Team 2: The House Party Blackjack

1
Team 2 The HouseParty Blackjack

• Mohammad Ahmad
• Jun Han
• Joohoon Lee
• Paul Cheong
• Suk Chan Kang

2
Team Members
Hwi Cheong (Paul) hcheong_at_andrew.cmu.edu
Mohammad Ahmad mohman_at_cmu.edu
Joohoon Lee jool_at_ece.cmu.edu
Jun Han junhan_at_andrew.cmu.edu
SukChan Kang sckang_at_andrew.cmu.edu
3
Baseline Application

• Blackjack game application
• User can create tables and play Blackjack.
• User can create/retrieve profiles.
• Configuration
• Operating System Linux
• Middleware Enterprise Java Beans (EJB)
• Application Development Language Java
• Database MySQL
• Servers JBOSS
• J2EE 1.4

4
Baseline Architecture

• Three-tier system
• Server completely stateless
• Hard-coded server name into clients
• Every client talks to HostBean (session)

5
(No Transcript)
6
(No Transcript)
7
Fault-Tolerant Design

• Passive replication
• Completely stateless servers
• No need to transfer states from primary to backup
• All states stored in database
• Only one instance of HostBean (session bean)
  needed to handle multiple client invocations ?
  efficient on server-side
• Degree of replication depends on number of
  available machines
• Sacred machines
• Replication Manager (chess)
• mySQL database (mahjongg)
• Clients

8
Replication Manager

• Responsible for server availability notification
  and recovery
• Server availability notification
• Server notifies Replication Manager during boot.
• Replication Manager pings each available server
  periodically.
• Server recovery
• Process fault pinging fails reboot server by
  sending script to machine
• Machine fault (Crash fault) pinging fails
  sending script does nothing machine has to be
  booted and server has to be manually launched.

9
Replication Manager (contd)

• Client-RM communication
• Client contacts Replication Manager each time it
  fails over
• Client quits when Replication Manager returns no
  server or Replication Manager cant be reached.

10
Evaluation of Performance (without failover)
11
Observable Trend
12
Failover Mechanism

• Server process is killed.
• Client receives a RemoteException
• Client contacts Replication Manager and asks for
  a new server.
• Replication Manager gives the client a new
  server.
• Client remakes invocation to new server
• Replication Manager sends script to recover
  crashed server

13
Failover Experiment Setup

• 3 servers initially available
• Replication Manager on chess
• 30 fault injections
• Client keeps making invocations until 30
  failovers are complete.
• 4 probes on server, 3 probes on client to
  calculate latency

14
Failover Experiment Result
Latency (ms)
Invocation
15
Failover Experiment Results

• Maximum jitter 700ms
• Minimum jitter 300ms
• Average failover time 404ms

16
Failover Pie-chart
Most of latency comes from getting an exception
from server and connecting to the new server
17
Real-time Fault-Tolerant Baseline Architecture
Improvements

• Fail-over time Improvements
• Saving list of servers in client
• Reduces time communicating with replication
  manager
• Pre-creating host beans
• Client will create host beans on all servers as
  soon as it receives list from replication manager
• Runtime Improvements
• Caching on the server side

18
Client-RM and Client-Server Improvements

• Client-RM and Client-Server communication
• Client contacts Replication Manager each time it
  runs out of servers to receive a list of
  available servers.
• Client connects to all servers in the list and
  makes a host beans in them, then starts the
  application with one server
• During each failover, client connects to the next
  server in the list.
• No looping inside list
• Client quits when Replication Manager returns an
  empty list of servers or Replication Manager
  cant be reached.

19
Real-time Server

• Caching in server
• Saves commonly accessed database data in server
• Use Hashmap to map query to previously retrieved
  data.
• O(1) performance for caching

20
Real-time Failover Experiment Setup

• 3 servers initially available
• Replication Manager on chess
• 30 fault injections
• Client keeps making invocations until 30
  failovers are complete.
• 4 probes on server, 5 probes on client to
  calculate latency and naming service time
• Client probes
• Probes around getPlayerName() and getTableName()
• Probes around getHost() for failover
• Server probes
• Record source of invocation name of method
• Record invocation arrival and result return times

21
Real-time Failover Experiment Results
Latency (ms)
Invocation
22
Real-time Failover Experiment Results

• Average failover time 217 ms
• Half the latency without improvements (404 ms)
• Non-failover RTT is visibly lower (shown on
  graphs below)

Before Real-Time Implementation
After Real-Time Implementation
23
Real-time Failover Experiment Results
24
Open Issues

• Blackjack game GUI
• Load-balancing using Replication Manager
• Multiple number of clients per table (JMS)
• Profiling on JBoss to help improve performance
• Generating a more realistic workload
• TimeoutException

25
Conclusions

• What we have accomplished
• Fault-tolerant system with automatic server
  detection and recovery
• Our real-time implementations proved to be
  successful in improving failover time as well as
  general performance
• What we have learned
• Merging code can be a pain.
• A stateless bean are accessed by multiple
  clients.
• State can exist even in stateless beans and is
  useful if accessed by all clients ? cache!
• What we would do differently
• Start evaluation earlier
• Put more effort and time into implementing
  timeouts to enable bounded detection of server
  failure.
