Air Data System

1

• Air Data System
• Total Air Temperature Probe
• Use of NCEP Warm Bias Data
• Presented by David Cole

2
BUG
3
Air Data System
4
Air Data System
5
AIR DATA MODULE
6
TAT PROBE
7
TAT FUNCTION
8
(No Transcript)
9
TOTAL AIR TEMPERATURE

• ?tw Total air temperature error correction due
  to resistance of the nominal length of wiring
  between the probe and the air data computer
  (degrees).
• TTi Indicated total air temperature - the total
  air temperature as measured at the input
  terminals of the air data computer (degrees
  absolute).

10
TOTAL AIR TEMPERATURE/STATIC AIR TEMPERATURE

• TT Total air temperature - indicated total air
  temperature corrected for wiring resistance and
  recovery error (degrees absolute) the air data
  computer output in degrees C.
• Ts Static air temperature - total air
  temperature corrected for the adiabatic
  temperature rise due to compressibility (degrees
  absolute) the air data computer output in
  degrees C.

11
FORMULAS

• TOTAL AIR TEMPERATURE
• TT Indicated Total Air Temp Total Air Temp
  Error Corr. Due to Wire Resistance
• 1- 0.2 Computer Mach Number Squared
• STATIC AIR TEMPERATURE
• TS Total Air Temp
• 1 0.2 Computer Mach Number Squared

12
TAT TEMPERATURE CURVE
13
TAT/ADIRU FUNCTION
14
TAT PROBE ANALYSIS
15
TAT PROBE REVIEW

• NCEP DATA ALLOWS CAL TO ISOLATE TAT PROBES THAT
  HAVE A HIGHER THAN NORMAL TEMPERATURE READING
• ISOLATION OF THESE PROBES ALLOWS CAL TO REPLACE
  THEM PRIOR TO A POSSIBLE FAILURE
• CAL AND BOEING ARE IN THE PROCESS OF IDENTIFYING
  HOW A HIGHER THAN NORMAL TAT PROBE TEMPERATURE
  CAN ALTER FUEL MILEAGE
