Connected Vehicles for a Connected World

1
Connected Vehicles for a Connected World

• Research Innovative Technology Administration
• US Department of Transportation
• January 2008

2
What VII will Enable . Safety

• Imagine
• Your vehicle knows the speed and location of
  approaching vehicles
• Your vehicle can see vehicles you cant see
• Your vehicle knows roadway conditions that you
  cant see

3
What VII will Enable.. Mobility

• Imagine
• You had traffic information on all your potential
  routes and modes of travel
• You could compare different routes and modes of
  travel based on traffic speed
• Your navigation unit could reroute you when an
  accident occurs during travel

4
What VII will Enable . Consumer Services

• Imagine
• You can quickly download movies and other high
  content material into your vehicle
• You can find and reserve available parking spaces
  before you arrive
• You can pay for tolls, parking, and your morning
  cup of coffee automatically from within your
  vehicle
• Your vehicle can tell you when it needs servicing
  and direct you to a service station

5
What VII will Enable . Agency Management
Operations

• Imagine
• Managing your system if you knew real-time travel
  speeds and densities, braking activities, and
  roadway temperatures for all major facilities
• Planning for growth when you know complete
  traffic patterns around development
• Having the information needed to measure and
  track system performance

6
VII Concept

• Situation Relevant Information

Probe Data
7
USDOTs Research and Demonstration Program
8
A Change in Strategy

• Previous approach
• Deployment decision by OEMs, US DOT, state
  transportations agencies in 2010 with
  synchronized deployments beginning around 2012
• Key technology for vehicle to infrastructure
  communications was Dedicated Short Range
  Communications (DSRC)
• Expectation that the infrastructure build out
  could be substantially funded by the Federal
  government
• Current approach
• Open up the architecture to allow for non-DSRC
  technology
• Work with aftermarket suppliers to enable VII
  capabilities sooner
• Demonstrate a subset of capabilities that VII can
  provide in a few, high concentration operational
  test sites
• Support growth in geographic coverage and
  functionality over time
• Leverage new technologies and private industry
  developments
• Learn from related state and university research

9
Program Goals and Objectives

• Goals
• Nationwide system
• Enable the full range of safety, mobility, and
  commercial applications
• Adaptable to technology evolution
• Objectives
• Near term to demonstrate current capability and
  provide for more rapid deployment of VII
  applications
• Mid term to expand both the system
  functionality and geographic coverage of the
  system
• Long term to enhance system performance

10
Multi-Phased Approach

• Phase 1 Field operational test site(s)
  established to demonstrate and test what can be
  done today
• Phase 2 Applied research and development
  activities to support the longer term needs of
  the program in areas of technology, policy, and
  public agency applications
• Phase 3 Monitoring and assessing new
  technologies that can enhance system performance

11
Phase 1 SAFE TRIP-21Safe and Efficient Travel
Through Innovation and Partnerships

• Develop field test bed(s) to
• Accelerate availability of travel information and
  services to provide users with greater
  situational awareness of safety hazards,
  congestion bottlenecks, and route and modal
  choices
• Evaluate impacts, value of integrated
  infrastructure for travelers and commercial
  operators, and market readiness of near-term
  applications, including but not limited to those
  using DSRC
• Leverage other U.S. DOT activities such as the
  Urban Partnership Agreements, the Corridors of
  the Future Sites, and others.
• Leverage existing systems and capabilities (i.e.,
  511, Highway Advisory radio, vehicle-based
  collision warning technologies, traffic reporting
  services, etc., and state, local, university, and
  industry research )

12
Phase 1 SAFE TRIP-21 (2007 2008)

• Key Dates and Milestones
• Request for Information (RFI) released December
  18, 2007
• Information requested on partnering for Phase 1
  test site development
• Information requested on test site
  characteristics, applications and their
  readiness, innovative technologies
• RFI responses expected by January 11, 2008
• Site(s) operational and evaluation to begin
  December 1, 2008
• Interim findings will be transitioned toward mid-
  and longer-term ongoing research in VII Phases 2
  and 3
• SAFE TRIP-21 Final Report in January 2010
  (Interim reports in 09)

13
Phase 2 Enable a Phased Nationwide Deployment

• Fund applied research and development activities
• In the areas of enabling technologies, public
  applications, and institutional issues
• To support a phased, nationwide deployment of VII
  capabilities between 2008 and 2015
• Key Objectives
• Assess and demonstrate capabilities of various
  technical solutions
• Identify phased roll-out strategies to support
  rapid deployment of near-term capabilities and
  enable the long term vision
• Analyze alternative business models and
  governance structures
• Develop technical and policy solutions to address
  security, privacy, liability and other
  institutional issues
• Develop key applications for the public sector
• Leverage results of operational tests and state
  and university research to improve and refine
  research and deployment approaches

14
VII National System Network Build Up
15
Phase 2 Enable a Phased Nationwide
DeploymentProof of Concept (POC) Testing MI
and CA

• Testing of public, private, and e-commerce
  applications
• Testing to be completed in March with results
  published in June 2008
• Validate the vehicle to roadside and vehicle to
  vehicle capabilities in a multi-application
  environment
• Demonstrate that VII technical approach ensures
  anonymity, privacy, and security
• The Michigan POC test includes
• 25 vehicles, 57 intersection and freeway
  locations near Detroit ? approximately 47 square
  miles of coverage
• Vehicle based communications is DSRC for both V2I
  and V2V
• Backhaul communications is a combination of 3G,
  WiMax, and Mesh
• Scheduled to operate through June 08
• Currently preparing an RFI to solicit input and
  expressions of interest in
• Using the test bed by other private and public
  sector entities and
• Options for continued operation and maintenance

16
Most of the VII POC Testing will be conducted in
the suburbs of Detroit. RSEs placed along
several stretches of highway as well as multiple
signalized intersections.
17
Michigan Test Bed - Private Applications
18
Michigan Test Bed Public Applications
Traveler Informationand Corridor Management Load
Balancing Applications
Weather Information and Corridor Management
Planning Assistance Applications use the entire
DTE area
All Applications
19
VII California Infrastructure

• Access to 60 miles of Right-of-Way, including
  hills and urban canyons
• Three, parallel, 20 mile long North/South routes
  US 101 SR 82 (El Camino Real) and I-280
• 12 RSEs are installed and operating, with
  approved FCC licenses
• Mix of freeway / intersection locations
• 28 more RSE sites have been selected and surveyed
• Installation of RSEs will continue through August
  2008
• Backhaul wired (T1 lines) and wireless (3G
  cellular WiMAX, Municipal WiFi)
• Communications choice is site dependent
• Back End Servers
• One at the 511 TIC in Oakland one at PATH in
  Richmond
• IP-based additional servers can be located
  anywhere

20
VII California TestbedSouthern Peninsula, San
FranciscoBay Areaviicalifornia.org
21
VII Technical Innovations

• Most extensive DSRC/WAVE protocol testbed (56
  RSEs)
• Prioritization of radio access messages for
  safety (while supporting other applications)
• Multi-channel DSRC radios with channel switching
• Single radio will support diverse applications
  simultaneously
• One-way, 2-way, individual, and broadcast
  communications
• Supports many vehicles simultaneously and
  scaleable to large population
• Groundbreaking method to maintain privacy
  anonymity while ensuring legitimacy of messages
  data
• Implement common vehicle interface for V2V across
  OEMs

22
Phase 2 Enable a Phased Nationwide Deployment
Technology and Testing Going Forward

• Continue technical research to support deployment
• Additional research anticipated in the areas of
• Communications
• Mapping
• Security
• Positioning
• Standards
• Enable future testing needs
• Ensure testing capabilities are available to
  support public and private interests
• Ensure test bed activities are working to common
  standards and interfaces

23
Phase 2 Enable a Phased Nationwide Deployment
Applications Activities Underway

• CICAS-V
• Violation warning at traffic signal and stop sign
  controlled intersections
• Prototype development complete summer 2008
• Field operational test option being examined
• Vehicle to Vehicle Communications
• Develop architecture and message sets
• Develop relative positioning technology using
  DSRC
• Develop and verify objective test procedures
• Applications being examined include
• Emergency Electronic Brake Light
• Forward Collision Warning
• Intersection Movement Assist
• Blind Spot Warning Lane Change Warning
• Do-Not-Pass Warning
• Control Loss Warning
• Assessment of benefits both with autonomous
  systems and DSRC alone
• Initial test platform to be established mid-2008
  with final project results end of 2009

24
Phase 2 Enable a Phased Nationwide Deployment
Applications Going Forward

• Begin development of deployment oriented
  applications
• Mobility applications using vehicle probe data
• Traveler information
• Traffic Management
• Transit operations
• Commercial vehicle operations
• Road weather information (building on current
  USDOT/NWS research)
• Electronic payment for tolling
• Leverage results of existing and future test and
  evaluation activities
• Public sector application workshop(s) to be held
  in spring 2008
• Identify real world needs for input into Concept
  of Operations and Requirements documents
• Provide basis for private sector development of
  products and services

25
Phase 2 Enable a Phased Nationwide Deployment
Business Models

• Request for Information related to the business
  model is expected to be released in Spring 2008
  to identify innovative partnerships as a means
  for cost-sharing and market stimulation
• Outcomes will be used to
• Identify possible roles of the public sector
  moving forward
• Initiate conversations with the private sector
  regarding cost-sharing arrangements
• Identify research gaps and ways for the Federal
  government to serve as a catalyst for the
  deployment of technologies and applications

26
Phase 2 Enable a Phased Nationwide Deployment
Institutional Issues

• Research to overcome potential institutional
  barriers to deployment
• Activities underway and to be initiated in 2008
• Privacy policy framework (complete)
• Benefit-cost analysis (underway)
• Legal research (underway)
• Patent search
• Liability analysis for public agencies and
  private partners
• Analysis of potentially influential federal
  legislation
• Identification of potential state legal and
  regulatory hurdles
• Data ownership and access rights (pending)
• Network ownership and access rights (pending)
• Capabilities and limitations of the 5.9GHz
  spectrum allocation (ongoing)

27
Phase 3 Monitor Cutting Edge Technology

• Monitor and assess developing technology that may
  be incorporated into the VII system to enhance
  system performance, including
• Advancements in mesh networks for vehicle to
  vehicle communications
• Mobile WiMax
• 4G cellular
• Low cost inertial navigation
