Emergency Services Workshop

1
Emergency Services Workshop

• UK VoIP 999/112s
• John Medland BT 999/112 Policy Manager

2
UK Emergency Service today
(222 Local Controls)
Police 56
BT or CW Operator Centres
Ambulance 35
BT or CW Public Ntwk (PSTN)
PSTN
Fire 8
999/112/ 18000
Other Networks
Coastguardlt1
BT 28m calls, 50 mobile, every call voice
location
999/112/18000
3
Handling VoIP 999/112 now

• Reach Call Centres through PSTN/IP Gateways
• Identified as VoIP
• Registered address accessed through tel number
• Name and address marked as needing confirmation
• Verbal routing.
• Devices/CPE use PSTN/GSM for 999 if possible
• Key issues for VoIP 112/999 - provision of
  112/999 access - registered name and address
  data kept up to date(end-user-gtCP1-gtCP2 to PSTN
  and PSAP)
• - 24 hour VSP contact point for PSAP use
  (tracing, alternative contacts)- lack of
  information to PSAP for nomadic users (definition
  of nomadic)- end user education- how to
  Automate Location provision

4
NICC Task Group

• The Network Interoperabilty Consultative
  Committee NICC is a UK telecommunications
  industry committee which acts as an industry
  consensus group in which specifications and
  technical issues associated with network
  competition can be discussed. It also is a source
  of advice to the Director General of
  Telecommunications on the harmonisation of
  interconnection arrangements
• Location Task Group Routing 999/112 for VoIP to
  correct local EA with VoIP caller location
  information
• Membership ITSPA, ISPA, BT, CW, Ericssons,
  Huawei, Andrew, ETSI, Gradwell, Magrathea, Thus,
  Truphone, IN UK, Virgin Media and Ofcom .
• Approach -- VSP, ISP and Access Provider(s)
  all different - Start with DSL and than tackle
  Cable, WiFI and GSM scenarios - Standards still
  developing (use wherever possible, eg IETF, ETSI)
  - Start with UK only (but need to allow for
  International dimension) - Dont rely on user-
  Dont rely on device (at least for next 2/3
  years)

5
Functional Architecture work in progress
6
Layers involved
User
Copper loop
BTOR / LLU
DSLAM,BRAS, RADIUS,(LAC)
ANP
LNS, RADIUS
ISP
EHA/PSAP
VSP
7
Implications

• Yes, automated routing and location provision is
  technically feasible (for ADSL case) but will
  imply -
• New requirements on all organisations (systems
  development)
• Many more organisations involved to deliver 112
  (not just traditional telcos but VSPs and ISPs)
• New operational components LIS and VPC
• New interfaces for all organisations based on
  international standards as far as possible (eg
  IETF HELD)
• Increased co-op between PSAP and VSP, ISP and
  Access networks
• Detailed document is now going through NICC
  review process ..

8
Challenges to adoption

• ISPs storing and updating association of IP/Line
  ID/ location at an ISP LIS
• LIS cascades to access providers and length of
  response times
• ANPs storing and updating association of (IP)Line
  IDs/ location at ANP LIS
• Challenging business cases (!) unless regulatory
  driven
• Current regulatory responsibility unclear when
  several CPs and an ISP involved

9
Further Challenges

• National solutions are being developed
• National solutions will need to evolve to cover
  international IP roamers
• Long transition periods with hybrid TDM/IP
  services
• Multimedia calls all organisations need clear
  112 requirements driven by users (112Net?)

10
Next Steps

• Next Steps -- Finalise basic architecture and
  BB ADSL scenario detail
• - Continued work on other UK scenarios (Cable,
  LLU, Private networks)- International Scenarios
  - IP end-to-end (as NGN, PSAP device
  capabilities become clear)

11
New Provide
Backhaul Aggregation Wholesaler
Openreach
Emergency Services Centre
Customer
ISP
New Provide (Instn Adrs)
New Provide (Instn Adrs)
New Provide (Instn Adrs)
SIDW-Instn Adrs
Confirm (SIDOR)
Confirm (SIDW)
LIS
PPP Login
PPP Login
Login OK IP Adrs
Login OK IP Adrs
IP-gtSIDW
IP- SIDW
LIS
Locn Req (IP adrs)
Locn Resp (Postal Adrs)
12
New Provide (case B)
Openreach
Emergency Services Centre
Customer
Backhaul Aggregation Wholesaler
ISP
New Provide (Instn Adrs)
New Provide (Instn Adrs)
New Provide (Instn Adrs)
Confirm (SiDOR)
Confirm (SIDW)
SIDOR-gtInstn Adrs
LIS
PPP Login
PPP Login
Login OK IP Adrs
Login OK IP Adrs
IP Adrs-gtSIDOR
Locn Req (IP adrs)
LIS
Locn Req (IP adrs)
LIS Relay
Locn Resp (Postal Adrs)
Locn Resp (Postal Adrs)
13
Current UK industry structure
End User
Telephone line calls
Broadband
reseller
Automated B2B systems processes currently (just
about) support this
Retail CP
Broadband Calls
Wholesale CP
Services CPS broadband
Infrastructure
WLR
SMPF / MPF
Network (Access) Provider Eg Openreach
14
