Interoperability between people, organisations, regions and equipment

1
Interoperability between people, organisations,
regions and equipment

• Middle East TETRA Conference
• Dubai May 2004
• Risto Toikkanen
• Nokia

11.05.2004
2
Various dimensions of Interoperability

• Global issues in Public Safety Security
• Organisational interoperability
• Between agencies/organisations
• Between people
• Regional interoperability
• Between regions
• Across national borders
• Technical interoperability
• Between equipment

3
Organisational dimension

• Organisational interoperability
• Capability for agencies to communicate with each
  other
• On a daily basis
• In emergency situations

• Hurdles
• Legislation and/or regulation
• Operating procedures practices
• Information security
• Radio spectrum
• Incompatible equipment

4
Inter-regional dimension

• Inter-regional interoperability
• Capability for peer agencies to communicate
  across borders
• Between regions
• Across national borders
• New dimension cross-agency cross border
• Hurdles
• Legislation and/or regulation
• Politics
• Operating procedures practices
• Information security
• Radio spectrum
• Incompatible technologies/equipment

In Europe the cross-border interoperability is
high on the EU/Schengen agenda.
5
Technology dimension

• Technical interoperability
• Process to ensure that equipment from multiple
  vendors are compatible
• Problem-free operation
• Wanted functionality
• In practice it is about protocol conformance
• Hurdles
• Standardisation
• Standard conformance
• Verification and certification
• Competitive environment
• Customer preferences
• Backward compatibility

6
Organisational interoperability solutions

• Operating procedures
• Agreements
• Training
• Dedicated radio channels
• Common technical specification
• Agreed procedures
• Radio spectrum harmonisation
• In some form this is a must
• Technology harmonisation standards
• Necessary to gain radio compatibility
• Shared networks
• By far the most efficient tool
• Requires high-tech system to ensure privacy
• Both operational benefit and cost benefit

BEST RESULT
7
Regional interoperability solutions

• 1. Political organisational readiness
• 2A. Conventional technical measures
• Extra equipment like cellphones
• Extended coverage across border or repeaters
• Control room interconnect by wireline
• Radio swap between control rooms e.g. Belgium
  France
• Radio swap between users
• 2B. Network interconnect
• TETRA Inter-System Interface (ISI)
• Three-country pilot Belgium Germany The
  Netherlands
• Cross-network PMR functionality, first time
• True cross-agency cross-border opportunity

8
Three-Country Pilot (1)

• Agreement between the governments of Belgium,
  Germany and The Netherlands
• Based on the requirements of the Schengen
  Agreement on cooperation of police forces and
  customs across the national borders
• To pilot cross-border functionality with TETRA
  ISI
• To create operational scenarios

9
Three-Country Pilot (2)

• Phase 1 pilot testing completed in 2003 by use of
  pre-ISI solutions
• Operational scenarios built and tested in
  practice
• final report published at www.3countrypilot.com
• Phase 2 ongoing now with operational requirements
  specification for the TETRA ISI produced in 2004
• Winner of Outstanding contribution to TETRA award
  in TWC 2003
• please see www.3countrypilot.com

10
Technical interoperability solutions

• Solutions are deeply technical
• Decisions are done in early development phase
• Cross-technology interoperability
• Specific operating modes like analog FM radio
  channels
• TETRA Interoperability
• The TETRA Interoperability (IOP) concentrates on
  technical interoperability certification of
  multi-vendor TETRA equipment.
• Successful IOP certification is fundamental in
  creation of open multi-vendor market.
• Open multi-vendor market is fundamental for the
  success of TETRA - and it has happened

11
Benefits of open multi-vendor market

• User benefits
• wide choice of compatible certified terminals
• specialised product for special needs
• continuous and genuine competition
• less dependency - lower risk of market
  disturbances
• Industry benefits
• wider market, bigger volumes
• more possibility to invest faster product
  creation
• longer lifetime of market
• TETRA MoU Association runs the IOP certification
  process to guarantee open multi-vendor market

12
TETRA IOP Certification process
ACCEPTED into OPERATION (Also need CE mark or TA)
STANDARDS
CERTIFICATE
TMO AI group DMO AI group ISI group (PEI group)
MoU
MoU
Operator/User Association Technical
Forum Members Enquiry
Certification Body ISCTI )
Rome/Italy
approx 12 suppliers
TEST PLANS
TIP SPECS
) Instituto Superiore delle Comunicazioni e
tecnologie dell'Informazione
13
TETRA IOP deliverables

• TETRA Interoperability Profile (TIP) documents
  available to members
• V D Air Interface TIPs Parts 1 to 17 are
  published or agreed
• DMO TIPs Parts 1 to 3 are published or agreed
• TETRA ISI TIPs Parts 1 to 6 are published
• TETRA Interoperability Test Plan documents
  available to members
• V D Air interface Test Plans Parts 1-5, 7, 9-11
  are published and used in certification
• DMO Test Plan Part 1 is published and used in
  certification
• Certification test sessions arranged at
  manufacturers premises to run the test cases
  specified in the Test Plans
• TETRA IOP Certificates are public documents and
  published at the TETRA MoU website
• A process is ongoing to improve the layout of the
  certification document to be more easily readable
• Most customers today require their equipment
  supplier to provide IOP certificates on the
  features they purchase

14
TETRA IOP achievements

• Tested and certified functionality
• V D Air Interface TIPs
• Part 1 Core (incl MS-ISDN dialling)
• Part 2 Short Data Service
• Part 3 Dynamic Group Number Assignment
• Part 4 Authentication
• Part 5 Packet Data
• Part 7 Fleet Specific Short Number Dialling
• Part 9 Ambience Listening
• Part 10 End-to-end encryption with CVO
• Part 11 Air Interface Encryption Direct Mode
  Operation TIPs
• Part 1 Core

• Tested products from
• Cleartone
• DeTeWe
• Frequentis
• IFR (tester)
• Marconi/OTE
• Motorola
• Niros
• Nokia
• Rohde Schwarz
• Rohill
• Simoco/Sepura
• Teltronic
• Thales
• Certificates at
• www.tetramou.com

THE AMOUNT OF CERTIFICATES VARIES BETWEEN
COMPANIES AND IS GROWING
15
Conclusions

• Organisational interoperability
• Best cooperation is achieved by a shared network
• Current TETRA technology allows privacy and
  sharing
• Not to forget the cost savings by sharing
• Regional interoperability
• Becoming more more important
• TETRA ISI is the tool for network interconnect
• Technical interoperability
• TETRA created a true multi-vendor market
• Benefits to both users and industry
• TETRA IOP Certificate is the paper to ask for
