RTP Real-Time Transport Protocol

1
RTPReal-Time Transport Protocol

• Patrick Burke
• Craig Webb

2
Outline

• Introduction
• RTP Network Stack
• Design Goals
• 2 Protocols in 1
• RTP Packet Format
• RTCP Packet Format
• Vulnerabilities

3
Intro / What is RTP?

• RFC 3550/3551 (obsoletes RFC 1889/1890)
• End-to-end delivery for real-time data
• Video/audio conferencing
• Simulations
• VOIP
• Provides functions to support loss, out-of-order,
  jitter, source/payload identification, rate
  control

4
RTP Network Stack

• Closely coupled with the transport layer (usually
  UDP)

5
Design Goals / What it does...

• Lightweight - specification and implementation
• Flexible - provide mechanism, dont dictate
  algorithms
• Protocol-neutral - UDP/IP, ST-II, IPX...
• Scalable - unicast, multicast 2 to O(107)
• Separate data and control - RTP / RTCP
• Separate packets for different media types
• Support for encryption

6
Design Goals / What it doesnt do...

• Ensure timely delivery
• Ensure quality-of-service
• Prevent out-of-order delivery
• Provides mechanisms for detecting/measuring these
  but relies on Transport layer and/or Application.
  Example Relies on UDP checksum service.

7
Separate data and control

• (Two protocols - consecutive UDP ports)
• RTP
• encapsulates data
• adds sequencing, timestamp, source identification
• RTCP (RTP Control Protocol)
• provides control information
• QoS feedback

8
RTP packet header
9
RTP packet header

• Version - currently 2
• Padding - used in encryption
• Extension - used in some implementations
• CSRC count - number of contributing source
  indentifiers (maximum of 15)
• Marker - significant events, defined by
  implementation (i.e. frame boundaries)
• Payload type - audio/video encoding method
• SSRC - synchronization source, randomly generated
  at start of session (no 2 SSRC within the same
  RTP session can have the same identifier)

10
RTP Packet Header

• Sequence number
• Initial value is random,
• Increment by 1 each RTP packet sent
• Loss detection
• Out-of-order detection
• Timestamp
• Used for synchronization
• Allows for QoS feedback (jitter calculations)
• Rate adaptation

11
RTP mixers and translators

• Mixer
• several media streams to one new stream
• becomes the new SSRC
• Translator
• converts data encoding

12
RTCP packet types

• SR - sender report, transmission and reception
  statistics from active members
• RR - receiver report, reception statistics from
  non-active members
• SDES - source description items, CNAME
  (user_at_host) plus any other pertinent info
• BYE - end of participation
• APP - application-specific functions

13
RTCP packet

• Each RTCP packet begins with a fixed part
  followed by structured elements of variable
  length (must end on a 32 bit boundary).
• Stackable within 1 UDP packet.

14
RTCP packet

• Periodically sent from
• Transmitting terminal to receiving terminal
• Receiving terminal to transmitting terminal
• Main functions are
• Rate control
• Membership identification
• QoS tracking

15
Issues and Vulnerabilities

• Theoretical Vulnerabilities
• Security Philosophy
• Documented Vulnerabilities

16
Theoretical Vulnerabilities

• RTP is a relative new-comer
• RFC 1889 approved in 1996
• RFC 3550 approved in 2003
• Functionally identical with 1880
• Updates to rules and algorithms governing how the
  protocol is to be used
• Widely used, but few documented exploitations
  documented to date

17
Theoretical Vulnerabilities

• Theoretically vulnerable to common
  transportation-layer weaknesses
• Denial of Service
• SSRC assumption by unauthorized user
• Packet injection
• Fake content inserted before real
• QoS Bandwidth Attack
• Embedded encryption breakable
• Sometimes KEY transmitted in the clear

18
Security Philosophy

• Network attacks hard to recognize without
  specific knowledge of application
• Targeted communication is high-speed
• Audio/Visual Communicaiton
• Multicast Communication
• Authentication Encryption, where required, are
  implemented at lower layers
• RTCP statistics are available to help
• Physician, heal thyself

19
Documented Vulnerabilities

• Total of 24 patents found referencing RTP
• Only 2 directly relate to RTP
• 6,856,613 Throttling audio packets to
  processing capacity
• 6,728,265 Controlling frame transmission rate
• Remainder merely mention RTP as a recommended or
  suggested transport method

20
Documented Vulnerabilities

• Only 3 documented CERT vulnerabilities
• VU460350 Apple Quicktime Streaming Server
• There is an error in the way Quicktime parses
  DESCRIBE requests containing specially crafted
  User-Agent fields. An attacker could exploit
  this vulnerability by sending a DESCRIBE request
  with an overly large User-Agent field.
• Legitimate users would be blocked from streamed
  content
• Apple released a patch for this condition

21
Documented Vulnerabilities

• CERT vulnerabilities (continued)
• VU148564 Apple Quicktime Streaming Server
• Includes a utility called MP3Broadcaster which
  contains an integer overflow which may be
  exploited to cause a DoS attack.
• No practical solution known by CERT
• Must be prevented by disabling unauthenticated
  remote broadcasts

22
Documented Vulnerabilities

• CERT vulnerabilities (continued)
• VU934932 RealNetworks Helix Universal Server 9
• Contains buffer overflow protection in two
  plug-in modules which has allowed remote
  attackers to execute arbitrary code causing the
  Server to crash
• No practical solution known by CERT
• Must be prevented by removing the associated
  plug-ins vsrcplin and vsrc3260

23
References

• http//www/cs/columbia.edu/hgs/rtp/faq.html
• http//www.kb.cert.org/vuls
• Kurose Ross, Computer Networking, 2003

24
Questions

• What is the main purpose of RTP?
• End-to-end delivery for real-time data
• Video/audio conferencing
• Simulations
• VOIP
• What is the purpose of RTCP?
• Provide RTP control information and QoS feedback

25
Questions

• Why does RTP rely on the applications to provide
  security measures?
• Targeted communication is high-speed
  (Audio/Visual and Multicast) making recognition
  of an attack without specific application
  knowledge difficult.
