Imbibition Assisted Recovery

1
Imbibition Assisted Recovery

• Orkhan H Pashayev
• Petroleum Engineering Department
• Texas AM University

February 2004
Masters Division
2
Presentation Outline

• Introduction
• Problem Statement
• Background and Literature Review
• Objectives
• Numerical Modeling
• Grid Sensitivity
• Matching Experimental Results
• Numerical Analyses of Spontaneous Imbibition
• Imbibition Upscaling
• Conclusions

February 2004
Imbibition Assisted Recovery
3
Problem Statement

• An understanding the role of imbibition in
  Naturally Fractured Reservoirs in order to
  achieve maximum recovery
• Lack of knowledge in upscaling laboratory
  imbibition experiments to field dimensions

February 2004
Imbibition Assisted Recovery
4
Background and Literature Review

• Two methods of modeling Naturally Fractured
  Reservoirs
• Numerical model with sufficiently refined grid to
  adequately represent matrix/fracture geometry
• Dual Porosity Model (Warren and Root, 1963)

February 2004
Imbibition Assisted Recovery
5
Background and Literature Review

• Expulsion of oil from matrix block to the
  surrounding fractures by capillary imbibition of
  water is the most important oil recovery in
  Naturally Fractured Reservoirs

February 2004
Imbibition Assisted Recovery
6
Background and Literature Review

• Transfer Functions
• Transfer functions that use Darcys Law
• Diffusivity transfer functions
• Empirical transfer functions
• Scaling transfer functions

February 2004
Imbibition Assisted Recovery
7
Background and Literature Review

• Scaling transfer functions
• Rapoport (1952)
• Graham and Richardson (1959), Mattax and Kyte
  (1962)
• Hamon and Vidal (1986), Bourblaux and Kalaidjian
  (1995), Akin and Kovsek (1998), etc
• Du Prey (1978), Kazemi (1992), Ma et.al (1996),
  etc

February 2004
Imbibition Assisted Recovery
8
Objectives

• Conduct numerical studies with matrix block
  surrounded by fractures to better understand the
  characteristic of spontaneous imbibition
• Evaluate dimensionless time tD and investigate
  the limitations of the upscaling laboratory
  imbibition experiments to field dimensions

February 2004
Imbibition Assisted Recovery
9
Presentation Outline

• Introduction
• Problem Statement
• Background and Literature Review
• Objectives
• Numerical Modeling
• Grid Sensitivity
• Matching Experimental Results
• Numerical Analyses of Spontaneous Imbibition
• Imbibition Upscaling
• Conclusions

February 2004
Imbibition Assisted Recovery
10
Simulation Parameters

• Two phase black-oil commercial simulator, CMG
• Core 3.2cm x 3.2cm x 4.9cm
• K 74.7
• SWi 41.61
• F 15.91
• µOIL 3.52 cp
• µWATER 0.68 cp
• APIOIL 31

February 2004
Imbibition Assisted Recovery
11
Grid Sensitivity Analyses

• Cartesian grid system

Simulation Run No. of gridblocks in I, J and K directions No. of gridblocks in I, J and K directions No. of gridblocks in I, J and K directions Total No. of gridblocks
Simulation Run I - Direction J - Direction K - Direction Total No. of gridblocks
1 7 7 7 343
2 12 12 12 1,728
3 16 16 16 4,096
4 20 20 20 8,000
5 20 20 25 10,000
February 2004
Imbibition Assisted Recovery
12
Grid Sensitivity Analyses

February 2004
Imbibition Assisted Recovery
13
Grid Sensitivity Analyses

February 2004
Imbibition Assisted Recovery
14
Grid Sensitivity Analyses

10000
8000
4096
1728
February 2004
Imbibition Assisted Recovery
15
Reservoir Grid

• I 20, J 20, K 20
• No. of gridblocks 8000
• Grid dimensions
• I 1x0.01cm 18x0.178cm 1x0.01cm
• J1x0.01cm 18x0.178cm 1x0.01cm
• K1x0.01cm 19x0.259cm

February 2004
Imbibition Assisted Recovery
16
Matching Experimental Results

February 2004
Imbibition Assisted Recovery
17
Matching Experimental Results

• The following logarithmic capillary pressure
  relationship was used

• PC - threshold capillary pressure
• SW water saturation

February 2004
Imbibition Assisted Recovery
18
Matching Experimental Results

February 2004
Imbibition Assisted Recovery
19
Gravity Effect

• Bond number
• ?WATER 1 g/cc
• ?OIL 0.8635 g/cc
• ?WATER ?OIL 0.8635 g/cc

February 2004
Imbibition Assisted Recovery
20
Different Boundary Conditions

• All Faces Open
• Two Ends Closed
• Two Ends Open
• One End Open

No Flow Surfaces
February 2004
Imbibition Assisted Recovery
21
Different Boundary Conditions

February 2004
Imbibition Assisted Recovery
22
Different Boundary Conditions

February 2004
Imbibition Assisted Recovery
23
Heterogeneities

• One End Open
• Case 1 K1 gt K2 gt K3 gt K4
• Case 2 K1 lt K2 lt K3 lt K4

water
February 2004
Imbibition Assisted Recovery
24
Heterogeneities

February 2004
Imbibition Assisted Recovery
25
Presentation Outline

• Introduction
• Problem Statement
• Background and Literature Review
• Objectives
• Numerical Modeling
• Grid Sensitivity
• Matching Experimental Results
• Numerical Analyses of Spontaneous Imbibition
• Imbibition Upscaling
• Conclusions

February 2004
Imbibition Assisted Recovery
26
Spontaneous Imbibition Upscaling
Theory

• Recovery behavior for a large reservoir matrix
  block could be predicted from lab experiments
• Mattax and Kyte
• Ma et.al

February 2004
Imbibition Assisted Recovery
27
Spontaneous Imbibition Upscaling

• All Faces Open, Two Ends Closed, Two Ends Open
  and One End Open
• Semi-log plot
• Normalized Recovery vs. Dimensionless Time

February 2004
Imbibition Assisted Recovery
28
Spontaneous Imbibition Upscaling
Comparison

February 2004
Imbibition Assisted Recovery
29
Spontaneous Imbibition Upscaling
Varying Mobility Ratio

February 2004
Imbibition Assisted Recovery
30
Spontaneous Imbibition Upscaling
Varying Mobility Ratio

• Mobility Ratio - not included
• Need to include mobility ratio into the
  formulation of dimensionless time

February 2004
Imbibition Assisted Recovery
31
Spontaneous Imbibition Upscaling
Varying Mobility Ratio

February 2004
Imbibition Assisted Recovery
32
TEO
Spontaneous Imbibition Upscaling

February 2004
Imbibition Assisted Recovery
33
TEC
Spontaneous Imbibition Upscaling

February 2004
Imbibition Assisted Recovery
34
Spontaneous Imbibition Upscaling
Heterogeneous Core

• One End Open
• Case 1 K1 gt K2 gt K3 gt K4
• Case 2 K1 lt K2 lt K3 lt K4

water
February 2004
Imbibition Assisted Recovery
35
Spontaneous Imbibition Upscaling
Heterogeneous Core

February 2004
Imbibition Assisted Recovery
36
Presentation Outline

• Introduction
• Problem Statement
• Background and Literature Review
• Objectives
• Numerical Modeling
• Grid Sensitivity
• Matching Experimental Results
• Numerical Analyses of Spontaneous Imbibition
• Imbibition Upscaling
• Conclusions

February 2004
Imbibition Assisted Recovery
37
Conclusions

• It was observed that time required to saturate
  core to Sw60 increases exponentially as the
  number of faces available for imbibition decrease
• Results proved that using characteristic length
  in the equation of dimensionless time, instead of
  length of the core improves upscaling of
  spontaneous imbibition

February 2004
Imbibition Assisted Recovery
38
Conclusions

• Further investigation revealed that upscaling
  correlations could be significantly improved by
  taking into account end-point mobilities and
  mobility ratio
• Spontaneous imbibition recovery is higher for a
  flow in the direction of decreasing permeability
  than in the case of a flow in the direction of
  increasing permeability

February 2004
Imbibition Assisted Recovery
39
Conclusions

• Some discrepancy observed in correlations, while
  upscaling heterogeneous core, indicated that
  existing transfer functions can not precisely
  account for heterogeneities in the core

February 2004
Imbibition Assisted Recovery
40
Acknowledgement

• Finally I would like to express my sincere
  gratitude and appreciation to my advisor Dr.
  David Schechter and Dr. Erwin Putra.

Thank You!
