Non-linear Neutrino Radiation-Hydrodynamics

1
Data Management Needs for Nuclear-Astrophysical
Simulation at the Ultrascale
2
Characteristics of Nuclear Astrophysical
Simulation Data

• Origin
• Usually from hydrodynamic, MHD, or
  radiation-transport components of a simulation
• Supernova models, neutron-star mergers, etc.
• Disk Access Patterns
• Data written read primarily from structured or
  block-structured AMR grids
• Unstructured grid or particle data is possible
• Writes reads done via parallelized I/O (usually
  MPI-I/O)
• Large number of processes (gt 1024)
• Post run analysis Viz requires accessing
  lengthy sequences of large files

3
Characteristics of Nuclear Astrophysical
Simulation Data

• File Sizes
• Large for both checkpointing and viz dumps
• Currently 1 Gbyte
• Near Future 10s of Gbytes
• File Abundances
• Many (typically 1000s) of files from a single
  batch job
• Especially true for long timescale problems
• File Access Frequency
• Low
• Perhaps only once per run
• Probably will be post-processed/analyzed on
  non-ultrascale platform

4
Problem Sizes

• A typical 2-D multi-group Boltzmann transport
  simulation
• A 3-D multi-group flux-limited diffusion model or
  3-D hydro model checkpoint file _at_ 1024x1204x1024
  resolution will be comparable in size

Scratch vectors
Angular points
Spatial points
256x256 x 50 x 16x16 x (6 8) x 8
100 Gbytes
Bytes/variable
Neutrino species
Energy bins
5
Distributed Set of Computing andAnalysis Sites

• Long round-trip time between sites
• Approx. 75 msec for NERSC to Stony Brook
• Bad for interactive visualization analysis of
  data
• Must use store forward capabilities of
  logisitical networking

6
Networking Challenges

• Movement of large data sets between compute
  user sites
• Needed for post-run analysis, reconstruction, and
  visualization
• A typical 2-D multi-group Boltzmann transport
  simulation
• A 3-D multi-group flux-limited diffusion model
  may produce a
• Terabyte of data

7
Data Management Needs of Ultrascale Nuclear
Astrophysical Simulation Projects

• Parallel I/O
• -Support for portable data formats in data
  storage and data management products tools
• Vendors need to be helpful to developers of these
  formats
• Support HDF5 netCDF
• Specifically must help portable data format
  developers
• -Support parallel HDF5 netCDF interfaces for
  vendor specific MPI-I/O implementations
• -Support for parallel HDF5 netCDF on vendor
  specific parallel filesystems
• -I/O must scale to large ( gt 2048) processors
• Asynchronous I/O support via MPI-2 is highly
  desireable

8
Data Management Needs of Ultrascale Nuclear
Astrophysical Simulation Projects

• Seamless file access across scratch tertiary
  file storage
• Tertiary storage files accessible via Unix paths
  directly from OS
• Enable easy Tbyte data transfer between select
  sites
• Vital for post-run analysis visualization
• Integration of storage with Logistical Networking
  (LBONE) depots
• Increase transfer throughput by use of dedicated
  non-tcp networks to handle scheduled transfers??
• Automated data migration between sites
• Ability to handle large numbers of large files
  from single batch job
• Need lots of scratch space on Ultrascale
  platforms
• Automate migration of files from scratch to
  tertiary storage
• Viz Analysis tools need to be able to handle
  long time- sequences of files from a simulation
