Microsoft Speech Server

1
Microsoft Speech Server 2004
2
Advanced Techniques for Speech Application
Development
Duane Laflotte MCSE, MCSD, MCT, MCPI, MCSA,
MCDBA
3
Who am I?

• Duane Laflotte
• CriticalSites
• dlaflotte_at_criticalsites.com
• Digital Samurai
• Security Department Manager
• Senior Developer Architect
• MCSE, MCSD, MCT, MCPI, MCSA, MCDBA
• Blog http//www.criticalsites.com/dlaflotte

4
Agenda

• Our Sample Application
• Speech Flow Control
• Interaction With Outside Data Sources
• Dynamic Grammars
• Multi-ModalComputer? Hello Computer?
• Design Considerations
• Questions?

5
Our Sample Application

• Blog -
• n a shared on-line journal where people can
  post diary entries about their personal
  experiences and hobbies

6
Demo

• This demonstration will show the blog software we
  use at CriticalSites (dasBlog www.dasblog.net)
  with some custom modifications to allow for
  speech interaction.

7
Agenda

• Our Sample Application
• Speech Flow Control
• Interaction With Outside Data Sources
• Dynamic Grammars
• Multi-ModalComputer? Hello Computer?
• Design Considerations
• Questions?

8
Speech Flow Control

• Client Side
• RunSpeech Its all about Control
• SpeechCommon Object
• SemanticItem Manipulation
• Server Side
• ASP.Net
• SemanticItem Manipulation

9
Client Side RunSpeech

• RunSpeech is the client side object that manages
  dialog flow.
• To change flow you dont interact with RunSpeech
  directly, however, dialog flow is modified by
  changing the state or attributes of semantic
  items being monitored by RunSpeech.
• Some Methods Pause(), Resume(), CurrentCall(),
  EventSource(), OnUserDisconnected()

10
Client Side SpeechCommon

• SpeechCommon allows you to check the state of
  SemanticItems.
• Some Constants SpeechCommon.EMPTY,
  SpeechCommon.NEEDSCONFIRMATION,
  SpeechCommon.CONFIRMED
• (example)
• if (mySemanticItem.state SpeechCommon.CONFIRMED
  )

11
Client Side SemanticItem Manipulation

• SemanticItems hold information gathered from
  users.
• Example siNumberOfShares, siPIN, siAccountNumber
• Some Methods SetText(string, bool), Confirm(),
  Clear(), IsEmpty(), GetAttribute(string),
  SetAttribute(String, object), isConfirmed()
• Some Properties .value, .state, .attributes

12
Show Code

• This demonstration will show how to manipulate
  the dialog flow utilizing client side functions,
  events, and objects.

13
Server Side ASP.Net

• Sometimes it is necessary to retrieve data or
  access other resources that arent available in
  client-side code.
• There are several methods to allow posting of
  data back to the server for processing.
• Page Complete post back
• autoPostBack when value of a SI changes
• autoPostBack when a Command is matched against
  the grammar
• Explicit by calling SpeechCommon.Submit()

14
Server Side SemanticItem Manipulation

• SemanticItems can be interrogated and manipulated
  on the server side as well as the client side.
• Example
• if(siQuantity.State ! Microsoft.Speech.Web.UI.Se
  manticState.Empty)
• siPrice.Text GetPrice(siQuantity.Text)

15
Show Code

• This demonstration will show how to manipulate
  the dialog flow utilizing server side functions,
  events, and objects.

16
Agenda

• Our Sample Application
• Speech Flow Control
• Interaction With Outside Data Sources
• Dynamic Grammars
• Multi-ModalComputer? Hello Computer?
• Design Considerations
• Questions?

17
Interaction With Outside Data Sources

• Relational Databases
• Web Services

18
Speech and Relation Data

• DataTableNavigator
• Web is 2D and great for displaying relational
  data. Voice is 1D which presents a problem
• Built in commands and events help the application
  respond to users (i.e. NVG_previousOnFirstError,
  etc)
• ADO.Net can also be used
• All navigation of the data would need to be
  handled by the developer and not a custom control.

19
Show Code

• This demonstration will show how to retrieve data
  from a database and how to use that dynamic data
  in your dialogs.

20
Speech and Web Services

• You can leverage web services from your speech
  applications
• Pros
• Allows for dynamic, up to the second, data from
  disparate data sources.
• Cons
• Web services leverage the web protocol which
  isnt known for its speed.

21
Demo Show Code

• This demonstration will show how to retrieve data
  from an external web service and use the returned
  response in your dialog.

22
Agenda

• Our Sample Application
• Speech Flow Control
• Interaction With Outside Data Sources
• Dynamic Grammars
• Multi-ModalComputer? Hello Computer?
• Design Considerations
• Questions?

23
Dynamic Grammars

• Pros
• Allows for natural speech interface
• Allows your application utilize responses that
  may be unknown at design time
• Cons
• Doesnt allow you to leverage some of the caching
  features built into Speech Server
• May make your application difficult to debug and
  optimize

24
Example Grammar

• lt!-- Yes._value string ("Yes") --gt
• ltrule id"Yes" scope"public"gt
• ltexamplegt yes lt/examplegt
• ltexamplegt yes please lt/examplegt
• ltexamplegt correct lt/examplegt
• ltexamplegt sure lt/examplegt
• ltexamplegt ok lt/examplegt
• ltitemgt
• ltone-ofgt
• ltitemgt yes lt/itemgt
• ltitemgt yeah lt/itemgt
• ltitemgt yeh lt/itemgt
• ltitemgt ya lt/itemgt
• ltitemgt yup lt/itemgt
• ltitemgt yep lt/itemgt
• ltitemgt indeed lt/itemgt
• ltitemgt positive lt/itemgt
• ltitemgt ok lt/itemgt
• ltitemgt sure lt/itemgt

25
Agenda

• Our Sample Application
• Speech Flow Control
• Interaction With Outside Data Sources
• Dynamic Grammars
• Multi-ModalComputer? Hello Computer?
• Design Considerations
• Questions?

26
Multi-Modality

• No one wants you to read the screen
• Think of this as an opportunity to deliver extra
  content, help around a topic, or to allow for
  mixed initiative interactions.
• Small screen real-estate and/or difficult data
  entry paradigms are perfect candidates!

27
Agenda

• Our Sample Application
• Speech Flow Control
• Interaction With Outside Data Sources
• Dynamic Grammars
• Multi-ModalComputer? Hello Computer?
• Design Considerations
• Questions?

28
Design Considerations

• Less is not more, but sometimes better then more
• We are pleased to
• Im sorry I didnt understand
• Design of VUI must be done upfront
• Design for your users base
• Are most one time callers?
• Should our system be advanced and allow
  Mixed-Initiative responses?
• Is Yes/No really that hard to understand?

29
Questions?
30
Thank You!
