Title: A MODELICABased ObjectCentric Virtual Power Electronics Laboratory


1
A MODELICA-Based Object-Centric Virtual Power
Electronics Laboratory
  • Janhavi Agashe
  • V.V.Sastry
  • V.Ajjarapu
  • S.S.Venkata

Dept. Of Electrical Computer Engineering Iowa
State University
2
Outline
  • Power Electronics Simulators
  • Object-Oriented Modeling Language Modelica
  • Modeling of Components in Modelica
  • Various Models Developed
  • Simulation Results
  • Conclusions

3
Inter-Disciplinary Nature of Power Electronics
Power Electronics
4
Power Electronics Simulators
  • A simulator for power electronic systems should
  • Have event handling capabilities.
  • Handle hybrid/ mixed-mode systems.
  • Support multi-domain modeling.
  • Widely used simulators SABER, PSPICE,
    MATLAB/SIMULINK etc.
  • Lack of Object-oriented features
  • Closed modeling environment

5
Object-oriented Modeling Language - Modelica
  • Developed by the Modelica Association, Germany
  • Key Features
  • Object-oriented modeling language
  • Hierarchical structuring
  • Reuse
  • Effective in solving large and complex models
  • Open Modeling Environment

6
Object-oriented Modeling Language - Modelica
  • Additional Features
  • Acausal modeling
  • Ports are not committed to input and output
    early in the modeling/design process
  • Simpler models
  • More efficient simulation
  • Multi-domain
  • Electrical circuits, multi-body systems, drive
    trains, hydraulics, thermodynamic systems

7
Object-oriented Modeling Language Modelica
  • Additional Features (contd.)
  • Several formalisms
  • ODE, DAE, bond graphs, finite state automata,
    state charts
  • Graphical user interfaces
  • Icons representing model components
  • Menu driven interface for modeling and simulation
  • Standardization effort
  • Group of internationally recognized and
    experienced researchers and companies worked for
    language and model development

8
Modeling of Components in Modelica
  • Model is derived as an extension of some base
    class using the extends statement
  • Required variables are declared
  • Necessary equations are defined in the equation
    section
  • The annotation section defines the graphical
    symbol i.e. icon for the model
  • The file is saved as .mo

9
Modeling of Components in Modelica
10
Thyristor Model in Modelica
  • model Thyristor
  • constant Boolean DymolaCompatibilitytrue
  • extends Modelica.Electrical.Analog.Interfaces.Th
    reePin
  • Real Gate
  • Real u
  • Real GOp 1.E-5
  • Real RCl 1.E-5
  • Real i
  • Boolean GATE
  • Boolean Op(starttrue)
  • equation
  • cont.v Gate
  • u p.v-n.v
  • ip.i
  • 0p.in.i
  • GATE if (Gate lt 1.0) then false else true
  • 0 if Op then i - GOp(p.v - n.v) else (p.v -
    n.v) - RCli
  • when (not (Op) and i lt 0) or (Op and u gt 0 and
    GATE) then
  • new(Op) (not (Op) and i lt 0) or (Op and not
    ((u gt 0 and GATE)))

11
Models in the Power Electronics Library
12
Architecture of Simulator
  • Front-end
  • Pre-processing tool that helps effective
    understanding and modeling
  • DYMODRAW
  • Simulation Engine
  • For conversion DAEs into state space form and
    solving them symbolically or with efficient
    numerical techniques.
  • DYMOSIM. Any other simulator like ACSL, SIMULINK,
    etc. can also be used.
  • Post-processing tool
  • Visualization of dynamic behavior, 2-D or 3-D
    graphical view or animation.
  • DYMOVIEW

13
Architecture of Simulator
14
Step by Step Simulation Procedure
Single Thyristor
Switch Library
Various Libraries
15
Step by Step Simulation Procedure
Connection of components
Entire Circuit its Translation
16
Step by Step Simulation Procedure
Simulation Control
Plot Window Output Variables
17
Single-Phase Bridge Rectifier
18
Single-Phase Bridge Rectifier
Firing Angle 45 degrees
Firing Angle 30 degrees
19
Buck Chopper
iout
Vout
20
Buck Chopper
Duty Ratio 0.75
21
MODELICA Based EE 452 Laboratory Experiments
  • Single Phase Thyristor Rectifier
  • Three Phase Thyristor Rectifier
  • Buck Chopper
  • Boost Chopper
  • Single Phase Square-Wave Inverter
  • Three Phase Square-Wave Inverter
  • Chopper-fed DC Motor Drive
  • V/F control of Induction Motor

22
Conclusions
  • Object-oriented modeling language enabled reuse
    of models, hierarchical structuring and easy
    maintenance of models
  • The power electronics library using MODELICA has
    been developed at Iowa State University
  • EE 452 experiments earlier written in DYMOLA have
    been designed around the new MODELICA library
