Title: Developing a NetCDF-4 Interface to HDF5 Data


1
Developing a NetCDF-4 Interface to HDF5 Data
  • Russ Rew (PI), UCAR Unidata
  • Mike Folk (Co-PI), NCSA/UIUC
  • Ed Hartnett, UCAR Unidata
  • Quincey Kozial, NCSA/UIUC
  • John Caron, UCAR Unidata
  • Robert E. McGrath, NCSA/UIUC

NASA award AIST-02-0071
2
Unidata A Community Endeavor
  • Community of educators and researchers at 120
    universities, 30 other institutions,
    international in scope
  • Managed by the University Corporation for
    Atmospheric Research
  • Mission providing data, tools, support, and
    community leadership for enhanced earth-system
    education and research
  • Atmospheric science community, expanding to
    oceanography, hydrology, other geosciences
  • Unidata Program Center 25 staff, 15 developers

3
Overview
  • What is netCDF? What is HDF5?
  • Why develop a netCDF interface to HDF5?
  • What is the current project status?
  • What still needs to be done?
  • Do we have the necessary resources?
  • What are the prospects for success?

4
NetCDF-3 and HDF5
Ad hoc standards are useful standards
  • Standard Data Models for scientific data and data
    abstractions
  • Standard Interfaces between data providers and
    data users
  • Standard Libraries for data access from various
    languages
  • Standard Formats for portable binary data
  • Users need not know about the format

5
Data Models

netCDF-3 HDF5

Variables Datasets
Dimensions Dataspaces
Attributes Attributes
Coordinates
Element types Datatypes
Groups
Links
References
Property Lists

6
Libraries
7
Formats
8
Other Characterisitics
9
Goals of NetCDF/HDF Combination
  • Create netCDF-4, combining desirable
    characteristics of netCDF-3 and HDF5, while
    taking advantage of their separate strengths
  • Widespread use and simplicity of netCDF-3
  • Generality and performance of HDF5
  • Make netCDF more suitable for high-performance
    computing
  • Provide simple high-level interface for HDF5
  • Demonstrate benefits of combination in advanced
    Earth science modeling efforts

10
NetCDF-4 Features Enabled by HDF5
  • Large file support
  • Parallel I/O
  • Multiple dynamic dimensions
  • Packed data, compression
  • New data types
  • Dynamic schema modifications
  • Other possibilities groups, user-defined types,
    better coordinate support,

11
Approach
  • Implement netCDF-3 over HDF5, to demonstrate
    backward compatibility with
  • Programming interface
  • Format
  • Design netCDF-4 interface
  • Implement netCDF-4 over HDF5 to add enhancements
    made possible with HDF5
  • Foster continued collaboration between Unidata
    and NCSA in design, development, testing, and
    support

12
NetCDF-4 Architecture
  • Access to netCDF-3, netCDF-4, and HDF5 data
    created through netCDF-4 interface

13
User View of NetCDF-4
  • NetCDF-4 library accesses either the netCDF-3 or
    HDF5 library to read or write data

14
Current Technical Status
15
NetCDF-3 Interface Using HDF5
  • 13,000 lines of C code
  • Passes all netCDF-3 tests
  • Demonstrates HDF5 practical for netCDF-4
  • Identifies HDF5 enhancements needed
  • Shows read/write times and file sizes
    satisfactory
  • Validates approach to backward compatibility
  • API compatibility only recompilation and
    relinking needed for existing netCDF-4 programs
  • Format compatibility accesses all current
    netCDF files as well as new HDF5 files
    transparently

16
NetCDF-3 Enhancements for NetCDF-4
  • To provide
  • stable foundation for incorporating netCDF-4
  • smooth transition for current users
  • Automated multi-platform testing
  • Documentation converted to maintainable form, new
    language-independent Users Guide
  • Added large file support with backward
    compatibility
  • Added default format interfaces
  • Better Windows and .Net support

17
HDF5 Additions for Supporting NetCDF-4
  • HDF5 enhancements
  • numeric type conversions
  • zero-dimensional datasets
  • overflow handling improvements
  • flexible parallel I/O
  • HDF5 design specifications
  • dimension scales for coordinate systems
  • shared object proposal

18
Project Schedule
Currently on schedule for a July 2005 release
  • July 2004 version 3.6.0 - revised
    documentation, 64-bit file offsets, default
    format functions
  • October 2004 version 3.7.0 - use of autotools
  • January 2005 version 3.7.1 netCDF-4 prototype
    included, support for multiple unlimited
    dimensions
  • March 2005 version 4.0.0_beta - test relelase
  • July 2005 version 4.0.0 - first netCDF-4
    production release

19
NetCDF-4 Design Issues
  • Issue support for coordinate systems in netCDF
    and HDF5 data models? under consideration
  • Issue addition of HDF5 Groups abstraction to
    netCDF data model? yes, tentatively
  • subset of HDF5 Group features
  • constrained by backward compatibility with
    netCDF-3
  • no Group aliases but try to support Variable
    aliases and Dimension scoping?
  • Issue can we just adopt Northwestern/Argonne
    pnetCDF interface for adding parallel I/O?

20
What remains to be done?
  • Next for netCDF-4 interface additions for
    multiple unlimited dimensions, group interfaces,
    dynamic schema modification, new data types,
    packed data, parallel I/O, compression
  • HDF5 enhancements
  • zero-length attributes
  • shared dimensions
  • creation order access for objects
  • Testing in models (CCSM, WRF, ESMF, ...)

21
Papers, Posters, Presentations
  • R. Rew, M. Folk, E. Hartnett, and R. McGrath
    Plans for an Enhanced NetCDF-4 Interface to HDF5
    Data. HDF/HDF-EOS Workshop VII, Silver Springs,
    September 2003. Poster and presentation.
  • M. Folk, R. Rew, K. Yang, R. McGrath NetCDF-4
    Combining netCDF and HDF5 Data. AGU Fall
    Meeting, San Francisco, December 2003. Poster.
  • R. Rew and E. Hartnett Merging NetCDF and HDF5.
    20th International Conference on Interactive
    Information Processing Systems (IIPS) for
    Meteorology, Oceanography, and Hydrology,
    Seattle, January 2004. Paper and poster.
  • E. Hartnett Merging the NetCDF and HDF5
    Libraries to Achieve Gains in Performance and
    Interoperability. 2004 Earth Science Technology
    Conference, Palo Alto, June 2004. Paper and
    presentation.

22
Excellent Prospects for Success
  • More software engineering than research
  • NetCDF-4 web site just announced
  • www.unidata.ucar.edu/packages/netcdf/netcdf-4/
  • Unidata and NCSA developers collaborating via
    email, teleconferences
  • On schedule for July 2005 release
  • www.unidata.ucar.edu/packages/netcdf/release_sched
    ule.html
  • Great interest in status of project! Ultimate
    goal to make earth science researchers more
    productive ...

23
Questions?
?
?
?
?
?
?
?
