Title: CS320, Programming Languages

Language Design
  • CS320, Programming Languages

Design and Implementation
  • Language Design Influences
  • Language Design Trade-offs
  • Implementation Methods
  • Language Evolution

Computer Architecture
  • Von Neumann Architecture is the most prevalent
  • Idea Instructions and data share memory
  • CPU processes instructions from MEM, invokes ALU,
    stores results in MEM

Execution on a von Neumann Machine
  • Proceeds as follows
  • Instructions are stored sequentially in memory
  • OS transfers control to user program at beginning
  • Control goes back to OS at the end

Building a Language
  • If we base it on von Neumann, we call this an
    imperative language
  • Any language whose central feature is variables
    and the assignment of values
  • Examples Fortran, Pascal, C, C, Java
  • What do variables model?
  • What does an assignment statement model?
  • Why is sequential instruction execution fast on a
    von Neumann machine?

Food for Thought
  • There are functional languages out there without
    these features whose only construct is applying
    functions to a set of arguments. Sounds simple
  • Examples Lisp, SCHEME
  • Von Neumann architectures are the most prevalent
  • So why have functional languages not become

Programming Methodologies
Categorizing Languages
Categorizing Debates
  • What do we call scripting languages?
  • Use the same metrics
  • What about markup languages (XML, HTML)?
  • They are description languages
  • And domain-specific languages?
  • Have their own classification schemes, really
  • So well stick to general purpose, programming

Tradeoffs in Language Design
  • Hoare (1973) There are so many important, but
    conflicting criteria, that their reconciliation
    and satisfaction is a major engineering task.
  • Lets go through some of the primary tradeoffs
    that we will sometime see.

Tradeoff 1 Reliability vs. Execution Time
  • The more runtime checks your perform, the slower
    your program will execute
  • Java is a classic example
  • All references to array elements get checked
    before use
  • C is the other side
  • You can access an array out of bounds
  • Itll trigger a memory access violation, or
    exhibit unpredictable behavior, or behave just
  • C is faster than the Java equivalent, Java is
    more reliable

Tradeoff 2 Readability vs. Writability
  • But wait, we said earlier that readability is a
    requirement of writability!
  • True, but sometimes a high level of writability
    reduces readability
  • Case in point APL
  • Lots of mathematical operators
  • High level of orthogonality operations on
  • Heres a one-line program that finds primes
  • Hardly readable!

Tradeoff 3 Writability vs. Reliability
  • C allows memory manipulation, through the pointer
    data type
  • If you access the wrong memory address again,
    access violations, unpredictable behavior, or
    normal execution could result
  • Java does not have pointers, and everything is
    automatically garbage collected. Thats safe.
  • C is thus more powerful, Java is more reliable
  • Is it clearer now, why C is often used to program
    operating systems?

Virtual Computers
  • This is what language tools (compilers,
    interpreters, etc.) create i.e. the aura of a
    Java computer
  • In reality, the computer itself understands its
    own machine language which we call
    macroinstructions, and the tools perform
    appropriate conversions

Sample Virtual Computers
  • Java Computer OS Java Compiler JVM
  • C Computer OS C Compiler
  • SCHEME Computer OS SCHEME Interpreter
  • Languages can directly or indirectly make system
    calls to the operating system
  • Request resources
  • Launch new processes
  • Open/close files

  • The user programs in a high-level language
  • But the computer can only understand machine
  • We need to convert between the two
  • This is the job of compilation
  • Advantage runtime speed

Lexical Analysis
  • Remove comments
  • Convert characters in the source into tokens
  • Example tokens
  • VAR(X)

Syntax Analysis
  • Takes the tokens as input
  • Knows the rules of the language, i.e. the
    language grammar
  • Produces syntax errors if there are any
  • For example, say in Java I left out a semicolon
  • int x 4
  • float y

Intermediate Code/Optimization
  • Simplified intermediate form generated
  • Semantic analyzer catches logic errors, like
    passing incompatible types
  • Optimization (optional) makes program smaller,
    faster, or use less memory
  • Whats the tradeoff with an optimizer?

Symbol Table
  • Acts as a database
  • Any user-defined names (variables or functions)
    and associated types are included
  • Lexical and Syntax Analyzer insert into the
  • Semantic Analyzer and Code Generator check it

Code Generation
  • Performs final conversion to machine language
  • Can we use the same code generation for all
    architectures (Intel, SPARC, etc.)?

  • What if we need to use other machine code?
  • For example, in C, if I want to print an integer
    x to the screen
  • printf(d, x)
  • Wheres the machine code for printf?
  • Answer It is contained within system files. We
    must thus link this machine code.

Linking Step
Something to remember
  • The von Neumann bottleneck
  • Remember, instructions and data each reside in
  • Loading an instruction from memory is in general
    much slower than executing the instruction.
  • Solution Parallel Computing
  • Important area of research

  • An interpreter is a software program which takes
    the source program and interprets its
  • Advantage Good debugging
  • Disadvantages
  • Slow execution time
  • Takes more memory

Hybrid (Java, Perl, Python..)
  • Java statements are first compiled to
    intermediate byte code
  • Byte code is then interpreted by the JVM
  • More tools have been developed recently
  • Machine language translators and JIT

Food for Thought
  • Why would having both a compiled and interpreted
    language implementation be a good thing?

  • Executed before compilation, performs
    substitutions in source code.
  • Seen more with C
  • Preprocessor can paste in the contents of a
  • include myFile.h
  • Preprocessor can substitute a value for an
  • define PI 3.1415926535

Interactive Development Environments
Evolution of Programming Languages
Anyone seen this before? Theres a more updated
version in your textbook! Rest of the class
will be a history lecture
The first language Plankalkul (1945)
  • Invented by the German scientist Konrad Zuse
  • Integer and floating point operations
  • Arrays and records
  • If statement, and looping
  • Ran on the Z4
  • Sample program to assign A5 A41,with A
    being an array of n-bit integers
  • A 1 gt A
  • V 4 5
  • S 1.n 1.n

Plankalkuls arrival got delayed..
  • In the meantime, people started programming in 0s
    and 1s
  • Each instruction for hardware was a series of
    on/off signals
  • Hard to read
  • If your program is stored sequentially in memory
    and instructions reference each other, adding or
    removing them becomes problematic
  • So we found our own need for higher level
  • Even though, really, Zuse had done it 10 years

Short Code (1952)
  • A bit higher level, operators represented by
    integer codes
  • For example
  • X0 sqrt(abs(Y0))
  • Would look like this
  • 00 X0 03 20 06 Y0
  • 50 times slower than machine code!
  • UNIVAC compiler was the first in 1953
  • Speedcoding introduced floating point operations
    in 1954

Fortran (1954)
  • IBM 704 included floating point operations in
  • Sparked the Laning and Zierler system (compiler)
  • Stands for FORmula TRANslating System FORTRAN
  • Fortran 0 Experimental
  • Fortran I (1957) I/O, six-character naming
    schemes, subroutines, if, do
  • Fortran II (1958) Independent subroutine
  • Fortran 66 (1966) Variable declarations
  • Fortran 77 (1977) Strings, else
  • Fortran 90 (1990) Dynamic arrays, records,
  • Fortran 95 (1995) forall
  • Fortran 03 (2003) OOP

LISP (1958)
  • Emerged from interests in list processing and AI
  • Two kinds of data structures
  • Atoms
  • Lists (contain atoms or other lists)
  • (A (B C) D (E (F G)))
  • A list means the application of a function, what
    are the functions above? You can write your own
  • (defun square (x) ( x x))
  • (square 4) lt- Returns the value 16
  • Descendants SCHEME (1975) and COMMON LISP (1996)

ALGOL 60 (1960)
  • This was the first attempt at a universal
    programming language. The ALGOrithmic Language.
  • Goals
  • Syntax close to mathematical notation
  • Use to describe an algorithm
  • Programs must translate to machine language
  • Success only as an algorithmic language
  • Failure as a programming language
  • Too much debate on features
  • No I/O
  • Features were too complex at the time people
    still entrenched with Fortran

COBOL (1960)
  • Designed primarily for business applications
  • Still the most widely used
  • Strengths Ease of use and readability
  • Sacrificed Computing power
  • But for the domain, thats really ok!
  • Biggest contribution The record
  • See an example, pages 65-67

PL/I (1965)
  • Another attempt at a universal language.
  • ..
  • Triggered by two separate groups of users
  • Goal replace Fortran, COBOL and LISP
  • ..
  • Contributions
  • Exception handling
  • Pointers
  • Array cross sections
  • Main problem was the large size (too many

SIMULA (1967)
  • Beginnings of data abstraction
  • Began the concept of a class
  • Designed mostly for simulation, struggled for
    acceptance outside of that area
  • What does this and the experience of ALGOL 60
    (which introduced blocks and good control
    structures) tell us?
  • Descendants of this and ALGOL are used today!

ALGOL 68 (1968)
  • Main goal was orthogonality
  • User-defined data types
  • Flexi-arrays
  • Goal was writability, compare to PL/I
  • PL/I achieved it by providing a large number of
  • ALGOL 68 provided a few basic constructs, but
    maintained orthogonality
  • Effectively an unlimited set of data types
  • Descendants Pascal, C, C, Java

BASIC (1971)
  • Designed for the user
  • Easy to learn
  • Pleasant and friendly
  • Biggest contribution Timesharing
  • GE 255 at Dartmouth University had the compiler
  • 14-20 students could execute batch jobs
  • At the time punch cards were popular
  • Early versions were not conducive to complex
  • Resurged in the 90s with True and Visual Basic
  • Example, p. 69

SNOBOL (1971)
  • First language designed for text processing
  • Powerful operations for string pattern matching
  • Where could this be applied?

Pascal (1973)
  • Designed as a teaching language
  • Most popular for teaching programming up through
    the late 1990s
  • Balanced simplicity and expressive power well
  • Not designed for scientific or performance
    intensive tasks

Prolog (1975)
  • Main logic language
  • Uses declarative semantics you can discern the
    meaning of a statement independently of context
  • High-level
  • Specifies the form of the result
  • Not how its computed
  • Example (evaluates to true)
  • parent(joanne, jake)
  • parent(vern, joanne)
  • grandparent(x, z) parent(x, y), parent(y, z)
  • grandparent(vern, jake)

C (1978)
  • BCPL (1969), simple systems language
  • B (1970)
  • Typeless
  • Everything considered in terms of (1 or more) 32
    bit words
  • C
  • Statically typed
  • Provides flexibility, sacrifices safety
  • No complete type checking
  • Memory management
  • Connections to UNIX

Smalltalk (1980)
  • Took SIMULA to the extreme
  • Completely object-oriented
  • Everything is an object, all computing follows
    the following procedure
  • Send a message to an object, invoking a member
  • Object replies by sending another object
    (message) back

Ada (1983)
  • 450 programming languages in use by the
    Department of Defense a problem
  • This was an attempt to standardize
  • Main features
  • Exception handling (clean recoveries from error)
  • Generic program units
  • Types can be unspecified, determined at compiled
  • Concurrent execution of procedures
  • Termed a rendezvous
  • Procedures could communicate and share data

Perl (1987)
  • Scripting language
  • Memory efficient arrays
  • Gaps do not take up space
  • Allows string-indexing
  • Implicitly declared variables
  • Scalars start with
  • Arrays start with _at_
  • Associative arrays start with
  • Look at p. 85 for an example.
  • Great for text processing (like SNOBOL)

C (1990)
  • Builds on C, support some of the features of
  • In fact, it was originally termed C with
  • Supports procedural and object-oriented
  • Can inherit from multiple superclasses
  • Virtual functions
  • Operators can be overloaded (meaning can
  • Functions generic by type (templates)
  • VERY popular language
  • Backcompatible with C and tools are inexpensive
  • Has similar insecurities and flexibility of C
  • Compare Eiffel (1992) and Delphi (Pascal,

Java (1993)
  • Derived from C
  • Goals Smaller, simpler and safer
  • Initially for embedded systems
  • Cannot write standalone programs all control
    proceeds through member functions starting with
  • Supports only object-oriented programming
  • No multiple inheritance
  • Supports concurrent execution
  • Implicit garbage collection
  • Safe type coercions
  • Unlike C, where a float could be coerced to an int

Java also wanted portability
  • So they implemented a two-step process
  • Compile source code to byte code
  • Run the JVM software to interpret the byte code
  • Any machine with a JVM could use Java
  • Problem Much slower than a fully compiled
    language which runs machine code on the hardware
  • Fix Just-In-Time Compilation
  • A third step
  • When a program is loaded into memory, translate
    byte code to machine code, then run it
  • So you only have an initial translation

Scripting Languages
  • JavaScript (1998)
  • Runs on a client, can create/modify HTML
  • PHP (2000)
  • Runs on a server, replaces its own source with
  • Can interact with databases
  • Python (2004)
  • Object-oriented, dynamically typed, lists,
    tuples, dictionaries, pattern matching, exception
    handling, garbage collection, can call
    precompiled C code
  • NEWS FLASH Popularity climbing
  • Ruby (2005)
  • Purely object-oriented, dynamic class definitions

C (2002)
  • Purpose Component-based software development
  • Brings back the features of C that Java took
  • Except multiple inheritance
  • Delegates allow functions to be passed around
    and assigned to variables
  • foreach statement useful for iterating over
    members of a container
  • Designed for use with .NET
About PowerShow.com
