Multithreaded and Distributed Programming -- Classes of Problems

1
Multithreaded and Distributed Programming --
Classes of Problems

• ECEN5053 Software Engineering of
• Distributed Systems
• University of Colorado

Foundations of Multithreaded, Parallel, and
Distributed Programming, Gregory R. Andrews,
Addison-Wesley, 2000
2
The Essence of Multiple Threads -- review

• Two or more processes that work together to
  perform a task
• Each process is a sequential program
• One thread of control per process
• Communicate using shared variables
• Need to synchronize with each other, 1 of 2 ways
• Mutual exclusion
• Condition synchronization

3
Opportunities Challenges

• What kinds of processes to use
• How many parts or copies
• How they should interact
• Key to developing a correct program is to ensure
  the process interaction is properly synchronized

4
Focus in this course

• Imperative programs
• Programmer has to specify the actions of each
  process and how they communicate and synchronize.
  (Java, Ada)
• Declarative programs (not our focus)
• Written in languages designed for the purpose of
  making synchronization and/or concurrency
  implicit
• Require machine to support the languages, for
  example, massively parallel machines.
• Asynchronous process execution
• Shared memory, distributed memory, networks of
  workstations (message-passing)

5
Multiprocessing monkey wrench

• The solutions we addressed last semester presumed
  a single CPU and therefore the concurrent
  processes share coherent memory
• A multiprocessor environment with shared memory
  introduces cache and memory consistency problems
  and overhead to manage it.
• A distributed-memory multiprocessor/multicomputer/
  network environment has additional issues of
  latency, bandwidth, administration, security, etc.

6
Recall from multiprogram systems

• A process is a sequential program that has its
  own thread of control when executed
• A concurrent program contains multiple processes
  so every concurrent program has multiple threads,
  one for each process.
• Multithreaded usually means a program contains
  more processes than there are processors to
  execute them
• A multithreaded software system manages multiple
  independent activities

7
Why write as multithreaded?

• To be cool ? (wrong reason)
• Sometimes, it is easier to organize the code and
  data as a collection of processes than as a
  single huge sequential program
• Each process can be scheduled and executed
  independently
• Other applications can continue to execute in
  the background

8
Many applications, 5 basic paradigms

• Iterative parallelism
• Recursive parallelism
• Producers and consumers (pipelines)
• Clients and servers
• Interacting peers
• Each of these can be accomplished in a
  distributed environment. Some can be used in a
  single CPU environment.

9
Iterative parallelism

• Example?
• Several, often identical processes
• Each contains one or more loops
• Therefore each process is iterative
• They work together to solve a single program
• Communicate and synchronize using shared
  variables
• Independent computations disjoint write sets

10
Recursive parallelism

• One or more independent recursive procedures
• Recursion is the dual of iteration
• Procedure calls are independent each works on
  different parts of the shared data
• Often used in imperative languages for
• Divide and conquer algorithms
• Backtracking algorithms (e.g. tree-traversal)
• Used to solve combinatorial problems such as
  sorting, scheduling, and game playing
• If too many recursive procedures, we prune.

11
Producers and consumers

• One-way communication between processes
• Often organized into a pipeline through which
  info flows
• Each process is a filter that consumes the output
  of its predecessor and produces output for its
  successor
• That is, a producer-process computes and outputs
  a stream of results
• Sometimes implemented with a shared bounded
  buffer as the pipe, e.g. Unix stdin and stdout
• Synchronization primitives flags, semaphores,
  monitors

12
Clients Servers

• Producer/consumer -- one-way flow of information
• independent processes with own rates of progress
• Client/server relationship is most common pattern
• Client process requests a service waits for
  reply
• Server repeatedly waits for a request then acts
  upon it and sends a reply.
• Two-way flow of information

13
Distributed procedures and calls

• Client and server relationship is the concurrent
  programming analog of the relationship between
  the caller of a subroutine and the subroutine
  itself.
• Like a subroutine that can be called from many
  places, the server has many clients.
• Each client request must be handled independently

• Multiple requests might be handled concurrently

14
Common example

• Common example of client/server interactions in
  operating systems, OO systems, networks,
  databases, and others -- reading and writing a
  data file.
• Assume file server module provides 2 ops read
  and write client process calls one or other.
• Single CPU or shared-memory system
• File server implemented as set of subroutines and
  data structures that represent files
• Interaction between client process and a file
  typically implemented by subroutine calls

15
Client/Server example

• If the file is shared
• Probably must be written to by at most one client
  process at a time
• Can safely be read concurrently by multiple
  clients
• Example of what is called the readers/writers
  problem

16
Readers/Writers -- many facets

• Has a classic solution using mutexes (in chapter
  2 last semester) when viewed as a mutual
  exclusion problem
• Can also be solved with
• a condition synchronization solution
• different scheduling policies
• Distributed system solutions include
• with encapsulated database
• with replicated files
• just remote procedure calls local
  synchronization
• just rendezvous

17
Consider a query on the WWW

• A user opens a new URL within a Web browser
• The Web browser is a client process that executes
  on a users machine.
• The URL indirectly specifies another machine on
  which the Web page resides.
• The Web page itself is accessed by a server
  process that executes on the other machine.
• May already exist may be created
• Reads the page specified by the URL
• Returns it to the clients machine
• Addl server processes may be visited or created
  at intermediate machines along the way

18
Clients/Servers -- on same or separate

• Clients are processes regardless of machines
• Server
• On a shared-memory machine is a collection of
  subroutines
• With a single CPU, programmed using
• mutual exclusion to protect critical sections
• condition synchronization to ensure subroutines
  are executed in appropriate orders
• Distributed-memory or network -- processes
  executing on different machine than clients
• Often multithreaded with one thread per client

19
Communication in client/server app

• Shared memory --
• servers as subroutines
• use semaphores or monitors for synchronization
• Distributed --
• servers as processes
• communicate with clients using
• message passing
• remote procedure call (remote method inv.)
• rendezvous

20
Interacting peers

• Occurs in distributed programs, not single CPU
• Several processes that accomplish a task
• executing the copies of same code (hence,
  peers)
• exchanging messages
• example distributed matrix multiplication
• Used to implement
• Distributed parallel programs including
  distributed versions of iterative parallelism
• Decentralized decision making

21
Among the 5 paradigms are certain characteristics
common to distributed environments.Distributed
memoryProperties of parallel applicationsConcurr
ent computation
22
Distributed memory implications

• Each processor can access only its own local
  memory
• Program cannot use global variables
• Every variable must be local to some process or
  procedure and can be accessed only by that
  process or procedure
• Processes have to use message passing to
  communicate with each other

23
Example of a parallel application

• Remember concurrent matrix multiplication in a
  shared memory environment -- last semester?
• Sequential solution first
• for i 0 to n-1
• for j 0 to n-1
• compute inner product of ai, and b,
  j
• ci, j 0.0
• for k 0 to n-1
• ci, j ci, j ai, k bk, j

24
Properties of parallel applications

• Two operations can be executed in parallel if
  they are independent.
• Read set contains variables it reads but does not
  alter
• Write set contains variables it alters (and
  possibly also reads)
• Two operations are independent if the write set
  of each is disjoint from both the read and write
  sets of the other.

25
Concurrent computation

• Computing rows of result-matrix in parallel.
• cobegin i 0 to n-1
• for j 0 to n-1
• ci, j 0.0
• for k 0 to n-1
• ci, j ci, j ai, k bk, j
• coend

26
Differences sequential vs. concurrent

• Syntactic
• cobegin is used in place of for in the outermost
  loop
• Semantic
• cobegin specifies that its body should be
  executed concurrently -- at least conceptually --
  for each value of index i.

27

• Previous example implemented matrix
  multiplication using shared variables
• Now -- two ways using message passing as means of
  communication
• 1. Coordinator process array of independent
  worker processes
• 2. Workers are peer processes that interact by
  means of a circular pipeline

28
Worker 0
Worker n-1
Results
data
data
Coordinator
...
Worker n-1
Worker 0
Peers
29

• Assume n processors for simplicity
• Use an array of n worker processes, one worker on
  each processor, each worker computes one row of
  the result matrix
• process workeri 0 to n-1
• double an row i of matrix a
• double bn,n all of matrix b
• double cn row i of matrix c
• receive initial values for vector a and
  matrix b
• for j 0 to n-1
• cj 0.0
• for k 0 to n-1
• cj cj ak bk, j send result
  c to coord

30

• Aside -- if not standalone
• The source matrices might be produced by a prior
  computation and the result matrix might be input
  to a subsequent computation.
• Example of distributed pipeline.

31
Role of coordinator

• Initiates the computation and gathers and prints
  the results.
• First sends each worker the appropriate row of a
  and all of b.
• Waits to receive row of c from every worker.

32

• process coordinator
• source matrix a, b, and c are declared
• initialize a and b
• for i 0 to n-1
• send row i of a to worker i
• send all of b to worker i
• for i 0 to n-1
• receive row i of c from worker i
• print results which are now in matrix c

33
Message passing primitives

• Send packages up a message and transmits it to
  another process
• Receive waits for a message from another process
  and stores it in local variables.

34
Peer approach

• Each worker has one row of a is to compute one
  row of c
• Each worker has only one column of b at a time
  instead of the entire matrix
• Worker i has column i of matrix b.
• With this much source data, worker i can compute
  only the result for ci, i.
• For worker i to compute all of row i of matrix c,
  it must acquire all columns of matrix b.
• We circulate the columns of b among the worker
  processes via the circular pipeline
• Each worker executes a series of rounds in which
  it sends its column of b to the next worker and
  receives a different column of b from the
  previous worker

35

• See handout
• Each worker executes the same algorithm
• Communicates with other workers in order to
  compute its part of the desired result.
• In this case, each worker communicates with just
  two neighbors
• In other cases of interacting peers, each worker
  communicates with all the others.

36
Worker algorithm
Process worker I 0 to n-1 double an
row i of matrix a double bn one column
of matrix b double cn row i of matrix
c double sum 0.0 storage for inner
products int nextCol i next column of results
37
Worker algorithm (cont.)
receive row i of matrix a and column i of matrix
b compute ci,i ai, x b,i for k 0
to n-1 sum sum ak bk cnextCol
sum circulate columns and compute rest of
ci, for j 1 to n-1 send my column of
b to next worker receive a new column of b
from previous worker
38
Worker algorithm (cont. 2)

• sum 0.0
• for k 0 to n-1
• sum sum ak bk
• if (nextCol 0)
• nextCol n-1
• else
• nextCol nextCol 1
• cnextCol sum
• send result vector c to coordinator process

39
Comparisons

• In first program, values of matrix b are
  replicated
• In second, each has one row of a and one column
  of b at any point in time -
• First requires more memory but executes faster.
• This is a classic time/space tradeoff.

40
Summary

• Concurrent programming paradigms in a
  shared-memory environment
• Iterative parallelism
• Recursive parallelism
• Producers and consumers
• Concurrent programming paradigms in a
  distributed-memory environment
• Client/server
• Interacting peers

41
Shared-memory programming
42
Shared-Variable Programming

• Frowned on in sequential programs, although
  convenient (global variables)
• Absolutely necessary in concurrent programs
• Must communicate to work together

43
Need to communicate

• Communication fosters need for synchronization
• Mutual exclusion need to not access shared data
  at the same time
• Condition synchronization one needs to wait for
  another
• Communicate in distributed environment via
  messages, remote procedure call, or rendezvous

44
Some terms

• State values of the program variables at a
  point in time, both explicit and implicit. Each
  process in a program executes independently and,
  as it executes, examines and alters the program
  state.
• Atomic actions -- A process executes sequential
  statements. Each statement is implemented at the
  machine level by one or more atomic actions that
  indivisibly examine or change program state.
• Concurrent program execution interleaves
  sequences of atomic actions. A history is a
  trace of a particular interleaving.

45
Terms -- continued

• The next atomic action in any ONE of the
  processes could be the next one in a history. So
  there are many ways actions can be interleaved
  and conditional statements allow even this to
  vary.
• The role of synchronization is to constrain the
  possible histories to those that are desirable.
• Mutual exclusion combines atomic actions into
  sequences of actions called critical sections
  where the entire section appears to be atomic.

46
Terms continued further

• Property of a program is an attribute that is
  true of every possible history.
• Safety never enters a bad state
• Liveness the program eventually enters a good
  state

47
How can we verify?

• How do we demonstrate a program satisfies a
  property?
• A dynamic execution of a test considers just one
  possible history
• Limited number of tests unlikely to demonstrate
  the absence of bad histories
• Operational reasoning -- exhaustive case
  analysis
• Assertional reasoning abstract analysis
• Atomic actions are predicate transformers

48
Assertional Reasoning

• Use assertions to characterize sets of states
• Allows a compact representation of states and
  their transformations
• More on this later in the course

49
Warning

• We must be wary of dynamic testing alone
• it can reveal only the presence of errors, not
  their absence.
• Concurrent and distributed programs are difficult
  to test debug
• Difficult (impossible) to stop all processes at
  once in order to examine their state!
• Each execution in general will produce a
  different history

50
Why synchronize?

• If processes do not interact, all interleavings
  are acceptable.
• If processes do interact, only some interleavings
  are acceptable.
• Role of synchronization prevent unacceptable
  interleavings
• Combine fine-grain atomic actions into
  coarse-grained composite actions (we call this
  ....what?)
• Delay process execution until program state
  satisfies some predicate

51

• Unconditional atomic action
• does not contain a delay condition
• can execute immediately as long as it executes
  atomically (not interleaved)
• examples
• individual machine instructions
• expressions we place in angle brackets
• await statements where guard condition is
  constant true or is omitted

52

• Conditional atomic action - await statement with
  a guard condition
• If condition is false in a given process, it can
  only become true by the action of other
  processes.
• How long will the process wait if it has a
  conditional atomic action?

53
How to implement synchronization

• To implement mutual exclusion
• Implement atomic actions in software using locks
  to protect critical sections
• Needed in most concurrent programs
• To implement conditional synchronization
• Implement synchronization point that all
  processes must reach before any process is
  allowed to proceed -- barrier
• Needed in many parallel programs -- why?

54
Desirable Traits and Bad States

• Mutual exclusion -- at most one process at a time
  is executing its critical section
• its bad state is one in which two processes are
  in their critical section
• Absence of Deadlock (livelock) -- If 2 or more
  processes are trying to enter their critical
  sections, at least one will succeed.
• its bad state is one in which all the processes
  are waiting to enter but none is able to do so
• two more on next slide

55
Desirable Traits and Bad states (cont.)

• Absence of Unnecessary Delay -- If a process is
  trying to enter its c.s. and the other processes
  are executing their noncritical sections or have
  terminated, the first process is not prevented
  from entering its c.s.
• Bad state is one in which the one process that
  wants to enter cannot do so, even though no other
  process is in the c.s.
• Eventual entry -- process that is attempting to
  enter its c.s. will eventually succeed.
• liveness property, depends on scheduling policy

56
Logical property of mutual exclusion

• When process1 is in its c.s., set property1 true.
• Similarly, for process2 where property2 is true.
• Bad state is where property1 and property2 are
  both true at the same time
• Therefore
• want every state to satisfy the negation of the
  bad state --
• mutex NOT(property1 AND property2)
• Needs to be a global invariant
• True in the initial state and after each event
  that affects property1 or property2
• ltawait (!property2) property1 truegt

57
Coarse-grain solution
bool property1 false property2
false COMMENT mutex NOT(property1 AND
property2) -- global invariant

• process process1
• while (true)
• ltawait (!property2) property1 truegt
• critical section
• property1 false
• noncritical section

• process process2
• while (true)
• ltawait (!property1) property2 truegt
• critical section
• property2 false
• noncritical section

58
Does it avoid the problems?

• Deadlock if each process were blocked in its
  entry protocol, then both property1 and property2
  would have to be true. Both are false at this
  point in the code.
• Unnecessary delay One process blocks only if
  the other one is not in its c.s.
• Liveness -- see next slide

59
Liveness guaranteed?

• Liveness property -- process trying to enter its
  critical section eventually is able to do so
• If process1 trying to enter but cannot, then
  property2 is true
• therefore process2 is in its c.s. which
  eventually exits making property2 false allows
  process1s guard to become true
• If process1 still not allowed entry, its because
  the scheduler is unfair or because process2 again
  gains entry -- (happens infinitely often?)
• Strongly-fair scheduler required, not likely.

60
Three spin lock solutions

• A spin lock solution uses busy-waiting
• Ensure mutual exclusion, are deadlock free, and
  avoid unnecessary delay
• Require a fairly strong scheduler to ensure
  eventual entry
• Do not control the order in which delayed
  processes enter their c.s.s when gt 2 try
• Busy-waiting solutions were tolerated on a single
  CPU when the critical section was bounded.
• What about busy-waiting solutions in a
  distributed environment? Is there such a thing?

61
Distributed-memory programming
62
Distributed-memory architecture

• Synchronization constructs we examined last
  semester were based on reading and writing shared
  variables.
• In distributed architectures, processors
• have their own private memory
• interact using a communication network
• without a shared memory, must exchange messages

63
Necessary first stepsto write programs for a
dist.-memory arch.

• 1. Define the interfaces with the communication
  network
• If they were read and write ops like those that
  operate on shared variables,
• Programs would have to employ busy-waiting
  synchronization. Why?
• Better to define special network operations that
  include synchronization -- message passing
  primitives

64
Necessary first stepsto write programs for a
dist.-memory arch. cont.

• 2. Message-passing is extending semaphores to
  convey data as well as to provide synchronization
• 3. Processes share channels - a communication
  path

65
Characteristics

• Distributed program may be
• distributed across the processors of a
  distributed-memory architecture
• can be run on a shared-memory multiprocessor
• (Just like a concurrent program can be run on a
  single, multiplexed processor.)
• Channels are the only items that processes share
  in a distributed program
• Each variable is local to one process

66
Implications of no shared variables

• Variables are never subject to concurrent access
• No special mechanism for mutual exclusion is
  required
• Processes must communicate in order to interact
• Main concern of distributed programming is
  synchronizing interprocess communication
• How this is done depends on the pattern of
  process interaction

67
Patterns of process interaction

• Vary in way channels are named and used
• Vary in way communication is synchronized
• Well look at asynchronous and synchronous
  message passing, remote procedure calls, and
  rendezvous.
• Equivalent a program written using one set of
  primitives can be rewritten using any of the
  others
• However message passing is best for programming
  producers and consumers and interacting peers
• RPC and rendezvous best for programming clients
  and servers

68
How related
Busy waiting
Semaphores
Message passing
Monitors
Rendezvous
RPC
69
Match Exampleswith Paradigms and Process
Interaction categories

• ATM
• Web-based travel site
• Stock transaction processing system
• Search service
