Physical Organization Index Structures Query Processing

1
Physical OrganizationIndex StructuresQuery
Processing

• Vishy Poosala

2
Ke y issues

• (1) Formatting fields within a record
• (2) Formatting records within a block
• (3) Assigning records to blocks.

3
Formatting fields within a record.

• Fixed length fields stored in a specific order.
• Fixed length fields stored as an indexed heap.
• Fields need not be stored in order.
• There is exactly one pointer in the header for
  each field, whether it is present or not.
• Variable length fields delimited by special
  symbols or length.

4
Formatting records within a block.

• Fixed-packed The records are stored contiguously
  within the block.
• A record is located by a simple address
  calculation.
• The structure is highly inflexible and introduces
  inefficiencies.
• Records may span blocks (expensive).
• Insertion and deletion become complicated.
• Page reorganization affects external pointers.

5
Indexed heap

• A block header contains an array of pointers
  pointing to the records within the block.
• A record is located by providing its block number
  and its index in the pointer array in the block
  header.
• The combination of block number and index is
  called TID.

6

• Insertion and deletion are easy they are
  accomplished by manipulating the pointer array.
• The block may be reorganized without affecting
  external pointers pointing to records, i.e.,
  records retain their tid even if they are moved
  around within a block

7
Assigning records to blocks.

• Heap Records are assigned to blocks
  arbitrarily, more or less in the order of
  insertion.
• easy to maintain but provides no help for
  retrievals whatsoever
• Keyed placement Records are assigned to blocks
  according to the values of some key fields.
• The supporting structure implementing the mapping
  of records with specific values in the key fields
  to blocks is called an index.

8
Keyed placement

• This facilitates the execution of retrievals,
  since to a large extent, only relevant records
  are retrieved.
• Updates (insertions and deletions) become
  more expensive, because of the index
  maintenance.
• There are three major index structures
• Hashing
• B-trees
• ISAM

9
Keyed placement by sorting

• Sort the file on the key field(s).
• It is a special case of the general keyed
  placement, with the distinguished characteristic
  that there is no index to be supported.
• Retrievals are performed by binary search
• Faster equality selection than nonkeyed.
• Good for range queries, e.g., age between 22 and
  28.
• Efficient joins, applying merge-scan.
• Slower equality selection than other keyed index
  structures.
• Updates are a pain.

10
Index Structures - ISAM

• ISAM is a multilevel tree structure providing
  direct access to tuples in a relation sorted
  according to some attribute.
• That attribute is called the key of the structure.

11

• Each node of the tree is a page (block) on the
  disk. The nodes of the tree contain
  ltkey_value,pointergt pairs, sorted on
  key_value.
• The internal nodes point to lower nodes in
  the tree, whereas the leaf nodes point to pages
  in the relation.
• A pointer points to a subtree with key values
  greater than or equal the corresponding key_value
  and less than the key_value corresponding to the
  next pointer.

12
Comments

• The tree structure is static, i.e., the
  key_values in the internal nodes do not
  change as tuples are inserted into the
  relation.
• To accommodate insertions of new tuples, overflow
  pages are created in the relation forming a
  linked list.
• Usually, tuples within the linked list of the
  primary and overflow pages are not sorted.

13
Comments

• Occasionally, the index is created with the
  nodes filled at less than maximum capacity
  in anticipation of future updates.
• Excessive overflows result in highly
  unbalanced trees. In this case, the relation
  is sorted and the index is created again.

14
Advantages of ISAM

• It provides a directory for a relation that is
  (for the most part) sorted. Exact queries on the
  key values, e.g., salary30K, are much faster
  than for an unstructured relation.
• The system starts at the root of the tree. It
  follows the pointers down the tree according to
  the given value, until it finally reaches a data
  page in the relation.
• It scans sequentially the data page and the
  possible overflow pages and gets the tuples
  satisfying the qualification.

15

• Assume that there are no overflow pages. Why is
  ISAM better than binary search on the relation?
• Why is ISAM better than binary search on a
  1-level index?
• Costs of 4 methos
• Scan, Binary search, Binary search on 1-level
  index, and ISAM.
• ISAM also facilitates the execution of range
  queries, e.g., 20Kltsalarylt40K

16
Disadvantages

• It is a static structure and may get unbalanced.
• If there is a lot of update activity the relation
  may be far from being "nearly sorted".
• The index does consume some space, which in some
  cases is valuable.

17
B-Trees

• Most popular Index structures
• Like ISAM
• multi-level tree structure
• sequential data organization below
• supports range, equality predicates
• But, Better
• never gets unbalanced
• dynamic reorganization

18

• Leaf nodes contain tuples in sorted order and are
  connected in that order
• All other internal nodes are of the following
  form
• P_1, K_1, P_2, K_2, ..., P_(N-1), K_(N-1), P_N
• say, ...s_i, p_i, k_(i1),... is the parent
  node
• P_1 points to a node containing key values v, v lt
  K_1 v gt s_i
• P_2 points to K_1 lt v lt K_2 ..
• P_N points to v gt K_(N-1), v lts_(i1)

19

• Every node is a page
• The data structure is on disk
• Each useful node is brought into memory for
  processing
• Operations within a page are done in memory

20
BTree Searching

• Follow pointers down the tree, looking for the
  given value.
• Input Key value v. Output Node containing tuple
  with key value v.
• Node Root
• While (Node is not a leaf) do
• Find i s.t. K_(i-1) lt v lt K_i in Node
• Node P_i
• end
• Print (Node)

21
Btree updates

• The tree has to remain balanced on updates in
  order for the fast access
• To insert a tuple with key value v, search for
  the leaf on which v should appear.
• If there is space on the leaf, insert the tuple.
• If not, split the leaf in half, and split the
  range of keys in the parent node in half also.
• If the parent node was also full, split that one.
  If this propagates to the root, split the root
  also.

22
BTree- Deletes

• To delete a tuple with key value v, search for
  the leaf on which v should appear and delete it
• If after the record is deleted the leaf becomes
  less than half full, then either
• move records into adjacent nodes, delete the
  leaf, and propagate the deletions to the parent,
  or
• move records from adjacent leaves into the
  underflowed leaf and propagate the changes.

23
B-Trees

• They have pointers to data from the internal
  nodes.
• For each key value that appears in an internal
  node, there is a direct pointer from that node to
  the leaves with tuples with that key value.
• Advantages Occasionally faster, if the key
  values are found early.
• Disadvantages Trees tend to be deeper because of
  the smaller fanout. The implementation is also
  more difficult.

24
Hashing

• Hashing Divide the set of blocks of the relation
  into buckets. Often each block is a bucket.
• Select the field(s) which is (are) being indexed.

• Devise a hashing function which maps each value
  in the field into a bucket.

25

• V Set of field values
• B The number of buckets H
• The hashing function H V -gt 0,1,2,...,B-1
• Example
• V 9 digit SSN
• B 1000
• H V -gt 0,1,2,...,999
• H(v) last 3 digits of v v MOD 1000
• Almost any numeric function that generates
  "random" numbers in the range of 0,B-1 is
  feasible.

26

• One of the most popular hashing functions is MOD,
  i.e., divide the field value by B and interpret
  the remainder as the bucket number.
• Example
• What is a BAD Hash function? Why?
• Overflows

27

• Overflows can occur because of the following
  reasons
• Heavy loading of the file.
• Poor hashing function, which doesn't distribute
  field values uniformly.
• Statistical peculiarities, where too many values
  hash to the same bucket.

28

• Overflows are usually handled by one of the
  following ways.
• Chaining If a bucket fills up, chain an empty
  block to the bucket to expand it.
• Open Addressing If H(v) is full, store the
  record in H(v)1, and so on.
• Two Hashing Functions If H(v) is full try H(v).
  If that is full, try any of the above
  solutions.

29

• Performance of a hashing scheme depends on the
  value of the loading factor ( tuples in the
  relation) / (B x S), where B buckets S
  tuples/bucket
• Rule of thumb When loading factor becomes too
  high, a typical tactic is to double B and rehash

30
Good/Bad

• Hashing is great for exact queries
• Since hashing doesn't keep the tuples in any
  sorted order, it is no help with range queries.

31
Secondary Indices

• The Btrees we looked at so far are primary
  indexes
• i.e., data is sorted in the order of the index
  key.
• Unless tuples are stored redundantly, a file can
  only have at most one primary index
• To improve performance of value-based queries on
  other fields, secondary indices can be
  constructed that point to tuples in the file, not
  necessarily stored in order.

32
Example

• Primary Btree index of Emp(name, sal, age) on
  sal and secondary hash index on age.

33
Query Processing

• Architecture of a DBMS query processor
• query language compiler translates the query into
  an internal form, usually a relational algebra
  expression
• query optimizer examines all the equivalent
  algebraic expressions and chooses the one that is
  estimated to be the cheapest.
• code generator or the interpreter implements the
  access plan generated by the optimizer

34

• access methods support commands to access records
  of a file, one at a time
• Record layout on pages
• Field layout in records
• Indexing records by field value
• file system supports page-at-a-time access to
  files.
• Partitioning the disk into files
• Managing free space on disk
• Issuing hardware I/O commands
• Managing main memory buffers.

35
Query optimization

• Given a query Q, there is a set A of access plans
  (strategies) to execute Q and find the answer.
• Query optimization is a process of identifying
  the access plan with minimum cost.
• What access plans are there?
• How do we compute a plans cost?
• How do we pick the best choice access plan?

36
Query Cost Estimation

• The cost is usually a weighted sum of the I/O
  cost (number of page accesses) and CPU cost
  (msec's).
• Parameters the optimizers use to estimate
  execution costs
• p(R) For a relation R, its size in pages.
• t(R) For a relation R, its size in tuples.
• v (A, R) For an attribute A in relation R, the
  number of unique values in A
• min (A, R) For an attribute A in relation R, the
  minimum value in A. And max(A,R)
• s(f) Selectivity of the operator f

37
Selectivity

• Ratio of result size to product of input sizes
• Why?
• Need to know sizes of intermediate result sizes
• For estimating their costs

38
Assumptions

• To start with access plans dont use indices
• ignore CPU costs.
• Make uniform distribution assumption over the data

39
Access Plans - Selections

• scan the entire file
• get tuples in memory
• apply predicate
• Cost p(R)
• Selectivity
• equality predicate (A c) t(R) / v(A)
• range predicate (A gt c) t(R) (max(A,R)-c) /
  (max(A,R)-min(A,R))

40
Access Plans - Nesed Loop Joins

• The system scans the complete relation R (outer
  loop).
• For each tuple in R, it scans S (inner loop) and
  whenever the tuples in S and R match on join
  attribute, their combination is put in the
  result.
• for each r in R do
• for each s in S do
• if r.As.A then put s,r in the result

41
N-L Join

• Estimated cost (with one buffer page per
  relation) p ( R ) t(R) p (S)
• Estimated cost for page nested loops (scan the
  inner relation once for every page of the outer
  relation) p ( R ) p(R) p ( S )
• Estimated size of result (assume the same
  number of unique values in A in both
  relations) (1/ v( A, R)) t(R) t(S)

42
Merge Scan / Sort Merge Join

• The system sorts R and S on the join attribute A
  (if they are not already sorted).
• It then scans the two sorted relations in
  parallel, merging tuples with matching join
  attribute values
• Cost
• sortcost(R) sortcost(S) p(R) p(S)
• Result Size same as NL

43
Projection

• Scan the relation
• Select out the necessary attributes
• Cost p(R)

44
Sorting

• Internal sorting doesnt work very well
• data doesnt fit in memory
• Need external sorts
• Use k-way merge sort

45
2-way merge sort

• Consider a relation R with p(R) pages and w
  buffer pages (Assume that p(R)/w 2k )
• Read in, sort in main-memory, and write out
  chunks of w pages. (2k sorted chunks of w
  pages.)
• Read in, merge in main-memory, and write out
  pairs of sorted chunks of w pages. (2(k-1)
  sorted chunks of 2w pages.)

46
2-Way External Sort

• Read in, merge in main-memory, and write out
  pairs of sorted chunks of 2w pages. (2(k-2)
  sorted chunks of 4w pages.)
• ...
• Read in, merge in main-memory, and write out
  pairs of sorted chunks of 2(k-2)w pages. (2
  sorted chunks of 2(k-1)w pages.)
• Read in, merge in main-memory, and write out
  pairs of sorted chunks of 2(k-1)w pages. (1
  sorted chunk of 2kw p(R) pages.)

47
Cost of External Sort

• Each pass requires reading and writing of the
  whole file. The algorithm's I/O cost
• is c(2-way sort ) 2 p(R) (k1) 2 p(R) log
  (p(R)/w) 1
• Example Sort a 20-page relation having a 5-page
  buffer pool.
• Exercise can do 3-way sort, 4-way, ...,
  (w-1)way!
• They are cheaper.

48
Query Processing with Indexes

• Cost Cost(index) Cost(data)
• New parameters
• p(I) For an index I, its size in pages.
• d(I) For a tree index I, the depth of the tree.
• lp(I) For a tree index I, the number of leaf
  pages.
• B(I) For a hash index I, the number of buckets

49
Selection (A c)

• Heap P(R)
• Hash (primary) P(R) / B(I)
• Hash (secondary) P(I) / B(I) t(R)/v(A,R)
• B-tree (primary) d(I) P(R) / v(A,R)
• B-tree (secondary) d(I) lp(I)/v(A,R) t(R) /
  v(A,R)

50
Selection (A gt c)

• Heap P(R)
• Hash (primary, secondary) P(R)
• B-tree (primary) d(I) frac(c) P(R)
• frac(c) (max(A,R) - c) / (max(A,R) - min(A,R))
• B-tree (secondary) d(I) frac(c) lp(I)
  frac(c) t(R)

51
Nested Loop Join on R.A S.A

• Tuple-level R is outer index (if any) on S.A
• Heap P(R) t(R) P(S)
• Hash(prim) P(R) t(R) P(S) / B(I)
• Hash(sec) P(R) t(R) P(I)/B(I) t(S)/v(A,S)
• B-tree(prim) P(R) d(I) P(S)/v(A,S) t(R)
• B-tree(sec) P(R) d(I) lp(I)/v(A,S)
  t(S)/v(A,S) t(R)

52
Merge-Scan

• Depends on indexes on each table
• Hash doesnt help
• Heap/Hash on both
• sortcost(R) sortcost(S) P(S) P(R)
• B-tree(prim) gets rid of the sortcost above

53
Merge-Scan

• Hash/Heap on R, B-tree(Sec) on S
• sortcost(R) P(R) d(Is) lp(Is) t(S)
• B-tree(prim) on R, B-tree(sec) on S
• gets rid of the sortcost above
• B-tree(sec) on R, B-tree(Sec) on S
• d(Ir) lp(Ir) t(R) d(Is) lp(Is) t(S)
