Scaling and Validation Programme

1
VL-e PoC Architectureand the VL-e Integration
Team
David Groep VL-e work shop, April 7th, 2006
2
The VL-e PoC Proof-of-Concept

• What is the PoC Environment?
• A shared, common environment,
• where different tools and services are
• both used and
• provided by the VL-e community
• The basis for further application development

3
PoC Position in the VL-e structure
Application specific service
App1
App 2
App 3
Application Potential Generic service
Virtual Lab. services
Virtual Lab. rapid prototyping (interactive
simulation)
Virtual Laboratory
Additional Grid Services (OGSA services)
Grid Middleware
Grid Network Services
Network Service (lambda networking)
Networking
VL-e Experimental Environment
VL-e Proof of concept Environment
4
PoC R1 Architectural Vision

• Many different tools and services
• from many different providers
• tied together in a common framework
• Service-Oriented Architecture (SOA)
• Aim for re-useable software components
• Integrated at the work-flow layer
• Needs commitment from everyone to work on and
  with the PoC and in this shared environment

5
Service Orientation

• All functions defined as services
• All services are independent
• Operate as "black boxes"
• external components neither know nor care how
  boxes are executed
• merely that they return the expected result.
• The interfaces are invocable
• At an architectural level, it is irrelevant
  whether
• they are local or remote
• what interconnect scheme or protocol is used to
  effect the invocation, c
• In the VL-e and Grid environment, these
  invocations are across different organisations
  and domains

from Adam Belloum, Introduction to Grid
Computing 2005-2006, UvA Master of Grid Computing
6
Service Orientation
non-SOA architecture
service oriented
Grid Services are services that operate
on stateful resources
from Adam Belloum, Introduction to Grid
Computing 2005-2006, UvA Master of Grid Computing
7
Service composition

• Services in the architecture represent basic (but
  not necessarily atomic) functionality
• Services can also be general purpose
• actors in work flow system run legacy
  applications
• use such general purpose services for
  high-through or high-performance tasks
• dont just servicize everything you see
• Work flow should be the integrative layer of VL-e
• means functionality should be invocable as a
  service
• work flow (graphical) systems help in
  compositionbut are not the only way to interact
  with services

8
PoC Environment

• The PoC distribution contains components to
• enable service-oriented development
• enable application development
• provide access to computing, storage, and
  information systems
• distributed geographically
• driven by the VL-e application scenarios (use
  cases)
• stable base environment, with managed releases
• today R1 is (still) mostly a bag of components

9
VLeIT the VL-e Integration Team

• Steering PoC Development and the VL-e Architecture

10
VLeIT members
Scientific Director (chair) Bob Hertzberger
Applications liaison Robert Belleman
Adapt. Inform. Disclosure Machiel Jansen
Workflow Zhiming Zhao, Paul van Hooft, Adam Belloum
Information Management Nader Mirzadeh,Hakan Yakali,Paul van Hooft
Visualization Robert van Liere
Problem Solving Environments Breanndán Ó Nualláin
HPCN and RP representative Kees Verstoep
Scaling Validation David Groep
PoC infrastructure Maurice Bouwhuis
11
VLeIT Activities

• Application scenario (use case) coordination
• Collecting usage scenarios
• Correlate across SPs and identify common
  elements
• Advising the application scenario groups
• Define the content of the PoC Distribution
• focus on tools that are shared between SPs
• incorporate tools that are the basis for our SOA
  model
• Management of the scientific-programmer pool
• prioritization of the development effort
• driven by the application scenario groups
• Outputs are Recommendations to the Directorate

12
Application Scenario Groups

• Scenarios proposed defined by the application
  SPs
• Small design team (3-4 persons)
• from application ICT experts and selected P2
  experts
• comes up with a design/sequence diagram
• identifies existing relevant components
• does a gap-analysis
• proposes the work plan to completion
• VLeIT compiles the results
• assigns scientific programmers
• updates the PoC environment with relevant
  components or new developments

13
Application Scenario Status

• 20 scenarios submitted
• Subset prioritized for the R1 timeframe
• Prioritization based on resource availability
• By VLeIT in consultation with the applications
• Some have been completed
• High-throughput parallel processing of R
• Several ongoing
• Targeted at or intended for the PoC Environment
• see Adam Belloums presentation this afternoon

14
Defining content of the PoC Distribution
Tagged Release Candidates
Download RepositoryPoC Installer
Common repositoryIntegration tests
stable, tested releases
External software
VLeIT Recommendation Point
15
Elements in the PoC

• The PoC refers to three distinct elements
• PoC Software Distribution
• set of software that is the basis for the
  applications
• both grid middleware and virtual lab generic
  software
• PoC Environment
• the ensemble of systems running the Distribution
• including your own desktops or local
  clusters/storage
• PoC Central Facilities
• those systems with the PoC Distribution centrally
  managed for the entire collaboration
• computing, storage and hosting resources

16
The PoC software distribution

• The PoC software suite. For convenience, the
  following elements of this suite can be
  distinguished
• Grid foundation middleware the basic software
  that is based on interfaces and concepts that are
  globally adopted and standardized. This includes
  elements such as the security model, resource
  allocation interface,
• Generic Virtual Laboratory software the software
  developed within the project for the PoC.
• Services imported from outside given that not
  all services are necessarily developed within
  VL-e, some will be imported.
• Associated installation and deployment tools the
  PoC suite is installed on the central facilities
  and (where applicable) also available for
  distributed installation.

17
PoC R1 Questions and Support

• Each software component has an expert on VLeIT
• to work with you on its optimal use or deployment
• coordinate enhancement requests
• see http//poc.vl-e.nl/ under software for a
  list
• Availability
• Download http//poc.vl-e.nl/distribution
• On DVD
• Via a trial run in a virtual machine (image on
  the DVD)

18
In Summary

• PoC provides common basis for applications
• Driven by the application scenarios
• Designed for your (application) purposes
• Managed via the VLeIT Team

http//poc.vl-e.nl/
