Allen D. Malony, Sameer Shende, Robert Ansell-Bell

1
TAU Performace System Developments and Evolution

• Allen D. Malony, Sameer Shende, Robert
  Ansell-Bell
• malony,sameer,bertie_at_cs.uoregon.edu
• Computer Information Science Department
• Computational Science Institute
• University of Oregon

2
Performance Needs ? Performance Technology

• Observe/analyze/understand performance behavior
• Multiple levels of software and hardware
• Different types and detail of performance data
• Alternative performance problem solving methods
• Multiple targets of software and system
  application
• Robust AND ubiquitous performance technology
• Broad scope of performance observability
• Flexible and configurable mechanisms
• Technology integration and extension
• Cross-platform portability
• Open, layered, and modular framework architecture

3
Complexity Challenges

• Computing system environment complexity
• Observation integration and optimization
• Access, accuracy, and granularity constraints
• Diverse/specialized observation
  capabilities/technology
• Restricted modes limit performance problem
  solving
• Sophisticated software development environments
• Programming paradigms and performance models
• Performance data mapping to software abstractions
• Uniformity of performance abstraction across
  platforms
• Rich observation capabilities and flexible
  configuration
• Common performance problem solving methods

4
General Problem

• How do we create robust and ubiquitous
  performance technology for the analysis and
  tuning of parallel and distributed software and
  systems in the presence of (evolving) complexity
  challenges?

5
Talk Outline

• Computation Model for Performance Technology
• TAU Performance Framework
• Model-oriented framework architecture
• TAU performance system toolkit
• Flexibility and portability (SIMPLE example)
• Recent Developments
• Complexity scenarios
• Mixed-mode performance analysis (OpenMPMPI)
• OpenMP performance API
• Performance mapping and C-SAFE Uintah
• TAU Evolution

6
Computation Model for Performance Technology

• How to address dual performance technology goals?
• Robust capabilities widely available
  methodologies
• Contend with problems of system diversity
• Flexible tool composition/configuration/integratio
  n
• Approaches
• Restrict computation types / performance problems
• limited performance technology coverage
• Base technology on abstract computation model
• general architecture and software execution
  features
• map features/methods to existing complex system
  types
• develop capabilities that can adapt and be
  optimized

7
Framework for Performance Problem Solving

• Model-based composition
• Instrumentation / measurement / execution models
• performance observability constraints
• performance data types and events
• Analysis / presentation model
• performance data processing
• performance views and model mapping
• Integration model
• performance tool component configuration /
  integration
• Can performance problem solving framework be
  designed based on general complex system model?

8
General Complex System Computation Model

• Node physically distinct shared memory machine
• Message passing node interconnection network
• Context distinct virtual memory space within
  node
• Thread execution threads (user/system) in context

Interconnection Network
Inter-node messagecommunication


Node
Node
Node
node memory
memory
memory
SMP
physicalview
VM space

?
?
?
modelview

Context
Threads
9
TAU Performance Framework

• Tuning and Analysis Utilities
• Performance system framework for scalable
  parallel and distributed high-performance
  computing
• Targets a general complex system computation
  model
• nodes / contexts / threads
• Multi-level system / software / parallelism
• Measurement and analysis abstraction
• Integrated toolkit for performance
  instrumentation, measurement, analysis, and
  visualization
• Portable performance profiling/tracing facility
• Open software approach

10
TAU Performance System Framework
11
TAU Instrumentation

• Flexible, multiple instrumentation mechanisms
• Source code
• manual
• automatic using PDT (tau_instrumentor)
• Object code
• pre-instrumented libraries
• statically linked
• dynamically linked
• fast breakpoints
• Executable code
• dynamic instrumentation using DynInstAPI (tau_run)

12
TAU Instrumentation (continued)

• Common target measurement interface (TAU API)
• C (object-based) design and implementation
• Macro-based, using constructor/destructor
  techniques
• Function, classes, and templates
• Uniquely identify functions and templates
• name and type signature (name registration)
• static object creates performance entry
• dynamic object receives static object pointer
• runtime type identification for template
  instantiations
• C and Fortran instrumentation variants
• Instrumentation and measurement optimization

13
TAU Measurement

• Performance information
• High resolution timer library (real-time /
  virtual clocks)
• Generalized software counter library
• Hardware performance counters
• PCL (Performance Counter Library) (ZAM, Germany)
• PAPI (Performance API) (UTK, Ptools Consortium)
• consistent, portable API
• Organization
• Node, context, thread levels
• Profile groups for collective events (runtime
  selective)
• Mapping between software levels

14
TAU Measurement (continued)

• Profiling
• Function-level, block-level, statement-level
• Supports user-defined events
• TAU profile (function) database (PD)
• Function callstack
• Hardware counts instead of time
• Tracing
• Profile-level events
• Interprocess communication events
• Timestamp synchronization
• User-controlled configuration (configure)

15
TAU Analysis

• Profile analysis
• Pprof
• parallel profiler with texted based display
• Racy
• graphical interface to pprof
• jRacy
• Java implementation of Racy
• Trace analysis
• Trace merging and clock adjustment (if necessary)
• Trace format conversion (ALOG, SDDF, PV, Vampir)
• Vampir (Pallas)

16
Strategies for Empirical Performance Evaluation

• Empirical performance evaluation as a series of
  performance experiments
• Experiment trials describing instrumentation and
  measurement requirements
• What/Where/How axes of empirical performance
  space
• Strategies for achieving flexibility and
  portability goals
• Limited performance methods restrict evaluation
  scope
• Non-portable methods force use of different
  techniques
• Integration and combination of strategies
• SIMPLE hydrodynamics benchmark (C, MPI)
• Multiple instrumentation methods
• Alternatives analysis techniques

17
Multi-Level Instrumentation with Profiling

• Source-based
• PDT
• MPI wrappers
• MPI profiling library
• Performance metrics
• Time
• Hardware counter

18
Multi-Level Instrumentation with Tracing
19
Dynamic Instrumentation

• Uses DyninstAPI for runtime code patching
• Mutator loads measurement library, instruments
  mutatee
• one mutator per executable image TAU, DynaProf
• one mutator for several executables Paradyn,
  DPCL

20
Performance Perturbation Study

• Measurement alternatives
• PAPI wallclock overhead 27 lower than
  gettimeofday system call under IA-32 Linux 2.x
• Source vs. runtime instrumentation
• source 23 lower than runtime for TAU profiling
• Need to balance alternatives
• Abstractions and instrumentation levels
• Flexibility /simplicity
• Instrumentation and Measurement Strategies for
  Flexible and Portable Empirical Performance
  Evaluation, PDPTA, June 2001.

21
Complexity Scenarios

• Object-oriented programming and templates
• Object-based performance analysis
• Performance measurement of template-derived code
• Array classes and expression transformation
• Source code performance mapping
• Multi-threaded and asynchronous execution
• Abstract thread-based performance measurement
• Multi-threaded parallel execution
• Asynchronous runtime system scheduling
• Parallel performance mapping

22
Complexity Scenarios (continued)

• Virtual machine environments
• Performance instrumentation in virtual machine
• Measurement of multi-level virtual machine events
• Mixed-mode parallel computation
• Portable shared memory and message passing APIs
• Performance measurement of message passing
  library
• Integration with multi-threading
• Hierarchical, hybrid parallel systems
• Combined task and data parallel execution
• Performance system configuration and model mapping

23
Multi-Threading Performance Measurement

• General issues
• Thread identity and per-thread data storage
• Performance measurement support and
  synchronization
• Fine-grained parallelism
• different forms and levels of threading
• greater need for efficient instrumentation
• TAU general threading and measurement model
• Common thread layer and measurement support
• Interface to system specific libraries (reg, id,
  sync)
• Target different thread systems with core
  functionality
• Pthreads, Windows, Java, SMARTS, Tulip, OpenMP

24
Mixed-mode Parallel Programs (OpenMPI MPI)

• Portable mixed-mode parallel programming
• Multi-threaded shared memory programming
• Inter-node message passing
• Performance measurement
• Access to RTS and communication events
• Associate communication and application events
• 2D Stommel model of ocean circulation
• OpenMP for shared memory parallel programming
• MPI for cross-box message-based parallelism
• Jacobi iteration, 5-point stencil
• Timothy Kaiser (San Diego Supercomputing Center)

25
OpenMP MPI Ocean Modeling (Trace)
Threadmessagepairing
IntegratedOpenMP MPI events
26
OpenMP MPI Ocean Modeling (HW Profile)
configure -papi../packages/papi -openmp
-cpgCC -ccpgcc -mpiinc../packages/mpich/in
clude -mpilib../packages/mpich/libo
IntegratedOpenMP MPI events
FP instructions
27
Mixed-mode Parallel Programs (Java MPI)

• Multi-language applications and mixed-mode
  execution
• Java threads and MPI
• mpiJava (Syracuse, JavaGrande)
• Java wrapper package with JNI C bindings to MPI
• Integrate cross-language/system technology
• JVMPI and Tau profiler agent
• MPI profiling interface - link-time interposition
  library
• Cross execution mode uniformity and consistency
• invoke JVMPI control routines to control Java
  threads
• access thread information and expose to MPI
  interface
• Integration and Application of the TAU
  Performance System in Parallel Java
  Environments, ISCOPE, 2001.

28
TAU Java Instrumentation Architecture
Java program
mpiJava package
TAU package
JNI
MPI profiling interface
Event notification
TAU wrapper
TAU
Native MPI library
JVMPI
Profile DB
29
Parallel Java Game of Life (Profile)
Merged Java and MPI event profiles

• mpiJavatestcase
• 4 nodes,28 threads

Thread 4 executes all MPI routines
Node 0
Node 1
Node 2
30
Parallel Java Game of Life (Trace)

• Integrated event tracing
• Mergedtrace viz
• Nodeprocessgrouping
• Threadmessagepairing
• Vampirdisplay

• Multi-level event grouping

31
OMP Performance Tools Interface

• Goal 1 Expose OpenMP events and execution states
  to a performance measurement system
• What are the OpenMP events / states of interest?
• What is the nature (mechanism) of the interface?
• Goal 2 Make the performance measurement
  interface portable
• Standardize on interface mechanism / semantics
• Goal 3 Support source-level and compiler-level
  implementation of interface
• Towards a Performance Tools Interface for
  OpenMP An Approach Based on Directive
  Rewriting, EWOMP 2001.

32
Performance State and Event Model

• Based on performance model for (nested) fork-join
  parallelism, multi-threaded work-sharing, and
  thread-based synchronization
• Define with respect to multi-level state view
• Level 1 serial and parallel states (with
  nesting)
• Level 2 work-sharing states (per team thread)
• Level 3 synchronization states (per team thread)
• Level 4 runtime system (thread) states
• Events reflect state transitions
• State enter / exit (begin / end)
• State graph with event edges

33
Fork-Join Execution States and Events
Events master slave
Parallel region operation
master starts serial execution X
parallel region begins X
S
STARTUP
slaves started X
team begins parallel execution X X
P
team threads hit barrier X X
slaves end master exits barrier X X
SHUTDOWN
master resumes serial execution X
S
34
Performance Measurement Model

• Serial performance
• Detect serial transition points
• Standard events and statistics within serial
  regions
• Time spent in serial execution
• Locations of serial execution in program
• Parallel performance
• Detect parallel transitions points
• Time spent in parallel execution
• Region perspective and work-sharing perspective
• Performance profiles kept per region
• More complex parallel states of execution

35
Event Generation (Callback) Interface

• Directive-specific callback functions
• omperf_NAME_TYPE(D)
• NAME is replaced by OMP directive name
• TYPE is either fork/join, enter/exit, begin/end
• D is a context (region) descriptor
• Advantages
• Standardizes function names independent of base
  programming language
• Specification tied directly to programming model
• Define addition OpenMP directives
• Initialization, termination, measurement control

36
Instrumentation Alternatives

• Source-level instrumentation
• Manual instrumentation (will be done anyway)
• Directive (source-to-source) transformation
• Compiler instrumentation
• More closely tied to directive processing
• Could allow more efficient implementation
• Runtime system instrumentation
• RTL-level events
• Possibly gain more detailed information
• Dynamic instrumentation
• May be very hard to do without well-defined
  interface

37
Proposal Based on Directive Transformation

• Consider source-level approach
• For each OMP directive, generate an
  instrumented version which calls the
  performance event API.
• What is the event model for each directive?
• Issues
• OMP RTL execution behavior is not fully exposed
• May not be able to generate equivalent form
• Possible conflicts with directive optimization
• May be less efficient
• Hard to access RTL events and information
• Proposed transformations (B. Mohr, Research
  Centre Juelich)

38
Parallel Region and Do Transformation

• !OMP PARALLEL structured block!OMP END
  PARALLEL
• call omperf_parallel_fork(d)!OMP PARALLEL
  call omperf_parallel_begin(d) structured block
  call omperf_barrier_enter(d) !OMP BARRIER
  call omperf_barrier_exit(d) call
  omperf_parallel_end(d)!OMP END PARALLELcall
  omperf_parallel_join(d)

• !OMP DO do loop!OMP END DO
• call omperf_do_enter(d)!OMP DO do loop!OMP
  END DO NOWAITcall omperf_barrier_enter(d)!OMP
  BARRIERcall omperf_barrier_exit(d)call
  omperf_do_exit(d)

39
Worksharing, Atomic, and Master Transformation

• !OMP WORKSHARE structured block!OMP END
  WORKSHARE
• call omperf_workshare_enter(d)!OMP WORKSHARE
  structured block!OMP END WORKSHARE NOWAITcall
  omperf_barrier_enter(d)!OMP BARRIERcall
  omperf_barrier_exit(d)call omperf_workshare_exit(
  d)

• !OMP ATOMIC atomic expression
• call omperf_atomic_enter(d)!OMP ATOMIC atomic
  expressioncall omperf_atomic_exit(d)
• !OMP MASTER structured block!OMP END MASTER
• !OMP MASTER call omperf_master_begin(d)
  structured block call omperf_master_end(d)!OMP
  END MASTER

40
Sections and Section Transformation

• !OMP SECTIONS!OMP SECTION structured
  block!OMP SECTION structured block!OMP END
  SECTIONS

• call omperf_sections_enter(d)!OMP
  SECTIONS!OMP SECTION call omperf_section_begin
  (d) structured block call omperf_section_end(d
  )!OMP SECTION call omperf_section_begin(d)
  structured block call omperf_section_end(d)!OM
  P END SECTIONS NOWAITcall omperf_barrier_enter(d)
  !OMP BARRIERcall omperf_barrier_exit(d)call
  omperf_sections_exit(d)

41
Critical, Barrier, and Single Transformation

• !OMP CRITICAL structured block!OMP END
  CRITICAL
• call omperf_critical_enter(d)!OMP CRITICAL
  call omperf_critical_begin(d) structured block
  call omperf_critical_end(d)!OMP END
  CRITICALcall omperf_critical_exit(d)
• !OMP BARRIER
• call omperf_barrier_enter(d)!OMP BARRIERcall
  omperf_barrier_exit(d)

• !OMP SINGLE structured block!OMP END SINGLE
• call omperf_single_enter(d)!OMP SINGLE call
  omperf_single_begin(d) structured block call
  omperf_single_end(d)!OMP END SINGLE
  NOWAITcall omperf_barrier_enter(d)!OMP
  BARRIERcall omperf_barrier_exit(d)call
  omperf_single_exit(d)

42
Combined Parallel Do Directive Transformation

• !OMP PARALLEL DO clauses do loop!OMP END
  PARALLEL DO

• call omperf_parallel_fork(d)!OMP PARALLEL
  other-clauses call omperf_parallel_begin(d)
  call omperf_do_enter(d) !OMP DO
  schedule-clauses
  ordered-clauses
  lastprivate-clauses do loop !OMP END DO
  NOWAIT call omperf_barrier_enter(d) !OMP
  BARRIER call omperf_barrier_exit(d) call
  omperf_do_exit(d) call omperf_parallel_end(d)
  !OMP END PARALLELcall omperf_parallel_join(d)

43
Combined Parallel Sections Transformation

• !OMP PARALLEL SECTIONS clauses!OMP SECTION
  structured block!OMP END PARALLEL SECTIONS

• call omperf_parallel_fork(d)!OMP PARALLEL
  other-clauses call omperf_parallel_begin(d)
  call omperf_sections_enter(d) !OMP SECTIONS
  lastprivate-clauses !OMP SECTION call
  omperf_section_begin(d) structured block
  call omperf_section_end(d) !OMP END
  SECTIONS NOWAIT call omperf_barrier_enter(d)
  !OMP BARRIER call omperf_barrier_exit(d)
  call omperf_sections_exit(d) call
  omperf_parallel_end(d)!OMP END PARALLELcall
  omperf_parallel_join(d)

44
Combined Parallel Work-Sharing Transformation

• !OMP PARALLEL WORKSHARE clauses structured
  block!OMP END PARALLEL WORKSHARE

• call omperf_parallel_fork(d)!OMP PARALLEL
  clauses call omperf_parallel_begin(d) call
  omperf_workshare_enter(d) !OMP WORKSHARE
  structured block !OMP END WORKSHARE NOWAIT
  call omperf_barrier_enter(d) !OMP BARRIER
  call omperf_barrier_exit(d) call
  omperf_workshare_exit(d) call
  omperf_parallel_end(d)!OMP END PARALLELcall
  omperf_parallel_join(d)

45
Performance Measurement Directives

• Support for user-defined events
• !OMP INST BEGIN (region name)arbitrary user
  code!OMP INST END (region name)
• Place at arbitrary points in program
• Translated into corresponding omperf_begin() and
  omperf_end() calls
• Measurement control
• !omp perf on/off
• pragma omp perf on/off
• Place at consistent points in program
• Translate by compiler into omperf_on/off()

46
Describing Execution Context

• Describe different contexts through context
  descriptor
• typedef struct ompregdescr char namechar sub
  _nameint num_sectionschar filenameint
  begin_line1, end_line1int begin_lineN,
  end_lineNWORD data4struct region_descr
  next
• Generate context descriptors in global static
  memory
• Table of context descriptors

47
Prototype Implementation

• OPARI (OpenMP Pragma And Region Instrumentor)
• Bernd Mohr (Research Centre Juelich)
• OMP directives and performance API directives
• Source-to-source transformation to omperf calls
• Full F77/F90 OMP 2.0, C/C OMP 1.0
• omperf library implementations
• EXPERT (Mohr)
• Automatic performance analysis (OpenMP, MPI,
  hybrid)
• Call EPILOG trace routines for omperf events
• TAU
• Profiling and tracing (OpenMP, MPI, hybrid)
• OPARI instrumentation

48
omperf_for_enter,exit (EXPERT, Mohr)

• void omperf_for_enter(OMPRegDescr r) struct
  ElgRegion e if (! (e (struct
  ElgRegion)(r-gtdata0))) e
  ElgRegion_Init(r) elg_enter(e-gtrid)void
  omperf_for_exit(OMPRegDescr r)
  elg_omp_collexit()

49
omperf_for_enter,exit (TAU)

• void omperf_for_enter(OMPRegDescr r) ifdef
  TAU_OPENMP_REGION_VIEW TauStartOpenMPRegionTimer
  (r)endifvoid omperf_for_exit(OMPRegDescr
  r) ifdef TAU_OPENMP_REGION_VIEW
  TauStopOpenMPRegionTimer(r)endif
• Can also have contruct-based view

50
OpenMP MPI REMO Code (OPARIEXPERT)

• Colors show percentage of CPU time

Isolate property performanceto code region
50 lost to sequentialexecution or was used by
idle threads
51
OpenMP MPI REMO Code (OPARIEXPERT)

• Large barrier time in implicit barrier of
  parallel do
• Different distribution across threads

52
OpenMP MPI Stommel Code (OPARI TAU)
53
Region and Construct Views (OPARI TAU)
54
Semantic Performance Mapping

• Associate performance measurements with
  high-level semantic abstractions
• Need mapping support

55
Semantic Entities, Attributes, Associations
(SEAA)

• New dynamic mapping scheme (S. Shende, Ph.D.
  thesis)
• Contrast with ParaMap (Miller and Irvin)
• Entities defined at any level of abstraction
• Attribute entity with semantic information
• Entity-to-entity associations
• Two association types
• Embedded extends data structure of associated
  object to store performance measurement entity
• External creates an external look-up table
  using address of object as the key to locate
  performance measurement entity

56
C-SAFE and TAU

• Center for Simulation of Accidental Fires
  Explosions
• ASCI Level 1 center
• PSE for multi-model simulation high-energy
  explosion
• Uintah parallel programming framework
• Component-based and object-parallel
• Multi-model task-graph scheduling and execution
• Shared-memory (thread), distributed-memory (MPI),
  and mixed-model parallelization
• Integrated with SCIRun framework
• TAU integration in Uintah
• Mapping task object ? grid object ? patch
  object

57
Task Execution in Uintah Parallel Scheduler
Task execution time dominates (what task?)
MPI communication overheads (where?)
58
Task Computation and Mapping

• Task computations on individual particles
  generate work packets that are scheduled and
  executed
• Interpolate particles to grid
• Assign semantic name to a task abstraction
• SerialMPMinterpolateParticleToGrid
• Partition execution time among different tasks
• Need to relate the performance of each particle
  computation (work packet) to the associated task
• External mapping to task timer object
• Profile and tracing measurement

59
Work Packet to Task Mapping (Profile)
60
Work Packet to Task Mapping (Trace)
See work packet computation events colored by
task type
Distinct phases of computation can be identifed
based on task
61
Statistics for Relative Task Contributions
62
XPARE - eXPeriment Alerting and REporting

• Experiment launcher automates configuration /
  compilation of performance tools and Uintah
  application for each experiment
• Collects performance data after experiment run
  and sends it to reporting system
• Reporting system checks data against predefined
  set of rules for the given experiment
• Alerts users via email if thresholds have
  exceeded
• Webtools allow alerting setup and full
  performance data reporting
• Historical performance data analysis

63
Alerting Setup
64
Experiment Results Viewing Selection
65
Web-Based Experiment Reporting
66
Web-Based Experiment Reporting (continued)
67
TAU Evolution

• Scalable Performance Technology for Terascale
  Computers, DOE Office of Science proposal.
• Advanced and dynamic performance measurement
• Application-level performance data access
• More sophisticated performance mapping
• Whole system performance analysis
• An Infrastructure for Scalable, Multi-Platform,
  Application Performance Tools, ASCI Level 2
  proposal
• Integration with dynamic instrumentation
• Multi-level performance measurement and mapping
• External runtime performance data access

68
TAU Evolution (continued)

• University of Utah
• Integrated performance analysis of Uintah
  framework
• Runtime performance analysis using SCIRun
• Scalable performance visualization
• Other activities
• Parallel performance database
• Automatic performance diagnosis and analysis
• Integration with Common Component Architecture
  (CCA)
• Performance technology
• Paraver (Barcelona), EARL (Juelich), SCALEA
  (Vienna)
• Integration with LLNL applications / libraries /
  tools

69
Integrated Performance Evaluation Environment
70
More Information and Acknowledgments

• URLs
• TAU www.cs.uoregon.edu/research/paracomp/tau
• PDT www.cs.uoregon.edu/research/paracomp/pdtoolk
  it
• Grant support
• DOE 2000 ACTS
• http//www-unix.mcs.anl.gov/DOE2000
• http//www.nersc.gov/ACTS
• ASCI Level 3 (LANL, LLNL)
• DARPA
