Complex Electronic Hardware

1
Complex Electronic Hardware

• Clive Lee

2
Complex Electronic Hardware

• Range of Logic Devices
• Programmable Logic Devices (PLDs)
• Programmable Logic
• Field Programmable Gate Arrays
• Application Specific Integrated Circuits (ASICs)
• PLDs/ASICs

3
Complex Electronic Hardware

• Hardware that is programmed like software
• Based on Integrated Circuits (ICs or chips)
• ICs connected on Circuit Board
• Circuit Board interfaced with other devices
  (sensors, actuators) to provide system function

4
Complex Electronic Hardware

• Integrated Circuits becoming more complex
• Scale of Integration no of transistors
• VLSI very large (gt1 hundred thousand) c.1980
• ULSI ultra large (gt 1 million transistors)
  c.1990
• WSI wafer processor memory FAILED 1984
• SOC system on chip 1990s

5
System on a Chip
6
System on a Chip

• Typical system consists of
• 1 or more microprocessor core(s)
• General or specialised (e.g. microcontroller or
  DSP)
• Memory
• RAM (SRAM, Flash), ROM, EEPROM
• Timing sources oscillators, PLL
• External Interfaces
• USB, Ethernet, SPI, FireWire, UART, CAN
• Analog interfaces
• ADC, DAC, UART

7
Complex Electronic Hardware

• Provides logic or function
• given inputs produce specified outputs
• Based on integrated circuits connected
• Chips with transistors, resistors, capacitors

• Used to be many SSI chips on Circuit Board
• Small scale integration (lt30 transistors on chip)

• Now fewer but higher density devices
• More than 1 million transistors on chip
• E.g. Itanium processor

8
Logic on Integrated Circuit
TTL 7400 quad NAND gates
9
Programmable Logic
A
B
Sum of Products e.g. _
_ ABAB
Programmed by blowing fuses to select AND inputs
(products)
10
Programmable Logic Devices (1)

• SPLD Simple Programmable Logic Device
• PLA AND-plane and OR-plane
• PAL AND-plane and fixed OR-plane
• CPLD Complex Programmable Logic Device
• Multiple SPLD-like blocks on one chip
• FPGA Field Programmable Gate Array
• Logic blocks and interconnect resources

11
Simple PLD Example

• 1983 AMD released 22V10 device
• 24 pins with 10 outputs
• Replaced all of AMD 24 pin fixed function ICs
• Configured during manufacture
• Programmable AND and fixed OR gates

12
Programmable Logic Devices (2)

• FPGA Field Programmable Gate Array
• Logic blocks and interconnect resources
• Structured ASIC
• Upper layers of chip programmable
• Lower levels of chip standard logic facilities
• ASIC Application Specific Integrated Circuit
• All layers of chip specific to application
• MicroProcessor / System on Chip
• All layers on chip provide general purpose
  computing platform.

13
Complex Electronic Hardware
Programmable Logic Devices
2 Major Categories
Application Specific Integrated Circuits
SPLD
Simple PLDs
CPLD
Complex
High CapacityPLDs
Structured ASIC
HCPLD
FPGA
Field Programmable Gate Arrays
Cell based ASIC
Custom ASIC
14
Programmable Logic Devices
Programmable Logic Devices
SPLD
Simple PLDs
CPLD
Complex PLDs several PLDs connected together
High CapacityPLDs
HCPLD
FPGA
Field Programmable Gate Arrays
15
Complex PLDs (CPLDs)

• Complexity lies between Simple PLDs and FPGAs
• Like PALs
• Based on sum-of-products logic array.
• Little scope for internal state or deeply layered
  logic
• Like FPGAs
• Equivalent to large no gates (up to 100,000, cf
  100 PAL)
• More complicated logic available than sum of
  products e.g. feedback, common functions such
  as integer arithmetic
• Non-volatile on chip memory
• Boot loader, can be used to load FPGA with
  configuration data

16
Complex PLD Example

• Altera MAX 7000 family
• Equivalence 600 - 10,000 gates, 36 to 212 pins

• Altera, Atmel, Xilinx, Lattice Semiconductor

17
FPGA Properties

• Up to several million gates
• High level embedded functions (adders,multipliers)

• Embedded memories
• Can be fully or partially reconfiguredFPGA
  Architecture
• Based on Configurable Logic Blocks
• LUT determines function of block
• Interconnections can be switched.

18
FPGA Example

• Company - Family
• Xilinx Virtex, Spartan
• Altera Stratix, Cyclone, Flex
• Lattice Semiconductor
• Actel ProASICplus
• QuickLogic
• Actmel

19
FPGA Modern Trends

• Additional functions (Hardware)
• FPGA chip has additional functions inbuilt on
  manufacture (e.g. microprocessor core, DAC, ADC,
  communications)
• Additional functions (Software)
• Extra functions inbuilt by committing gates to
  provide required logic (e.g. soft cores such as
  microprocessors and other IP code).

20
Complex Electronic Hardware
Programmable Logic Devices
2 Major Categories
Application Specific Integrated Circuits
SPLD
Simple PLDs
CPLD
Complex
High CapacityPLDs
Structured ASIC
HCPLD
FPGA
Field Programmable Gate Arrays
Cell based ASIC
Custom ASIC
21
ASICs
System-on-Chip
ASSP Application Specific Standard Product
Application Specific Integrated Circuit
Over 100 thousand gates
Structured ASIC
Predefined layers in chip
Cell based ASIC
Technology-library
Custom ASIC
Every function optimised
22
ASIC Design Steps

• Description of ASIC in Hardware Design Language
  (HDL) e.g. VHDL, Verilog
• Translation into RTL (Register Transfer Level)
• Verification by simulation tool
• Translation by logic synthesis tool into
  gate-level netlist e.g. blocks, cells and
  connections
• Routing tool produces photomasks
• Estimates of power consumption,parasitic
  resistance, capacitance, delays made.

23
Hardware Design Processes
System Safety Assessment Process
Hardware Life Cycle Processes
24
Implementation Options

• Computing System Choice
• Microprocessor System
• General Purpose with logic interpreted
• ASIC System
• Application Specific with logic inbuilt
• FPGA System
• Logic selected or tailored

25
Micro, ASIC, FPGA Comparison
26
Complex Electronic Hardware Devices - Issues

• They cannot be tested for all inputs and paths
• They are developed by tools which may introduce
  additional errors
• They are more likely to have undetected design
  and implementation faults
• They have unanticipated interactions
• It is a common observation during development
  that the requirements are inadequate,
  particularly incomplete

27
Acronyms Abbreviations
28
Questions
