Evaluation of performance aspects of the Auto-ID Infrastructure

1
Evaluation of performance aspects of the Auto-ID
Infrastructure

• Kai Sachs (TU Darmstadt)Supervisors Christof
  Bornhoevd (SAP)
• Mariano Cilia (TU Darmstadt)

2
CONTENTS
Auto-ID Infrastructure
Measurement Approach
Results of the Experiments
Final Conclusions
3
Auto-ID Infrastructure
Measurement Approach
Results of the Experiments
Final Conclusions
4
AII Overview (1)

• SAP Auto-ID Infrastructure 2.0 (AII)
• Middleware solution
• Receiving RFID data from data capture sources
  (e.g. RFID devices)
• Integrates the data into enterprise applications.

• Early prototype

5
AII Overview (2)

• The illustration below shows an overview of SAP
  RFID landscape

SAP Exchange Infrastructure (XI)
Device Controller
SAP R/3
SAP Auto-ID Infrastructure (AII)
Reader
Backend
RFID Tags
AII
Auto-ID Cockpit(Web User Interface)
From SAP RFID Solution Package SAP Auto-ID
Infrastructure 2.0 (AII) Theory
6
Auto-ID Node System Architecture

Auto-ID Cockpit
Auto-ID Node
DC
BE
IDoc
Activities
Message Dispatcher
XML
XML
Integration Layer (XI)
Communication Layer
Communication Layer
XML
TG
BE
IDoc
Rule Engine
AIN Repository
From SAP Auto-ID Infrastructure
7
CONTENTS
Auto-ID Infrastructure
Measurement Approach
Results of the Experiments
Final Conclusions
8
Test Environment
9
What should be observed?

• Experiments settings
• Multiple readers
• Message size
• System behavior
• CPU load
• IO Activities
• Single processes
• Memory
• Throughput
• Components on the Auto ID Infrastructure
• Gross Times
• Gross CPU Times

Customized Traffic Generator
Microsoft Performance
Customized Traffic Generator
JARM
10
Microsoft Performance

• Part of Microsoft Windows 2000 XP
• System Monitor
• Allows to observe
• Single processes
• IO Activities
• CPU load
• Observations could be logged in a CSV - file.

11
JARM

• Allows observation of Java components
• Provides averages values and sums per component
• Hierarchies of components are possible
• Results are accessible through Visual
  Administrator
• Needs source code modifications!
• Problems, if JMS is used

12
JARM Measurement Points

Auto-ID Cockpit
Auto-ID Node
DC
BE
IDoc
Activities
Message Dispatcher
XML
XML
Integration Layer (XI)
Communication Layer
Communication Layer
XML
TG
BE
IDoc
Rule Engine
AIN Repository
13
JARM Measurement Points

Auto-ID Cockpit
Auto-ID Node
DC
BE
IDoc
Activities
Message Dispatcher
XML
XML
Integration Layer (XI)
Communication Layer
Communication Layer
XML
TG
BE
IDoc
Rule Engine
AIN Repository
Parser
Rule Processor
HTTP
14
Customized Traffic Generator

• Based on SAP Traffic Generator
• Used to simulate reader observations
• New logging functions were added ?Every sent
  request can be logged ?Allows better review of
  throughput
• Other new functions
• Add Timeframes for experiments
• Send a defined number of messages
• Possibility to run different scripts parallel
• Scenario Definitions

15
CONTENTS
Auto-ID Infrastructure
Measurement approach
Results of the Experiments
Conclusion
16
Results of Experiments

• CPU Load
• IO Activities
• Throughput
• J2EE Components of the Auto-ID Node
• Different VM settings
• Settings of Message Dispatcher

17
Results of Experiments

• CPU Load
• IO Activities
• Throughput
• J2EE Components of the Auto-ID Node
• Different VM settings
• Settings of Message Dispatcher

18
CPU Load
Fall down
Incursions
19
CPU Load

• Incursions and the observed fall down have heavy
  influence on the average CPU load
• ?CPU load differ for the experiments
• ?Throughput depends on CPU load

Need for a key figure for comparison of the
different experiments. ?
20
IO Activities I
Savepoints of MaxDB
21
IO Activities II
Savepoints of MaxDB
22
IO Activities III

• MaxDB Savepoints have a significant influence on
  the system behavior.
• Settings for MaxDB Savepoint intervals can be
  changed.
• Influence of Savepoints is bigger, if the files
  are fragmented.
• The Savepoints could not explain the CPU load
  fall down in the end of the experiment time
  frame!!!

23
Throughput

• Different message sizes
• 9 EPCs per message
• 45 EPCs per message
• 90 EPCs per message
• 900 EPCs per message
• Multiple readers
• 1 simulated reader
• 3 simulated readers
• 5 simulated readers
• 7 simulated readers
• 10 simulated Reader

24
Throughput II
25
Throughput III
26
Throughput IV
27
Throughput V

• Conclusions
• Influence of message size
• Bigger message size ?Higher throughput in no. of
  EPCs per sec.
• Influence of multiple simulated RFID readers
• Throughout increases up to n reader decreases
  after that
• Throughput decreases over time

28
Auto-ID Node Components
29
Auto-ID Node Components
30
Auto-ID Node Components II
31
Auto-ID Node Components III
32
Auto-ID Node Components IV

• Conclusions
• Gross Times scale linear for different message
  sizes.
• The activities are the dominating part of the
  Auto-ID Node.
• The activities are dominated by database
  accesses.

33
CONTENTS
Auto-ID Infrastructure
Measurement Approach
Results of the Experiments
Final Conclusions
34
Final Conclusions I

• CPU Load
• CPU load has short incursions
• Number of simulated readers has no influence on
  the CPU load
• Message size influences the proportions of the
  system processes regarding CPU load
• CPU load decrease at the end of the experiment
  time frame
• IO Activities
• MaxDB Savepoints have a significant influence on
  the system behavior
• Throughput
• Throughput is higher for larger messages
• Throughput decreases over time
• Throughput depends on number of readers

35
Final Conclusions II

• Components of the Auto-ID Node
• Auto-ID Node components scale linear
• Rule Activities are the dominating component
• Performance of Activities is dominated by
  database accesses
• Number of simulated readers has significant
  influence on the Gross Time
• Settings of Java Virtual Machine
• Heap size is the most important parameter for
  higher throughput
• JMS settings of Message Dispatcher
• Throughput is lower, if JMS is used.
• Gross Time is higher, if JMS is used.
