, Journal of
  Computing Sciences in Colleges, December 2005
• Integrating a real-world scheduling problem into
  the basic algorithms course, Yana Kortsarts,
  Journal of Computing Sciences in Colleges, June
  2007

32
Advanced Algorithms in Introductory CS Curriculum

• Merkle-Hellman Knapsack Cryptosystem 31
• Elegant and beautiful underlying mathematics
• Due to its simple structure, the knapsack
  cryptosystem is an ideal model for introducing
  algorithmic techniques and a concept of Public
  Key cryptosystem to computer science students
• Sequence Alignment 32, 33
• Needleman and Wunsch Algorithm (Global Alignment)
• Smith-Waterman Algorithm (Local Alignment)

33
Knapsack Cryptosystem in Computer Science
Curriculum
Cryptology
Design and Analysis of Algorithms
Introduction to Computer Science
Concept of Public Key Cryptosystem

• Knapsack Problem
• Subset-Sum Problem
• Algorithmic Techniques
• Concept of Public Key
• Cryptosystem

• Computational Problems
• Prime Numbers
• GCD, Euclidian Algorithm
• Modular Exponentiation
• Primitive Roots for Primes

Undergraduate Student Research Projects
34
Sequence Alignment

• Global Alignment compare two sequences in their
  entirety the gap penalty is assessed regardless
  of whether gaps are located internally within a
  sequence, or at the end of one or both sequences.

• The Needleman and Wunsch Algorithm.
• Local Alignment find best matching subsequences
  within the two search sequences.
• The Smith-Waterman Algorithm.

35
REFERENCES

• 1 S. Arora, C. Lund, R. Motwani, M. Sudan and
  M. Szegedy. Proof verication and the hardness of
  approximation problems. Journal of ACM,
  45(3)501-555, 1998.
• 2 G. J. Brebner and L. G. Valiant, Universal
  schemes for parallel communication. Proceedings
  of the thirteenth annual ACM symposium on Theory
  of computing, Pages 263 - 277, 1981
• 3 T. H. Cormen, C. E. Leiserson, and R. L.
  Rivest. Introduction to algorithms. The MIT
  Press, 2nd edition, 2001.
• 4 S. Chakrabarti, C. A. Phillips, A. S. Schulz,
  D. B. Shmoys, C. Stein and J. Wein. Improved
  scheduling algorithms for-minsum criteria. ICALP
  '96, 875-886.
• 5 A. Fiat, R. M. Karp, M. Luby, L. A. McGeoch,
  D. D. Sleator, and N. E. Young, Competitive
  paging algorithms. Journal of Algorithms archive
  Volume 12(4) 685 - 699 1991
• 6 O. Goldreich, S. Micali, and A. Wigderson.
  Proofs that yield nothing but their validity or
  all languages in NP have zero-knowledge proof
  systems. Journal of the ACM, 38(3)690 - 728,
  1991

36
REFERENCES

• 7 L. A. Hall, D. B. Shmoys, and J. Wein.
  Scheduling to minimize average completion time
  O-line and on-line algorithms. SODA'96, 142-151.
  42-151, Jan 1996.
• 8 L. A. Hall, A. Schulz, D. B. Shmoys, and J.
  Wein. Scheduling to minimize average completion
  time O-line nd on-line approximation algorithms.
  Math. Operations Research 22513-544, 1997.
• 9 G. Kalai, A subexponential randomized simplex
  algorithm, Proceedings of the twenty-fourth
  annual ACM symposium on Theory of computing, 475
  - 482, 1992
• 10 R. M. Karp, E. Upfal and A. Wigderson.
  Constructing a perfect matching is in random NC.
  Combinatorica Volume 6(1)35-48, 1986
• 11 M. Queyranne, M. Sviridenko. Approximation
  algorithms for shop scheduling problems with
  minsum objective. J. Scheduling 5287-305, 2002.
• 12 R. L. Rivest, A. Shamir, L. M. Adleman, A
  Method for Obtaining Digital Signatures and
  Public-Key Cryptosystems. Commun. ACM
  21(2)120-126, 1978

37
REFERENCES

• 13 N. Alon and R Yuster and U Zwick.
  Color-coding Journal of the ACM, 42(4)844 - 856
• 14 A. Bjorklund, T. Husfeldt and S. Khanna.
  Approximating Longest Directed Path. Symposium on
  Automata, Languages and Programming (ICALP) 2004,
  to appear.
• 15 D. Dor, U. Zwick, Selecting the Median, SIAM
  J. Comput, 28(5) 1722-1758, 1999.
• 16 D. Dor and U. Zwick, Median Selection
  Requires (2epsilon)n Comparisons, SIAM Journal
  on Discrete Mathematics, 14(3)312-325

38
REFERENCES

• 17 R. W. Floyd and R. L. Rivest Expected time
  bounds for selection Communications of the ACM,
  18(3)165 - 172, 1975.
• 18 T. Feder, R. Motwani, C. Subi. Finding long
  paths and cycles in sparse Hamiltonian graphs
  Proceedings of the ACM symposium on Theory of
  computing, pages 524 - 529, 1999
• 19 H. Gabow, Finding paths and cycles of
  superpolylogarithmic size.
• Proceedings of the ACM symposium on
  Theory of computing, pages 407-416, 2004.
• 20 M. T. Goodrich and R. Tamassia. Using
  randomization in the teaching of data structures
  and algorithms, The proceedings of the thirtieth
  SIGCSE technical symposium on Computer science
  education, 53 - 57, 1999
• 21 D. Karger, R. Motwani, and G.D.S. Ramkumar.
  On Approximating the Longest Path in a Graph.
  Algorithmica 18 (1997) 82-98.

39
REFERENCES

• 22 R. M. Karp. Reducibility among combinatorial
  problems, R. E. Miller and J. W. Thatcher, eds.,
  Complexity of Computer Computations, Plenum
  Press, New York, 1972, pp. 85-103.
• 23 M. O. Rabin Probabilistic algorithm for
  testing primality, J. Number Theory, 12, 128-138,
  1980.
• 24 N. Robertson and P. Seymour, Graph minors.
  II. Algorithmic aspects of tree-width. J.
• Algorithms 7, 1986.
• 25 R. Motwani and P. Raghavan, Randomized
  Algorithms, Cambridge University Press, 1995
• 26 R.M. Karp, An Introduction to randomized
  algorithms, Discrete Applied Mathematics, 34
  165-201, 1991

40
REFERENCES

• 27 D.R.Karger, Global min-cuts in RNC, and
  other ramifications of a simple min-cut
  algorithm, In Proceedings of the 4th Annual
  ACM-SIAM Symposium on Discrete Algorithms, pp.
  21- 30, 1993.
• 28 M. J. Quinn, Parallel Programming in C with
  MPI and OpenMP, McGraw-Hill, 2004
• 29 Y. Kortsarts, J. Rufinus, Teaching the Power
  of Randomization Using Simple Game, SIGCSE 2006
• 30 Y. Kortsarts, J. Rufinus, How (and why) to
  Introduce Monte Carlo Randomized Algorithms Into
  a Basic Algorithms Course?, Journal of Computing
  Sciences in Colleges, 2005

41
REFERENCES

• 31 R. C. Merkle, M. E. Hellman,  Hiding
  Information
• and Signatures in Trapdoor Knapsacks,
  IEEE
• Transactions on Information Theory, vol.
  IT-24, 1978, pp. 525-530.
• 32 An Introduction to Bioinformatics
  Algorithms,
• N.C. Jones and P. A. Pevzner, The MIT
  Press, 2004
• 33 Fundamental Concepts of Bioinformatics,
• D. E. Krane and M . L. Raymer,
  Publisher
• Benjamin Cummings, 2002
