Replication

1
Chapter 4

• Replication

2
Learning Objectives

• Understand how the nature of a virus genome
  determines its pattern of replication
• Describe a typical, generalized replication cycle
  of a virus
• Compare the patterns of replication of each of
  the seven major virus groups

3
Classification of Viruses

• The way in which viruses are classified has
  altered as our perception of them has changed
• By disease early civilizations
• not good as many have the same symptoms
• By morphology 1930s-1950s
• similar shapes but different clinical symptoms,
  use serology
• Functional classification
• replication strategies

4
Investigation of Virus Replication

• Bacteriophages have long been used by virologists
  as models to understand the biology of viruses
• Two particularly significant experiments which
  illustrate the fundamental nature of all viruses
  were performed on bacteriophages
• Ellis and Delbruck in 1939
• Hershey and Chase in 1952

5
The Single-Burst Experiment or One-Step
Growth Curve

• This was the first experiment to show the three
  essential phases of virus replication
• Initiation of infection
• Replication and expression of the virus genome
• Release of mature virions from the infected cell

6
The Single-Burst Experiment

• Bacteriophages were added to a culture of rapidly
  growing bacteria
• After a few minutes, the culture was diluted,
  preventing further interaction between the phage
  particles and the cells.
• This step synchronizes the infection of the cells
  and allows the subsequent phases of replication
  in a population of individual cells and virus
  particles to be viewed as if it were a single
  interaction.
• Repeated samples of the culture were taken at
  short intervals and analysed for bacterial cells
  by plating onto agar plates and phage particles
  by plating onto lawns of bacteria.

7
The Single-Burst Experiment
8
The Single-Burst Experiment

• There is a stepwise increase in the concentration
  of phage particles with time, each increase
  representing one replicative cycle of the virus
• However, the data from this experiment can also
  by analysed by plotting the number of
  plaque-forming units (p.f.u.) per bacterial cell
  against time

9
Single-Burst Experiment

• Total number of pfu per bacterial cell (dotted
  line)
• Lyse bacteria with chloroform and can determine
  the total number of pfu (solid line)

10
Additional Terms

• Eclipse period 10-15 minutes no phage
  present, virus breaking down and releasing
  genome, not infectious at this tiem
• Latent period 20-25 minutes before start to see
  extracellular particules
• Release/Rise period
• The yield (number) of particles produced per
  infected cell can be calculated from the overall
  rise in phage titer

11
Virus Replication

• Following the development of plaque assays for
  animal viruses in the 1950s, 'single burst'
  experiments have been performed for eukaryote
  viruses
• Major difference between these viruses and
  bacteriophages is the much longer time interval
  required for replication, which is measured in
  terms of hours or days rather than minutes
• difference reflects the slower growth rate of
  eukaryotic cells and the complexity of virus
  replication in compartmentalized cells

12
Eukaryotic Virus Replication
13
Biochemical Analysis of Virus Infection

• Use radioisotopes to follow the rate of growth of
  eukaryotic cells and viruses
• rate of incorporation determines amount of growth

14
The Hershey-Chase Experiment

• Bacteriophage T2 was propagated in Escherichia
  coli cells which had been 'labelled' with one of
  two radioisotopes
• either 35S, which is incorporated into
  sulphur-containing amino acids in proteins
• or 32P, which is incorporated into nucleic acids
  (which do not contain any sulphur)
• Particles labelled in each of these ways were
  used to infect bacteria

15
The Hershey-Chase cont

• After a short period to allow attachment to the
  cells, the mixture was homogenized in a blender
  which did not destroy the bacterial cells but
  removed the phage coats from the outside of the
  cells
• Analysis of the radioactive content in the cell
  pellets and culture supernatant (containing the
  empty phage coats) showed that most of the
  radioactivity in the 35S-labelled particles
  remained in the supernatant, while in the
  32P-labelled particles, most of the radiolabel
  entered the cells

16
Hershey-Chase Experiment
17
The Hershey-Chase Results

• DNA genome of the bacteriophage entered the cells
  and initiated the infection
• indicates that nucleic acid carries the genetic
  information of the phage
• At the time, it was generally believed that
  proteins were the carriers of the genes and that
  DNA was probably a structural component

18
The Replication Cycle
19
The Replication Cycle

• Virus replication can be divided into eight
  arbitrary stages
• regardless of their hosts, all viruses must
  undergo each of these stages in some form to
  complete their replication cycle
• Not all the steps described here are detectable
  as distinct stages for all viruses

20
Attachment

• Virus attachment consists of specific binding of
  a virus-attachment protein (or 'anti-receptor')
  to a cellular receptor molecule
• Target receptor molecules on cell surfaces may be
  proteins (usually glycoproteins), or the
  carbohydrate residues present on glycoproteins or
  glycolipids
• Some complex viruses (e.g. poxviruses,
  herpesviruses) use more than one receptor and
  have alternative routes of uptake into cells

21
Virus Receptors

• Virus receptors fall into many different classes
• immunoglobulin-like superfamily molecules
• membrane-associated receptors
• transmembrane transporters and channels
• Viruses have subverted molecules required for
  normal cellular functions
• Plants enter thru breach, usually caused by
  vector cant penetrate the waxy coat, pectin or
  cell wall

22
Virus Receptors

• Many examples of virus receptors are now known.
• Schematic representation of some virus receptors
• arrows indicate virus attachment site

23
Virus-Receptor Interactions

• The major human rhinovirus (HRV) receptor
  molecule (4), ICAM-1 (intercellular adhesion
  molecule 1), is an adhesion molecule whose normal
  function is to bind cells to adjacent substrates
• ICAM-1 is similar to an immunoglobulin molecule,
  with constant (C) and variable (V) domains
  homologous to those of antibodies and is a member
  of the immunoglobulin superfamily of proteins
• The poliovirus receptor (1) is also a member of
  this family, with one variable and two constant
  domains

24
Virus-Receptor Interactions

• Human rhinoviruses (HRVs) have a deep cleft known
  as the 'canyon' in the surface of each face of
  the capsid
• formed by the flanking monomers, VP1, VP2, and
  VP3
• Interaction between ICAM-1 and the virus particle
  occurs in this canyon
• unlike other areas of the virus surface, the
  amino acid residues forming the internal surfaces
  of the canyon are relatively invariant (same in
  all rhinoviruses)
• also protected from antigenic pressure because
  the antibody molecules are too large to fit into
  the cleft
• Other members of family use low-density
  lipoproteins, vascular cell adhesion molecule-1
  or glycophorin 1
• Picornoviruses use integrins, very-late
  antigen-2, fibronectin, decay accelerating factor

25
Poliovirus Receptor Binding
26
Influenza Virus Receptor Binding

• The influenza haemagglutinin protein (HA) is one
  of two types of glycoprotein spike on the surface
  of influenza virus particles, the other type
  being the neuraminidase protein (NA)
• HA spike is composed of a trimer of three
  molecules, while the NA spike consists of a
  tetramer
• HA spikes are responsible for binding the
  influenza virus receptor, which is sialic acid
  (N-acetyl neuraminic acid)
• result little cell-type specificity imposed by
  this receptor interaction and therefore influenza
  viruses bind to a wide variety of different cell
  types

27
Influenza Virus Receptor Binding
28
Neuraminidase

• Functions to detach virus from cell
• Attachment to cellular receptors is usually
  reversible and influenza may bind inappropriately
  to a variety of cells and cell debris because of
  the sialic acid wide-spread distribution
• Neuraminidase is an esterase which cleaves sialic
  acid from sugar side-chains allows for release
  of virus
• Elution from the cell surface after receptor
  binding has occurred often leads to changes in
  the virus (e.g. loss or structural alteration of
  virus-attachment protein) which decrease or
  eliminate the possibility of attachment to other
  cells

29
Cell Tropism

• The expression of receptors on the surface of
  cells largely determines the tropism of a virus,
  i.e. the type of host cell in which it is able to
  replicate
• This initial stage of replication has a major
  influence on virus pathogenesis and in
  determining the course of a virus infection

30
Multiple Receptors (1)

• In some cases, interactions with more than one
  protein are required for virus entry - neither
  protein alone is a functional receptor
• Adenovirus receptor-binding is a two stage
  process involving an initial interaction of the
  virion fiber protein with a range of cellular
  receptors, including MHC class I molecule and the
  coxsackievirus-adenovirus receptor (CAR)
• Another virion protein, the penton base, then
  binds to the integrin family of cell surface
  heterodimers allowing internalization of the
  particle via receptor-mediated endocytosis
• Most cells express primary receptors for the
  adenovirus fiber coat protein however, the
  internalization step is more selective

31
Multiple Receptors (2)

• The primary receptor for HIV is the T cell
  antigen, CD4
• Transfection of human cells which do not express
  CD4 with recombinant CD4-expression constructs
  makes them permissive for HIV infection
• Transfection of rodent cells with human CD4 does
  not permit productive HIV infection
• If HIV DNA is added to rodent cells by
  transfection, virus is produced - no
  intracellular block to infection
• Several members of a family of proteins known as
  b-chemokine receptors play a role in the entry of
  HIV into cells, and their distribution may be the
  primary control for the tropism of HIV for
  different cell types (lymphocytes, macrophages,
  etc)

32
Accidental Virus Uptake

• Can use pinocytosis, phagocytosis
• usually very low incidence
• Ab coated viruses can be taken up by FC receptor
• important in HIV uptake by macrophages and
  monocytes

33
Penetration

• Penetration of the target cell normally occurs a
  very short time after attachment of the virus to
  its receptor in the cell membrane
• Unlike attachment, cell penetration is generally
  an energy-dependent process, i.e. the cell must
  be metabolically active for this to occur
• Three main mechanisms are involved
• translocation
• endocytosis
• fusion

34
Translocation

• Translocation of the entire virus particle across
  the cytoplasmic membrane of the cell
• Process is relatively rare among viruses and is
  poorly understood
• Mediated by proteins in the virus capsid and
  specific membrane receptors

35
Endocytosis

• Endocytosis of the virus into intracellular
  vacuoles is probably the most common mechanism
• Does not require any specific virus proteins
  (other than those utilized for receptor binding)
  but relies on the formation and internalization
  of coated pits at the cell membrane
• Receptor-mediated endocytosis is an efficient
  process for taking up and concentrating
  extracellular macromolecules

36
Fusion

• Fusion of the virus envelope with the cell
  membrane, either directly at the cell surface or
  in a cytoplasmic vesicle
• Requires the presence of a fusion protein in the
  virus envelope which promotes joining of the cell
  and virus membranes, resulting in the
  nucleocapsid being deposited directly in the
  cytoplasm
• There are two types of virus-driven membrane
  fusion
• pH-dependent
• pH-independent

37
Uncoating

• Uncoating is a general term for the events which
  occur after penetration
• relatively poorly understood
• not aggressively studied
• Product of uncoating depends on the structure of
  the virus nucleocapsid
• picornovirus uses VPg protein attached to viral
  RNA (simple)
• retrovirus is more complex with diploid RNA
• Structure and chemistry of the nucleocapsid
  determines the subsequent steps in replication

38
Poliovirus Penetration and Uncoating

• Linked together
• Acid environment on capsid causes exposure of
  hydrophobic regions with the endosome membrane
  forms a pore for genome to exit

39
Genome Replication and Gene Expression

• All viruses can be divided into seven groups
• Originally, this classification included only six
  groups, but it has since been extended to include
  the hepadnaviruses and caulimoviruses
• For viruses with RNA genomes in particular,
  genome replication and the expression of genetic
  information are inextricably linked, so both are
  taken into account

40
Class I Double-stranded DNA

• 2 subgroups to this class
• Exclusively nuclear replication
• relatively dependent on cellular factors
• Cytoplasm replication such as poxviruses
• evolved (or acquired) all the necessary factors
  for transcription and replication of their
  genomes and are therefore largely independent of
  the cellular machinery

41
Class I Double-stranded DNA
42
Class II Single-stranded DNA

• Replication occurs in the nucleus, involving the
  formation of a double-stranded intermediate which
  serves as a template for the synthesis of
  single-stranded progeny DNA

43
Class III Double-stranded RNA

• These viruses have segmented genomes
• Each segment is transcribed separately to produce
  individual monocistronic mRNAs

44
Class IV ss ()sense RNA

• These can be subdivided into two groups
• Viruses with polycistronic mRNA
• the RNA genome forms the mRNA
• translated to form a polyprotein product, which
  is subsequently cleaved to form the mature
  proteins
• Viruses with complex transcription
• two rounds of translation (e.g. Togavirus) or
  subgenomic RNAs (e.g. Tobamovirus) are necessary
  to produce the genomic RNA

45
Class IV ss ()sense RNA
46
Class V ss ()sense RNA

• The genomes of these viruses can be divided into
  two types
• Non-segmented genomes (order Mononegvirales)
• 1st step is reverse transcription to mRNA and
  then becomes template for new genomes
• some are ambisense
• Segmented genomes (orthomyxoviruses)
• in nucleus
• monocistronic mRNA by viral transcriptase from
  full length

47
Class V ss ()sense RNA
48
Class VI ss ()sense RNA with DNA Intermediate

• Retrovirus genomes are ()sense RNA but unique in
  that they are diploid, and do not serve directly
  as mRNA, but as a template for reverse
  transcription into DNA

49
Class VII Double-stranded DNA with RNA
Intermediate

• Relies on reverse transcription but occurs inside
  the virus particle during maturation
• On infection of a new cell, the first event to
  occur is repair of the gapped genome, followed by
  transcription
• hepadnavirus and cauliomavirus

50
Class VII Double-stranded DNA with RNA
Intermediate
51
Assembly

• Involves the collection of all the components
  necessary for the formation of the mature virion
  at a particular site in the cell
• during assembly, the basic structure of the virus
  particle is formed
• Site of assembly depends on the site of
  replication within the cell and on the mechanism
  by which the virus is eventually released
• in picornaviruses, poxviruses and reoviruses
  assembly occurs in the cytoplasm
• in adenoviruses, polyomaviruses and parvoviruses
  it occurs in the nucleus

52
Maturation

• Stage of the replication-cycle at which the virus
  becomes infectious
• Usually involves structural changes in the virus
  particle which may result from specific cleavages
  of capsid proteins, conformational changes in
  proteins
• Virus proteases are frequently involved in
  maturation, although cellular enzymes or a
  mixture of virus and cellular enzymes are used in
  some cases

53
Release

• Apart from plant viruses which have evolved
  particular strategies to overcome the structure
  of plant cell walls, all other viruses escape the
  cell by one of two mechanisms
• for lytic viruses (most non-enveloped viruses),
  release is a simple process - the infected cell
  breaks open and releases the virus.
• for enveloped viruses - acquire their lipid
  membrane as the virus buds out of the cell
  through the cell membrane or into an
  intracellular vesicle prior to subsequent release
• virion envelope proteins are picked up during
  this process as the virus particle is extruded -
  this process is known as budding

54
Budding
55
Summary

• Virus replication involves three broad stages
  which are carried out by all types of virus
• initiation of infection
• replication and expression of the genome
• release of mature virions from the infected cell
• At a detailed level, there are many differences
  between the replication processes of different
  viruses
• Nevertheless, it is possible to derive an
  overview of virus replication with common stages
  which are followed by all viruses
