A Toolkit for statistical comparison of data
distributions
Monte Carlo 2005 - Chattanooga, April 2005
2
Data analysis

• Provide tools for the statistical comparison of
  distributions
• equivalent reference distributions
• experimental measurements
• data from reference sources
• functions deriving from theoretical calculations
  or fits

Detector monitoring Simulation
validation Reconstruction vs. expectation Regressi
on testing Physics analysis
3
GoF statistical toolkit
A project to develop a statistical comparison
system
4
Software process guidelines

• United Software Development Process, specifically
  tailored to the project
• practical guidance and tools from the RUP
• both rigorous and lightweight
• mapping onto ISO 15504
• Guidance from ISO 15504
• Incremental and iterative
• life cycle model

5
Architectural guidelines

• The project adopts a solid architectural approach
• to offer the functionality and the quality needed
  by the users
• to be maintainable over a large time scale
• to be extensible, to accommodate future
  evolutions of the requirements
• Component-based approach
• to facilitate re-use and integration in different
  frameworks
• AIDA
• adopt a (HEP) standard
• no dependence on any specific analysis tool

6
(No Transcript)
7
The tests are specialised on the kind of
distribution (binned/unbinned)
8
G.A.P Cirrone, S. Donadio, S. Guatelli, A.
Mantero, B. Mascialino, S. Parlati, M.G. Pia, A.
Pfeiffer, A. Ribon, P. Viarengo A
Goodness-of-Fit Statistical Toolkit IEEE-
Transactions on Nuclear Science (2004), 51 (5)
2056-2063.
Release StatisticsTesting-V1-01-00 downloadable
from the web http//www.ge.infn.it/geant4/analysi
s/HEPstatistics/
9

• Applies to binned distributions
• It can be useful also in case of unbinned
  distributions, but the data must be grouped into
  classes
• Cannot be applied if the counting of the
  theoretical frequencies in each class is lt 5
• When this is not the case, one could try to unify
  contiguous classes until the minimum theoretical
  frequency is reached
• Otherwise one could use Yates correction

10
unbinned distributions
Dmn
SUPREMUM STATISTICS
11
binned/unbinned distributions
12

• Simple user layer
• Only deal with AIDA objects and choice of
  comparison algorithm

13
Unit tests
Rigorous software process adopted
Test process
Integration tests
System tests

• Testing focuses primarily on the evaluation or
  assessment of quality of the software product,
  guaranteeing its correctness and robustness.
• finding and documenting defects in software
  quality
• validating software product functions as
  designed
• validating that the requirements have been
  implemented appropriately
• Test result summaries are included as part of the
  documentation of the Toolkit release and are
  available on the web.

14
supremum statistics

• Weighted KS tests
• Weighted CVM tests
• CVM approximation to a ?2 (Tiku test)
• Exact Anderson-Darling test
• Watson test
• Watson approximation to a ?2 (Tiku test)
• With these tests the GoF Statistical Toolkit will
  be the most complete toolkit for the two-sample
  problem in physics as well as in the statistics
• domain.

unbinned distributions
quadratic statistics
binned/unbinned distributions
unbinned distributions
15
The power of a test is the probability of
rejecting the null hypothesis correctly
In terms of power

• ?2 loses information in a test for unbinned
  distribution by grouping the data into cells
• Kac, Kiefer and Wolfowitz (1955) showed that
  Kolmogorov-Smirnov test requires n4/5
  observations compared to n observations for ?2
  to attain the same power
• Cramer-von Mises and Anderson-Darling statistics
  are expected to be superior to Kolmogorov-Smirnov
  s, since they make a comparison of the two
  distributions all along the range of x, rather
  than looking for a marked difference at one point

16
(No Transcript)
17
K. Amako, S. Guatelli, V. Ivanchenko, M. Maire,
B. Mascialino, K. Murakami, P. Nieminen, L.
Pandola, S. Parlati, A. Pfeiffer, M. G. Pia, M.
Piergentili, T. Sasaki, L. Urban Precision
validation of Geant4 electromagnetic physics
p-value stability study
Geant4 LowE Penelope Geant4 Standard Geant4 LowE
EEDL NIST - XCOM
Geant4 LowE Penelope Geant4 Standard Geant4 LowE
EEDL
The three Geant4 models are equivalent
Z
18
Radioprotection applications in manned space
missions
inflatable habitat

• Comparison of inflatable and conventional rigid
  habitat concepts Effect of different shielding
  materials Effect of shielding thickness E.m.
  and hadronic interactions

thanks to Susanna Guatelli
KS TEST
S. Guatelli, B. Mascialino, P. Nieminen, M. G.
Pia Radioprotection for interplanetary manned
missions
S. Guatelli, B. Mascialino, P. Nieminen, M. G.
Pia Radioprotection for interplanetary manned
missions
19
c2 not appropriate (lt 5 entries in some bins,
physical information would be lost if rebinned)
Anderson-Darling Ac (95) 0.752
A. Mantero, B. Mascialino, P. Nieminen, M. G.
Pia, A. Owens, M. Bavdaz, A. Peacock A library
for simulated X-ray emission from planetary
surfaces
thanks to Alfonso Mantero
20
dose
dose
Kolmogorov-Smirnov test
Distance (mm)
Distance (mm)
thanks to Michela Piergentili
Range D p-value
-56 ? -35 mm 0.26 0.89
-34 ? -22 mm 0.43 0.42
-21 ?21 mm 0.38 0.08
22 ? 32 mm 0.26 0.98
33 ? 36 mm 0.57 0.13
Range D p-value
-84 ? -60 mm 0.385 0.23
-59 ? -48 mm 0.27 0.90
-47 ? 47 mm 0.43 0.19
48 ? 59 mm 0.30 0.82
60 ? 84 mm 0.40 0.10
F. Foppiano, B. Mascialino, M. G. Pia, M.
Piergentili Geant4 simulation of an accelerator
head for intensity modulated radiotherapy
21
Conclusions

• This is a new up-to-date easy to handle and
  powerful tool for statistical comparison in
  particle physics.
• It the first tool supplying such a variety of
  sophisticated and powerful statistical tests in
  HEP.
• Released and downloadable from the web.
• AIDA interfaces allow its integration in any
  other data analysis tool.

Applications in HEP, astrophysics, medical
physics,
