Title: Launching Systems


1
Launching Systems
2
Launching Systems
Purpose To place a weapon into a flight path
as rapidly as the situation
demands.
Requirements
1. Speed 2. Reliability 3. Safety 4.
Compatibility
3
Functions of a Launching System
Storage - Safe and readily accessible until
needed. Transfer - Move from storage to
launcher and back. Loading - Put into
ready to fire position. Control - Direct
and point launcher - Provide Weapons
Orders Launching - Get the weapon away
- Protect ship and people
4
Three Types of Launchers
  • Gravity
  • Impulse
  • Reaction

5
Gravity Type Launchers
  • Slow-moving aircraft turbulence
  • Velocity and Direction from vehicle

6
Impulse Type Launchers
  • Gun-type launchers
  • 5, 16, CIWS
  • Ejector-type
  • Tube launchers Trident, torpedo, TLAM

7
5 Gun
8
CIWS
9
Vulcan Chain Gun
10
16
11
USMC Sniper
12
USMC Deadly Hammer??????
13
Impulse (contd)
  • Ejector -type Launcher
  • Gases created by a high pressure gas system on
    the launching platform.

14
Ejector Type Launching
15
Reaction Type of Launchers
  • Rail
  • Zero Length
  • Canister

16
Mk 13
17
Mk 26 Double Arm Bandit
18
Mk 26 Again
19
F/A - 18
20
(No Transcript)
21
Canister Launchers
  • Launcher and Storage all-in-one!

22
(No Transcript)
23
Harpoon
24
TLAM
25
Questions???
