Safety

1
Safety Security WithAnhydrous Ammonia
Ammonium Nitrate

• (presenter name org.)

2
NH3 Chemical and Physical Properties

• pungent, colorless gas
• lighter than air
• water 8.33 lbs/gal
• NH3 5.13 lbs/gal
• liquid under pressure
• -28ºF boiling point
• 1 gallon expands to a vapor cloud 850 gallons
  (113 ft3) in size.

3
NH3 Rescue First Aid

• Injury from
• Dehydration
• Caustic burning
• Freezing body tissue
• Move victim to fresh air
• Apply water to skin (gt20 min)
• Keep patient warm quiet
• Monitor breathing

4
What is Methamphetamine?

• Psycho-stimulant
• Powerful upper
• Affects the central nervous system
• Increases metabolism, heart rate, blood pressure
• Increases body temperature and rate of breathing
• Produces euphoria
• Poor Mans Cocaine

5
(No Transcript)
6
Meth Ingredients

• Ephedrine or Pseudoephedrine (required)
• Anhydrous Ammonia (or Red Phosphorus)
• Ether or Starting Fluid
• Hydrocloric Acid
• Drain Cleaner
• Battery Acid
• Lye
• Lantern Fuel
• Antifreeze

7
What do clandestine labs look like, and why are
they considered extremely dangerous?

• Toxic time bombs
• Highly flammable liquids
• Caustics
• Acids
• Gases
• Explosive

8
What to look for
Unusually large and repetitive purchases or
thefts of

• starter fluid (ether)
• drain cleaner (sulfuric acid)
• lye
• matchbooks (red phosphorus)
• paint thinner
• pseudoephedrine tablets
• cold allergy medicines, like Sudafed
• lithium batteries
• rubbing alcohol, acetone

1 lb of meth creates 6 lbs of hazardous waste!!
9
Anhydrous Ammonia

• 90 of meth labs use it !!
• Thefts at farms and fertilizer dealers/outlets
• Tanks with tampered valves and hoses
• attempts to drill holes in tanks
• theft of entire tanks
• Taped coolers, propane tanks, and other
  containers nearby

10
Tampering of propane tanks
Indicators corrosion around valve tank bloated
or otherwise deformed
11
(No Transcript)
12
Preventing Anhydrous Theft

• Outreach / Education
• Theft deterrents
• locks, lights, fencing, cameras etc.
• Local law enforcement
• Additive research at Iowa State University
• HB 4108 / SB 877 878
• Safety and Security Practices
• Tank Locks and GloTell (HB)
• Liability Tax Credits

13
Preventing Thefts (cont)

• Keep anhydrous tanks on the farm no longer than
  necessary
• Park nurse tanks in a well-lighted area that is
  visible from the road.
• Ask the distributor to install locks which cover
  the valve stem.
• Ask the distributor to use GloTell or similar
  stain product with sticker on tank.

14
GloTell

• New ammonia additive
• Designed to deter theft and detect leaks
• Leaves a pink stain on skin, clothing, meth,
  instruments, etc.
• Detectable up to 7 days
• washed off, detectable under UV light for
  24-72 hours
• 1.5 oz per ton of ammonia

15
If You Find a Meth Lab

• Do not handle the materials.
• Do not confront meth lab operators.
• Call your local law enforcement office
• Or
• Call the Meth Tip hotline at
• 1-866-METH-TIP

16
Legal Requirements with a Spill of Anhydrous
Ammonia gt 19 gal

• MUST CALL IMMEDIATELY !!!!
• County Emergency Management Coordinator 911
• DEQ Pollution Emergency Alert System
• [phone]
• EPA National Response Center
• [phone]
• Fines levied if not reported immediately

17
Ammonium Nitrate (AN) Security
18
What is Ammonium Nitrate?

• Odorless, colorless or while crystal salt
• Produced by the reaction of ammonia and nitric
  acid.
• Strong oxidizing agent
• Agricultural grade
• Nitrogen fertilizer (33 - 34)
• quickly available to plants
• primarily used - West Michigan
• fruit trees, veg crops, no till fields
• Explosive grade
• finer granules than ag grade
• treat titanium ore and make mining explosives

19
(No Transcript)
20
AN Security Concerns

• Criminal Misuse
• associated with at least four terrorist attacks
  over the last 10 years
• Oklahoma City Bombing
• Murrah Federal Building
• Highly reactive product
• Sensitive to heat
• Keep away from combustible and organic material,
  metals.

21
Whats being done?

• Americas Security Begins with You campaign
• Federal legislation
• 2 bills introduced in U.S. Congress
• State legislation
• In 7 states, including Michigan
• AN security legislation was signed into Michigan
  law on July 11, 2005.

22
AN Security Requirements

• Requires retailers to
• Secure ammonium nitrate fertilizer at all times
  against theft or unauthorized access.
• Obtain certain information about the AN sale and
  purchaser.
• Keep records of ammonium nitrate sales for at
  least two years and make them available to MDA
  upon request. Records are exempt from disclosure
  under FOIA.
• Allows retailers the authority to refuse to sell
  AN fertilizer under suspicious circumstances.

23
AN Security Requirements

• Buying AN fertilizer?
• Heres what Michigan retailers will be asking
  for
• Date of sale
• Quantity purchased
• Purchasers drivers license number
• Purchasers name, address, and phone number.
• The agency relationship, if any, between the
  purchaser and the person picking up or accepting
  delivery of the fertilizer.
• Retailers must keep records for 2 years

24
Bureau of Alcohol, Tobacco, Firearms and
Explosives (ATF)

• Know your customer
• Be alert to cash payments, customers who will not
  accept delivery, or do not know the product
• Report suspicious activity, thefts or unexplained
  losses
• ATF Joint Support Operations Center (JSOC)
  1-800-800-3855
• ATF Detroit Field Division 313-259-8050

25
For More Information

• Michigan Department of Agriculture
• Contact April Hunt [phone]
• www.michigan.gov/mda
• Michigan State University Extension
• Contact Mark F. Hansen [phone]
• www.msue.msu.edu/emergency
• Michigan State Police
• Contact Meth Investigation Team [phone]
• www.michigan.gov/meth-response
• www.michigan.gov/meth
• METH Tip Hotline 1-866-METH-TIP
