Title: Web 2'0 Overview


1
Web 2.0 Overview
  • An Overview of the Evolution of the WWW

2
This course has been produced under the USAID
Enterprise Development Strengthening project
implemented by CHF International
3
Course Overview
  • Web 2.0
  • a concept, not a technology
  • Open Source and Agile Development
  • Quick releases
  • AJAX
  • Toolkits
  • MS Atlas
  • Ruby on Rails
  • Rapid Development and Prototyping

4
Course Schedule Day 1
5
Course Schedule Day 2
6
The Traditional Web - 1.0
  • Mostly static pages
  • Centrally controlled
  • Traditional producer-consumer model
  • Minimal Participation by the users
  • Passive consumers
  • Web 1.5
  • More dynamic, data-driven content
  • Some Flash-based rich clients

7
What is Web 2.0?
  • Web 2.0 is not AJAX!
  • Not any particular technology
  • A new approach, attitude, way of thinking
  • Coined by OReilly Media and MediaLive
  • Brainstorming session after the dot-com bubble
    burst
  • Trying to figure out where the post-bubble web
    was headed

8
Web 1.x Producer-Consumer
  • Producers live in the universe of the Consumers

9
Web 2.0 Consumer feeds self
  • Producers create the universe in which Consumers
    feed themselves

10
Forces Driving the Shift
  • Success of Free, Open Source Software (FOSS)
  • Increasing user self-moderation
  • Increasing need for collaboration over the
    internet
  • Availability of Broadband (high-speed)
    connections
  • Proliferation of peer-to-peer networks
  • Instant access to a large audience
  • Rise of online communities and social networks

11
Technologies Driving the Shift
  • Open Source Languages, Formats, Protocols
  • Freely available for anyone to setup a powerful
    website
  • Rich-Client platforms (AJAX, Flash)
  • Proliferation of Broadband connections
  • Increasing demand for richer content
  • More content digitally captured
  • Syndication (RSS, ATOM)

12
Web 2.0 Characteristics
  • Built on any platform (open or closed source)
  • Hackability
  • Allows its functionality to be utilized in new
    ways by hacking through the code
  • Example Google Maps Mashups
  • Experience is Emergent
  • Users intentions are not predetermined
  • Experience constantly tweaked based on feedback
  • Trust your users
  • Trust users with content and moderation, and
    self-policing

13
Web 2.0 Characteristics
  • Loosely Coupled
  • Open APIs exposed through Web Services
  • SOAP/REST
  • Modularized
  • Specific Services can be leveraged
  • Example Google API, AdWords API
  • Rich User Experience
  • Rich-Clients using technologies such as AJAX,
    Flash, DHTML
  • Design interfaces around high responsiveness
  • Allow the user to actively participate in the
    growth of the site

14
Web 2.0 Characteristics
  • Constant Development
  • Concept of a perpetual beta
  • Flickr makes fun of this by calling their site a
    gamma
  • Not a Traditional Software Development Lifecycle
  • Agile, quick iterations, constant redesigns and
    optimizations

15
Demo Website - Writely
  • Web-based Word Processor
  • Purely a rich-client platform based on AJAX
  • Allows for real-time, collaborative editing
  • Built-in revision control with diff file
    capability
  • like a source control repository
  • Export your document to open (PDF, RTF, HTML,
    OpenOffice) and closed (MS Word) formats

16
Section Complete
  • Questions?

17
In-Room Experiences
  • Describe yourself and your Projects

18
Course Schedule Day 1
19
Tell us about
  • Yourself
  • Technical/Non-Technical Background
  • Project you have worked on
  • Did it succeed/fail? Why?
  • Technologies and Platforms you have used
  • Have your clients talked about Web 2.0?

20
Ajax
  • Finally, we see some code!

21
Course Schedule Day 1
22
What is AJAX?
  • Asynchronous JavaScript And XML
  • AJAX isnt one technology
  • A combination of existing technologies
  • JavaScript, XML, and XHTML
  • A naming concept similar to Dynamic HTML
  • HTML, JavaScript, CSS

23
Elements of AJAX
  • standards-based presentation using XHTML and CSS
  • dynamic display and interaction using the
    document object model
  • data interchange and manipulation using XML and
    XSLT
  • Asynchronous data retrieval using XMLHttpRequest
  • JavaScript binding everything together.

24
History of AJAX
  • Microsoft created XMLHttpRequest
  • Early AJAX Applications
  • Microsoft Outlook Web Access (Exchange 2000,
    2003)
  • MSNBC Polls
  • Other browsers gradually followed with native
    implementations
  • Opera
  • Mozilla Firefox
  • Apple Safari

25
Synchronous vs. Asynchronous
26
Synchronous vs. Asynchronous
27
What is Ajax a solution to?
  • Decreases bandwidth between client and server
  • Most content is loaded only once
  • MacRumors.com
  • Rumor site for Apple Computers products
  • Live coverage of CEO Steve Jobs Keynote speeches
  • 100,000 unique users in a 1 hour span
  • Everyone refreshes the page once a minute (if not
    more often)
  • Estimated bandwidth, 196 GB (in about 2 hours)
  • Moved live feed system to Ajax
  • Observed bandwidth usage drop to 32 GB, a 6x
    decrease

28
What is Ajax a solution to?
  • Roundtrips and delays
  • Traditional HTTP requires a full roundtrip
    between the client-server
  • User has to wait longer
  • System is not as responsive
  • Users prefer rich client applications for higher
    responsiveness

29
What is XMLHttpRequest?
  • A mechanism that allows for asynchronous GET and
    POST requests to the server
  • Minimal Feedback to the User
  • Ideal for background tasks
  • Allows you to specify a callback method
  • Handle changes in the state of the connection
  • Allows for multiple simultaneous connections
  • Traditional synchronous browser model allows for
    only one connection (browser threads initiate
    parallel connections to download images, but all
    happens only once during loading)

30
XMLHttpRequest - Methods
  • open(method, URL)
  • Opens a request using the method (GET, POST) to
    URL
  • open(method, URL, async, username, password)
  • Same as above, with optional arguments
  • async (boolean) to tell the browser to wait (or
    not) for a response
  • username username for the URL (if
    authentication required)
  • password password for the URL (if
    authentication required)
  • send(content)
  • Initiates connection and sends DOM data or string
  • abort()
  • Terminates HTTP Request

31
XMLHttpRequest - Methods
  • getAllReponseHeaders()
  • Returns a delimited string of all the HTTP
    headers (names and values) from the response
  • Examples Content-Type text/html, Referer lturlgt
  • getResponseHeader(header)
  • Returns the value of the header (such as
    Content-Type)
  • setRequestHeader(name,value)
  • Allows you to specify certain HTTP headers to
    send to the server

32
XMLHttpRequest - Properties
  • onreadystatechange
  • The function invoked when the request status
    changes
  • status
  • HTTP status returned from the server
  • 200 OK, 404 Not Found, 500 Internal Server Error
  • responseText
  • A raw string of all the response content
  • responseXML
  • DOM Document of XML data returned
  • statusText
  • Status text returned from the server

33
Creating a Request
  • Initialize the XMLHttpRequest object
  • Slightly Simplified Version

if (window.XMLHttpRequest) // Mozilla, Safari,
http_request new XMLHttpRequest() else
if (window.ActiveXObject) // IE
http_request new ActiveXObject("Microsoft.XMLHTT
P")
34
Creating a Request
  • Set the callback function
  • Specifies which function to call when the request
    status changes
  • Write the callback function

http_request.onreadystatechange
myCallbackFunction
function myCallbackFunction() if
(http_request.readyState 4) //
everything is good, the response is received
else // still not ready
35
Creating a Request
  • Check the response code of your request

function myCallbackFunction() if
(http_request.readyState 4) if
(http_request.status 200) // perfect!
else // there was a problem with
the request else // still not
ready
36
Creating a Request
  • Retrieve the contents of the servers response

http_request.responseText // will return the
server response as a string of text
http_request.responseXML // will return the
response as an XMLDocument object// you can
traverse using the JavaScript DOM functions
37
Call the function
  • Send the request to the server

http_request.open(GET,page.htm,
true) http_request.send(null)
38
Data Exchange XML
  • XHR designed to send and receive XML payloads
  • Structured data (objects, not just primitives)
  • Fully formed and valid xml document trees
  • Built in parser can be used to validate
    structures

39
Data Exchange JSON
  • JSON Javascript Object Notation
  • Text-based way of serializing objects
  • Platform-independent
  • Easy use
  • Pass the serialized object string through eval()
  • eval() returns the object

40
Data Exchange Text
  • XHR can also be used to exchange plain text
  • Response can be taken as one string
  • Effective when no parsing is required
  • Minimal overhead

41
Security and Limitations
  • Requests can only be made to the same domain
  • Not used to access web services because of lack
    of cross-domain access
  • IFRAMEs can be used to get around this limitation

42
Frameworks Easy Ajax wrappers
  • Prototype
  • Lightweight JavaScript library that allows for
    simplified Ajax calls.
  • Provides convenience, cleanup, etc
  • Used in Ruby on Rails
  • All invocation code generated automatically

43
Frameworks Backend (Java)
  • DWR Direct Web Remoting (Java)
  • Converts Java classes to JavaScript classes
  • JavaScript code can be made to look like Java
  • More like XML-RPC

44
Frameworks Backend (.NET)
  • Microsoft Ajax Scripting Library (Atlas)
  • Microsofts AJAX framework for ASP.NET
  • Makes client/server calls
  • Generates all invocation code automatically
  • Part of Visual Studio 2005, Web Developer Express
  • Well cover more of this on Day 2
  • Ajax.NET Professional
  • Third-party Ajax library for ASP.NET
  • Minimal setup

45
Frameworks Visual Effects
  • OpenRico
  • Used by FiveRuns and other client libraries for
    effects (BlindDown, Drag and Drop, etc)
  • Script.aculo.us
  • Used by Ruby on Rails and Prototype for Drag n
    Drop effects, and various PowerPoint slide
    transition-type effects (wipe, shrink, grow)
  • Moo.fx
  • A super-lightweight (3kb file size) effects
    library that allows for the building of custom
    effects too

46
Frameworks Widget Toolkits
  • Zimbra
  • Makers of a rich client Outlook type
    application
  • Toolkit still in development (removing all
    zimbra-specific code from the widget toolkit)
  • Google Widget Toolkit (GWT)
  • Utilizes Java Swing-like methodology to build
    web-based Ajax widgets
  • Build classes and interfaces like you would in
    Swing
  • GWT converts to Javascript and HTML code
  • Yahoo! User Interface Library

47
Drawbacks of AJAX
  • Browser Incompatibility
  • Unless you use a toolkit, you have to worry about
    DOM differences in each browser
  • XMLHttpRequest Inconsistency
  • XHR is not standardized JavaScript
  • Different Browsers have different implementations
  • ActiveX Object in IE 5.x, 6
  • Native Object in Firefox, Opera, Safari, etc
  • Requires different initializations

48
Drawbacks of AJAX
  • Accessibility
  • Breaks the traditional browser back button
  • Problems with screen readers
  • Fallback to static pages
  • What if JavaScript is disabled?
  • What if ActiveX is disabled?
  • Dual-development needed
  • Presentation and flow has to be duplicated and
    modified for a static page, non-Ajax page

49
Drawbacks of AJAX
  • Development
  • Backend developers now need to know presentation
    logic
  • Frontend developers/designers must have
    JavaScript skills
  • Debugging
  • Difficult because you are debugging two languages
  • Debugging two environments (Server, Client)

50
Drawbacks of AJAX
  • Limited Audience
  • Only supported on modern browsers
  • XML, XSLT
  • Javascript enabled
  • ActiveX enabled (in the case of Internet Explorer
    4 6)
  • Internet Explorer 7 makes XMLHttpRequest a native
    JS object
  • Similar to Firefox, Safari, and Opera
  • ActiveX will not be required for XHR from IE7
    onwards

51
Demo Website - Flickr
  • Users (owners) can upload and organize photos
  • Peer Reviewed
  • Owner applies licensing (Creative Commons, etc)
  • Rated by other users
  • Users comment on each photo
  • Users also tag photos
  • Rich Client (one of the best examples)

52
Flickr
  • Hackability
  • Flickr has a robust API that allows for
    uploading, replacing, and organizing photos
  • http//www.flickr.com/services/api
  • Uses open formats
  • SOAP/REST/XML-RPC
  • API Kits in every major platform
    (.NET/Java/Perl/PHP/Ruby)
  • The key is for easy mash-ups.
  • Others may come up with ideas to use Flickr that
    they couldnt come up with

53
Section Complete
  • Questions?

54
Debugging Ajax
  • Various tools that can help you develop with AJAX
    productively

55
Course Schedule Day 1
56
DOM Inspectors
  • Internet Explorer
  • IE Developer Toolbar
  • Released by Microsoft
  • Allows you to traverse the DOM tree of any page
    loaded in IE
  • Allows you to find where a DOM object is in the
    page (highlights the object when you select it)
  • Any values or attributes can be modified
  • Allows developers to render/test on various
    resolutions

57
History of Tools
  • Old Javascript Debugging Tools
  • Regular JavaScript Editors
  • Notepad!
  • Visual InterDev had some debugging
  • TCP/IP proxy
  • Our best friend, alert()

58
JS Debuggers
  • Firefox Javascript Console
  • Part of all Firefox installations
  • Venkman (Firefox JS Debugger)
  • Setting breakpoints
  • Triggering breakpoints based on variable values
    and exceptions
  • Watching variable values
  • Profiling of Javascript code

59
DOM Inspectors
  • Mozilla/Firefox
  • Can be optionally installed as part of the
    Firefox developer tools
  • Very similar to IEs DOM inspector (many
    identical features)

60
Traffic Monitors
  • Fiddler
  • Tracks HTTP traffic between the client (browser)
    and server
  • Can break down each request/response
  • HTTP Headers
  • Session information
  • HTTP Request data
  • Add breakpoints
  • Request can be paused, modified, and resumed
  • Great for debugging HTTP traffic

61
IDEs
  • Eclipse Ajax tools
  • Eclipse Foundation Project to build tools to
    simplify Ajax development
  • VS.NET
  • Through Atlas, increased support for Ajax style
    development
  • Powerful Javascript debugger provided by Microsoft

62
Demo Website - Digg
  • User-edited News site
  • All articles are submitted by users
  • Users vote on whether an article is
    good/important/interesting
  • More votes push an article up the ladder,
    eventually to the front page
  • Comments are also user-moderated
  • Good comments get a vote and are pushed up the
    comment chain

63
Section Complete
  • Questions?

64
Web 2.0 Solutions
  • Build a web 2.0 style solution for a client

65
Course Schedule Day 1
66
Instructions
  • Discuss within your group for the time the
    instructor has given you to design a solution
    together based on the problem assigned to you
  • Present a high-level description of your solution
    that you would give to a business manager, not a
    technical person

67
Your clients
  • Group 1 - Newspaper wants to encourage more user
    participation
  • Group 2 - Ice Cream Store with 8 branches across
    the country, would like to branches to
    collaborate in designing their brochures and
    notices
  • Group 3 - Investment bank wants to pool their
    researchers web resources together in a
    meaningful way
  • Group 4 - University wants a way that students
    can trade textbooks and other second-hand
    materials with each other

68
Microsoft .NET and Web 2.0
  • Microsofts initiatives in Web 2.0 and
    Rich-Client development

69
Course Schedule Day 1
70
Microsofts History with AJAX
  • XMLHttpRequest
  • Microsoft invented it they were early adopters
  • Some of the earliest applications to use them
  • Microsoft Outlook Web Access (OWA)
  • Microsoft Developer Network (MSDN) Library
    Tree-View
  • MSNBC Live Voting (votes updated instantaneously)
  • Part of the MSXML libraries since 1998

71
Windows Live
  • Microsofts web strategy to deal with
    Google/Yahoo
  • Web based rich client versions of popular windows
    applications
  • Windows Live Search
  • Windows Live Mail
  • Ajax version of Hotmail (looks like Outlook 2003)
  • Response to rich email clients like GMail and
    Yahoo
  • Windows Live Local (Beta, of course)
  • Includes Microsoft Virtual Earth

72
.NET AJAX Development
  • A few robust frameworks available
  • Different architectures and Implementations
  • Allow for ASP.NET pages to use Ajax
  • Integrate perfectly with Visual Studio.NET

73
Ajax.NET Professional Library
  • Available as a compiled library
  • Steps for easy implementation
  • Add a reference in Visual Studio
  • Wire up Ajax.NET Pro library in the Web.Config
    file
  • Add an HTTP Handler under ltsystem.webgt

lthttpHandlersgt ltadd verbPOST, GET
pathAjaxPro/.ashx typeAjaxPro.AjaxHan
dlerFactory,AjaxPro /gt lt/httpHandlersgt
74
Ajax.NET Professional Library
  • Write a method to be called by the client, to
    perform certain steps and return output
  • Code-Behind Page
  • Register the method as an Ajax-enabled method
    (available to Ajax.NET pro)
  • Add AjaxPro.AjaxMethod above the method
  • Tells AjaxPro to create a Javascript wrapper
    around that method
  • Main Page
  • Call the method from Javascript

75
Microsoft Atlas
  • Microsofts Javascript-related tools
  • Ajax Library and support functions
  • Library to support the generation of code that
    uses XmlHttpRequest for asynchronous operations
  • Browser-based components and widgets
  • Similar to server-side components, but generated
    by the browser as xhtml/javascript

76
Atlas Layers
  • Web Parts and Gadgets
  • AtlasWebParts.js, GadgetRuntime.js
  • Component Model and UI
  • Support for component based rich animations and
    effects, drag n drop
  • AtlasUIDragDrop.js

Source Beginning Ajax with ASP.NET
(beginningajax.com)
77
Atlas Layers
  • Base Class Library (BCL)
  • Modeled after the .NET BCL
  • Provides StringBuilder, Debug, Event, WebRequest,
    WebResponse
  • Provides support for ASP.NET services like
    authentication and profile

Source Beginning Ajax with ASP.NET
(beginningajax.com)
78
Atlas Layers
  • Browser Compatibility Layer
  • Abstracts support for browsers
  • Eliminates (if browser firefox) type code
  • Supports various versions of IE, Firefox, Safari

79
Atlas Layers
  • Controls and Components
  • Support for some Windows and Windows Live
    controls converted to XHTML/CSS/JS
  • ListView
  • MapControl
  • Allows you to embed Microsoft Virtual Earth
    controls in your webpages
  • AtlasUIMap.js

80
Atlas Layers
  • Script Core
  • Language extensions to Javascript
  • Support for Namespaces, classes, interfaces,
    inheritance, enumerations, delegates
  • Brings JS closer to .NET in functionality and
    concept
  • Javascript Extensions
  • Support for objects, functions, data types that
    are not natively in Javascript

81
Client-Side Framework Sarissa
  • sarissa.sourceforge.net
  • Client-side Javascript library
  • Provides a browser-independent API for common JS
    tasks
  • XML DOM manipulation
  • XMLHttpRequest, XSLT, XPath
  • Object serialization and deserialization
  • Why need an abstraction?
  • Some browsers natively support these
    functionalities, others dont

82
Client-Side Framework Sarissa
var xmlhttp new XMLHttpRequest() xmlhttp.open(
GET, http//www.YourServer.com/DataDocumen
t.xml, true) xmlhttp.onreadystatechange
function() if(xmlhttp.readyState 4)
alert(Finished loading!) xmlhttp.send(null)
  • XMLHttpRequest() is actually a sarissa class
  • Abstracts creation between Firefox/IE/Safari

83
Client-Side Framework Sarissa
  • Check for various browser features
  • IS_ENABLED_SELECT_NODES
  • Whether the browser supports XPath queries
  • IS_ENABLED_XMLHTTP
  • If we can use Ajax

84
Just one more thing Demo
  • Microsoft Virtual Earth

85
Microsoft Virtual Earth
  • Rich client Mapping from Microsoft
  • Includes birds-eye views, extremely
    hi-resolution imagery of larger cities
  • Drag n drop
  • Local Search
  • Fully dynamic, allows user to store notes

86
Section Complete
  • Questions?

87
Infrastructure 2.0 andOpen Source
  • How many Web 2.0 sites are hosted

88
Course Schedule Day 2
89
Goals of a good Infrastructure
  • Cost
  • Adding more infrastructure should incur a minimal
    cost
  • Scalability
  • Site should be designed from the ground up for
    scalability
  • Rapid Deployment
  • Steps for deployment must be fast and easy, new
    iterations can sometimes come out daily

90
Rapid Deployment - Facebook
  • Allowed users to track the movements of other
    users across the site
  • Seen as a Privacy Violation by thousands of users
  • Many campaigns launched (inside Facebook) against
    the new feature
  • Facebook responded by quickly adding permissions
    systems to control how much data is disclosed
  • New features were deployed within days
  • Users were happy!

91
Big Iron the old way
  • Traditional, Monolithic Mainframes
  • Name given to the traditional supercomputer
    systems
  • Everything centralized in one box
  • Proprietary hardware
  • Very high quality
  • Expensive
  • Drivers developed/customized by Vendor
  • Proprietary/commercial administration products
  • Highly customized and tuned OS
  • Very high cost, due to RD budgets required to
    develop a line of Mainframes

92
Little Iron the web 2.0 way
  • Highly decentralized clusters
  • No master slave relationship
  • All nodes are equal, except for load balancers,
    etc
  • No single point of failure
  • If any server dies, the rest of the servers pick
    up the workload
  • Not designed to prevent failure
  • Designed around acceptable rate of failure
  • Software designed to retry if it encounters
  • If one server is not available, just send your
    request to another

93
Little Iron the web 2.0 way
  • Use of commodity parts
  • Standard build your own boxes from OEM parts
  • Standard x86 (or x86-64) Intel or AMD chips
  • Google uses this for their entire cluster
    (100,000 servers)
  • Open source OS (Linux/Unix)
  • Fully customizable kernel, no license
    restrictions
  • Simplified Scalability
  • Buy more servers and connect!
  • An effective load balancer will automatically
    redistribute the load when new nodes are added

94
Little Iron the web 2.0 way
  • Extreme redundancy
  • When servers fail, others pick up the workload
    since they are all identical
  • Maintainability
  • Instead of taking down the entire mainframe for
    maintenance, sections of the cluster can be
    upgraded
  • Zero Downtime
  • By never taking down the entire cluster, the site
    is never down for maintenance

95
Commercial Platforms
  • Advantages
  • Products from same vendor work perfectly together
  • Unified solution, solves many design challenges
  • Little to no time spent getting pieces of a
    solution to communicate with each other
  • Staffing is easier (looking for people with a
    certain combination of skills)

96
Commercial Platforms
  • Disadvantages
  • Dependence on a single vendor
  • Patches, Updates, Official Support
  • Constrained market can not propose solutions
    where the customer requires a different platform

97
Open Source Platforms
  • Advantages
  • Use the best tool for each problem
  • Vendors compete with each other
  • Products are constantly improved
  • Can fix-it-yourself (fill security holes, etc)
  • Customize any level of the system to your own
    needs
  • Linux kernel being open source even allows you to
    customize the memory management
  • Open Formats and Protocols
  • If a tool to perform a task is not available, you
    can build one

98
Open Source Platforms
  • Disadvantages
  • Software will not always communicate well
    together
  • Longer initial setup time
  • Staffing - can be difficult to find people with a
    certain combination of skills

99
Free/Open Source Licensing
  • Allows for the unrestricted use of software
    (usually free of charge)
  • Source Code is publicly available
  • Many different licenses (vary in restrictions
    for code disclosure
  • MIT, GPL, LGPL, Apache, Ruby
  • GPL
  • GNU Public License
  • Unrestricted commercial or non-commercial use
  • Modifiable source code, as long as you publish
    changes

Richard Stallman
100
Free/Open Source Licensing
  • Source Code is publicly available
  • Many different licenses (vary in restrictions for
    code changes disclosure)
  • MIT, GPL, LGPL, Apache, Ruby
  • GPL
  • GNU Public License
  • Unrestricted commercial or non-commercial use
  • Modifiable source code, as long as you publish
    changes

101
Demo - FiveRuns
  • Systems Administration meets Web 2.0
  • Web-based rich client for administering servers
  • Allows for same responsiveness as a regular
    systems management solution, but totally
    centralized
  • Near-zero setup
  • Just install the agents on each server, and
    they send encrypted data back to FiveRuns
    periodically
  • The real web2.0 reason - allows for collaboration
  • Systems administrators apply solutions to
    metrics, these solutions are publicized and rated

102
FiveRuns
103
Section Complete
  • Questions?

104
Web 2.0 Rich Client - Banking
  • Build web 2.0 style Improvements into online
    banking

105
Course Schedule Day 2
106
Develop web 2.0 improvements for
  • Online Banking, including
  • How customers could possibly share data (without
    sharing personal data)
  • Rich Client Applications for Personal Banking
  • Better distribution of account information

107
Ruby
  • The Agile New Language.

108
Course Schedule Day 2
109
What is Ruby?
  • Hottest new language that is taking on the Java
    and .NET community.
  • Takes on the following and does it one better
  • The objected-orientedness of Java
  • The expressiveness of Perl
  • The simplicity of Python
  • Invented by Yukihiro Matsumoto
  • Developed by a world-wide network of open source
    developers.

110
Standard language design goals
  • Running Efficiency
  • Simpler Parsing
  • Maintainability
  • Make managers happy
  • Make compilers happy

111
  • The author of Ruby, Yukihiro Matsumoto set out
    to create a language that would "make programmers
    happy."
  • The benevolent dictator of Ruby

112
Objects
  • Everything in Ruby is an object

'hello'.upcase -42.abs 3.times puts 'Ni!' x
'vubee', 'java', 'python', 'monty' x.length
113
Some Ruby-isms
  • No need for semi-colons

puts 'hello'.length Unless you have multiple
statements on same lineputs -42.abs puts 'hello'
  • No curly brackets for control structures

if (condition) ...
if (condition) ...end
  • Braces are optional for expressions and methods
    calls

puts 'hello' if x gt 0 Is same as puts('hello')
if (x gt 0)
114
Naming Conventions
  • Local variables start with lowercase or
    underscore.
  • Constants start with uppercase (and do not use
    underscores)
  • Class names and module names start with uppercase
    (and do not use underscores).
  • Instance variables start with an _at_ sign.

GeeForce 9.80665 Constant account_va
lue 3141592654 Local variable Book my_book
Class name (Book) MathPI
Module name (Math)
115
Arrays and Hashes
reptiles 'lizard', 'crocodile',
'turtle' reptiles wlizard crocodile
turtle amphibians Array.new amphibians.push
'frog' amphibians.push 'salamander' ectotherms
reptiles amphibians puts ectotherms.sort h
'name' gt 'yoda', 'age' gt 1000, 'hobby' gt
'yoga' puts h'name' h name gt 'yoda',
age gt 1000, hobby gt 'yoga' puts hname
116
Regular Expressions
  • Supports Perl-like regular expressions and most
    methods.

puts 'facetious'.gsub(/aeiou/, '') puts
'anthropomorphic'.gsub(/(o.)3/, '') alphabet
'the quick brown fox jumped over the lazy
dog' puts alphabet.gsub(/\s/, '').split(/\s/).uni
q.sort.to_s
117
Control Structures
if (condition) ...elsif (condition)
...else ...end
unless (condition) ...else ...end
interest_category (interest_rate gt 9) ? 'high'
'low'
case (interest_rate) when 0..9 puts
'low' when 10..99 puts 'high'
else puts 'invalid' end
118
Loops
  • Standard while loops
  • Or the opposite

while (condition) ...end
until (condition) ...end
119
Iterators
  • Iterators make your life simple!

books 'ruby', 'java', 'python'for b in
books puts bendfor n in 0..3 puts
nend4.upto(8) do i puts iend3.times do
print 'Ja! 'end
120
Iterators in Java?
  • Using an iterator in Java looks like

List bookList Iterator iter
bookList.iterator() while (iter.hasNext()) bo
ok (Book)bookList.next() // yada yada
121
Blocks
  • A block is a chunk of code (enclosed in curly
    brackets) passed to a method.
  • Internally the method calls the block using
    yield command, optionally passing variables.
  • These variables are available to the block by
    assigning them in between the pipes ().

blockvariable
blockmethod
books 'ruby', 'java', 'python'books.each
x puts x
block
122
Methods
def just_do_it(n) n.times do puts 'just do
it!' endend puts just_do_it 2
def square(n) nnendputs square(3)
def convert(args) if (argskg)
argskg2.2 else argslb/2.2
endendputs convert(lb gt 110)
123
Classes and Accessors
class Aircraft attr_reader model
attr_accessor manufacturer def
initialize(model) _at_model model
endendfighter_jet Aircraft.new('F-16')fight
er_jet.model 'MiG-29' This will throw an
errorfighter_jet.manufacturer 'out-sourced to
Romania'puts fighter_jet.modelputs
fighter_jet.manufacturer
124
Class Inheritance
class PassengerJet lt Aircraft attr_accessor
seats def initialize(model, seats)
super(model) _at_seats seats
endendairbus PassengerJet.new('A380',
800)airbus.manufacturer 'Airbus
Industries'airbus.seats 600puts
airbus.modelputs airbus.manufacturerputs
airbus.seats
125
Modules
  • Modules are classes that cannot be instantiated.
  • Consider it like a library class.

module Geometry def Geometry.degrees2radians(d
egrees) degrees/180.0 MathPI
end end puts Geometry.degrees2radians(90)
126
Logging
  • Built-in logging functions with trace levels.
  • Trace levels can be changed at run-time.

log Logger.new(STDOUT) log.level
LoggerDEBUG log.datetime_format
'HMS' log.info 'starting logging' log.debug
'testing logging' log.warn 'possible system
failure!'
127
Exception Handling
file File.open('tmp.txt') begin do
stuff raise 'Error bad file!' rescue handle
error ensure file.close unless file.nil? end
128
File Handling
animals wcow elephant parrot monkey
Writingfile File.open('tmp.txt',
'w') animals.each do a file.puts
a end file.close Reading File.open('tmp.txt').e
ach line puts line
129
Database Access
  • Perl-like database abstraction library

require 'dbi'db DBI.connect('DBImysqldatabas
etest')stmt db.execute('select from
products')stmt.fetch_hash do row puts
row'description'endstmt.finishdb.disconnect
130
And much more...
  • Reflection
  • Threads
  • Dynamic Loading
  • Tons of built-in library modules
  • NetFTP, NetHTTP, NetWebServices
  • Encryption
  • Process, Kernel
  • Mixins
  • Garbage collection
  • Marshelling

131
Demo
  • Google Maps

132
Google Maps
  • First high-profile mapping sites that utilized
    AJAX
  • Enabled Rich-Client mapping
  • More attractive maps using their implementation

133
Google Maps - Hackability
  • Initial release had no public API
  • JavaScript is inherently open source
  • Many community-created GMap toolkits were created
  • Mashups were created (housingmaps.com)
  • Google released a Google Maps API, free for all
    non-commercial use
  • Enabled more mashups, including Googles own
  • (Green environmentally friendly sites mashup
    for Earth Day, etc)

134
Section Complete
  • Questions?

135
Ruby on Rails
The Agile New Framework
136
Course Schedule Day 2
137
Model-View-Controller
  • MVC is an architecture that separates out the
    business model (Model), the presentation (View),
    and the application logic (Controller).
  • There have been many frameworks that have
    attempted to achieve this
  • Struts Framework (w/EJB) (2000-2004)
  • Tapestry (2003-2007?)
  • Spring Framework (w/Hibernate) (2004-2008?)
  • Ruby Rails (2004-2012?)

138
Why Java/EJB failed...
  • Why are many veteran J2EE developers switching to
    Ruby on Rails?
  • Complexity of EJB.
  • Complexity of Java based MVC frameworks (like
    Struts)
  • Repetitiveness of code. For example, the Model
    (definition and relationships) have to be
    redefined in 3 places SQL, XML, and Java.
  • Maintenance nightmare.
  • Inflexible to change not Agile.

139
What is Ruby on Rails
  • Ruby on Rails is an MVC Framework created by
    David Heinemeier Hansson, supported by the open
    source community.
  • Developers around the world have experienced that
    it cuts down development by at least 40
  • It does so by the DRY principle Don't Repeat
    Yourself. A great breakthrough from the Java
    based frameworks where every change involves
    touching N files.

140
RoR Model
Presentation Layer
Application Logic
Business Model
View
Controller
Model
DB
  • Controllers
  • Actions
  • Sessions
  • Flash
  • Filters
  • ActiveRecords
  • Validators
  • RHTML
  • Helpers
  • Layouts
  • Partials

RoR Model
141
Model
Books to Reviews is a one-to-many relation.
create table products ( id int not null
auto_increment, title varchar(50) not null,
price decimal(10, 2) not null, primary key
(id)) create table reviews ( id int not
null auto_increment, product_id int not
null, reviewer varchar(50) not null,
comments text, published_date datetime,
constraint fk_product_id foreign key (product_id)
references products(id), primary key
(id))
RoR Model
142
Active Record
  • Knows which table, based on class name.
  • No need to define any class attributes!
  • Automatically determines it from database.
  • Need to define type of relationship.

class Product lt ActiveRecordBase has_many
reviews end class Review lt ActiveRecordBase
belongs_to product end
RoR Model
143
Active Record
  • Creating and saving.

product Product.new(title gt 'RubyBook',
price gt '15.00')product.save!review
Review.new(reviewer gt 'Rama', product gt
product)review.comments 'Very good
book.'review.save!review Review.new(reviewer
gt 'Krishna', product gt product)review.comment
s 'Great book.'review.save!product.reviews.ea
ch review pp review
RoR Model
144
Validation
  • Several built-in validation methods

class Product lt ActiveRecordBase has_many
reviews validates_presence_of title,
price validates_numericality_of
price end class Review lt ActiveRecordBase be
longs_to product validates_presence_of
reviewer, product end
RoR Model
145
Active Record
  • Ruby uses finder methods with SQL-like conditions
    syntax.

products Product.find(all, conditions gt
"title 'RubyBook' and price lt 20", limit gt
10, order gt 'title DESC') products
Product.find(all, conditions gt "title ?
and price lt ?", 'RubyBook', 20) params
title gt 'RubyBook', price gt 20 products
Product.find(all, conditions gt "title
title and price lt price", params) products.eac
h product pp product
RoR Model
146
RoR View
Presentation Layer
Application Logic
Business Model
View
Controller
Model
DB
  • Controllers
  • Actions
  • Sessions
  • Flash
  • Filters
  • ActiveRecords
  • Validators
  • RHTML
  • Helpers
  • Layouts
  • Partials

RoR View
147
RHTML
  • Embed Ruby in HTML
  • Similar to JSP/PHP tags
  • lt ruby code gt
  • lt ruby expression gt
  • ERb - Lightweight Templating System

RoR View
148
RHTML
  • Sample

lthtmlgt Embedded Ruby expression inside
HTMLltbr/gt The time is lt Time.now gt
ltbr/gt Embedded Ruby code inside HTML
ltpgt lt books 'ruby', 'java',
'python' books.each x puts x
gt lt/pgt lt/htmlgt
RoR View
149
Helpers
  • Share reusable code.
  • Helper modules.

module ShoppingCartHelper def items_in_cart nit
ems get_number_of_items_in_cart if nitems
0 return Your shopping cart is
empty else return You have ntems in
your cart end endend
lthtmlgt lth3gt Status lt items_in_cart gt
lt/h3gt lt/htmlgt
RoR View
150
Built-in Helpers
  • Formatting Helpers

lthtmlgt lt human_size(1024) gt ltbr/gt lt
number_to_currency(161.80) gt ltbr/gt lt
number_to_phone(1112223333, area_codegttrue,
delimitergt'-') gt lt number_with_delimiter(1112
22333) gt lt/htmlgt
1 KB 161.80 (111)222-3333 111,222,333
RoR View
151
Built-in Helpers
  • Form Helpers
  • lt form_tag(action, class) gt
  • lt end_form_tag gt
  • lt text_field(variable, attribute, options
    gt
  • lt hidden_field(variable, attribute, options
    gt
  • lt password_field(variable, attribute,
    options gt
  • lt radio_button(variable, attribute,
    tag_value, option gt
  • lt check_box(variable, attribute, options,
    on_value, off_value gt
  • lt select(variable, attribute, choices,
    options, html_options gt
  • lt date_select(variable, attribute, options)
    gt

RoR View
152
Layouts
  • Many pages share the same header, footer,
    sidebars, and other layouts.
  • To give all pages a consistent look and feel this
    layout is separated out...
  • Into a layout template.
  • Rails renders views by wrapping them with the
    layout template.
  • Makes all views simpler focusing only the chunk
    of code that concerns them.

RoR View
153
Layouts
  • Sample layout template

lthtmlgt ltheadgt lttitlegtBook Storelt/titlegt lt
stylesheet_link_tag 'bookstore'
gt lt/headgt ltbodygt lt!-- Header HTML code here
--gt lt _at_content_for_layout gt lt!-- Footer
HTML code here --gt lt/bodygt lt/htmlgt
RoR View
154
Partials
  • Are chunks of reusable view templates.
  • For example, list of products may be displayed in
    multiple areas of the application that code can
    be reused.
  • It is like any other view template, except that
    its name starts with an underscore.
  • Example, _blog_entry.rhtml

RoR View
155
Controllers
  • Following the MVC paradigm, RoR applications are
    invoked through the controllers.

http//localhost/bookstore/admin/add_product
Identifies the application (bookstore)
Identifies the controller (AdminController)
Identifies the action/method to invoke
(add_product)
RoR Controller
156
RoR Controller
Presentation Layer
Application Logic
Business Model
View
Controller
Model
DB
  • Controllers
  • Actions
  • Sessions
  • Flash
  • Filters
  • ActiveRecords
  • Validators
  • RHTML
  • Helpers
  • Layouts
  • Partials

RoR Controller
157
Controllers
  • The Controller

class AdminController lt ApplicationController def
add_product ... end end
  • When the action has finished it renders the
    corresponding view (default same name as action
    - add_product.rhtml).
  • It also passes parameters to the view.

RoR Controller
158
Sessions
  • Session information is stored in hash called
    session.
  • It is available across all the controllers.

Helper method, available to all controllers to
retrieve the current shopping cart from the
session. def get_shopping_cart sessioncart
Cart.new end
RoR Controller
159
The Flash
  • The flash is a convenient hash you can store
    stuff in, and is visible to the view.
  • Useful for displaying error messages.

class AdminController lt ApplicationController def
add_product ... product.save redirect_to(
action gt 'list_products') rescue flashnotic
e Failed to add product redirect_to(action
gt 'show_error') end end
RoR Controller
160
Filters
  • Filters are a powerful feature. It is a method
    that is invoked before any action is invoked.

class AdminController lt ApplicationController bef
ore_filter authorize ...end
This should go in app/controllers/application.rb
def authorize unless sessionuser_id flash
notice Please login in redirect_to(contro
ller gt login, action gt login) endend
RoR Controller
161
And much more...
  • Emphasis on test driven development
  • Interactive console for fast debugging
  • Emphasis on Elegance of APIs

RoR Controller
162
Demo
  • Del.icio.us

163
Del.icio.us
  • Social Bookmarking
  • Users store lists of URLs that they find
    interesting
  • Tags can be added to each bookmark (folksonomy)
  • Multiple users add bookmarks and tags
  • These combinations are grouped together
  • Algorithms are used to pool tags that are joined
    by bookmark, by user, or by other shared common
    tags

164
Section Complete
  • Questions?

165
Ajax on Rails
  • Redefining Web Development.

166
Let's code...
  • Assume a form has this ltdivgt tag

ltdiv idmydivgtWe're going to change this text
using Ajax!lt/divgt
  • Let's change the text using Ajax (that is,
    without submitting the form).
  • We can do that by adding the Ajax'ed link

lt link_to_remote(Ajax demo!, update gt
'mydiv', url gt action gt test_ajax) gt
167
Straight to the code...
  • Define the action.
  • Tell it not to use layouts wrapper.

def test_ajax render(layout gt false) end
  • Define the view (test_ajax.rhtml).

ltemgtText has changed! Time on the server is lt
Time.now gtlt/emgt
168
Let's try it!
  • Initial Page
  • Upon clicking the link

169
Behind the scenes...
  • Rails accomplishes this by
  • prototype.js a JavaScript library that includes
    prototype, effects, dragdrop, and controls.
  • JavaScriptHelper module wraps JavaScript in
    Ruby code.
  • The ltheadgt should include

lt javascript_include_tag prototype gt
170
Ajax any Form
  • You can ajax any form by using the
    form_remote_tag() instead of the form_tag()

lt form_remote_tag(update gt mydiv,
url gt action gt guess) gt
171
Observers
  • Monitors the specified field in a form
  • Calls an Ajax action when user changes the data
    in that field.

ltlabel forsearchgtSearchlt/labelgtlt
text_field_tag search gtlt observe_field(sear
ch, frequency gt 0.5,
update gt results,
url gt action gt search) gtltdiv
idresults/gt
172
Periodic Updates
  • Periodically call an Ajax action.

lt periodically_call_remote(
frequency gt 2 update gt
results, url gt action gt
server_time) gtltdiv idresultsgtlt/divgt
def server_time render(text gt Time.now) end
173
Special Effects
  • Effects to convey something has been changed or
    added.
  • The following snippet calls item_added action to
    update items when the submit action (add_item) is
    completed.

lt form_remote_tag(url gt action gt
add_item, update gt items, position gt
bottom, complete gt item_added(request),)
gt lt end_form_tag gt
174
Special Effects
  • Note that the Ajax action add_item returns the id
    of the item via the header.

def add_item item Item.new(name gt
paramsname) item.save! headers.'x-item-id'
item.id render(partial gt item, object gt
item)end
  • The _item.rhtml should have the id field

ltli iditem_lt item.idgtgt lt/ligt
175
Special Effects
  • The following JavaScript (added to the forms
    layout), determines the effect.
  • It uses built-in special effects Effect.Highlight
  • Also uses the built-in helper (id) which returns
    the DOM element with given id.

ltscriptgt function item_added(request) var id
request.getResponseHeader('x-item-id') new
Effect.Highlight('item_' id) ('new_item').va
lue ''lt/scriptgt
176
And more...
  • Effect.Appear Changes the opacity from 0 to
    100 making it come into visibility smoothly
  • Effect.Fade Fades out an element smoothly
  • Effect.Highlight Smoothly highlights an
    element.
  • Effect.Puff Elements gently disappear in a
    cloud of smoke.
  • Effect.Squish Elements disappear by getting
    squished out.

177
Wikipedia
  • Collaborative Encyclopedia
  • Anyone can edit ANY article
  • Actively moderated by other users
  • Growing to be as prominent as Encyclopedia
    Britannica
  • Constant comparisons made between both
  • Researchers found about the same number of
    factual accuracy as Britannica
  • Published in the Journal Nature

178
Section Complete
  • Questions?

179
Web 2.0 Solutions
  • Build a web 2.0 style solution for a client

180
Course Schedule Day 2
181
More web 2.0 brainstorming!
  • Within each group, pick a project that one member
    implemented in their organization
  • Knowing what youve learned from the course, how
    would you re-implement it to be more Web 2.0
  • Whether you would use rails, etc
  • Just adding AJAX is not enough!!!

182
Ajax on Rails
  • Redefining Web Development.

183
Course Schedule Day 2
184
Let's code...
  • Assume a form has this ltdivgt tag

ltdiv idmydivgtWe're going to change this text
using Ajax!lt/divgt
  • Let's change the text using Ajax (that is,
    without submitting the form).
  • We can do that by adding the Ajax'ed link

lt link_to_remote(Ajax demo!, update gt
'mydiv', url gt action gt test_ajax) gt
185
Straight to the code...
  • Define the action.
  • Tell it not to use layouts wrapper.

def test_ajax render(layout gt false) end
  • Define the view (test_ajax.rhtml).

ltemgtText has changed! Time on the server is lt
Time.now gtlt/emgt
186
Let's try it!
  • Initial Page
  • Upon clicking the link

187
Behind the scenes...
  • Rails accomplishes this by
  • prototype.js a JavaScript library that includes
    prototype, effects, dragdrop, and controls.
  • JavaScriptHelper module wraps JavaScript in
    Ruby code.
  • The ltheadgt should include

lt javascript_include_tag prototype gt
188
Ajax any Form
  • You can ajax any form by using the
    form_remote_tag() instead of the form_tag()

lt form_remote_tag(update gt mydiv,
url gt action gt guess) gt
189
Observers
  • Monitors the specified field in a form
  • Calls an Ajax action when user changes the data
    in that field.

ltlabel forsearchgtSearchlt/labelgtlt
text_field_tag search gtlt observe_field(sear
ch, frequency gt 0.5,
update gt results,
url gt action gt search) gtltdiv
idresults/gt
190
Periodic Updates
  • Periodically call an Ajax action.

lt periodically_call_remote(
frequency gt 2 update gt
results, url gt action gt
server_time) gtltdiv idresultsgtlt/divgt
def server_time render(text gt Time.now) end
191
Special Effects
  • Effects to convey something has been changed or
    added.
  • The following snippet calls item_added action to
    update items when the submit action (add_item) is
    completed.

lt form_remote_tag(url gt action gt
add_item, update gt items, position gt
bottom, complete gt item_added(request),)
gt lt end_form_tag gt
192
Special Effects
  • Note that the Ajax action add_item returns the id
    of the item via the header.

def add_item item Item.new(name gt
paramsname) item.save! headers.'x-item-id'
item.id render(partial gt item, object gt
item)end
  • The _item.rhtml should have the id field

ltli iditem_lt item.idgtgt lt/ligt
193
Special Effects
  • The following JavaScript (added to the forms
    layout), determines the effect.
  • It uses built-in special effects
About PowerShow.com
