ECE 491 Senior Design I

1
ECE 491 - Senior Design I

• Lecture 2 - Verilog Review
• Fall 2004
• Announcement No lab this week
• Handout Structural Design with Verilog (from
  last year)Read Sections 1-5

Prof. John NestorECE DepartmentLafayette
CollegeEaston, Pennsylvania 18042nestorj_at_lafayet
te.edu
2
Todays Outline

• Overview Electronic Design with FPGAs
• Verilog Review Part 1
• Language Overview
• Combinational Logic
• Continuous Assignment
• Module Instantiation
• always blocks
• Discuss Lab 1
• Overview of the Spartan-3 Starter Kit Board
• Design Problem

3
Levels of Abstraction in Design
Specification (what the chip does, inputs/outputs)
Architecture major resources, connections
Register-Transfer logic blocks, FSMs, connections
Logic gates, flip-flops, latches, connections
Circuit transistors, parasitics, connections
Layout mask layers, polygons
4
FPGA Design Flow

• Synthesis
• Translate HDL to hardware
• Optimize map to CLBs
• Estimate timing
• Placement
• Map CLBs to specific locations
• Routing
• Determine how to interconnect CLBs
• Program
• Download bitstream into FPGA

5
Verilog Review

• Important Points
• Basic Module Syntax
• Combinational Logic
• Parameters
• Module Instantiation
• Sequential Logic
• Finite State Machines

6
Important Points about Verilog

• Verilog is designed to model hardware
• Hardware is parallel, so execution is parallel

7
Important Points about Verilog (contd)

• Verilog is based on event-driven simulation
• Signal values change at specific timepoints
• Each model
• Activates in response to input events
• Creates output events to represent output changes

8
Important points about Verilog (contd)

• Verilog was designed as a simulation language
• Synthesis added as an afterthought
• Only a subset of the language supported for
  synthesis
• Synthesis must match simulated behavior
• Well focus mostly on the synthesis subset
• Structural Descriptions - module instantiations
• Behavioral Descriptions
• assign - continuous assignments
• always blocks
• But, well use simulation capabilities for
  verification
• initial blocks
• Delay

9
Verilog module construct

• Key building block of language
• declaration - specifies a module interface
• Input output ports connections to outside world
• black box model - no details about internals
• body - specifies contents of "black box"
• behavior - what it does
• structure - how it's built from other "black
  boxes"

10
Verilog Review - Language Details

• Syntax - See Quick Reference Card
• Major elements of language
• Lexical Elements (tokens and token
  separators)
• Data Types and Values
• Operators and Precedence

11
Verilog Lexical Elements

• Whitespace - ignored except as token separators
• blank spaces
• tabs
• newlines
• Comments
• Single-line comments //
• Multi-line comments / /
• Operators- unary, binary, ternary
• Unary a b
• Binary a b c
• Ternary a (b lt c) ? b c

12
Verilog Numbers

• Sized numbers ltsizegt'ltbase formatgtltnumbergt
• ltsizegt - decimal number specifying number of bits
• ltbase formatgt - base of number
• decimal 'd or 'D
• hex 'h or 'H
• binary b or B
• ltnumbergt - consecutive digits
• normal digits 0, 1, , 9 (if appropriate for
  base)
• hex digits a, b, c, d, e, f
• x "unknown" digit
• z "high-impedance" digit
• Examples
• 4b1111 12h7af 16d255

13
Verilog Numbers (cont'd)

• Unsized numbers
• Decimal numbers appearing as constants (236, 5,
  15, etc.)
• Bitwidth is simulator-dependent (usually 32 bits)
• Negative numbers
• sized numbers '-' before size -8'd127 -3'b111
• unsized numbers '-' before first digit -233
• Underline '_' can be used as a "spacer
• 12'b00010_1010_011 is same as
  12'b000101010011

14
Verilog Strings

• Anything in quotes is a string "This is a
  string" "a / b"
• Strings must be on a single line
• Treated as a sequence of 1-byte ASCII values
• Special characters - C-like (\)

15
Verilog Identifiers

• Starting character alphabetic or '_'
• Following characters alpha, numeric, or '_'
• Examples george _paul
• "Escaped" identifiers
• start with backslash
• follow with any non-whitespace ASCII
• end with whitespace character
• Examples \212net \xyzzy \foo
• Special notes
• Identifiers are case sensitive
• Identifiers may not be reserved words

16
Verilog Reserved Words

• always and assign begin buf bufif0 bufif1 case
• casex casez cmos deassign default defparam disabl
  e edge
• else end endcase endfunction endmodule
• endprimitive endspecify endtable endtask event for

• force forever fork function highz0 highz1 if ifnon
  e
• initial inout input integer join large macromodule

• medium module nand negedge nmos nor not
• notif0 notif or output parameter pmos
• posedge primitive pull0 pull1 pulldown pullup rcmo
  s
• real realtime reg release repeat rnmos rpmos rtran

• rtranif0 rtranif1 scalared small specify specparam
  strong0
• strong1 supply0 supply1 table task time tran trani
  f0
• tranif1 tri tri0 tri1 triand trior trireg vectored

• wait wand weak0 weak1 while wire wor xnor
• xor

17
Verilog Data Types

• nets - describe wire connections
• general purpose wire
• special purpose supply0, supply1, tri0,
  tri1, triand, trior, trireg, wand, wor
• registers - variables (assigned values by
  procedural statement)
• reg - basic binary values
• integer - binary word (32 bits - machine
  dependent)
• real - floating point (not supported by
  synthesis)
• time - simulation time (not supported in
  synthesis)
• realtime - simulation time (not supported in
  synthesis)

18
More about Data Types

• Vectors - Multiple-Bit Signals (net or register)
• wire 310 sum
• reg 70 avg
• Arrays - used for memories
• reg 70 memory 0255

19
Verilog Logic Values

• Each wire or register type can take on 4 values
• 0 - Standard binary FALSE
• 1 - Standard binary TRUE
• X - UNKNOWN
• Z - High Impedance
• During simulation, all variables originally X
• Complication x z sometimes used as wildcards
  (e.g. casex, casez)

20
Operators and Precedence

• Override with parentheses () when needed

21
Verilog Module Declaration

• Describes the external interface of a single
  module
• Name
• Ports - inputs and outputs
• General Syntax
•         module modulename ( port1, port2, ... )
•           port1 direction declaration
• port2 direction declaration
• reg declarations
• wire declarations
• module body - parallel statements
•         endmodule // note no semicolon () here!

22
Verilog Body Declaration - Parallel Statements

• Parallel statements describe concurrent behavior
  (i.e., statements which execute in parallel)
• Types of Parallel Statements
• assign - used to specify simple combinational
  logic
• always - used to specify repeating behavior for
  combinational or sequential logic
• initial - used to specify startup behavior (not
  supported in synthesis - but useful in
  simulation!)
• module instantiation - used for structure
• and other features useful only in simulation

23
Continuous Assignment - Example

• Full Adder
• module fulladder(a, b, cin, sum, cout)
• input a, b, cin
• output sum, cout
• assign sum a b cin
• assign cout a b a cin b cin
• endmodule

24
Comments about the First Example

• Verilog describes a circuit as a set of modules
• Each module has input and output ports
• Single bit
• Multiple bit - array syntax
• Each port can take on a digital value (0, 1, X,
  Z)
• Three main ways to specify module internals
• Continuous assignment statements - assign
• Concurrent statements - always
• Submodule instantiation (hierarchy)

25
Bitwise Operators

• Basic bitwise operators identical to C/C/Java
• module inv(a, y)
• input 30 a
• output 30 y
• assign y a
• endmodule

26
Reduction Operators

• Apply a single logic function to multiple-bit
  inputs
• module and8(a, y)
• input 70 a
• output y
• assign y a
• endmodule

equivalent to a7 a6 a5 a4 a3
a2 a2 a2 a0
27
Conditional Operators

• Like C/C/Java Conditional Operator
• module mux2(d0, d1, s, y)
• input 30 d0, d1
• input s
• output 30 y
• assign y s ? d1 d0// output d1 when s1,
  else d0
• endmodule

28
More Operators

• Equivalent to C/C/Java Operators
• Arithmetic - /
• Comparison ! lt lt gt gt
• Shifting ltlt gtgt
• Example
• module adder(a, b, y)
• input 310 a, b
• output 310 y
• assign y a b
• endmodule
• Warning small expressions can make big hardware
  if complex operators are used!

29
Bit Manipulation Concatenation

• is the concatenation operator
• module adder(a, b, y, cout)
• input 310 a, b
• output 310 y
• output cout
• assign cout,y a b
• endmodule

30
Bit Manipulation Replication

• n pattern replicates a pattern n times
• module signextend(a, y)
• input 150 a
• output 310 y
• assign y 16a15, a150
• endmodule

31
Internal Signals

• Declared using the wire keyword
• module fulladder(a, b, cin, s, cout)
• input a, b, cin
• output s, cout
• wire prop
• assign prop a b
• assign s prop cin
• assign cout (a b) (cin (a b))
• endmodule

32
Combinational always blocks

• Motivation
• assign statements are fine for simple functions
• More complex functions require procedural
  modeling
• Basic syntax
• always (sensitivity-list)
• statement
• or
• always (sensitivity-list)
• begin
• statement-sequence
• end

33
Combinational Modeling with always

• Example 4-input mux behavioral model
• module mux4(d0, d1, d2, d3, s, y)
• input d0, d1, d2, d3
• input 10 s
• output y
• reg y
• always _at_(d0 or d1 or d2 or d3 or s)
• case (s)
• 2'd0 y d0
• 2'd1 y d1
• 2'd2 y d2
• 2'd3 y d3
• default y 1'bx
• endcase
• Endmodule

34
Another Example ALU from ECE 313

• module alu(ctl, a, b, result, zero)
• input 20 ctl
• input 310 a, b
• output 310 result
• output zero
• reg 310 result
• reg zero
• always _at_(a or b or ctl)
• begin
• case (ctl)
• 3'b000 result a b // AND
• 3'b001 result a b // OR
• 3'b010 result a b // ADD
• 3'b110 result a - b // SUBTRACT
• 3'b111 if (a lt b) result 32'd1
• else result 32'd0 //SLT
• default result 32'hxxxxxxxx
• endcase
• if (result 32'd0) zero 1

35
Modeling with Hierarchy

• Create instances of submodules
• Example Create a 4-input Mux using mux2 module
• Original mux2 module
• module mux2(d0, d1, s, y)
• input 30 d0, d1
• input s
• output 30 y
• assign y s ? d1 d0
• endmodule

36
Modeling with Hierarchy

• Create instances of submodules
• Example Create a 4-input Mux using mux2 module
• module mux4(d0, d1, d2, d3, s, y)
• input 30 d0, d1, d2, d3
• input 10 s
• output 30 y
• wire 30 low, high
• mux2 lowmux(d0, d1, s0, low)
• mux2 highmux(d2, d3, s0, high)
• mux2 finalmux(low, high, s1, y)
• endmodule

37
Data Types and Module Ports

• Input ports must always be a wire (net)
• Output ports can be wire or reg

wire
reg
wire
wire
wire
wire
38
Parameterized Modules

• Parameters - define values that can change
• Declaration
• module mod1(in1, in2, out1, out2)
• parameter Ndefault-value
• input N-1 0 in1, in2
• output N-1 0 out1
• endmodule
• Instantiation
• wire 70 w, x, y
• wire z
• mod1 (8) my_mod1(w,x,y,z)

39
Parameterized Modules Example

• N-bit 2-1 multiplexer (parameterized bitwidth)
• module mux2( sel, a, b, y )
• parameter bitwidth32
• input sel
• input bitwidth-10 a, b
• output bitwidth-10 y
• assign y sel ? b a
• endmodule
• Instantiations
• mux2 (16) my16bit_mux(s, a ,b, c)
• mux2 (5) my5bit_mux(s, d, e, f)
• mux2 (32) my32bit_mux(s, g, h, i)
• mux2 myDefault32bit_mux(s, j, k, l)

40
Symbolic Constants with Parameters

• Idea use parameter to name special constants
• parameter RED_ALERT 2b11
• parameter YELLOW_ALERT 2b01
• parameter GREEN_ALERT 2b00
• Dont change in module instances
• Do this to make your code more understandable
• For others reading your code
• For yourself reading your code after some time
  has passed

41
Symbolic Constant Example

• 7-segment decoder from Verilog Handout (Part 1)
• module seven_seg_display_decoder(data, segments)
• input 30 data
• output 60 segments
• reg 60 segments
• // Segment abc_defg hex
  equivalent
• parameter BLANK 7b111_1111 // h7F
• parameter ZERO 7b000_0001 // h01
• parameter ONE 7b100_1111 // h4F
• parameter TWO 7b001_0010 // h12
• parameter THREE 7b000_0110 // h06
• parameter FOUR 7b100_1100 // h4C
• parameter FIVE 7b010_0100 // h24
• parameter SIX 7b010_0000 // h20
• parameter SEVEN 7b000_1111 // h0F
• parameter EIGHT 7b000_0000 // h00
• parameter NINE 7b000_0100 // h04

42
Symbolic Constant Example

• 7-segment decoder from Verilog handout (Part 2)
• always _at_(data)
• case (data)
• 0 segments ZERO
• 1 segments ONE
• 2 segments TWO
• 3 segments THREE
• 4 segments FOUR
• 5 segments FIVE
• 6 segments SIX
• 7 segments SEVEN
• 8 segments EIGHT
• 9 segments NINE
• default segments BLANK
• endcase
• endmodule

43
Symbolic Constants using define

• Like C/C, Verilog has a preprocessor
• define - equivalent to define in C/C
• Symbolic constant definition
• define ZERO 7b0000_0001
• Symbolic constant usage preface with
• segments ZERO
• Other preprocessor directives
• ifdef
• else
• endif

44
More about always

• Specifies logic with procedural statements
• Simulation model executes statements in order
• Synthesized hardware matches simulation
• reg declarations
• treat like variables in C or Java
• assignment holds value until a new assignment is
  made
• module my_logic(a, b, c, d)
• input a, b
• output c, d
• reg c,d
• always _at_(a or b) begin
• c a b
• d b c
• end
• endmodule

45
Synthesizing Comb. Logic

• When no if, case, or loop statements
• Assignment statements generate logic
• Outputs are values of last assignments
• Logic optimized, reduced during synthesis
• module my_logic(a, b, c, d)
• input a, b
• output c, d
• reg c,d
• always _at_(a or b) begin
• c a b
• d b c
• c d a
• end
• endmodule

46
Synthesizing Comb. Logic - if/else

• if/else statements become multiplexers
• multiplexers follow statement order
• always _at_(c or d or x or y) begin
• if (c 1b1) z x y
• else z x - y
• if (d 1b0) w z
• else w x
• end

47
Synthesizing Comb. Logic - if /else if / else

• Each else implies mutual exclusion
• if / else if / else creates a priority encoder
• always _at_(c or d or x or y) begin
• if (c 1b1) z x y
• else if (d 0b0) z x - y
• else z x
• end
• Use sequential if statements without else if to
  avoid priority if desired

48
Synthesizing Comb. Logic - if without else

• if without else output depends on previous value
• always _at_(a or x or y) begin
• w x y
• if (a 1b1) w x
• end
• What if no previous value is specified?
• Must preserve the semantics of the language
• This requires a latch inference
• always _at_(a or x) begin
• if (a 1b1) w x
• end

49
Synthesizing Comb. Logic - if without else
(latch inference)

• if without else output depends on previous value
• always _at_(a or x or y) begin
• if (a 1b1) w x
• end
• What if no previous value is specified?
• Must preserve the semantics of the language
• This requires a latch inference to store old
  value

50
Synthesizing Comb. Logic - case statements

• Verilog case treated as if / else if / else ...
• always _at_(e or x or y) begin
• case (e)
• 2b00 w x y
• 2b01 w x - y
• 2b10 w x y
• default w 4b0000
• endcase
• end
• Use default to avoid latch inference!

51
Synthesizing Comb. Logic -One Last Pitfall

• always must include all inputs in sensitivity
  list
• OR mismatch between synthesis simulation!
• always _at_(e or x) begin
• case (e)
• 2b00 w x y
• 2b01 w x - y
• 2b10 w x y
• default w 4b0000
• endcase
• end

52
About Lab 1

• Goals of Lab 1
• Review Combinational Logic Design with Verilog
• Learn about FPGA Design with Verilog
• Learn about the Spartan-3 Starter Kit Board (S3
  Board)

53
Starter Kit Board - Overview
54
S3 Board Seven-Segment Display

• Segment signals - active low
• Digit enables used to time multiplex digits

55
Using the S3 Board with Verilog

• Top-level module file s3board.v
• Contains declarations for all input output pins
• Switches pushbuttons
• LEDs and 7-segment displays
• RS-232 port(s)
• Not used (currently) PS/2 port, VGA port
• Use as a starting point for your design
• Constraint file s3board.ucf
• Contains pin assignments for all inputs outputs
• Uncomment pins that youre going to use (remove
  )
• These files can be downloaded from the website

56
What to Do in Lab 1

• Download s3board.v and s3board.ucf
• Run ISE and create a new project
• Add s3board.v and s3board.ucf
• Add Verilog code for a 4-bit adder
• Add Verilog code for a 7-segment decoder with hex
  digits
• Connect slide switches to adder inputs
• Connect 7-segment decoder to adder output
• Connect 7-segment decoder to display LSB
• Compile, download, debug

57
Lab 1 - Block Diagram
58
Coming Up

• Sequential Logic Design with Verilog FPGAs

59
The remaining slides are under construction

• What are these pitfalls?
• Latch Inference
• Missing inputs on sensitivity list

60
Sequential Design in Verilog - Basic Constructs

• Describe edge-triggered behavior using
• always block withedge event
• always _at_(posedge clock-signal)
• always _at_(negedge clock-signal)
• Nonblocking assignments (lt)
• _at_always(posedge clock-signal)
• begin
• output1 lt expression1
• . . .
• output2 lt expression2
• . . .
• end

61
Combining Sequential and Combinational Outputs

• General circuit - both registered and comb.
  outputs
• Approach multiple always blocks or assign
  statements

62
Example Adding carry to 4-bit Counter

• module counter(clk, Q, carry)
• input clk
• output 30 Q
• output carry
• reg 30 Q // a signal that is assigned a
  value
• assign carry (Q 4'b1111)
• always _at_( posedge clk )
• begin
• Q lt Q 1
• end
• endmodule

63
Review Question What Happens Here?

• module counter(clk, Q, carry)
• input clk
• output 30 Q
• output carry
• reg 30 Q // a signal that is assigned a
  value
• reg carry
• always _at_( posedge clk )
• begin
• carry lt (Q 4'b1111)
• Q lt Q 1
• end
• endmodule

64
State Machine Design

• Traditional Approach
• Create State Diagram
• Create State Transition Table
• Assign State Codes
• Write Excitation Equations Minimize
• HDL-Based State Machine Design
• Create State Diagram (optional)
• Write HDL description of state machine
• Synthesize

65
Coding FSMs in Verilog - Explicit Style

• Clocked always block - state register
• Combinational always block -
• next state logic
• output logic

66
Coding FSMs in Verilog - Code Skeleton

• Part 1 - Declarations
• module fsm(inputs, outputs)
• input . . .
• input . . .
• reg . . .
• parameter NBITS-10
• S0 2'b00
• S1 2'b01
• S2 2b'10
• S3 2b'11
• reg NBITS-1 0 CURRENT_STATE
• reg NBITS-1 0 NEXT_STATE

67
Coding FSMs in Verilog - Code Skeleton

• Part 2 - State Register, Logic Specification
• always _at_(posedge clk)
• begin
• CURRENT_STATE lt NEXT_STATE
• end
• always _at_(CURRENT_STATE or xin)
• begin
• case (CURRENT_STATE)
• S0 . . . determine NEXT_STATE, outputs
• S1 . . . determine NEXT_STATE, outputs
• end case
• end // always
• endmodule

68
Verilog and Event-Driven Simulation

• Key idea model circuit operation as sequence of
  events that take place at specific times
• Input events - when input changes
• Output events - response to input events (only
  generated when output changes)

69
Event-Driven Simulation

• Example Modeling and AND Gate
• Input events changes on A, B input net
• Output events changes on C output net after
  delay

A
delay12
A
B
C
B
C
70
Event-Driven Simulation

• Output events from AND input events for OR
• Simulation time jumps from event to event

A
delay3
B
A
D
delay4
C
B
E
C
D
E
71
Notes about Event-Driven Simulation

• Why use event-driven simulation? Because it's
  fast
• Only model when signals change
• Loss of accuracy assumes ideal logical behavior
• What are the alternatives?
• Circuit simulation (e.g. PSpice)
• Numerical model of continuous behavior
• More accurate, but slower
• Cycle-Level Compiled code simulation
• Model behavior in each clock cycle
• Faster, but doesnt model dlay

72
Event-Driven Simulation (cont'd)

• Processing Events - Data Structures
• Event - specifies
• time event will occur
• net where signal will change
• new value of net
• Event Queue - data structure that sorts events by
  time
• front of queue - earliest event
• back of queue - latest event
• also called a timing wheel

73
Event-Driven Simulation - Algorithm

• Processing Events - Simulation Algorithm
• initialization set all nets regs to x
• while (event queue not empty)
  current_event "earliest" event in queue
  current_time current_event.time
  current_event.net.value current_event.value
  for (each module input connected to net)
  evaluate(module) if output of module
  changes create new event to represent
  output change add new event to queue


74
Verilog Simulation Model

• assign statement
• executes when event changes any input
• produces output event when output values changes
• always block
• executes when event changes variable in
  sensitivity list
• produces output events when outputs change

75
Coming Up

• Delay Modeling in Verilog
• Other Verilog Features
• tasks functions
• system tasks
• Verilog coding styles
• Behavioral Modeling
• Testbenches and Verification

76
Course Map
